Optex InSight INS-QXI-ST User manual

59-xxxx-0 2102-10
EN
CAD 絵は線画に差替え予定
INS-QXI-ST
INS-QXI-ST
Camera and PIR detector
INSTALLATION INSTRUCTIONS
1
2
3
4
5
6
- Parts identification
- Accessories
- Manufacture’ s statement
- Detection area
- Specifications
- Compliance
- How to reset to the factory default
Before installation
Others
<< Contents >>
- 1 -
1-1. Disassemble
1-2. Mounting
1-3. Fall prevent wire
1-4. Wiring
1-5. Assembling
4-1. PIR area direction
4-2. PIR area masking
4-3. Switch settings
4-4. Walk test
4-5. LED indicator
Page
2
3
5
6
12
13
14
IP camera settings
CHeKT settings
Step
IP camera settings
CHeKT settings
https://navi.optex.net/manual/50426
https://chekt.com/registration
Enable
Disable
Installation
IP address settings
Registration InSight to CHeKT portal site
DHCP
Detection area settings and walk test
Camera angle settings
System check

- Manufacture’ s statement
Failure to follow the instructions provided
with this indication and improper handling
may cause death or serious injury.
Failure to follow the instructions provided
with this indication and improper handling
may cause injury and/or property damage.
Check mark indicates recommendation.
Nix sign indicates prohibition.
Special attention is required to the section
of this symbol.
Symbol Meaning Symbol Meaning
Warning
Caution
NOTE
Warning
Caution
Tilt
Before installation
- Parts identification
- 2 -
- Accessories
4 x 20 mm
Mounting screws T20 Torx wrench
Waterproof cap
for LAN connection
PIR area masking strips
(Both side “e” are attached
to the lens in the factory)
Section
“e”
PIR detector
Bracket angle adjusting screw
PIR cover
Camera unit Camera angle adjusting screw
Back cover
Mounting plate
Mounting height
2.2 m (7’ 3” ) to 2.7 m (8’ 11” )

1Installation
Step
Remove the main unit and the mounting plate.
1-2. Mounting 1-3. Fall prevent wire
Hook the fall prevent wire.
1-1. Disassemble
- 3 -
12 3

1-4. Wiring
PoE LAN cable
DC power cable
12 V DC power for camera and PIR
8-pin I/O cable
Tamper
Alarm
Power
+- SP N/A COM AL TP TP
Pink
Orange
Yellow
Brown
Green
Purple
Black
Red
Do not connect to
the N/A terminal.
Waterproof cap
for LAN connection
Caution
The connector can be fixed inside
the main body with double-sided tape.
NOTE
1-5. Assembling
Replace the main unit with the mount base.
12
1
Installation
Step
- 4 -
Cut the rubber and put the LAN cable into
(a), then (b) will be assembled to (a) tightly.
As a final step, (c) need to be assembled
to (b) without making any space.
Put the main body back on mounting plate.
Caution Do not pinch the cable when restoring the PIR detector.

2IP address settings
Step
The default network type of InSight is dynamic. If you do not have a DHCP server,
access the following IP address. Change the InSight network type to Static and set
the IP address;
Initial address: Refer to the label on the InSight
User name: root
Default password: OPTEX
Refer to the “IP Camera Setting Manual” in more detail.
IP Camera Setting Manual
3Registration InSight to CHeKT portal site
Step
- 5 -
The default network type of InSight is dynamic. If you have a DHCP server, it will automatically set the IP address.
1. Setup your CHeKT Dealer Portal:
2. Before getting started with CHeKT, you will need access to a CHeKT dealer web portal.
Access to this portal allows you to install and manage the InSight series.
If you do not have an account, please request a dealer account by visiting:
www.chekt.com/registration
Refer to the “https://support.chekt.com” for more detail. CHeKT settings

Detection area settings and walk test
4
Step
1
2
Caution
Do not use the vertical angle adjustment of the main unit other than adjusting
the detection area surface to be parallel to the ground inclination.
Parallel Adjusting the detection range
Remove the Back cover by hand.
Raise the Back cover up.
Pull it back.
Adjust PIR area direction
Angle can be adjusted with either left or right screw.
4-1. PIR area direction
12
The display of the detection area helps to set the area.
- 6 -
Settings on the InSight web
It is possible to refer the location of the detection area following procedure.
SETUP -> PIR DETECTOR -> PIR area viewer
In this step, do not change the camera tilt angle on InSight web settings.
Horizontal ±95°
Vertical 0° to -20°
1
2
NOTE
IP camera settings

4
Step
Detection area settings and walk test
Open the PIR cover
4-2. PIR area masking
1
- 7 -
Lock screw
( Use as necessary)
* Remove before,
if used.
[1] Unlock the cover using a
screwdriver (-).
[2] Lift the cover up.
Attach the area masking strips
a
b
c
d
b
c
d
ｆｆ
a
b
c
dｆ
b
c
dｆ
e
PIR area masking strips
(Both side “e” are attached
to the lens in the factory)
e
e
e
2

4
Step
Detection area settings and walk test
- 8 -
4-3. Switch settings
ON OFF
Alarm output N.O. N.C.
LED ON OFF
3 4
3 4
3 4
3 4
Low
Middle
PIR sensitivity
High
Super High
1
2
3
4 56 7 8
Default
Default
Future use
Do not move the mirror nor PCB from the factory settings as Pet alley cannot be set.
Caution
ミラーを下げた絵に変更
Close the detector cover.
1
2
Set the DIP switch 1 to 4, as necessary.

- 9 -
4-4. Walk test
4
Step
Detection area settings and walk test
4-5. LED indicator
[1] Warm-up
[2] Alarm
[3] Walk test end
60
2
5
Seconds
LED
1Turn LED back ON, if it was turned OFF (DIP switch No. 1, Default ON).
Walk around the detection area to make sure it is set as intended.
If necessary, turn LED OFF again.
Fix the cover with the cover lock screw included in the housing,
after completion as necessary.
2
For the walk test, walk at least 1.0 m (3’ 3” ) away from the detector.
3
4
For confirmation, the LED will light up according to the alarm output for 3 minutes
after the detector cover is installed again in any setting.
Conduct a walk test at least once a year.
Caution
NOTE

- 10 -
Camera angle settings
5
Step
Default
Camera angle adjustment
Loosen the screw to adjust camera angle.
Angle can be adjusted with either left or right screw.
20°min.
35°max.
30°
1

Replace the Back cover by hand.
If the angle of the camera is adjusted up or down,
the detection area display of the detector on the screen
will be different from the actual one. Adjust the display
on the web. See the IP camera manual.
System check
6
Step
Check the image at the time of detection on the monitoring portal.
- 11 -
Replace the back cover
Setting on the InSight web
1
2
2
3
IP camera settings

- Detection area
Others
- 12 -
Top view
Side view
30 35 25
0
10
912 m
4
7.5 m
2
0
2
510 20
15
3
4
6
40 ft.
5
15
25 ft.
7.5 m
5
10
15
25 ft.
0
0
20
6
6 20
35
30
25
9
20
6
2.2 m
0
1510
5
0
312 m
40 ft.
2.7 m
b
c
d
e
e
fb
c
d
f
Area on both sides are masked with the area strips by default.
e
a
PIR
Camera
Caution
7’3”
8’11”
Pet alley can not be set because the camera performance is not fully exhibited.
Do not slide the main unit of the detector.
Do not raise the mirror of the detector.

- Specifications
Others
- 13 -
• These units are designed to detect an intruder and activate an alarm control panel.
Being only a part of a complete system, we cannot accept responsibility for any
damages or other consequences resulting from an intrusion.
• Specifications and designs are subject to change without prior notice.
INS-QXI-ST
Passive infrared
12.0 m (40') 75°wide
32 zones
0.3 to 2.0 m/s (1' to 6'7"/s)
2.0℃( 3.6°F) at 0.6 m/s
PoE (IEEE 802.3af compliant)
Mini-jack 12 V DC 420 mA max.
Terminal 9.5 to 16 V DC/ 20 mA max. at 12 V DC
2.0 ± 0.5 s
Approx. 60 s (LED blinks)
N.C/N.O. switchable, 28 V DC 0.1 A max.
N.C. 28 V DC 0.1 A max.
Open when the cover is opened
[1] Warm-up [2] Alarm [3] Walk test end
1/2.8” CMOS
H: 114° V: 61°
Color: 0.02 lux. 0 lux. with IR
Visible up to 12 m
Day & Night Automatic/Manual switching
H.264, H.265, MJPEG
1080/ 30 fps, D1 (704 x 480 or 704 x 576)
IPv4: TCP/IP, UDP, RTP(UDP/TCP), RTSP, NTP, HTTP,
HTTPS, SSL, DHCP, SNMPv1/v2/v3(MIB-2), ONVIF
HTTPS(SSL), IP filtering, 802.1x, Digest authentication (ID/PW)
-30℃to +50℃(-22°F to +122°F)
95% max.
IP 54
Wall (Outdoor, Indoor)/Gang box
2.2 to 2.7 m (7' 3" to 8'11")
xxx g (x.xx oz)
[1] Mounting screw (4 x 20 mm) x 2
[2] T20 Torx wrench x 1
[3] Area masking strips x 1
[4] Waterproof cap for LAN connector x 1
Model
Detection method
PIR coverage
PIR zones
Detectable speed
Sensitivity
Power input
Alarm period
Warm-up period
Alarm output
Tamper output
LED indicator
Image sensor
Viewing angle
Minimum illumination
IR illumination
Night vision
Image compression
Resolution/ frame rate
Network protocol
Security
Operation temperature
Environment humidity
International protection
Mounting
Mounting height
Weight
Accessories

- Dimensions
Others
- 14 -
Unit: mm (inch)
214 (8.43)
84 (3.31) 209 (8.23)
140 (5.51)
83.5 (3.29)

FCC notification
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Personal Information
This product is equipped with the function to produce moving image of the designated area and
its surrounding, but not equipped with the function to store or register such image.
Prior to the installation of this product, the compliance to local laws and regulations needs to be
confirmed by the user of this product for the lawful installation and use of this product, and signage
and notification when using this product. User of this product is deemed to be responsible for the
compliance of any laws and regulations relating to personal information, privacy protection and
rights of portrait upon use of this product. Image taken by this product is required to be treated
appropriately under the responsibility of the user of this product.
Installation of this product, producing image, monitoring, recording with camera and handling of
personal information or data shall all be performed under discretion and responsibility of user of
this product, and OPTEX shall not be held liable for any dispute between a user and a third party.
- Compliance
- 15 -
About distribution of source code for open source software
This product includes open source software（” OSS”） distributed under OSS License. In compliance
with the OSS Licenses such as GPL (GNU GENERAL PUBLIC LICENSE), LGPL (GNU LESSER-
GENERAL PUBLIC LICENSE), and/or others included, we are making the source code of the OSS
available, at the actual cost, to our customer upon his/her request. The source code corresponding to
OSS included in this product will be provided in a prescribed manner for at least than three(3) years
after the date of purchase. Please note that the OSS is provided without warranty of any kind.
Others

- How to reset to the factory default
EU contact information
Manufacturer:
OPTEX CO., LTD.
5-8-12 Ogoto, Otsu, Shiga, 520-0101 JAPAN
Authorized representative in Europe:
OPTEX (EUROPE) LTD./EMEA HEADQUARTERS
Unit 13, Cordwallis Park, Clivemont Road,
Maidenhead, Berkshire, SL6 7BU U.K.
OPTEX INC./AMERICAS HQ (U.S.)
www.optexamerica.com
OPTEX (EUROPE) LTD./EMEA HQ (U.K.)
www.optex-europe.com
OPTEX SECURITY B.V.
(The Netherlands)
www.optex-europe.com/nl
OPTEX SECURITY SAS (France)
www.optex-europe.com/fr
OPTEX SECURITY Sp.z o.o. (Poland)
www.optex-europe.com/pl
OPTEX PINNACLE INDIA,
PVT., LTD. (India)
www.optexpinnacle.com
OPTEX KOREA CO.,LTD. (Korea)
www.optexkorea.com
OPTEX (DONGGUAN) CO.,LTD.
SHANGHAI OFFICE (China)
www.optexchina.com
OPTEX (Thailand) CO., LTD. (Thailand)
www.optex.co.th
Copyright (C) 2021 OPTEX CO.,LTD.
OPTEX CO., LTD. (JAPAN)
www.optex.net
Factory Reset Switch
123
Caution
Press to reset for 5 seconds.
Follow the steps below to perform a factory reset (for example, forget the password).
The IP address, ID, password and camera settings will be initialized.
Do not pinch the cable when restoring the PIR detector.
Others
- 16 -
