Optelecom-nkf 9000 Series User manual

9000 Series
Installation and Operation Manual
Model 9225DT
Model 9225DR
Fiber Optic Video Duplex Data
Transmitter and Receiver
Standalone Modules
For transport of one NTSC, PAL, or SECAM
video signal and one duplex RS232, RS422,
RS485, or Manchester data over one optical
fiber. Digital encoding and transmission
techniques are utilized for the video (9-bit) and
the data.
UM50327, Manual 9225D, ECN E08-00190, Rev. G
9225DT Front Panel
9225DR Front Panel
Rear Panel

Table of Contents
Section Page
Safety Instructions ii
Fiber Information vi
Functional Description 1
9225DT Indicator and Connector Locations 2
9225DR Indicator and Connector Locations 4
Set Up and Operation of the 9225D 6
Typical Application Drawing 7
Troubleshooting 9225D Links 7
Operation with the Network Management Software 8
Specifications 9
UM50327, Manual 9225D, ECN E08-00190, Rev. G

ii
The optical devices used in this equipment are Hazard Level 1M. As required by IEC60825-1, the installer is responsible for insuring that the label
depicted below is present in the restricted locations where this equipment is installed.
This assembly contains parts sensitive to damage by electrostatic discharge (ESD). Use ESD precautionary procedures when
touching, removing, or inserting parts or assemblies.
The DC power input connector serves as a service disconnect for this module. This module is intended for installation in locations that
p r o vide suitable access to the DC power input connector.
The chassis into which this unit is installed must be housed in a properly rated NEMA enclosure.
When this unit is operated in extremely elevated temperature conditions, it is possible for internal and external metal surfaces to
become extremely hot. Care should be taken to insure this unit is installed in a restricted area where only properly trained service
personnel have access to the unit.
Safety Instructions SA-1
This product contains Class 1M lasers or LEDs.
•Class 1M laser product according to IEC60825-1:1993+A1+A2
•CAUTION: Use of controls or adjustments or procedures other than those specified herein may result in hazardous
radiation exposure.
• Precautions should be taken to prevent exposure to optical radiation when the unit is removed from its enclosure or when
the fiber is disconnected from the unit.
•Laser radiation may be present on a fiber connection to this unit even when the power has been removed from the unit.
• This unit is intended for installation in locations where only trained service personnel have access to the fiber connections.
• The locations of all optical connections are listed in the Connection Locations and Function section of this manual.
•Optical outputs and wavelengths are listed in the Specifications section of this manual.
The safety information contained in this section, and on other pages of this manual, must be observed whenever this unit is operated,
serviced, or repaired. Failure to comply with any precaution, warning, or instruction noted in the manual is in violation of the standards
of design, manufacture, and intended use of the unit. Optelecom-NKF assumes no liability for the customer’s failure to comply with any
of these safety requirements.
LASER RADIATION
DO NOTVIEW DIRECTLYWITH OPTICAL INSTRUMENTS (MAGNIFIERS).
CLASS 1M LASER PRODUCT
CAUTION:
DISCONNECTED OPTICAL CONNECTORS MAY EMIT OPTICAL ENERGY.
DO NOTVIEW BEAM WITH OPTICAL INSTRUMENTS (MAGNIFIERS).

ii
Los dispositivos ópticos usados en este equipo son de Nivel de Riesgo 1M. Según lo exige la norma IEC60825-1, el instalador es responsable de
asegurar que la etiqueta descrita a continuación esté presente en las ubicaciones restringidas donde se instale este equipo.
Este ensamblaje contiene piezas sensibles al daño por descargas electrostáticas (ESD, por sus siglas en inglés). Use
procedimientos para prevenir las descargas electrostáticas al tocar, desmontar o insertar piezas o ensamblajes.
El conector de entrada de energía de CC sirve como desconector de servicio para este módulo. Este módulo está destinado a
i n s tal arse en ubicaciones que ofrecen acceso adecuado al conector de entrada de energía de CC.
El chasis en el cual está instalada esta unidad debe estar dentro de un alojamiento debidamente calificado por NEMA.
Cuando se opera esta unidad en condiciones de temperatura sumamente elevada, es posible que las superficies internas y
externas de metal se pongan extremadamente calientes. Debe tenerse cuidado para asegurar que esta unidad se instale en un
área restringida donde sólo tenga acceso a la unidad el personal de servicio debidamente capacitado.
Instrucciones de seguridad SA-1
Este producto contiene rayos láser o diodos emisores de luz Clase 1M.
• Producto láser Clase 1M conforme a la norma IEC60825-1:1993+A1+A2
•PRECAUCIÓN: El uso de los controles o ajustes o procedimientos aparte de lo especificado aquí puede ocasionar
exposición peligrosa a la radiación.
•Deben tomarse precauciones para evitar la exposición a la radiación óptica cuando se saque la unidad de su alojamiento, o
cuando se desconecte la fibra de la unidad.
• Puede haber radiación láser en una conexión de fibra a esta unidad aun cuando se haya eliminado la corriente de la unidad.
• Esta unidad está destinada a instalarse en ubicaciones donde sólo el personal de servicio competente tenga acceso a las
conexiones de fibra.
•Las ubicaciones de todas las conexiones ópticas se enumeran en la sección Ubicaciones de las conexiones y funciones de
este manual.
•Las salidas ópticas y longitudes de onda aparecen en la sección Especificaciones de este manual.
Debe observarse la información de seguridad contenida en esta sección, y en otras páginas de este manual siemptre que se opere, dé
servicio o repare esta unidad. Si no se cumple con alguna precaución, advertencia o instrucción indicada en este manual se infringen los
estándares de diseño, fabricación y el uso destinado a la unidad. Optelecom-NKF no asume ninguna responsabilidad si el cliente no
cumple con alguno de estos reequisitos de seguridad.
RADIACIÓN LÁSER
NO VER DIRECTAMENTE CON INSTRUMENTOS ÓPTICOS (DE AUMENTO)
PRODUCTO LÁSER CLASE 1M
PRECAUCIÓN:
LOS CONECTORES ÓPTICOS DESCONECTADOS PUEDEN EMITIR ENERGÍA ÓPTICA
NO VER EL HAZ CON INSTRUMENTOS ÓPTICOS (DE AUMENTO)

iii
Die optischen Vo r r i ch t ungen in diesem Gerät haben Gefa h r e n s t u fe 1M. Wie vo r g e s chrieben durch IEC60825-1 ist der Installateur dafür ve r a n t wo r t l i ch ,
s i ch e rzu stellen, dass die unten abgebildeten Schilder an den Orten mit eingeschränktem Zugang, an denen dieses Gerät aufgestellt ist, vorhanden sind.
Diese Baugruppe enthält Teile, die durch elektrostatische Entladungen (ESD) beschädigt werden können. Vorsichtsmaßnahmen
zum Schutz vor elektrostatischer Entladung treffen, wenn Teile oder Baugruppen berührt, ausgebaut oder eingefügt werden.
Der Gleich s t r o m - E i n g a n g s s t e ck v erbinder dient als Unterbrechung der Stromversorgung für dieses Modul. Dieses Modul ist für den
Einbau an Orten vorgesehen, an denen geeigneter Zugang zu einem Gleich s t r o m - S t e ck v erbinder vorhanden ist.
Das Gestell, in dem diese Einheit eingebaut ist, muss in einem entsprechend klassifizierten NEMA-Sch u t z g e h ä u s e
u n t e r g e b r a cht sein.
Wenn diese Einheit bei besonders hohen Temperaturen betrieben wird, können interne und externe Metallflächen extrem heiß
werden. Es muss darauf geachtet werden, dass diese Einheit in einem Bereich mit eingeschränktem Zugang aufgestellt wird,
damit nur geschultes Wartungspersonal Zugang zur Einheit hat.
Sicherheitsanleitungen SA-1
Dieses Produkt enthält Laser oder LEDs der Klasse 1M.
•Laserprodukt der Klasse 1M gemäß IEC60825-1:1993+A1+A2
•VORSICHT: Wenn die Bedienungselemente anders als hier besch r ieben bzw. a n d e re Einste l l u n g en ve r w endet we rd e n ,
kann es zu sch ä d l i c her Strahlenaussetzung ko m m e n .
•Es müssen Vorsichtsmaßnahmen getroffen werden, um Aussetzung an optischer Strahlung zu vermeiden, wenn die Einheit
aus dem Gehäuse genommen oder die Faseroptik von der Einheit getrennt wird.
•In einer Faseroptik-Verbindung dieser Einheit kann auch dann Laserstrahlung vorhanden sein, wenn die Stromversorgung
zur Einheit abgeschaltet wurde.
•Diese Einheit ist zum Einbau an Orten vorgesehen, an denen nur geschultes Personal Zugang zu den Faseroptik-
Verbindungen hat.
•Die Lage aller optischen Verbindungen ist im Abschnitt über die Lage von Anschlüssen und Funktionsweise dieses
Handbuchs zu finden.
• Optische Ausgänge und Wellenlängen sind im Abschnitt mit den technischen Daten dieses Handbuchs zu finden.
Die in diesem abschnitt und auf anderen seiten dieses handbuchs enthaltenen sicherheitsinformationen müssen befolgt werden, wenn diese einheit betrieben,
gewartet oder repariert wird. Falls vorsichtsmassnahmen, warnungen oder anweisungen in diesem handbuch nicht befolgt werden, verstösst dies gegen die
konstruktions, und herstellungsstandards und erfolgt im gegensatz zum vorgesehenen verwendungszweck dieser einheit. Optelecom-NKF übernimmt keine
haftung für das verabsäumnis des kunden, diese sicherheitsanforderungen einzuhalten.
LASER-STRAHLUNG
NICHT DIREKT MIT OPTISCHEN INSTRUMENTEN (LUPEN) ANSEHEN
LASER-PRODUKT DER KLASSE 1M
VORSICHT:
ABGEKLEMMTE OPTISCHE STECKVERBINDER KÖNNEN OPTISCHE ENERGIE FREI SETZEN
NICHT MIT OPTISCHEN INSTRUMENTEN (LUPEN) IN DEN STRAHL BLICKEN.

iv
Les appareils optiques utilisés dans cet équipement correspondent à un niveau de danger 1M. Comme exigé par la norme IEC60825-1, il incombe à
l’installateur de s’assurer que l’étiquette ci-dessous est présente aux endroits d’accès limité où cet équipement est installé.
Cet ensemble contient des pièces sensibles aux décharges électrostatiques (ESD). Prendre les précautions relatives aux ESD avant
de toucher, retirer ou insérer des pièces ou des ensembles.
Le connecteur d’entrée d’alimentation c.c. sert de sectionneur de maintenance pour ce module. Ce module est prévu pour une
i n s tal lation à des endroits donnant raisonnablement accès au connecteur d’entrée d’alimentation c.c.
Le châssis dans lequel est installé cet appareil doit être placé dans une enceinte NEMA conforme aux spécifications nominales.
Lorsque cet appareil fonctionne à une température ambiante extrêmement élevée, il est possible que les surfaces métalliques
internes et externes deviennent extrêmement chaudes. S’assurer que cet appareil est installé dans une zone dont l’accès est
limité à un personnel de maintenance correctement formé.
Consignes de sécurité SA-1
Ce produit contient des lasers ou diodes électroluminescentes de classe 1M.
• Produit laser de classe 1M conformément à IEC60825-1:1993+A1+A2
•ATTENTION: L’utilisation de commandes ou réglages, ou de procédures différentes de celles indiquées ici risque de
provoquer une exposition dangereuse au rayonnement.
• Prendre des précautions pour empêcher une exposition au rayonnement optique lorsque l’appareil est retiré de son boîtier ou
lorsque le câble optique fibre est débranché de l’appareil.
• Un rayonnement laser pourra être présent dans un câble optique branché sur cet appareil, même une fois l’alimentation coupée.
• Cet appareil est prévu pour une installation à des endroits où seul un personnel de maintenance formé a accès aux câbles optiques.
• Les points de branchement de tous les câbles optiques sont indiqués à la section Points de branchement et fonction de ce manuel.
• Les sorties et longueurs d’onde optiques figurent à la section Caractéristiques techniques de ce manuel.
Les consignes de securi te contenues dans cette section et dans le res te de ce manuel doivent etre resp e c tees a chaque fois que cet apparei l
est utilise ou fait l’objet d’une maintenance ou d’une re p a ra tio n . Le non-respect d’une pre c a uti o n , d’un ave rtissement ou d’une instru c t ion
fig u rant dans ce manuel est une violation des normes de conception, fa b rication et indication d’usage de l’appareil . O p telecom-NKF n’est
pas responsable du non-respect de ces consignes de securi te par le client.
RAYONNEMENT LASER
NE PAS REGARDER DIRECTEMENT AVEC DES INSTRUMENTS OPTIQUES (LOUPES)
PRODUIT LASER DE CLASSE 1M
ATTENTION:
LES CONNECTEURS OPTIQUES DEBRANCHES PEUVENT EMETTRE UNE ENERGIE OPTIQUE.
NE PAS REGARDER LE FAISCEAU AVEC DES INSTRUMENTS OPTIQUES (LOUPES)

vi
Fiber Information
This unit was manufa c tured with attention to fiber cleanliness by Optelecom-NKF. Beyond the optical safe t y
i n formation contained in this manual, the fo l l o wing guidelines should be observed when working with
optical fibers.
The biggest problem is dirt!
It takes very little contamination to cause problems with optical fiber connections; cleanliness is extremely
important to proper operation of optical equipment.
1. Protect optical connectors by leaving the connector covers in place on unused fiber connections and on
the fiber tips themselves.
2. Personnel who remove and replace fibers should be equipped with a fiber cleaning kit. These are
inexpensive and can be obtained from any fiber equipment supply house. If you choose to, you can use
propanol and lint-free tissue to clean fibers.
a. a. Do not use isopropanol alcohol (typically called rubbing alcohol) mixed with water. This can cause
additional spots. (Caution: Pure isopropanol is very flammable!)
b. Use lintless tissues to clean fibers.
c. Clean the fiber with a folded tissue moistened with the propanol, pulling the connector tip across the
tissue, then turn the connector 90 degrees and repeat in a different spot on the tissue.
d. Don’t pull the fiber across and then push it back. This will put the dirt that was cleaned off back on
again.
e. Repeat the process on a dry, folded tissue.
3. When removing fibers, always clean them when replacing them no matter how long you had them off.
4. When connecting fibers, pay attention to the bend radius of the fibers. A general rule is to have a 3-inch
(8 cm) bend radius. A bend radius less than 3 inches is an attenuator and can cause optical signal loss.
5. Installers of fiber equipment should be equipped with the equipment manuals and an optical power meter
to measure the optical inputs and outputs in a system. An optical power meter is an inexpensive tool that
can save much time and effort in getting optical communications links up and running. Properly equipped
and trained installers can quickly determine the source of any problems that occur.

Functional Description
The 9225DT transmitter accepts a composite video signal in NTSC, PAL, or SECAM format via the BNC video
input port. This baseband video signal is sampled at a 16 mHz rate by an A-to-D converter operating with nine
bits of precision. Data signals are combined into the bit stream and converted to an optical signal for
transmission over the optical fiber.
The receiver accepts the optical signal and converts it back to a serial bit stream. The signal is deserialized
and converted back into the video and data signals, which are output on the BNC and data connectors.
Data in the reverse direction is converted to an optical signal by the receiver at a different wavelength and
sent over the fiber to the transmitter where it is decoded and converted back to the data format for output.
The 9225DT and 9225DR are compatible with the 9221DT and 9221DR rack-mount models.
The 9225DT and 9225DR operate on 8 to 15 VDC from the 9014PS or other DC power supplies. The 9225DT
is also available in an18 to 30 VAC or VDC version. Add –AC to the model number.
1

9225DT Indicator and Connector Locations
2
FIGURE 1
1. POWER CONNECTOR
Connector for 8 to 15 VDC on the standard model or 18 to 30 VAC or VDC on the 9225DT/xx-xx-AC
version.
2. VIDEO PRESENT INDICATOR
This green LED illuminates when a video signal is present on the input BNC connector.
3. LOOP INDICATOR
This green indicator, when illuminated, shows that both local and remote units are communicating
correctly.
4. NOT SYNC INDICATOR
This red indicator, when illuminated, shows that the local unit is not receiving sufficient optical signal from
the remote unit or the local demux circuitry is not able to synchronize to the incoming signal.
5. PTZ DATA INDICATOR
This green indicator flashes as data is received on the data channel.
6. SYNC INDICATOR
This green indicator, when illuminated, shows that the local unit is receiving sufficient optical signal from
the remote unit and local demux circuitry is synchronized to the incoming signal.
7. OPTICAL CONNECTOR
The optical fiber connection is made here.

8. VIDEO INPUT CONNECTOR
The video input signal cable is connected to this BNC connector.
9. MODE SWITCH FOR PTZ/DATA CHANNEL
This dipswitch is used to set the data parameters for the PTZ/Data Channel.
10. PTZ/DATA CHANNEL CONNECTOR
This is the data I/O connector.
11. IEC LASER WARNING LABEL
Refer to the Safety Instructions at the beginning of this manual.
12. VIDEO SYNC INDICATOR
This LED position is not installed on this unit and is, therefore, inoperative.
3

9225DR Indicator and Connector Locations
4
1. POWER CONNECTOR
The power is connected here.
2. Tx VIDEO PRESENT INDICATOR
This green LED illuminates when a video signal is present on the transmitter input BNC connector.
3. LOOP INDICATOR
This green indicator, when illuminated, shows that both local and remote units are communicating
correctly.
4. NOT SYNC INDICATOR
This red indicator, when illuminated, shows that the local unit is not receiving sufficient optical signal from
the remote unit or the local demux circuitry is not able to synchronize to the incoming signal.
5. PTZ DATA INDICATOR
This green indicator flashes as data is received on the data channel.
6. SYNC INDICATOR
This green indicator, when illuminated, shows that the local unit is receiving sufficient optical signal from
the remote unit and local demux circuitry is synchronized to the incoming signal.
7. OPTICAL CONNECTOR
The optical fiber connection is made here.
FIGURE 2

8. VIDEO OUTPUT CONNECTOR
The video output signal cable is connected to this BNC connector.
9. MODE SWITCH FOR PTZ/DATA CHANNEL
This dipswitch is used to set the data parameters for the PTZ/Data Channel.
10. PTZ/DATA CHANNEL CONNECTOR
This is the data I/O connector.
11. IEC LASER WARNING LABEL
Refer to the Safety Instructions at the beginning of this manual.
12. VIDEO SYNC INDICATOR
This LED position is not installed on this unit and is, therefore, inoperative.
5

6
Set Up and Operation of the 9225DT and DR
Operation of the 9225DT and 9225DR units consists of setting the data parameter switches as required,
installing the card in a compatible Series 9000 chassis, connecting the optical cables, the video input, and the
data signals.
PTZ/DATA CHANNELS SWITCH SETTINGS AND CONNECTIONS
The PTZ data channel switch sets the data input and output formats. Refer to Table 1 and the input/output
connection diagrams below to set and connect data signals.
TABLE 1 — 9225D DIPSWITCH SETTINGS
Type/Switch
Position 1 2 3 4 5 6 7 8 9 10
RS232 ON OFF OFF OFF OFF N/A N/A OFF ON OFF
(Down) (Up) (Up) (Up) (Up) (Up) (Down) (Up)
RS422 OFF OFF ON ON ON T T ON OFF ON
(Up) (Up) (Down) (Down) (Down) (Down) (Up) (Down)
RS485 2-Wire ON ON OFF ON ON T T ON OFF ON
(Down) (Down) (Up) (Down) (Down) (Down) (Up) (Down)
RS485 4-Wire OFF ON OFF ON ON T T ON OFF ON
(Up) (Down) (Up) (Down) (Down) (Down) (Up) (Down)
Manchester ON ON ON OFF OFF T T ON OFF ON
(Down) (Down) (Down) (Up) (Up) (Down) (Up) (Down)
Disabled OFF OFF OFF N/A N/A N/A N/A N/A N/A N/A
(Up) (Up) (Up)
Notes
1N/A = Not applicable; switch position does not affect setting.
2T = Input Termination Setting, ON = Termination On, OFF = Termination Off.
FIGURE 3

7
FIGURE 4
FIGURE 5
FIGURE 6

Troubleshooting 9225D Links
Troubleshooting 9225 links is usually started at the transmitter end. At least one of the indicators should be
illuminated, indicating that power is applied to the unit.
The Video Present indicator illuminates when a video signal is present on the input BNC connector. If this is
not green, check the incoming video source.
The Loop, Sync and Not Sync indicators are used together to troubleshoot fiber and other problems. If the
loop indicator is illuminated, both local and remote units are communicating correctly. If the Sync indicator is
illuminated, but not the Loop, the remote unit is not synchronized with the local unit. Check the fiber for
optical losses above the specifications.
Should the Not Sync indicator be illuminated (red), the local unit is not receiving sufficient optical signal from the
remote unit or the local demux circuitry is not able to synch r o n i ze to the incoming signal. Check the fiber fo r
losses or the remote unit for powe r.
The RD indicator can help troubleshoot the data channel. When any data is received, this indicator will flash. If
data is not being received, check to make sure the data interface has been configured properly to receive the
type of data connected.
8
Typical Application of the 9225D
FIGURE 7

Specifications for the Model 9225D
OPTICAL
9
Model MM MM MMH MMH SM
Fiber Size 50/125 62.5/125 50/125 62.5/125 09/125
Transmitter Optical Output Power (dBm) –21 –17 –7 –7 –7
Transmitter Optical Output Wavelength (nm) 1310 1310 1310 1310 1310
Transmitter Optical Input Sensitivity (dBm) –34 –34 –30 –30 –30
Maximum Transmitter Optical Input (dBm) –10 –10 –5 –5 0
Receiver Optical Output Power (dBm) –21 –17 –7 –7 –7
Receiver Optical Output Wavelength (nm) 850 850 1550 1550 1550
Receiver Optical Input Sensitivity (dBm) –27 –27 –30 –29 –30
Maximum Receiver Optical Input (dBm) –15 –15 –5 –5 –5
Txmtr Opt Budget (Txmtr Out Pwr-Rcvr Input Sens) (dB) 610 23 22 23
Rcvr Opt Budget (Rcvr Out Pwr-Txmtr Input Sens) (dB) 17 21 23 23 23
Estimated Distance (km) 50 m1, 23N/A 19 N/A N/A
Estimated Distance (km) 62.5 m1, 2N/A 6N/A 19 N/A
Estimated Distance (km) 09 m1, 2N/A N/A N/A N/A 57
1Range estimates based on fiber losses of 3.0 dB/km @ 850 nm and 1.0 dB/km @ 1310 nm and 1550 nm on 62.5/125 fiber, 0.35 dB/km @ 1310 nm and 0.25 dB/km @ 1550
nm on 09/125 fiber, and include a 3 dB safety factor.
2Range estimates may be affected by chromatic dispersion, modal dispersion, and fiber bandwidth capabilities. Multimode range estimates are based on fiber
specifications of 500 Mhz/km.
VIDEO SPECIFICATIONS
Video Sampling Rate/Resolution 16.0 Mhz., 9-bit
Video Input/Output Signal NTSC, PAL, or SECAM, 1V p-p, 75W
Video Input/Output Connector BNC
Video Bandwidth 6.5 Mhz (–3.0 dB)
SNR ≥63 dB
Differential Phase ≤1°
Differential Gain ≤2%
DATA SPECIFICATIONS
RS232, RS422 2- and 4-wire, RS485 2- and 4-wire, Manchester (Bi-Phase, Burle, American Dynamics),
switch-selectable; Auto Baud, maximum data rate 115.2 Kbps
POWER
DC Version
Voltage 8 to 15 VDC

10
Current
9225DT 250 mA @ 9VDC
240 mA @ 12 VDC
230 mA @ 15 VDC
9225DR 290 mA @ 9VDC
270 mA @ 12 VDC
260 mA @ 15 VDC
AC Version (9225DT only)
Voltage 18 to 30 VAC/VDC
Current ≥120 mA
PHYSICAL
Dimensions (in inches) 1.5 H x 3.2 W x 5.0 D
ENVIRONMENTAL
Operating Temperature –40° C to +74° C
Storage Temperature –55° C to +85° C
Relative Humidity0 to 95% noncondensing
For installation in outdoor or hazardous locations, this unit should be housed in a properly rated NEMA
enclosure.
MECHANICAL

Optelecom-NKF Inc.
12920 Cloverleaf Center Drive • Germantown, MD 20874 • USA
Main: +1 301.444.2200 • Fax: [phone]
U.S. Toll Free: 800.293.4237
Optelecom-NKF B.V
Zuidelijk Halfrond 4 • 2801 DD Gouda • The Netherlands
Telephone: [phone] • Fax: [phone]
Email: [e-mail] • Website: www.optelecom-nkf.com
