Optimum B50 GSM User manual

 2014
US
Page 122 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Geared drill
B50 GSM
Operating manual
Version 1.0.3
Keep for future reference!
29" Item No. 3034504

 2014 US
Seite 2 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
OPTIMUM
MASCHINEN - GERMANY
Table of contents
Preface
C
h
a
n
g
e
s
The illustrations of the geared drill might in some details deviate from the illustrations of this operating manual but
this will have no influence on the operation of the geared drill.
Any changes in the construction, equipment and accessories are reserved for reasons of enhancement. Therefore,
no claims may be derived from the instructions and descriptions.
1Safety
1.1 Safety warnings (warning notes) .......................................................................................................6
1.1.1 Classification of hazards ....................................................................................................6
1.1.2 Other pictograms ...............................................................................................................7
1.2 Proper use ........................................................................................................................................8
1.3 Possible dangers caused by the geared drill ....................................................................................8
1.4 Qualification of personnel .................................................................................................................9
1.4.1 Target group ......................................................................................................................9
1.4.2 Authorised personnel .........................................................................................................9
1.5 User positions .................................................................................................................................10
1.6 Safety measures during operation ..................................................................................................10
1.7 Safety devices .................................................................................................................................10
1.7.1 EMERGENCY- STOP button ...........................................................................................11
1.7.2 Main switch ......................................................................................................................11
1.7.3 Drilling table .....................................................................................................................12
1.7.4 Drill chuck guard ..............................................................................................................12
1.7.5 Prohibitive, warning and information labels .....................................................................12
1.8 Safety check ...................................................................................................................................12
1.9 Personnel protective equipment .....................................................................................................13
1.10 Safety during operation ...................................................................................................................14
1.11 Safety during maintenance .............................................................................................................14
1.11.1 Disconnecting the geared drill and making it safe ...........................................................14
1.11.2 Using lifting equipment ....................................................................................................14
1.11.3 Mechanical maintenance work ........................................................................................15
1.12 Electrical system .............................................................................................................................15
2 Technical data
2.1 Power connection ...........................................................................................................................16
2.2 Drill capacity ....................................................................................................................................16
2.3 Spindle ............................................................................................................................................16
2.4 Drilling table ....................................................................................................................................16
2.5 Work area .......................................................................................................................................16
2.6 Speeds ............................................................................................................................................16
2.7 Ambient conditions ..........................................................................................................................17
2.8 Operating material ..........................................................................................................................17
2.9 Coolant system ...............................................................................................................................17
2.10 Emissions ........................................................................................................................................17
2.11 Dimensions .....................................................................................................................................18
3 Assembly
3.1 Delivery volume ..............................................................................................................................19
3.2 Transport .........................................................................................................................................19
3.3 Storage ...........................................................................................................................................20

 2014
US
Page 322 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
3.4 Installation and assembly ............................................................................................................... 20
3.4.1 Site requirements ............................................................................................................ 20
3.4.2 Assembly ......................................................................................................................... 21
3.4.3 Load suspension point .................................................................................................... 21
3.4.4 Installation ....................................................................................................................... 21
3.4.5 Securing .......................................................................................................................... 22
3.5 First use .......................................................................................................................................... 23
3.5.1 Power supply ................................................................................................................... 23
3.5.2 Checks ............................................................................................................................ 24
4 Handling
4.1 Safety .............................................................................................................................................. 25
4.2 Control and indicating elements ..................................................................................................... 25
4.2.1 Control panel ................................................................................................................... 26
4.3 Drill depth stop ................................................................................................................................ 28
4.4 Spindle feed .................................................................................................................................... 28
4.4.1 Manual spindle feed ........................................................................................................ 29
4.4.2 Automatic spindle feed ....................................................................................................29
4.4.3 Handwheel for the fine adjustment of the spindle ............................................................ 29
4.5 Removing, mounting of drill chucks and drill bits ............................................................................ 30
4.5.1 Removing the drill chuck ................................................................................................. 30
4.5.2 Mounting the drill chuck ................................................................................................... 31
4.6 Liquid cooling system ..................................................................................................................... 31
4.7 Working with the machine ............................................................................................................... 32
4.7.1 Preparation ...................................................................................................................... 32
4.7.2 Bit .................................................................................................................................... 33
4.8 Bit speed table ................................................................................................................................ 33
4.9 Standard values for speeds with HSC - Eco - twist drill cooling ..................................................... 33
5 Determining the cutting speed and the speed
5.1 Table cutting speeds / infeed .......................................................................................................... 35
5.2 Speed table ..................................................................................................................................... 35
5.3 Examples to calculatory determine the required speed for your drilling machine ........................... 37
6 Maintenance
6.1 Safety .............................................................................................................................................. 39
6.1.1 Preparation ...................................................................................................................... 39
6.1.2 Restarting ........................................................................................................................ 39
6.2 Inspection and maintenance ........................................................................................................... 40
6.3 Repair ............................................................................................................................................. 45
6.4 Lubricant table ................................................................................................................................ 45
7 Spare parts - B50GSM
7.1 Spare parts drawing drilling head ................................................................................................... 46
7.2 Spare parts drawing drilling head 1-7 ............................................................................................. 47
7.3 Spare parts drawing drilling head 2-7 ............................................................................................. 48
7.4 Spare parts drawing drilling head 3-7 ............................................................................................. 49
7.5 Spare parts drawing drilling head 4-7 ............................................................................................. 50
7.6 Spare parts drawing drilling head 5-7 ............................................................................................. 51
7.7 Spare parts drawing drilling head 6-7 ............................................................................................. 52
7.8 Spare parts drawing drilling head 7-7 ............................................................................................. 53
7.9 Spare parts drawing column and drilling table 1-2 .......................................................................... 54
7.10 Spare parts drawing column and drilling table 2-2 (optional) .......................................................... 55

 2014 US
Seite 4 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
OPTIMUM
MASCHINEN - GERMANY
7.11 Drill Chuck Guard ............................................................................................................................56
7.12 Wiring diagram ................................................................................................................................57
7.13 Parts list ..........................................................................................................................................58
7.14 Electrical terminal diagram .............................................................................................................63
7.14.1 Spare parts electrical components ..................................................................................64
8 Troubleshooting
9 Appendix
9.1 Copyright .........................................................................................................................................67
9.2 Terminology/Glossary .....................................................................................................................67
9.3 LIMITED WARRANTY ...................................................................................................................68
10Index

 2014
US
Page 522 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Safety
1 Safety
Glossary of symbols
This part of the operating manual
does explain the meaning and how to use the warning references contained in this opera-
ting manual,
does explain how to use the geared drill machine,
highlights the dangers that might arise for you and others if these instructions are not
followed thoroughly,
informs you on how to prevent dangers.
In addition to this operating manual, please note
applicable laws and regulations,
legal regulations for preventing an accident,
the prohibition, warning and mandatory signs as well as the warning notes on the geared
drill machine.
Always keep the operating manual close to the geared drill for further reference.
INFORMATION
If you are not able to solve a problem using this manual, please do not hesitate to contact us for
further professional advice:
If you are unable to solve a problem using this manual, please contact us for advice:
Exclusive USA Agent
LDS Industries, LLC
930 W. National Ave.
Addison, IL 60101
Tel.: [phone]
gives additional advice
calls on you to act
 enumerations

 2014 US
Page 6 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Safety
OPTIMUM
MASCHINEN - GERMANY
1.1 Safety warnings (warning notes)
1.1.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (pictograms) and warning for the specific danger and its (possible) con-
sequences.
Pictogram Alarm
Expression Definition/Consequences
DANGER! Imminent danger that will cause serious injury or death to
personnel.
WARNING! Hazard: a danger that will cause serious injuries or death
personnel.
CAUTION! Danger or unsafe procedure that might cause injury to
personnel or damage to property.
ATTENTION!
Situation that could cause damage to the machine and
product and other types of damage.
No risk of injury to personnel.
INFORMATION
Application tips and other important or useful information
and warnings.
No dangerous or harmful consequences for personnel or
objects.
In the case of specific dangers, we replace the pictogram
or
General
danger with a warning of injuries to hands, hazardous electrical
voltage,
rotating parts.

 2014
US
Page 722 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Safety
1.1.2 Other pictograms
Warning of
automatic start-up! Disconnect main power!
Activation for-
bidden! Use ear protection!
Use safety shoes! Use protective gloves!
Wear a safety suit! Protect the environment!
Use safety glasses! Contact address

 2014 US
Page 8 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Safety
OPTIMUM
MASCHINEN - GERMANY
1.2 Proper use
WARNING!
Improper use of the machine
• will endanger personnel,
• will endanger the machine and other items used by the operator,
may affect proper operation of the machine.
The geared drill is designed and manufactured for boring cold metals or other non-flammable
materials that do constitute a health hazard. It uses a rotating cutting tool with several cutting
edges.
The geared drill must only be used with keyless drill chuck.
Chucks that require a key to secure the bit must not be used on this geared drill.
If the geared drill is used in any way other than described above, or modified without authoriza-
tion, then the geared drill- is being used improperly.
We do not take liability for damage caused by improper use.
We would like to stress that any modifications to the construction, or technical or technological
modifications that have not been authorized will also render the warranty null and void.
It is also part of proper use that
the limits of the geared drill are complied with,
the instruction manual is observed,
review and maintenance instructions are observed.
 „Technical data“ on page 16
WARNING!
Very serious injury.
It is forbidden to make any modifications or alterations to the operating values of the gea-
red drill! These could endanger personnel and cause damage to the geared drill.
1.3 Possible dangers caused by the geared drill
The geared drill is carried out with the latest technological advances.
Nonetheless, there remains a residual risk, since the geared drill operates with
high revolutions,
rotating parts,
electrical voltage and currents.
We have used construction resources and safety techniques to minimise the health risk to per-
sonnel resulting from these hazards.
If the geared drill is used by personnel who are not duly qualified, there may be a risk resulting
from incorrect operation or unsuitable maintenance.
INFORMATION
All personnel involved in assembly, commissioning, operation and maintenance must
be duly qualified,
follow this instruction manual.
In the event of improper use
there may be a risk to personnel,
there may be a risk to machine and other items,

 2014
US
Page 922 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Safety
correct functioning of the geared drill may be affected.
Disconnect the geared drill from the electrical whenever cleaning or maintenance work is being
carried out.
WARNING!
The geared drill may only be used with the safety devices activated.
Disconnect the geared drill from the electrical power whenever you detect a failure in the
safety devices or when they are not fitted!
All additional installations carried out by the operator must incorporate the prescribed
safety devices.
As the machine operator, this will be your responsibility!
 „Safety devices“ on page 10
1.4 Qualification of personnel
1.4.1 Target group
This manual is addressed to
operators,
users,
maintenance staff.
The warning notes therefore refer to both operation and maintenance of the geared drill.
Determine clearly and irrevocably who will be responsible for the different activities on the
machine (use, maintenance and repair).
Vague or unclear assignment of responsibilities constitutes a safety hazard!
Always switch off the main power of the geared drill. This will prevent it being used by unautho-
rised personnel. Always disconnect the geared drill from the main electrical power.
1.4.2 Authorised personnel
WARNING!
Incorrect use and maintenance of the geared drill causes danger for personnel, objects
and the environment.
Only authorised personnel may operate the geared drill!
Personnel authorised to use and perform maintenance are the trained and instructed technical
staff working for the operator and manufacturer.
The operator must
Obligations
of the opera-
tor
train staff,
instruct staff regularly (at least once a year) on
- all safety standards that apply to the machine,
- operation,
- accredited technical guidelines,
check staff‘s understanding,
document training/instruction,
require staff to confirm participation in training/instruction by a signature,
check whether the staff are aware of safety and of dangers in the workplace and whether
they observe the instruction manual.

 2014 US
Page 10 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Safety
OPTIMUM
MASCHINEN - GERMANY
The user must
Obligations
of the user have received training in operation of the geared drill,
know the function and principle of operation,
before the machine is first used
- have read and understood the instruction manual,
- be familiar with all safety devices and regulations.
Additional
qualification
requi-
rements
For work on the following machine components there are additional requirements:
Electrical components or equipment: Only an electrician or person working under the
instructions and supervision of an electrician.
Before carrying out work on electric components or operating units, the following measures
need to be performed in the order given.
Disconnect main power
Ensure that the machine cannot be turned on again
Check that there is no voltage
1.5 User positions
The user must stand in front of the geared drill.
INFORMATION
The main power of the geared drill must be freely accessible.
1.6 Safety measures during operation
CAUTION!
Risk due to inhaling health hazardous dusts and mist.
Depending on the material being processed and any additional dusts and mist in the
work area, conditions might impair your health.
Make sure that the generated health hazardous dusts and mist are safely removed at the
point of origin and are collected and/ or filtered from the working area. Use an appropri-
ate dust collection/ filter unit.
CAUTION!
Risk of fire and explosion by using flammable materials or cooling lubricants.
Take additional preventive measures in order to safely avoid health hazards before pro-
cessing flammable materials (e.g. aluminum, magnesium) or before using flammable
additives (e.g. solvents).
1.7 Safety devices
Use the geared drill only with properly functioning safety devices.
Stop the geared drill immediately if there is a failure in the safety device or if it is not functioning
for any reason.
It is your responsibility!
If a safety device has been activated or has failed, the geared drill must only be used when
the cause of the failure has been removed,
it has been verified that there is no resulting danger for personnel or objects.

 2014
US
Page 1122 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Safety
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other personnel working with the geared drill. The possible consequences
are
• damage or injuries as a result of components or parts of components flying off at high
speed,
• contact with rotating parts,
• fatal electrocution.
The geared drill includes the following safety devices:
EMERGENCY stop button.
Main lockable switch.
A drilling table with T-slots to fasten the work piece or a vise.
Adjustable drill chuck guard with position switch.
WARNING!
The separating protective equipment which is made available and delivered together with
the machine is designed to reduce the risk of workpieces or fractions of them which
being expelled, but not to remove them completely.
1.7.1 EMERGENCY- STOP button
CAUTION!
After actuating the EMERGENCY-STOP-
button the drilling spindle will turn
some more seconds depending on the
previously set speed.
Fig. 1-1: EMERGENCY-STOP button
1.7.2 Main switch
In the "0" position, the lockable switch can
be protected with a padlock against unau-
thorised or accidental activation.
When the main switch is off, the power
supply to the motor is cut off.
Fig. 1-2: Main switch
Points marked with the pictogram shown here are not included. These points may be live even
when the main switch is off.
EMERGENCY-STOP
button
Main switch

 2014 US
Page 12 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Safety
OPTIMUM
MASCHINEN - GERMANY
1.7.3 Drilling table
There are T-Slots in the drilling table for the
T-slot nuts.
WARNING!
Risk of injury from parts flying off at
high speed. Secure the piece firmly on
the drilling table.
Fig. 1-3: Drilling table
1.7.4 Drill chuck guard
Adjust the drill chuck guard to the requi-
red height.
Move the drill chuck guard into place
before you start drilling.
The geared drill can only be activated as soon
as the drill chuck guard been closed.
Fig. 1-4: Drill chuck guard
1.7.5 Prohibitive, warning and information labels
INFORMATION
All warning labels must be legible. Check them regularly.
1.8 Safety check
Check the geared drill at least once per shift. Inform the person responsible immediately of any
damage, defect or change in operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped),
once a week (with the machine in operation),
after every maintenance and repair operation.
Check that prohibitive, warning and information labels and the markings on the geared drill
can be identified (if not, clean them),
are complete.
INFORMATION
Use the following table for checking.
T-Slot for T-slot nuts
( 18 mm )
Drill chuck guard

 2014
US
Page 1322 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Safety
1.9 Personnel protective equipment
For certain work personnel protective equipment is required. This includes:
a safety helmet,
safety glasses or face guard,
protective gloves,
safety shoes with steel toe cap,
ear protection.
Before starting work check that the proper equipment is available in the workplace.
CAUTION!
Dirty or contaminated personnel protective equipment can cause disease.
Clean your personnel protective equipment
• after every use,
• regularly, at least once a week.
Personnel protective equipment for special work
Protect your face and eyes: During all work, and specifically work during which your face and
eyes are exposed to hazard, a safety helmet with a face guard should be worn.
Use protective gloves when lifting or handling pieces with sharp edges.
Wear safety shoes when you position, dismantle or transport heavy components.
General check
Equipment Check OK
Protective covers Mounted, firmly bolted and not damaged
Drill chuck guard
Labels, markings Installed and legible
Date: Checked by (signature):
Test run
Equipment Check OK
EMERGENCY stop
button Once the emergency stop button is activated, the geared drill should be switched off.
Drill chuck guard The geared drill can only be switched on as soon as the
drill chuck guard has been closed.
Date: Checked by (signature):

 2014 US
Page 14 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Safety
OPTIMUM
MASCHINEN - GERMANY
1.10 Safety during operation
In the description of work with and on the geared drill we highlight the dangers specific to that
work.
WARNING!
Before activating the geared drill, double check that this will not
• endanger other people
• cause damage to equipment.
Avoid unsafe working practices:
Make sure your work does not endanger anyone.
The instructions in this manual must be observed during assembly, handling, maintenance
and repair.
Do not work on the geared drill if your concentration is reduced, for example, because you
are taking medication.
Observe the rules for preventing accidents issued by your association for the prevention of
occupational accidents and safety in the workplace or other inspection authorities.
Inform the inspector of any danger or failure.
Stay at the geared drill until all rotating parts have come to a halt.
Use prescribed protective equipment. Make sure to wear a well-fitting work suit and,
where necessary, a hairnet.
Do not use protective gloves during drilling work.
1.11 Safety during maintenance
Inform operators in good time of any repair and maintenance work.
Report all safety relevant changes or performances details of the geared drill. Document all
changes, have the operation manual changed accordingly and train the machine operators.
1.11.1 Disconnecting the geared drill and making it safe
Turn the machine off using the main switch before beginning any maintenance or repair work.
Use a padlock to prevent the switch being turned on without authorisation, and keep the key in a
safe place.
All machine components and hazardous voltages disconnected. Only the points marked with the
pictogram shown here are not included.
Place a warning sign on the machine.
1.11.2 Using lifting equipment
WARNING!
Use of unstable lifting and load suspension gear that breaks under load can cause very
serious injuries or even death.
Check that the lifting and load suspension gear
• is of sufficient load capacity,
• is in perfect condition.
Observe the rules for preventing accidents issued by your association for the prevention
of occupational accidents and safety in the workplace or other inspection authorities.
Fasten the loads properly. Never walk under suspended loads!

 2014
US
Page 1522 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Safety
1.11.3 Mechanical maintenance work
Remove all protection and safety devices before starting any maintenance work and re-install
them once the work has been completed. This includes:
covers,
safety indications and warning signs,
earth (ground) connection.
If you remove protection or safety devices, refit them immediately after completing the work.
Check if they are working properly!
1.12 Electrical system
Have the machine and/or the electrical equipment checked regularly, and at least every six mon-
ths.
Eliminate immediately all defects such as loose connections, defective wires, etc.
A second person must be present during work on live components, to disconnect the power in
the event of an emergency.
Disconnect the geared drill immediately if there are any problems in the power supply!
 „Maintenance“ on page 38

 2014 US
Page 16 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Technical data
OPTIMUM
MASCHINEN - GERMANY
2 Technical data
The following information gives the dimensions and weight and is the manufacturer’s authorised
machine data.
2.1 Power connection
Total connection rate 4 HP, 230V, 3 Ph, 60Hz
Cooling pump 40W, 230V, 60Hz
Permitted voltage tolerance 220V-240V
2.2 Drill capacity
Drill capacity in steel ø 50 mm (1.968“)
Tapping in steel M 42 (1-5/8“)
Drill capacity in cast iron ø 60 mm (2.362“)
Tapping in cast iron M 50 (1.968“)
Working radius 375 mm (14.763“)
Spindle travel 230 mm (9.055“)
2.3 Spindle
Spindle taper MK4 (4 MT)
Spindle feed [in / rev] 6 steps, 0,05 -0, 3mm/ 0.002-0.012“
 „Automatic spindle feed“ on page 29
2.4 Drilling table
Table measurements
Length x Width 600 x 600 mm (23.62 x 23.62“)
Size of T-slots 18 mm (0.709“)
Maximum distance
spindle - table 800 mm (31.50“)
Work area of base
Length x Width 600 x 860 (23.62 x 33.86“)
Maximum distance
spindle - base 1300 mm (51.19“)
Maximum load table
column center - spindle 200 - 250 Kg. (440-550 LBS)
Maximum load table
column center - base 250 - 300 Kg. (550-660 LBS)
2.5 Work area
Height 3000 mm (118.11“)
Depth 1800 mm (70.87“)
Width 1200 mm (47.24“)
2.6 Speeds
Spindle rotating speeds [rpm] 54 - 2090
No. of speeds 18

 2014
US
Page 1722 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Technical data
2.10 Emissions
The noise level (emission) of the mill drill machine is below 76 dB(A). If the mill drill machine is
installed in an area where various machines are in operation, the acoustic influence (immission)
on the operator of the mill drill machine may exceed 85 dB(A).
INFORMATION
This numeric value had been measured on a new machine under conventional operating condi-
tions. Depending on the age or wear of the machine, the noise behavior of the machine might
change.
Furthermore, the extent of the noise emission is also depending on manufacturing
influence factors, such as speed, material and clamping conditions.
INFORMATION
The mentioned numerical value is an emission level and not necessarily a safe
working level.
Unless the degree of noise emission and the degree of noise disturbance are depending on one
another it is not possible to use it in order to reliably determine if it is necessary to take further
preventive measures or not.
The following factors influence the actual degree of the noise disturbance of the
operator:
•Characteristics of the working chamber, e.g. size or damping behavior,
• Other noise sources, e.g. the number of machines,
• Other processes proceeding nearby and the period during which the operator is exposed to
the noise.
Consult OSHA, state and local regulations in order to determine compliance, dangers and risks
to the operator.
CAUTION!
The machine operator has to wear an appropriate ear protection depending on the overall
stress caused by noise and on the basic limit values.
We generally recommend using a sound and ear protection.
2.7 Ambient conditions
Temperature 5 - 35°C (40 - 95 °F.)
Rel. humidity 25 - 80 %
2.8 Operating material
Gear oil for drilling head gear 2.7 qts  „Lubricant table“ on page 45
Rack and column of the drill commercial heavy grease
 „Lubricant table“ on page 45
2.9 Coolant system
Height of pressure 9.75 feet
Tank capacity 5.28 quarts
Rate of flow 31 gallons/ hour

 2014 US
Page 18 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Technical data
OPTIMUM
MASCHINEN - GERMANY
2.11 Dimensions
Fig.2-1: B50GSM

 2014
US
Page 1922 / 07 / 2014 Version 1.0.3 B50 GSM Geared drill
OPTIMUM
MASCHINEN - GERMANY
Assembly
3 Assembly
INFORMATION
The geared drill is delivered pre-assembled.
3.1 Delivery volume
When the machine is delivered, check immediately that the geared drill has not been damaged
during shipping and that all components are included. Also check for loose set screws. Check
the components with the packing list.
3.2 Transport
WARNING!
Machine parts which fall off forklift trucks or other transport vehicles could cause very
serious or even fatal injuries. Follow the instructions and information on the box.
WARNING!
Use of unstable lifting and load suspension gear that breaks under load can cause very
serious injuries or even death.
Check that the lifting and load suspension gear has sufficient load capacity and is in per-
fect condition. Observe the rules for preventing accidents issued by your association for
the prevention of occupational accidents and safety in the workplace or other inspection
authorities.
Hold the loads properly. Never walk under suspended loads!
Center of gravity
Attachment positions (marking the positions for
the attachment position gear)
Prescribed transport position (marking the top
side)
Means of transportation to be used
Weights

 2014 US
Page 20 Geared drill B50 GSM Version 1.0.3 22 / 07 / 2014
Assembly
OPTIMUM
MASCHINEN - GERMANY
3.3 Storage
ATTENTION!
Improper storage may cause important parts to be damaged or destroyed.
Store packed or unpacked parts only under the following ambient conditions.
Please follow the instructions and indications on the transportation box:
Consult LDS Industries if the geared drill and accessories have to be stored for a period of over
three months or under different external conditions than those given here  „Information“ on
page 5.
3.4 Installation and assembly
3.4.1 Site requirements
Organize the working space around the geared drill according to the local safety regulations.
INFORMATION
In order to provide for good functionality and high machining accuracy as well as long durability
of the machine the site should fulfill certain criteria.
Observe the following items:
The device must only be installed and operated in dry ventilated places.
Avoid places nearby machines generating chips or dust.
The site has to be vibration-free, i.e. at a distance from presses, planing machines, etc.
The substructure has to be appropriate for geared drill. Also make sure that the load bear-
ing capacity and the evenness of the floor are appropriate.
The substructure has to be prepared in a way that possibly used coolant cannot penetrate
into the ground.
Fragile goods (goods require careful handling)
Protect against humidity and humid environments
 „Ambient conditions“ on page 17.
Prescribed position of the packaging box (marking
the top side – arrows pointing upward)
Maximum stacking height
Example: non-stackable – do not pile any further
packaging boxes on top of the first packaging box
