Optelec Compact 5 HD User manual
Optelec Compact 5 HD
1
Contents
1. Introduction..................................................................................................12
About this manual ................................................................................. 13
What’s in the box?................................................................................. 13
2. Getting started .............................................................................................14
Using the Compact 5 HD in the closed or open position.......................15
Cleaning the camera lens and mirror....................................................20
Buttons..................................................................................................21
Switching the power on and off............................................................. 22
Adjusting the magnification ................................................................... 23
Selecting a viewing mode...................................................................... 24
Using the snapshot button.....................................................................25
3. Charging the battery .................................................................................... 27
Charging the Compact 5 HD.................................................................27
Standby and Auto Power Off.................................................................28
Battery warning.....................................................................................28
4. The Compact 5 HD Menu ............................................................................ 29
Activating the menu...............................................................................30
Navigating the menu ............................................................................. 30
Exiting the menu ...................................................................................30
Menu: Information................................................................................. 31
Menu: Brightness..................................................................................32
Menu: Power.........................................................................................33
Optelec Compact 5 HD
2
Menu: Sound.........................................................................................38
Menu: Light ...........................................................................................39
Menu: Color........................................................................................... 40
Menu: Reset..........................................................................................41
Appendix A: Safety ..........................................................................................42
Appendix B: Technical information...................................................................43
Appendix C: Warranty Conditions....................................................................45
Optelec Offices Worldwide......................…………………………………….….246
Inhoudsopgave
1. Inleiding .......................................................................................................50
Over deze handleiding ..........................................................................51
Inhoud van de verpakking.....................................................................51
2. Aan de slag.................................................................................................. 52
Het gebruik van de Compact 5 HD in de open/gesloten positie............ 52
Het schoonhouden van de cameralens en de spiegel...........................58
Knoppen................................................................................................59
De unit aan- en uitzetten....................................................................... 60
Aanpassen van de vergroting................................................................61
Een leesstand selecteren......................................................................62
Het gebruik van de snapshotfunctie......................................................63
3. Netstroom en batterijgebruik........................................................................ 65
Optelec Compact 5 HD
3
De Compact 5 HD opladen ...................................................................65
Stand-by en Automatisch Uitschakelen................................................. 66
Batterijwaarschuwing ............................................................................66
4. Het Compact 5 HD Menu.............................................................................67
Het menu activeren...............................................................................68
Navigeren in het menu..........................................................................68
Het menu verlaten.................................................................................68
Menu: Informatie (Information).............................................................. 69
Menu: Helderheid (Brightness).............................................................. 70
Menu: Stroominstellingen (Power) ........................................................71
Menu: Geluid (Sound)...........................................................................77
Menu: Licht (Light) ................................................................................78
Menu: Kleur (Color)...............................................................................79
Menu: Fabrieksinstellingen (Reset).......................................................80
Bijlage A: Veiligheid.........................................................................................81
Bijlage B: Technische informatie......................................................................82
Opteleckantorenwereldwijd...........................…………………………………….….246
Table des matières
1. Introduction..................................................................................................86
À propos du manuel..............................................................................87
Le matériel dans la boîte.......................................................................88
Optelec Compact 5 HD
4
2. Connaître votre Compact 5 HD....................................................................89
Utiliser le Compact 5 HD en position ouverte ou fermée.......................89
Nettoyer la lentille de la caméra et le miroir .......................................... 95
Les boutons........................................................................................... 96
Allumer et éteindre le Compact 5 HD....................................................97
Régler le niveau de grossissement .......................................................98
Sélectionner le mode de visualisation...................................................99
Utiliser le bouton photo instantanée....................................................100
3. Chargement de la pile................................................................................102
Charger le Compact 5 HD...................................................................102
Mise en veille et mise hors tension automatique.................................103
Avis de pile faible................................................................................103
4. Le menu du Compact 5 HD .......................................................................104
Ouvrir le menu.....................................................................................105
Naviguer dans le menu .......................................................................105
Fermer le menu...................................................................................105
Menu: Information............................................................................... 106
Menu: Luminosité (Brightness)............................................................ 107
Menu: Alimentation (Power)................................................................108
Menu: Son (Sound).............................................................................113
Menu: Lumière (Light)......................................................................... 114
Menu: Couleur (Color).........................................................................115
Menu: Configuration par défaut (Reset).............................................. 116
Optelec Compact 5 HD
5
Annexe A: Mesures de sécurité.....................................................................117
Annexe B: Renseignements techniques........................................................118
Annexe C: Conditions de garantie .................................................................120
Optelec dans le monde...........................…………………………………….….246
Índice
1. Introducción ...............................................................................................124
Acerca de este manual .......................................................................125
¿Qué contiene la caja?.......................................................................126
2. Conocer su Compact 5 HD........................................................................ 127
Utilizar el Compact 5 HD en la posición cerrada o abierta..................127
Limpiar el lente de la cámara y el espejo............................................133
Los botones......................................................................................... 134
Encender y apagar la unidad .............................................................. 136
Ajustar la amplificación .......................................................................137
Seleccionar un modo de visualización ................................................138
Utilizar el botón de foto instantánea.................................................... 139
3. Carga de la batería....................................................................................141
Cargar el Compact 5 HD.....................................................................141
Modo de reposo y función de apago automático.................................142
Aviso de batería vacía......................................................................... 142
4. El menú del Compact 5 HD........................................................................143
Optelec Compact 5 HD
6
Navegar en el menú............................................................................ 144
Salir del menú.....................................................................................144
Menú Información (Information)..........................................................145
Menú Brillo (Brightness)......................................................................146
Menú Alimentación (Power)................................................................147
Menú Sonido (Sound).........................................................................152
Menú Iluminación (Light).....................................................................153
Menú Color (Color).............................................................................. 154
Menú Restablecer (Reset) ..................................................................155
Apéndice A: Seguridad..................................................................................156
Apéndice B: Características técnicas............................................................. 157
Apéndice C: Condiciones de garantía............................................................159
Sedi Optelec nel mondo..........................…………………………………….….246
Sommario
1. Introduzione...............................................................................................164
A proposito di questo manuale............................................................165
Contenuto della confezione.................................................................165
2. Per iniziare.................................................................................................166
Utilizzare Compact 5 HD in posizione chiusa o aperta........................166
Pulire la lente della telecamera e lo specchio .....................................172
Pulsanti ............................................................................................... 173
Optelec Compact 5 HD
7
Accensione e spegnimento.................................................................174
Regolare l’ingrandimento .................................................................... 175
Selezionare la modalità di visualizzazione.......................................... 176
Pulsante Foto......................................................................................177
3. Ricarica della batteria ................................................................................179
Come ricaricare Compact 5 HD ..........................................................179
Standby e Auto spegnimento..............................................................180
Avviso batteria.....................................................................................180
4. Menu di Compact 5 HD..............................................................................181
Attivare il menu ...................................................................................181
Attivare il menu ...................................................................................182
Navigare nel menu.............................................................................. 182
Uscire dal menu.................................................................................. 182
Menu: Informazioni.............................................................................. 183
Menu: Luminosità................................................................................ 184
Menu: Alimentazione...........................................................................185
Menu: Audio........................................................................................190
Menu: Luce .........................................................................................191
Menu: Colore.......................................................................................192
Menu: Reset........................................................................................193
Appendice A: Sicurezza.................................................................................194
Appendice B: Scheda tecnica........................................................................195
Appendice C: Condizioni di garanzia.............................................................197
Optelec Compact 5 HD
8
Optelec en el mundo...............................…………………………………….….246
Inhalt
1. Einführung ................................................................................................. 203
Über dieses Handbuch........................................................................204
Lieferumfang.......................................................................................204
2. Erste Schritte .............................................................................................205
Benutzen des Compact 5 HD geschlossen oder geöffnet...................205
Reinigung der Kameralinse und des Spiegels..................................... 211
Tastenbelegung .................................................................................. 212
Compact 5 HD ein- und ausschalten...................................................213
Einstellen der Vergrößerung ............................................................... 214
Auswahl des Darstellungsmodus........................................................ 215
Schnappschuss-Funktion....................................................................216
3. Aufladen des Akkus...................................................................................218
Aufladen des Compact 5 HD...............................................................218
Standby und automatisches Ausschalten ........................................... 219
Akkuwarnung ......................................................................................219
4. Das Compact 5 HD Menü..........................................................................220
Das Menü aktivieren ...........................................................................221
Navigieren im Menü............................................................................ 221
Verlassen des Menüs..........................................................................221
Optelec Compact 5 HD
9
Menü: Information............................................................................... 222
Menü: Brightness Helligkeit ............................................................223
Menü: Power Ein-und Ausschalten.................................................224
Menü: Sound Signalton .................................................................. 229
Menü: Light Objektbeleuchtung...................................................... 230
Menü: Color Farbe.......................................................................... 231
Menü: Reset Zurücksetzen.............................................................232
Anhang A: Sicherheitshinweise .....................................................................233
Anhang B: Technische Informationen............................................................ 234
Anhang C: Garantiebedingungen...................................................................236
Optelec Zweigniederlassungen Weltweit…………………………………….….246
Optelec Compact 5 HD
English 11
WEEE Notice
The directive on Waste Electrical and Electronic Equipment (WEEE), which entered
into force as European law on 13th February 2003, resulted in a major change in the
treatment of electrical equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of WEEE, and in
addition, to promote the reuse, recycling and other forms of recovery of such wastes
so as to reduce disposal.
The WEEE logo (shown at the left) on the product or its box indicates that
this product must not be disposed of or dumped with your other household
waste. You are liable to dispose of all your electronic or electrical waste
equipment by relocating over to the specified collection point for recycling
of such hazardous waste. Isolated collection and proper recovery of your
electronic and electrical waste equipment at the time of disposal will allow us to help
conserving natural resources. Moreover, proper recycling of the electronic and
electrical waste equipment will ensure safety of human health and environment. For
more information about electronic and electrical waste equipment disposal, recovery,
and collection points, please contact your local city centre, household waste disposal
service, shop from where you purchased the equipment, or manufacturer of the
equipment.
Optelec Compact 5 HD
12 English
1. Introduction
Congratulations on choosing the Compact 5 HD!
Optelec’s unique auto focus electronic video magnifier enables you to view and
magnify printed text and images in high resolution HD quality in full color or one
of the high contrast modes. The Compact 5 HD 5-inch display, combined with
its low magnification of 1.5 times, gives you maximum overview, while providing
up to 18 times magnification for those who need a higher zoom level.
With its multifunctional design, unique lighting concept, distance view and
integrated reading stand, the Compact 5 HD can be used for reading, viewing
images, price tags, displays and much more while at home or on the go.
If you have questions or suggestions concerning the use of this product, please
contact your distributor or the Optelec headquarters using the contact
information on the last page of this manual. Your feedback is greatly
appreciated. We hope you enjoy working with your Compact 5 HD!
Optelec Compact 5 HD
English 13
About this manual
At Optelec, we are constantly improving our products and their functionalities.
Therefore, it is possible that this manual is not the latest version. Please
download the most up-to-date manual on www.optelec.com at the Support
section.
This manual will familiarize you with the features and basic operation of the
Compact 5 HD. Please read this manual carefully before using your device.
What’s in the box?
The Compact 5 HD packaging contains the following:
The Compact 5 HD video magnifier
A protective pouch
A wrist strap
A power supply
4 country specific power plugs (EU, US, UK and AU), of which one is
already mounted onto the power supply
A screen cleaning cloth
A user manual
If any items are missing from your package, please contact your distributor.
Optelec Compact 5 HD
14 English
2. Getting started
The Compact 5 HD is placed correctly in front of you when the screen is facing
up and the Optelec logo is in the centre at the bottom of the screen.
Compact 5 HD closed Compact 5 HD open
Optelec Compact 5 HD
English 15
Using the Compact 5 HD in the closed or open position
The Compact 5 HD can be used in two ways: in the closed and in the open
position.
In the closed position, hold the unit in your hand and point the camera (located
at the back of the unit) to the object or text you wish to view or read.
The closed position is ideal for distance viewing and to quickly scan and view
objects or documents.
In the open position, the screen will be set in an ergonomic angle for reading
and the camera will point downwards. The open position enables you to read
longer texts, thanks to the integrated reading stand.
To open the unit, follow these steps:
1. Attach the supplied wrist strap to the unit by connecting the two parts
of the click mechanism. To use the Compact 5 HD in the open
position, place the wrist strap around your right wrist and set the unit
on a flat surface, such as a desk.
Optelec Compact 5 HD
16 English
2. Place your middle fingers against the black opening support located
on the top corners of the lower part of the unit.
Optelec Compact 5 HD
English 17
3. Place your index fingers above your middle fingers against the top
corners of the upper part of the unit.
Optelec Compact 5 HD
18 English
4. Place your thumbs against the black opening supports underneath
the display on the bottom corners of the upper part of the unit.
Table of contents
Languages:
