Optimum BF 30 Vario User manual

GB 2008
16 / 09 / 2008
OPTIMUM
M A S C H I N E N - G E R M A N Y
http://www.zavodprodam.ru/
Operating manual
Version 1.0.3
Drilling-Milling machine
BF 30 Vario
Keep for future reference!
Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 1

OPTIMUM
M A S C H I N E N - G E R M A N Y
Table of Contents
Preface
We thank you very much that you have decided for the drilling-milling machine BF 30 Vario
made by Optimum Maschinen Germany GmbH.
Changes The illustrations of the drilling-milling machine might in some details deviate from the illustrations
of this operating manual but this will have no influence on the operation of the drilling-milling
machine.
Any changes in the construction, equipment and accessories are reserved for reasons of enhan-
cement. Therefore, no claims may be derived from the indications and descriptions. Errors
excepted!
1
Safety
1.1
Safety warnings (warning notes).............................................................................................
5
1.1.1
Classification of hazards..............................................................................................
5
1.1.2
Further pictograms.......................................................................................................
6
1.2
Proper use ..............................................................................................................................
6
1.3
Possible dangers caused by the drilling-milling machine........................................................
7
1.4
Qualification of personnel........................................................................................................
7
1.4.1
Target group ................................................................................................................
7
1.5
Safety devices.........................................................................................................................
8
1.5.1
EMERGENCY-STOP button........................................................................................
8
1.5.2
Lockable main switch...................................................................................................
9
1.5.3
Protective cover ...........................................................................................................
9
1.5.4
Separating protective equipment ...............................................................................
10
1.6
Safety check .........................................................................................................................
10
1.7
Individual protection gear ......................................................................................................
11
1.8
For your own safety during operation....................................................................................
11
1.9
Disconnecting the drilling-milling machine and making it safe ..............................................
12
1.10
Using lifting equipment..........................................................................................................
12
2
Technical data
2.1
Power connection..................................................................................................................
13
2.2
Drilling- milling capacity.........................................................................................................
13
2.3
Spindle holding fixture...........................................................................................................
13
2.4
Drill- mill head .......................................................................................................................
13
2.5
Cross table ............................................................................................................................
13
2.6
Work area..............................................................................................................................
13
2.7
Speeds ..................................................................................................................................
13
2.10
Emissions..............................................................................................................................
14
2.8
Environmental conditions ......................................................................................................
14
2.9
Operating material.................................................................................................................
14
2.11
Installation plan BF 30 Vario .................................................................................................
15
2.12
Installation plan of optional substructure...............................................................................
16
3
Unpacking and connecting
3.1
Extent of supply ....................................................................................................................
17
3.2
Transport...............................................................................................................................
17
3.3
Storage .................................................................................................................................
17
3.4
Installation and assembly......................................................................................................
18
3.4.1 Requirements of the installation site..........................................................................
18
3.4.2
Load suspension point...............................................................................................
18
3.4.3
Installation..................................................................................................................
18
3.4.4
Installation drawing ....................................................................................................
19
3.5
First use ................................................................................................................................
19
3.5.1
Cleaning and lubricating ............................................................................................
19
3.5.2 Fill in gear lubricant oil ...............................................................................................
19
3.6
Optional accessory................................................................................................................
20
Page 2 Drilling-Milling machine BF 30 Vario Version 1.0.3 16 / 09 / 2008
2008 GB

OPTIMUM
4
Operation
4.1
Safety
................................................ ......... ................
.... ......... ................. ......... ......... ...........
21
4.2
Control and indicating elements ............................................................................................
21
4.2.1....................................................................................................................................22
4.3
Starting.......................................................................................thedrilling-millingmachine
23
4.4
Switching..............................................................................-offthedrilling-millingmachine
23
4.5
Inserting.......................................................................................................................atool
23
4.5.1..................................................................................................................
In
st
al
la
ti
o
n
23
4.5.2...............................................................................................................
Di
s
a
ss
e
m
bl
y
24
4.5.3...................................................................................................Useofcolletchucks
24
4.6
Clamping......................................................................................................theworkpieces
24
4.7
Changing....................................................................................................thespeedrange
25
4.8
Selecting...............................................................................................................thespeed
25
4.8.1............................................................................Standardvaluesforcuttingspeeds
25
4.8.2.......................................StandardvaluesforspeedswithHSS–Eco–twistdrilling
26
4.9
Manual.......................................................................spindlesleevefeedwiththefinefeed
27
4.10 Manual.....................................................spindlesleevefeedwiththespindlesleevelever
27
4.11
Digital.................................................................................displayforspindlesleevetravel
28
4.11.1............................................................................................................Technicaldata
28
4.11.2........................................................................................................................Design
28
4.12
Trouble....................................................................................................................shooting
29
4.13
Swivelling..................................................................................................thedrill-millhead
29
5
Maintenance
5.1
Safety ....................................................................................................................................
30
5.1.1................................................................................................................
Pr
e
p
ar
at
io
n
30
5.1.2...................................................................................................................
R
e
st
ar
ti
n
g
31
5.2
Inspection.................................................................................................andmaintenance
31
5.3
Repair....................................................................................................................................
36
6
Ersatzteile - Spare parts - BF30 Vario
6.1
Säule -......................................................................................................................Column
37
6.2
Kreuztisch................................................................................................-Crosstable1-2
38
6.3
Kreuztisch................................................................................................-Crosstable2-2
39
6.4
Schutzeinrichtung...................................................................................-Protectiondevice
40
6.5
Fräskopf..................................................................................................-Millinghead1-3
41
6.6
Fräskopf..................................................................................................-Millinghead2-3
42
6.7
Fräskopf..................................................................................................-Millinghead3-3
43
6.8
Maschinenunterbau......................................................(Optional)-Machinestand(option)
44
6.9
Schaltplan..................................................................................................-Wiringdiagram
45
6.10
Teileliste...............................................................................................................-Partslist
46
7
Anomalies
7.1
Anomalies..............................................................................inthedrilling-millingmachine
52
8
Appendix
8.1
Copyright ...............................................................................................................................
53
8.2
Terminology/Glossary ...........................................................................................................
53
8.3
Warranty................................................................................................................................
54
8.4
Disposal.................................................................................................................................
54
8.5
RoHS...............................................................................................................,2002/95/CE
54
8.6
Product...................................................................................................................follow-up
55
8.7
EC Declaration................................................................................................ofConformity
56
9
Index
2008
GB
16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 3

OPTIMUM
Safety
M A S C H I N E N - G E R M A N Y
1Safety
Glossary of symbols
give additional indications
calls on you to act
enumerations
This part of the operating manual
explains the meaning and use of the warning references contained in the
operating manual,
explains how to use the drilling-milling machine properly,
highlights the dangers that might arise for you and others if these instructions are
not obeyed.
In addition to this operating manual please observe
applicable laws and regulations,
legal regulations for accident prevention,
the prohibition, warning and mandatory signs as well as the warning notes on the
drilling-milling machine.
ALWAYS KEEP THIS DOCUMENTATION CLOSE TO THE DRILLING-MILLING MACHINE.
INFORMATION
If you are unable to solve a problem using this manual, please contact us for advice:
Optimum Maschinen Germany
GmbH Dr. Robert-Pfleger-Str. 26
D- 96103 Hallstadt
Page 4 Drilling-Milling machine BF 30 Vario Version 1.0.3 16 / 09 / 2008
2008 GB

Safety OPTIMUM
M A S C H I N E N - G E R M A N Y
1.1 Safety warnings (warning notes)
1.1.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (pictograms) and warnings for the specific danger and its (possible)
consequences.
Pictogram
Alarm expres-
Definition/Consequences
sion
DANGER!
Imminent danger that will cause serious injury or death to
personnel.
WARNING!
Risk: a danger that might cause serious injury or death to
personnel.
CAUTION!
Danger of unsafe procedure that might cause injury to
personnel or damage to property.
Situation that could cause damage to the drilling-milling
ATTENTION!
machine and product and other types of damage.
No risk of injury to personnel.
Application tips and other important or useful information
INFORMATION
and notes.
No dangerous or harmful consequences for personnel or
objects.
In the case of specific dangers, we replace the pictogram by
or
General dan-
with a warning
injuries to
hazardous
rotating parts.
ger
of
hands,
electrical
voltage,
GB 2008
16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 5

OPTIMUM
Safety
M A S C H I N E N - G E R M A N Y
1.1.2 Further pictograms
Activation forbidden! Read the operating Pull the mains plug! Use protective goggles!
manual before the
machine is first used!
Use protective gloves Use protective boots! Wear a safety suit! Use ear protection!
Protect the environ- Contact address
ment!
1.2 Proper use
WARNING!
In the event of improper use, the drilling-milling machine
•will endanger personnel,
•will endanger the drilling-milling machine and other material property of the operator,
•may affect proper operation of the drilling-milling machine.
The drilling-milling machine is designed and manufactured to be used for milling and drilling
cold metals or other non-flammable materials or that do not constitute a health hazard by using
com-mercial milling and drilling tools.
The drilling-milling machine must only be installed and operated in a dry and well-ventilated
place.
If the drilling-milling machine is used in any way other than described above, modified without
the authorisation of the company Optimum Maschinen Germany GmbH or operated with diffe-
rent process data, then the drilling-milling machine is being used improperly.
We do not take liability for damages caused by improper use.
We would like to stress that any modifications to the construction, or technical or technological
modifications that have not been authorised by the company Optimum Maschinen Germany
GmbH will also render the guarantee null and void. It is also part of proper use that
the maximum values for the drilling-milling machine are complied
with, the operating manual is observed,
inspection and maintenance instructions are observed.
„Technical data“ on page 13
Page 6 Drilling-Milling machine BF 30 Vario Version 1.0.3 16 / 09 / 2008
2008 GB

Safety OPTIMUM
M A S C H I N E N - G E R M A N Y
WARNING!
Very serious injury due to improper use.
It is forbidden to make any modifications or alterations to the operating values of the dril-
ling-milling machine. These could endanger the staff and cause damage to the drilling-
milling machine.
1.3 Possible dangers caused by the drilling-milling machine
The drilling-milling machine was built using the latest technological advances.
Nonetheless there remains a residual risk, since the drilling-milling machine operates with
high revolutions, rotating
parts and tools,
electrical voltage and currents.
We have used construction resources and safety techniques to minimise the health risk to the
staff resulting from these hazards.
If the drilling-milling machine is used and maintained by personnel who are not duly qualified,
there may be a risk by the drilling-milling machine resulting from incorrect operation or unsuita-
ble maintenance.
All personnel involved in assembly, commissioning, operation and maintenance must
be duly qualified,
strictly follow this operating manual .
Disconnect the drilling-milling machine whenever cleaning or maintenance work is being carried
out.
WARNING!
The drilling-milling machine may only be used with the safety devices activated.
Disconnect the drilling-milling machine whenever you detect a failure in the safety
devices or when they are not fitted!
All additional installations carried out by the operator need to incorporate the prescribed
safety devices.
As the machine operator, this will be your
responsibility! „Safety devices“ on page 8
1.4 Qualification of personnel
1.4.1 Target group
This manual is addressed to
the operator,
the user,
the maintenance staff.
The warning notes therefore refer to both operation and maintenance of the drilling-milling
machine.
Always disconnect the drilling-milling machine plug from the mains. This will prevent it being
used by unauthorised staff.
GB 2008
INFORMATION
All personnel involved in assembly, commissioning, operation and maintenance need to
16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 7

OPTIMUM
Safety
M A S C H I N E N - G E R M A N Y
be duly qualified,
strictly follow this operating manual
. In the event of improper use
there may be a risk to the staff,
there may be a risk to the drilling-milling machine and other material
property, may affect proper operation of the drilling-milling machine.
1.5 Safety devices
Use the drilling-milling machine only with properly functioning safety devices.
Stop the drilling-milling machine immediately if there is a failure in the safety device or if it is not
functioning for any reason.
It is your responsibility!
If a safety device has been activated or has failed, the drilling-milling machine must only be
used when
the cause of the failure has been removed,
it has been verified that there is no resulting danger for the staff or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other personnel working with the drilling-milling machine. The possible
con-sequences are
•damage as a result of components or parts of components flying off at high speed,
•contact with rotating parts,
•fatal electrocution.
The drilling-milling machine includes the following safety devices:
an EMERGENY-STOP button,
a protective cover at the drill-mill head,
a separating protective equipment on the milling spindle.
1.5.1 EMERGENCY-STOP button
The EMERGENCY-STOP button switches
the drilling-milling machine off.
„Starting the drilling-milling machine“
on page 23 EMERGENCY-STOP
Illustr. 1-1: EMERGENCY-STOP button
Page 8 Drilling-Milling machine BF 30 Vario Version 1.0.3 16 / 09 / 2008
2008 GB

GB 2008
Safety
OPTIMUM
M A S C H I N E N - G E R M A N Y
ATTENTION!
The EMERGENCY-STOP button switches off the drilling-milling machine immediately.
Only press the EMERGENCY-STOP button in case of danger! If the emergency stop but-
ton is actuated in order to stop the drilling-milling machine generally you might damage
tools or workpieces.
After actuating the button, turn it to the right, in order to restart the machine.
1.5.2
Lockable main switch
In the position " 0 " the lockable main
switch can be secured against accidental
or non-authorised switching on by means
Main switch
of a padlock.
When the main switch is switched off, the
current supply is been interrupted.
Except for the areas marked by the picto-
gram in the margin.
Illustr. 1-2: Main switch
WARNING!
Dangerous voltage even if the main switch is switched off. In the areas marked by the
pictogram in the margin, there might be voltage, even if the main switch is switched off.
1.5.3
Protective cover
The drill-mill head is fitted with a
protective cover. Protective cover
WARNING!
Remove the protective cover only
after the mains plug of the drilling-
milling machine has been pulled.
Illustr. 1-3: Protective cover
16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 9

OPTIMUM
Safety
M A S C H I N E N - G E R M A N Y
1.5.4 Separating protective equipment
Adjust the protective equipment to the
correct height before you start working.
To do so, detach the clamping screw,
adjust the required height and retighten
the clamping screw.
A switch is integrated in the fixture of the
spindle protection which monitors that the
cover is closed.
INFORMATION
YOU CANNOT START THE MACHINE IF
THE DRILL CHUCK PROTECTION IS
NOT CLOSED.
Locking screw
Illustr. 1-4: Separating protective equipment
1.6 Safety check
Check the drilling-milling machine
regularly. Check all safety advices
at the beginning of each shift,
once a week (with the machine in operation),
after every maintenance and repair operation.
General check
Equipment
Check
OK
Protective covers
Fitted, firmly bolted and not damaged
Labels,
Installed and legible
markings
Run test
Equipment
Check
OK
EMERGENCY-STOP but-
When the EMERGENCY-STOP button is activated, the drilling-
ton
milling machine should switch off. A restart will not be possible
until the EMERGENCY-STOP button has been unlocked and the
ON switch has been activated.
Separating protective
Only switch on the drilling-milling machine if the protective equip-
equipment around the dril-
ment is closed.
ling and milling spindle
Page 10 Drilling-Milling machine BF 30 Vario Version 1.0.3 16 / 09 / 2008
2008 GB

GB 2008
Safety
OPTIMUM
M A S C H I N E N - G E R M A N Y
1.7 Individual protection gear
For certain work individual protection gear is required.
Protect your face and eyes: During all work and specifically work during which your face and eyes are
exposed to hazards, a safety helmet with a face guards should be worn.
Use protective gloves when handling pieces with sharp edges.
Use safety shoes when you position, dismantle or transport heavy components.
Use ear protection if the noise level (emission) in the workplace exceeds 80 dB (A).
Before starting work, make sure that the prescribed individual protection gear is available at the
workplace.
CAUTION!
Dirty or contaminated body protection gear can cause disease. Clean it each time after
it has been used and once a week.
1.8 For your own safety during operation
WARNING!
Before activating the drilling-milling machine, double check that this will not
endanger other people and cause damage to equipment.
Avoid any unsafe working practises:
Make sure your work does not endanger anyone.
The instructions in this manual need to be observed during assembly, handling,
mainte-nance and repair.
Use protective goggles.
Turn off the drilling-milling machine before measuring the workpiece.
Do not work on the drilling-milling machine if your concentration is reduced, for
example, because you are taking medication.
Stay on the drilling-milling machine until the working spindle has come to a complete halt.
Use prescribed protection gear. Make sure to wear a well-fitting work suit, when
neces-sary, a hairnet.
Do not use protective gloves during drilling or milling work.
Unplug the shockproof plug from the mains before changing the
tool. Use suitable devices for removing drilling and milling chips.
Make sure your work does not endanger anyone.
Clamp the workpiece tightly before activating the drilling-milling machine.
In the description of work with and on the drilling-milling machine we highlight the dangers spe-
cific to that work.
16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 11

OPTIMUM
Safety
M A S C H I N E N - G E R M A N Y
1.9 Disconnecting the drilling-milling machine and making it safe
Switch off the drilling-milling machine with the main switch before starting any maintenance and
repair works.
1.10 Using lifting equipment
WARNING!
Use of unstable lifting equipment and load-suspension devices that break under load
can cause very serious injury or even death.
Check that the lifting equipment and load-suspension devices are of sufficient load
capa-city and are in perfect condition.
Observe the rules for preventing accidents issued by your association for the prevention of
occupational accidents and safety in the workplace or other inspection authorities.
Hold the loads properly.
Never walk under suspended loads!
Positions of the signs on the drilling-milling machine
Illustr. 1-5: BF 30 Vario
Page 12 Drilling-Milling machine BF 30 Vario Version 1.0.3
16 / 09 / 2008
2008 GB

Technical data OPTIMUM
M A S C H I N E N - G E R M A N Y
2Technical data
The following information gives the dimensions and weight and is the manufacturer’s authorised
machine data.
2.1
Power connection
Motor power consuption
230V ~ 50Hz 1,5 kW
2.2
Drilling- milling capacity
Drilling capacity in steel [mm]
max. Ø30
Drilling capacity cast iron [mm]
max. Ø35
Milling capacity of end-mill cutter [mm]
max. Ø30
Milling capacity of inserted tooth cutter [mm]
max. Ø75
Working radius [mm]
220
2.3
Spindle holding fixture
Spindle holding fixture
MT 3
ISO 30
Extraction rod
M12
Sleeve travel [mm]
90 mm
2.4
Drill- mill head
Swivelling
+ / - 30°
Gearbox stages
3
Z-axis travel [mm]
470
2.5
Cross table
Table length [mm]
750
Table width [mm]
210
Y-axis travel [mm]
200
X-axis travel [mm]
450
T - slot size / distance [mm]
12 / 63
2.6
Work area
Height [mm]
2100
Depth [mm]
1900
Width [mm]
2500
2.7
Speeds
Gearbox stage slow
[min-1]
65 - 650
Gearbox stage average
[min-1]
150 - 1500
 2 0 0 8
Gearbox stage fast [min-1]
330 - 3300
GB
16 / 09 / 2008 Technical data Drilling-Milling machine BF 30 Vario ; Version 1.0.3 Page 13

OPTIMUM
Technical data
M A S C H I N E N - G E R M A N Y
2.8
Environmental
BF 30 Vario
conditions
Temperature
5-35 °C
humidity
25 - 80%
2.9
Operating material
BF 30 Vario
Gearbox
Oil quantity 1,2 litres
Mobilgear 627, ISO VG 100
viscosity 100 cSt at 40° or a corresponding oil
blank steel parts
Mobilgrease OGL 007 or,
Mobilux EP 004, acid-free oil, e.g. weapon oil,
motor oil
2.10 Emissions
The noise level (emission) of the drilling-milling machine is below 78 dB(A). If the drilling-milling
machine is installed in an area where various machines are in operation, the acoustic influence
(emission) on the user of the drilling-milling machine may exceed 85 dB(A) at the workplace.
We recommend the use of soundproofing ear protection. Remember that the duration of the
noise pollution, the type and characteristics of the working area and operation of other
machines influence the noise level in the workplace.
INFORMATION
We recommend to take sound protection and ear protection measures. Please make sure that
the period of the noise stress, the type and nature of the working area as well as other
machines which are operated simultaneously will influence the noise level at the working place.
Page 14 Technical data Drilling-Milling machine BF 30 Vario ; Version 1.0.3 16 / 09 / 2008
2008 GB

Technical data OPTIMUM
M A S C H I N E N - G E R M A N Y
2.11 Installation plan BF 30 Vario
GB 2008
16 / 09 / 2008 Technical data Drilling-Milling machine BF 30 Vario ; Version 1.0.3 Page 15

OPTIMUM
M A S C H I N E N - G E R M A N Y
2.12 Installation plan of optional substructure
Page 16 Technical data Drilling-Milling machine BF 30 Vario ; Version 1.0.3
Technical data
16 / 09 / 2008
2008 GB

GB 2008
Unpacking and connecting
OPTIMUM
M A S C H I N E N - G E R M A N Y
3Unpacking and connecting
INFORMATION
The drilling-milling machine comes pre-assembled.
3.1 Extent of supply
When the drilling-milling machine is delivered, immediately check that the machine has not
been damaged during shipping and that all components are included. Also check that no faste-
ning screws have come loose.
Compare the parts supplied with the information on the packaging list.
3.2 Transport
WARNING!
Machine parts falling off forklift trucks or other transport vehicles could cause very
serious or even fatal injuries. Follow the instructions and information on the
transport case:
•centres of gravity
•suspension points
•weights
•means of transport to be used
•prescribed shipping position
WARNING!
Use of unstable lifting equipment and load-suspension devices that break under load
can cause very serious injuries or even death.
Check that the lifting and load suspension gear has sufficient load capacity and that it
is in perfect condition.
Observe the rules for preventing
accidents. Hold the loads properly.
Never walk under suspended loads!
3.3 Storage
ATTENTION!
Improper storage may cause important parts to be damaged or destroyed.
Store packed or unpacked parts only under the intended environmental
conditions. „Environmental conditions“ on page 14
Consult the company Optimum Maschinen Germany GmbH if the drilling-milling machine or
accessories have to be stored for a period of over three months or under different environmental
conditions to those given there.
Stand 16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 17

OPTIMUM
Unpacking and connecting
M A S C H I N E N - G E R M A N Y
3.4 Installation and assembly
3.4.1 Requirements of the installation site
The working area for operation, maintenance and repair work must not be
hindered. The mains plug of the drilling-milling machine must be freely accessible.
3.4.2 Load suspension point
WARNING!
Danger of crushing and overturning. Proceed with extreme caution when lifting, installing and
assembling the machine.
Secure the load-suspension device around the drill-mill head. Use a lifting sling for this
pur-pose.
Clamp all the clamping levers at the drilling-milling machine before lifting the drilling-
milling machine.
Make sure that no add-on pieces or varnished parts are damaged due to the load-
suspen-sion.
3.4.3 Installation
Check the horizontal orientation of the base of the drilling-milling machine with a spirit level.
Check that the foundation has sufficient floor-load capacity and rigidityt. The total
weight amounts to 265 kg.
ATTENTION!
Insufficient rigidity of the foundation leads to the superposition of vibrations between the
drilling-milling machine and the foundation (natural frequency of components). Insuf-ficient
rigidity of the entire milling machine assembly also rapidly causes the machine to reach
critical speeds, with unpleasant vibrations, leading to bad milling results.
Position the drilling-milling machine on the intended foundation.
Attach the drilling-milling machine using the provided recesses in the machine base.
WARNING!
The quality of the substructure and the kind of fixture of the machine stand to the sub-
structure has to assimilate the loads of the machine. The substructure needs to be
even. Please check the horizontal alignment of the substructure of the machine with a
spirit level. Fix the machine to the substructure at the provided recesses at the stand.
We recommend the use of shear connector cartridges or heavy-duty bolts.
Page 18 Drilling-Milling machine BF 30 Vario Version 1.0.3
Stand 16 / 09 / 2008
2008 GB

GB 2008
Unpacking and connecting
OPTIMUM
M A S C H I N E N - G E R M A N Y
3.4.4 Installation drawing
Illustr. 3-1: Machine base
3.5 First use
3.5.1 Cleaning and lubricating
Remove the anti-corrosive agent applied to the drilling-milling machine for transport and
storage purposes. We recommend the use of stove distillate.
Do not use any solvents, thinners or other cleaning agents which could corrode the varnish
on the drilling-milling machine. Follow the specifications and indications of the manufacturer
of the cleaning agent.
Lubricate all bright machine parts with non-corrosive lubricating oil.
Grease the drilling-milling machine using the lubrication
chart. „Inspection and maintenance“ on page 31
Check the smooth running of all spindles. The spindle nuts can be readjusted.
Disassemble the taper gibs of the cross table and clean the gibs from the anti-corrosive
agent. „Taper gib“ on page 35
3.5.2 Fill in gear lubricant oil
The drilling-milling machine is delivered without oil filling. Fill in gear lubricant
oil. „Oil change“ on page 32
Stand 16 / 09 / 2008 Version 1.0.3 BF 30 Vario Drilling-Milling machine Page 19

OPTIMUM
Unpacking and connecting
M A S C H I N E N - G E R M A N Y
3.6
Optional accessory
Designation:
Item No
Machine substructure
3338430404
Dimensions (L x B x H): 650 x 550 x 750
Vice FMS 125
3355127
Hydraulic vice HMS 125
335 2044
Kit of parallel spacers 18 pcs
3354000
Universal coolant equipment 230 V
3352002
Universal coolant equipment 400 V
3352001
Levelling- damping element SE1
3381012
Levelling- damping element SE2
3381016
Milling cutter kit HSS 20 pcs
3386200
Collet chucks kit direct clamping MT 3
3352014
Draw-in collet chucks kit MT 3
3352050
Cutter head for copy and surface milling MT 3
3350213
Height-adjustable tailstock RST 1
3356155
Horicontal-vertical circular dividing table
335 6150
RT 150
Page 20 Drilling-Milling machine BF 30 Vario Version 1.0.3
Stand 16 / 09 / 2008
2008 GB
