Opticon OPI 4002 User manual

2D Barcode Scanner
OPI 4002
The OPI 4002 is a 2D barcode scanner that •provides
wireless communication compliant with IEEE
802.15.4 between the OPI 4002 and a host system. Specifications Manual

Opticon
OPI 4002
Specifications Manual
2
All information subject to change without notice.
Document History
Model Number: OPI 2002 Specification Number: SS06077
Edition: 1A Original Spec Number: SS06076
Date: 2006-12-22
Copyright 2006 Opticon.All rights reserved.
This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic or
machine readable form without prior written consent of Opticon.
Limited Warranty and Disclaimers
PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE
PRODUCT.
Serial Number
A serial number appears on all Opticon products. This official registration number is directly related to the device
purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.
Warranty
Unless otherwise agreed in a written contract, all Opticon products are warranted against defects in materials and
workmanship for two years after purchase. Opticon will repair or, at its option, replace products that are defective in
materials or workmanship with proper use during the warranty period. Opticon is not liable for damages caused by
modifications made by a customer. In such cases, standard repair charges will apply. If a product is returned under
warranty and no defect is found, standard repair charges will apply. Opticon assumes no liability for any direct, indirect,
consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Opticon
has been informed about the possibility of such damages.
Packaging
The packing materials are recyclable. We recommend that you save all packing material to use should you need to
transport your scanner or send it for service. Damage caused by improper packaging during shipment is not covered by
the warranty.
Trademarks
Trademarks used are the property of their respective owners.
Opticon Inc. and Opticon Sensors Europe B.V. are wholly owned subsidiaries of OPTOELECTRONICS Co., Ltd., 12-17,
Tsukagoshi 4-chome, Warabi-shi, Saitama, Japan 335-0002. TEL [phone]; FAX [phone]
SUPPORT
USA Europe
Phone: [phone]
Email: [e-mail] Email: [email protected]
Web: www.opticonusa.com Web: www.opticon.com

Opticon
OPI 4002
Specifications Manual
3
Contents
1. Abstract....................................................................................................................................... 6
2. Overview...................................................................................................................................... 6
3. Physical Features....................................................................................................................... 7
3.1. Dimensions ......................................................................................................................... 7
3.2. Weight ................................................................................................................................. 7
3.3. Color.................................................................................................................................... 7
4. Environmental Specifications ................................................................................................... 7
4.1. Operating Temperature and Humidity................................................................................. 7
4.2. Storage Temperature and Humidity .................................................................................... 7
4.3. Ambient Light Immunity....................................................................................................... 8
5. Electrical Specifications ............................................................................................................ 8
5.1. Main Battery ........................................................................................................................ 8
5.2. Battery Operating Time and Charging Time ....................................................................... 8
5.3. AC Adaptor.......................................................................................................................... 9
5.4. Operating Indicators............................................................................................................9
5.4.1. LED Indicator and Buzzer ..........................................................................................................9
6. Optical Specifications.............................................................................................................. 10
6.1. Imager Scanning ............................................................................................................... 10
7. Technical Specifications.......................................................................................................... 10
7.1. Test Samples: 1D Symbologies ........................................................................................ 11
7.2. Test Samples: 2D Symbologies ........................................................................................ 11
7.3. Print Contrast Signal (PCS) .............................................................................................. 12
7.4. Minimum Resolution.......................................................................................................... 12
7.5. Scan Area and Resolution ................................................................................................ 13
7.5.1. Depth of Field...........................................................................................................................13
7.6. Pitch, Skew, and Tilt.......................................................................................................... 14
7.7. Curvature .......................................................................................................................... 15
8. Aiming ....................................................................................................................................... 16
8.1. Aiming Patterns.................................................................................................................16
8.2. Aiming Guidelines ............................................................................................................. 16
9. Interface Specifications ........................................................................................................... 17
9.1. Wireless Interface ............................................................................................................. 17

Opticon
OPI 4002
Specifications Manual
4
9.2. IEEE 802.15.4 ...................................................................................................................17
9.2.1. Radio Equipment .....................................................................................................................17
9.2.2. Frequency Band.......................................................................................................................17
10. Default Settings ........................................................................................................................ 18
10.1. Set Default Interface ......................................................................................................... 18
10.1.1. Default Settings........................................................................................................................18
10.2. Configuring Settings by Reading Menu Barcode Labels................................................... 18
10.2.1. Address Registration to Connect with OPA 1001....................................................................18
10.2.2. Wireless Communication Channel Settings: CH11–CH26 ......................................................18
10.2.3. Data Memorizing Settings Outside the Communication Range: DTME/DTMD.......................18
10.3. Default Settings 1: Readable Codes ................................................................................. 19
10.4. Default Settings 2: Read Options, Trigger, Buzzer ........................................................... 20
10.5. Default Settings 3: Other Communication Settings........................................................... 21
11. Serial Number and Labeling.................................................................................................... 21
11.1. FCC Label ......................................................................................................................... 21
12. Packaging Specifications ........................................................................................................22
12.1. Collective Packaging Specification ................................................................................... 23
13. Durability................................................................................................................................... 24
13.1. Electrical Noise ................................................................................................................. 24
13.2. Static Electricity................................................................................................................. 24
13.3. Shock ................................................................................................................................ 24
13.3.1. Drop Test (without packaging).................................................................................................24
13.3.2. Drop Test (with individual packaging)......................................................................................24
13.4. Vibration Strength ............................................................................................................. 24
13.5. Dust and Drip Proof........................................................................................................... 25
14. Reliability................................................................................................................................... 25
15. Regulatory Compliance ...........................................................................................................26
15.1. LED Safety ........................................................................................................................ 26
15.2. Product Safety................................................................................................................... 26
15.3. EMC .................................................................................................................................. 26
15.4. RoHS................................................................................................................................. 26
15.5. R&TTE .............................................................................................................................. 26
15.6. Radio Law ......................................................................................................................... 27
15.7. State of California: Perchlorate Best Management Practices ........................................... 27

Opticon
OPI 4002
Specifications Manual
5
16. Safety......................................................................................................................................... 28
16.1. Shock ................................................................................................................................ 28
16.2. Temperature Conditions.................................................................................................... 28
16.3. Foreign Materials .............................................................................................................. 28
16.4. Other ................................................................................................................................. 28
16.5. AC/DC Adapter ................................................................................................................. 28
17. Mechanical Drawing................................................................................................................. 29
Table of Figures
Figure 1: Depth of field ............................................................................................................... 13
Figure 2: Pitch, skew, and tilt...................................................................................................... 14
Figure 3: Curvature..................................................................................................................... 15
Figure 4: Aiming patterns............................................................................................................ 16
Figure 5: Serial number diagram ................................................................................................ 21
Figure 6: FCC label .................................................................................................................... 21
Figure 7: Individual packaging.................................................................................................... 22
Figure 8: Collective packaging.................................................................................................... 23
Figure 9: Mechanical drawing..................................................................................................... 29

Opticon
OPI 4002
Specifications Manual
6
1. Abstract
This manual provides master specifications for the OPI 4002 2D barcode scanner (hereafter
referred to as “scanner”).
2. Overview
The OPI 4002 includes the following features:
•A 1.3 million-pixel (SXGA) CMOS area image sensor, and a compact camera module
with wide-angle lens that enables scanning of wider symbologies at higher resolution
•Wide-angle lens optics that make it possible to scan wider symbologies at closer
distances
•A small, high-performance, power-saving decoder that processes data faster and
provides smoother scanning of both linear (1D) and 2D symbologies
•Wireless communication compliant with IEEE 802.15.4 (an interface standard for ZigBee
physical layer and MAC layer) is the interface between the OPI 4002 and a host system
•The scanner is supplied with an IEEE 802.15.4 dongle to establish wireless
communication through the USB port of hosting hardware.
•Scanner settings can be configured by scanning menu labels.
•A lithium-ion secondary battery is used as the power supply for the scanner.
•Connect a dedicated AC adapter or an optional charger directly to the OPI 4002 to
charge the battery.
•The OPI 4002 complies with the Restriction of Hazardous Substances (RoHS).

Opticon
OPI 4002
Specifications Manual
7
Supported symbologies:
Linear (1D) Postal Code 2D
JAN/UPC/EAN, incl. add-on Chinese Post Aztec Code
Codabar/NW-7 Korean Postal Authority Code Aztec Runes
Code 39 Composite Codes
Code 93 Data Matrix (ECC 0-140, ECC200)
Code 128 Maxi Code (mode 2~5)
GS1-128 (EAN-128) MicroPDF417
GS1 Databar (RSS) Micro QR Code
IATA PDF417
Industrial 2of5 QR Code
Interleaved 2of5
ISBN-ISSN-ISMN
Matrix2of5
MSI/Plessey
S-Code
Telepen
Tri-Optic
UK/Plessey
3. Physical Features
3.1. Dimensions
W 58.1 mm x D 42.4 mm x H 163.9 mm
3.2. Weight
125 grams, max.
3.3. Color
Light gray
4. Environmental Specifications
4.1. Operating Temperature and Humidity
Temperature: 0 to 40° C
Humidity: 5 to 90% RH
4.2. Storage Temperature and Humidity
Temperature: -20 to 60° C
Humidity: 5 to 90% RH

Opticon
OPI 4002
Specifications Manual
8
4.3. Ambient Light Immunity
Decoding performance is guaranteed when the range of illumination on a barcode
surface is between zero and the following values:
Incandescent light to 10,000 lx
Fluorescent light to 10,000 lx
Sunlight to 100,000 lx
Direct light or specular reflection from a light source should be prevented from entering
the acceptance area.
5. Electrical Specifications
5.1. Main Battery
The main battery is a lithium-ion secondary battery.
Nominal capacity: 1100 mAh
Nominal voltage: 3.6 V
Item Specifications Conditions
15 mA (max.) When idle
250 mA (max.) When scanning
Consumption
current
550 mA (typ.) When charging
5.2. Battery Operating Time and Charging Time
Items Specifications Conditions
Battery life 30 hours (min.)
1 scan / 5 s
Discharge and charge 300 times
Battery capacity 70% (1C charging)
Charging time 3 hours Time necessary to fully charge an empty battery
Note: Battery life may be shorter than specified above when the quality of the battery
pack is degraded.
Conditions
Ambient temperature: +25°
Symbology: 1-digit Code 39, PCS = 0.9, Resolution = 1.0 mm
Distance: 85 mm from the front edge of the scanner. (Single read)

Opticon
OPI 4002
Specifications Manual
9
5.3. AC Adaptor
The OPI 4002 can be charged by an optional AC adapter of 6.0 V / 750 mA. This optional
adapter is used for charging the internal battery.
Conditions
Connect 1Ωresistance to a power supply line in series and measure the current by
the voltage between both ends of resistance.
Power supply voltage is measured at a connector terminal area.
The current value depends on the interface type and host computer to which the
device is connected.
5.4. Operating Indicators
5.4.1. LED Indicator and Buzzer
The OPI 4002 uses LEDs and a buzzer to indicate its status.
State Color Display Operating State Buzzer
Red Lighting Shows that the scanner is being
charged. -
Charging
Green Lighting The light changes from red to green
when charging is completed. -
Green Blinking
Shows that the scan or transmission was
executed normally. Trrr
Red Blinking Shows that the data could not be
transmitted. Pip, Pip, Pip
Scanning
Orange Blinking Shows that the data is being stored in
memory. Trrrrrrrrrrr
Green Lighting
Shows that registration was completed. Peeeeeeeeep
(Completion of
Registration)
Wireless
Connection
Red Lighting Shows that registration failed. Pip, Pip, Pip

Opticon
OPI 4002
Specifications Manual
10
6. Optical Specifications
6.1. Imager Scanning
Parameter Specification Unit
Scanning method CMOS area sensor
(black and white)
—
Effective pixels 1280 (H) x 1024 (V) dots
Frame rate 30 fps
Aiming LED wavelength
(2 green LEDs)
527 nm
Lighting LED wavelength
(4 red LEDs)
630 nm
View angle Horizontal: 47
Vertical: 37.5
°
Focal length 85 mm
Notes:
Refer to chapter 7, “Technical Specifications,” to read about scanning performance.
7. Technical Specifications
The conditions for technical specifications are as follows, unless otherwise specified in each
section.
Conditions
Ambient temperature
and humidity:
Room temperature (5 to 35º C)
Room humidity (45% to 85% RH)
Ambient light: 1000 to 1500 lx (on the surface of a barcode)
Light source: 3-wavelength inverter fluorescent light
Angles: α= 0°, β= +15°, γ= 0°
Curvature R = ∞
Background: Barcode = black
Space = white
Margin = white
Background of label = black
Power supply voltage: 3.6 V
Decoding test: Approve the performance when decoding is successful in 70% or more of
the tests

Opticon
OPI 4002
Specifications Manual
11
7.1. Test Samples: 1D Symbologies
The size of barcodes does not include quiet zones.
1D Barcode
Resolution Symbology PCS Size (mm) Digits
0.254 mm Code 39 0.9 14 x 10 2
0.1 mm Code 39 0.9 11 x 10 4
0.26 mm 13-digit JAN 0.9 25 x 19 13
0.26 mm 8-digit JAN 0.9 17.5 x 15.5 8
Barcode samples with 0.127 mm and 0.26 mm resolution are OPTOELECTRONICS
test samples. Other charts are printed by a regular printer.
N/W Ratio: 1:2.5
Angle: α= 0°, β= 15°, γ= 0°
Curvature R = ∞
7.2. Test Samples: 2D Symbologies
PDF417
Resolution Error Correction PCS Size (mm) Characters
0.127 mm Level-4 0.9 13 x 8 17
0.254 mm Level-4 0.9 26 x 16.5 17
0.339 mm Level-4 0.9 35 x 22 17
Charts are printed by a regular printer.
Horizontal to vertical ratio is 3:1
Data Matrix
Resolution Model PCS Size (mm) Characters
0.169 mm ECC200 0.9 4 x 4 40
0.339 mm ECC200 0.9 8 x 8 40
QR Code
Resolution Model PCS Size (mm) Characters
0.169 mm M 0.9 5 x 5 44
0.339 mm M 0.9 10 x 10 44

Opticon
OPI 4002
Specifications Manual
12
7.3. Print Contrast Signal (PCS)
0.45 or higher (over 70% of reflectivity of space and quiet zone).
PCS=Reflectance of white bar－Reflectance of black bar
Reflectance of white bar
Scanning performance may decline if dirt or scratches mar the optical window. Keep the
optical window clean.
7.4. Minimum Resolution
Resolution Symbology
0.1 mm Code 39
0.127 mm PDF417
0.169 mm QRCode
0.169 mm Data Matrix

Opticon
OPI 4002
Specifications Manual
13
7.5. Scan Area and Resolution
7.5.1. Depth of Field
The depth of field is measured from the edge of the optical window.
Figure 1: Depth of field
Symbology Resolution (mm) Decode Depth (mm) PCS
Code 39 0.1
0.254
55–75
30–105
0.9
PDF417 0.127
0.339
45–80
25–130
0.9
QR Code 0.169
0.339
45–75
25–100
0.9
Data Matrix 0.169
0.339
45–70
35–95
0.9

Opticon
OPI 4002
Specifications Manual
14
7.6. Pitch, Skew, and Tilt
Pitch: α= ±50°
Skew: β= ±60° or less
Tilt: γ= 360° or less
Figure 2: Pitch, skew, and tilt
Conditions
Barcode Sample: CODE39 and PDF417 with 0.254 mm resolution, PCS: 0.9
Distance: 56 mm from the front edge of the scanner
Curvature: R = ∞
(The calculation of pitch and tilt angles is based on the skew angle
formula being β= +15°)
Notes
When a barcode is printed on glossy paper or a card case, it may cause difficulties in
scanning due to the reflection of lighting LEDs. To improve scanning performance
under these circumstances, scan the barcode with a scan angle of 15 degrees or with
lighting LEDs turned off. When scanning a barcode with lighting LEDs turned off,
confirm that there is enough ambient lighting in the room (1000 lx or higher), or
scanning performance may decline. Scanning performance may also decline if room
light reflects on the barcode surface.

Opticon
OPI 4002
Specifications Manual
15
7.7. Curvature
With 8-digit JAN/UPC/EAN barcodes, decoding performance is guaranteed when
R≥15 mm.
With 13-digit JAN/UPC/EAN barcodes, decoding performance is guaranteed when
R≥20 mm.
Figure 3: Curvature
Conditions
Barcode Sample: Symbology: 13-digit JAN, resolution: 0.26 mm, PCS: 0.9 mm
Distance: 56 mm from the front edge of the scanner
Angle: α= 0°, β=＋15°, γ= 0°

Opticon
OPI 4002
Specifications Manual
16
8. Aiming
8.1. Aiming Patterns
During a scan, the green LED patterns shown below will be visible. These patterns assist
you in aiming the scanner; they are superimposed on the illuminated scan field. The
aiming patterns are only a guide. They do not indicate exact scannable width or distance
between a scanner and a barcode.
Figure 4: Aiming patterns
8.2. Aiming Guidelines
•The focal point is where two central LED light patterns (green and square-shaped)
overlap—where two dots meet.
•To scan a barcode within the aiming range, make sure that two central LED light
patterns overlap, then place the center of the overlapping LED light patterns on the
center of the barcode.
•To scan a barcode wider than a width of the aiming range, aim at the barcode from
further away. Make sure that the barcode is between two LED light patterns on both
the right and left.
•Scanning performance may decline due to the specular reflection when the
symbology is printed on certain types of materials. In such cases, incline the scanner
at 15 degrees to adjust the scanning angle.

Opticon
OPI 4002
Specifications Manual
17
9. Interface Specifications
9.1. Wireless Interface
Complies with IEEE 802.15.4 (ZigBee’s physical layer and MAC layer).
Item Specification Notes
Frequency 2400 MHz to 2483.5 MHz
Communication specification IEEE 802.15.4 compliant
Transmission power 0 dBm or less
Communication distance 30 m or longer Depends on the environment.
Baud rate 250 Kbps
Antenna 1/4λsurface-mounted type
Communication configuration One OPI 4002 to one OPA 1001
Encryption 128-bit encryption
9.2. IEEE 802.15.4
9.2.1. Radio Equipment
The electromagnetic wave absorption (2.4 GHz) used by this product is also
shared by various other devices. Therefore, baud rate and communication
distance may be negatively impacted, or their communications may be
disconnected, by other devices using the same absorption rate.
Baud rate and communication distance are affected by obstacles, wave
conditions, or a device at the other end.
This product is equipped with an antenna. Bringing this product too close to a
metallic object may affect communication. Anticipated interference distance is 10
m or less.
9.2.2. Frequency Band
This product uses the 2.4 GHz frequency band. Scientific, medical, and industrial
devices, including microwaves, wireless security (camera) systems and W-LAN
use the same frequency band as this scanner. Other radio stations also use this
frequency for mobile object identification, including local private radio stations that
require a license (for example, manufacturing lines at factories), specific power-
saving radio stations requiring no license, and amateur radio stations.
Interference from other devices may affect the communication speed or
communication range of this scanner or vice versa.

Opticon
OPI 4002
Specifications Manual
18
10. Default Settings
10.1.Set Default Interface
Scan the following menu barcodes to return to the default settings.
There are two ways to configure factory default settings:
•One-by-one configuration by scanning the Code 39 menu labels below.
Note: When duplicated scanning of a menu label occurs, the last label scanned will
take effect.
•Multi-configuration by scanning the QR code menu label below.
10.1.1. Default Settings
Code 39 Menu Labels for One-by-One Configuration QR Code Label for
Multi-Configuration
ZZ Set [[ 
C02
Interface Settings
IEEE802.15.4 HID Data Transmission
D13

ZZ End [[ 
10.2.Configuring Settings by Reading Menu Barcode Labels
Communication parameter settings for the OPI 4002 can be configured by scanning
menu labels.
Refer to the instruction manual for further information about menu labels.
10.2.1. Address Registration to Connect with OPA 1001
Read an address barcode printed on the label attached to the OPA 1001 cradle.
Confirm that the OPA 1001 is connected to the OPI 4002
Note: Scanned data cannot be transmitted unless the address registration is
completed.
10.2.2. Wireless Communication Channel Settings: CH11–CH26
The wireless communication channel settings can be adjusted.
10.2.3. Data Memorizing Settings Outside the Communication Range:
DTME/DTMD
Selecting “Data Memorizing Enabled” allows the scanner to read data outside the
communication range and store the data in OPI 4002 memory. When the scanner

Opticon
OPI 4002
Specifications Manual
19
returns to the communication range, it will be re-connected and the temporarily
stored data will automatically be transmitted to the host.
Note: When “Data Memorizing Disabled” is selected, the scanner will not read
data outside the range.
10.3.Default Settings 1: Readable Codes
Symbology Read Transmit
Code
Length
Transmit
CD Calculate CD Set Prefix Set Suffix Other
UPC-A X — CR
UPC-A Add-on X X — CR
UPC-E X — CR
UPC-E Add-on X X — CR
EAN-13 X — CR
EAN-13 Add-on X X — CR
EAN-8 X — CR
EAN-8 Add-on X X — CR
Aztec Code X X — CR
Aztec Runes X X X — CR
Codabar / NW-7 X X — CR Not transmit ST/SP
Code 39 X X — CR Not transmit ST/SP
Code 93 X — CR
Code 128 X — CR
Data Matrix
(ECC0-140)
X X X — CR
Data Matrix
(ECC200)
X X — CR
GS1-128
(EAN/UCC-128)
X X X — CR
GS1 DataBar
(RSS) (all, incl.
CC-A/B);
Omnidirectional/
Truncated/
Stacked/Limited/
Expanded
X X X — CR
IATA X X — CR
Industrial2of5 X X — CR
Interleaved2of5 X X — CR
Matrix2of5 X X
X — CR
Maxi Code X X — CR

Opticon
OPI 4002
Specifications Manual
20
Symbology Read Transmit
Code
Length
Transmit
CD Calculate CD Set Prefix Set Suffix Other
MicroPDF417 X X — CR
Micro QR X X X — CR
PDF417 X X — CR
QR Code X X — CR
MSI/Plessey X CD1 CD1 — CR
UK/Plessey X — CR
S-Code X X — CR
Telepen X — CR
Tri-Optic X X — CR Not transmit ST/SP
Notes:
In the “Reading” column, “” means “Enable reading” and “X” means “Disable reading.”
In the “Transmit code length” column, “” means “Transmit code length”
and “X” means “Do not transmit code length.”
In the “Transmit CD” column, “” means “Transmit check digit”
and “X” means “Do not transmit check digit.”
In the “Calculate CD” column, “” means “Calculate check digit”
and “X” means “Do not calculate check digit.”
“— “ means “not supported.” In the “Prefix” column, “—“ means “there is no prefix setting.”
10.4.Default Settings 2: Read Options, Trigger, Buzzer
Item Default Setting
Setting the number of characters Fixed length OFF all codes
Read mode Multiple read
Multiple label read Disable
NW-7 intercharacter gap check Up to 1 character
Trigger switch Enable
Read time 2 seconds (when trigger enabled)
Buzzer duration 200 ms
Buzzer frequency 3kHz + 2.5 kHz
Buzzer loudness Loud
Good read LED Indicator duration 200 ms
