Optimum OPTIdrill DQ 25 User manual

Operating Manual
Version 1.0.1
Drilling machine
Part no. 3191049
Part no. 3191047
DQ32
DQ25

Version 1.0.1 - 2021-01-282 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GBIVZ.fm
Table of contents
1 Safety
1.1 Rating plates................................................................................................................................................5
1.2 Safety instructions (warning notes)..............................................................................................................6
1.2.1 Classification of hazards................................................................................................................6
1.2.2 Other pictograms............................................................................................................................6
1.3 Intended use................................................................................................................................................7
1.4 Reasonably foreseeable misuses................................................................................................................7
1.4.1 Avoiding misuse.............................................................................................................................8
1.5 Possible dangers posed by the drilling machine..........................................................................................8
1.6 Qualification.................................................................................................................................................9
1.6.1 Target group private users.............................................................................................................9
1.6.2 Obligations of the User...................................................................................................................9
1.6.3 Additional requirements regarding the qualification .......................................................................9
1.7 User positions..............................................................................................................................................9
1.8 Safety measures during operation.............................................................................................................10
1.9 Safety devices ...........................................................................................................................................10
1.10 Personal protective equipment..................................................................................................................10
1.11 Safety check..............................................................................................................................................11
1.12 Emergency stop switch..............................................................................................................................12
1.12.1 Drilling table .................................................................................................................................12
1.13 Separating protective devices....................................................................................................................12
1.13.1 Drill chuck guard ..........................................................................................................................12
1.13.2 Protective cover of the V-belts.....................................................................................................12
1.13.3 Prohibition, warning and mandatory signs...................................................................................12
1.14 Personal protective equipment..................................................................................................................12
1.15 Safety during operation..............................................................................................................................13
1.16 Safety during maintenance........................................................................................................................13
1.16.1 Disconnecting and securing the drilling machine.........................................................................13
1.16.2 Mechanical maintenance .............................................................................................................13
1.17 Electronics.................................................................................................................................................13
1.18 Inspection deadlines..................................................................................................................................14
2 Technical specification
2.1 Emissions ..................................................................................................................................................16
2.2 Dimensions DQ25......................................................................................................................................17
2.3 Dimensions DQ32......................................................................................................................................18
3 Delivery, internal transport and commissioning
3.1 Notes on transport, installation and commissioning ..................................................................................19
3.1.1 General risks during internal transport.........................................................................................19
3.2 Delivery......................................................................................................................................................19
3.3 Unpacking..................................................................................................................................................19
3.3.1 Standard accessories...................................................................................................................19
3.4 Assembly...................................................................................................................................................20
3.5 Installation requirements............................................................................................................................22
3.5.1 Foundation and ground................................................................................................................23
3.5.2 Fixing............................................................................................................................................23
3.6 First commissioning...................................................................................................................................24
3.7 Electrical connection..................................................................................................................................24
3.7.1 Warming up the machine.............................................................................................................24
4Operation
4.1 Control and indicating elements ................................................................................................................25
4.2 Control panel .............................................................................................................................................26
4.3 Switching the machine on..........................................................................................................................26
4.4 Switching off the machine..........................................................................................................................26
4.5 Drill depth...................................................................................................................................................26
4.5.1 Drill depth stop.............................................................................................................................26
4.6 Table Inclination.........................................................................................................................................26
4.7 Speed variation..........................................................................................................................................27
4.7.1 DQ25 spindle speeds...................................................................................................................28

Version 1.0.1 - 2021-01-28 3Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GBIVZ.fm
4.7.2 DQ32 spindle speeds .................................................................................................................. 28
4.8 Before starting work .................................................................................................................................. 29
4.9 During work............................................................................................................................................... 29
4.10 Spindle sleeve feed................................................................................................................................... 29
4.11 Disassembly, assembly of drill chucks and drill bits.................................................................................. 29
4.11.1 Fitting the drill chuck.................................................................................................................... 30
4.12 Cooling...................................................................................................................................................... 30
5 Determining the cutting speed and the speed
5.1 Table cutting speeds / infeed .................................................................................................................... 31
5.2 Speed table............................................................................................................................................... 31
5.2.1 Examples to calculatory determine the required speed for your drilling machine........................ 33
6 Maintenance
6.1 Safety........................................................................................................................................................ 34
6.1.1 Preparation.................................................................................................................................. 34
6.1.2 Restarting .................................................................................................................................... 34
6.2 Inspection and maintenance ..................................................................................................................... 35
6.3 Repair........................................................................................................................................................ 39
6.3.1 Customer service technician........................................................................................................ 39
7 Ersatzteile - Spare parts
7.1 Ersatzteilbestellung - Ordering spare parts............................................................................................... 40
7.2 Hotline Ersatzteile - Spare parts Hotline ................................................................................................... 40
7.3 Service Hotline.......................................................................................................................................... 40
7.4 Ersatzteilzeichnungen - Spare part drawings............................................................................................ 41
7.5 DQ25 / DQ32 Schaltplan - Wiring diagram DQ25 / DQ32......................................................................... 48
8 Malfunctions
9 Appendix
9.1 Copyright................................................................................................................................................... 50
9.2 Terminology/Glossary ............................................................................................................................... 50
9.3 Liability claims/warranty ............................................................................................................................ 50
9.4 Storage...................................................................................................................................................... 51
9.5 Advice for disposal / Options of reuse:...................................................................................................... 51
9.5.1 Decommissioning ........................................................................................................................ 52
9.5.2 Disposal of new device packaging............................................................................................... 52
9.5.3 Disposal of the old device............................................................................................................ 52
9.5.4 Disposal of electrical and electronic components........................................................................ 53
9.6 Disposal via municipal collection facilities................................................................................................. 53
9.7 Change information manual ...................................................................................................................... 53
9.8 Product follow-up....................................................................................................................................... 53

Version 1.0.1 - 2021-01-284 Translation of original instruction
DQ25 | DQ32
EN
_GB_preface.fm
Preface
Dear customer,
Thank you very much for purchasing a product made by OPTIMUM.
OPTIMUM metal working machines offer a maximum of quality, technically optimum solutions and convince
by an outstanding price performance ratio. Continuous enhancements and product innovations guarantee
state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get familiar with
the machine. Please also make sure that all persons operating the machine have read and understood the
operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation, operation and main-
tenance of the machine. The continuous observance of all notes included in this manual guarantee the safety
of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information for its eco-
nomic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which the operator
must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the current state of
construction of your machine. Being the manufacturer we are continuously seeking for improvements and
renewal of the products. Therefore, changes might be performed without prior notice. The illustrations of the
machine may be different from the illustrations in these instructions with regard to a few details. However,
this does not have any influence on the operability of the machine.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors are reserved
!
Your suggestion with regard to these operating instructions are an important contribution to optimising our
work which we offer to our customers. For any questions or suggestions for improvement, please do not hesi-
tate to contact our service department.
If you have any further questions after reading these operating instructions and you are not able to
solve your problem with a help of these operating instructions, please contact your specialised
dealer or directly the company OPTIMUM.
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D-96103 Hallstadt
Fax (+49)0951 / 96555 - 888
Email: in[email protected]
Internet: www.optimum-machines.com

Safety
Version 1.0.1 - 2021-01-28 5Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_1.fm
1 Safety
Glossary of symbols
This part of the operating instructions
explains the meaning and use of the warning notes included in these operating instructions,
defines the intended use of the drilling machine,
points out the dangers that might arise for you or others if these instructions are not
observed,
informs you about how to avoid dangers.
In addition to these operating instructions, please observe
the applicable laws and regulations,
the statutory provisions for accident prevention,
the prohibition, warning and mandatory signs as well as the warning notes on the drilling
machine.
Always keep this documentation close to the drilling machine.
INFORMATION
If you are unable to rectify an issue using these operating instructions, please contact us for
advice:
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
email: [e-mail]
1.1 Rating plates
provides further instructions
calls on you to act
listings
drill
®
DQ 32
1,1 kW
400 V ~50Hz
120 kg
NO
Optimum Maschinen
Germany GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Germany
3191049
Year
1810 min-1
DE Säulenbohrmaschine
EN Upright drilling machine
FR Perceuse à colonne
ES Taladro
IT Trapano a colonna
CS Sloupová vrtačka
DA Søjleboremaskine
EL Επιδαπεδειο Δραπανο
FI Pylväsporakone
HU Asztali fúrógép
NL Kolomboormachine
PL Wiertarka kolumnowa
PT Máquina de perfuração
RO Mașină de găurit cu coloană
RU Станок вертикальный сверлильный
SK Stĺpová vŕtačka
SL Steberni vrtalni stroj
SV Pelarborrmaskin
TR Sütunlu Matkap
SN
drill
®
DQ 25
0,75 kW
400 V ~50Hz
71 kg
NO
Optimum Maschinen
Germany GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Germany
3191047
Year
2440 min-1
DE Säulenbohrmaschine
EN Upright drilling machine
FR Perceuse à colonne
ES Taladro
IT Trapano a colonna
CS Sloupová vrtačka
DA Søjleboremaskine
EL Επιδαπεδειο Δραπανο
FI Pylväsporakone
HU Asztali fúrógép
NL Kolomboormachine
PL Wiertarka kolumnowa
PT Máquina de perfuração
RO Mașină de găurit cu coloană
RU Станок вертикальный сверлильный
SK Stĺpová vŕtačka
SL Steberni vrtalni stroj
SV Pelarborrmaskin
TR Sütunlu Matkap
SN

Safety
Version 1.0.1 - 2021-01-286 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_1.fm
1.2 Safety instructions (warning notes)
1.2.1 Classification of hazards
We classify the safety warnings into different categories. The table below gives an overview of
the classification of symbols (ideogram) and the warning signs for each specific danger and its
(possible) consequences.
1.2.2 Other pictograms
Symbol Alarm expression Definition / consequence
DANGER! Impending danger that will cause serious injury or death to people.
WARNING! A danger that can cause serious injury or death.
CAUTION!
A danger or unsafe procedure that can cause personal injury or damage
to property.
ATTENTION!
Situation that could cause damage to the drilling machine and product, as
well as other types of damage.
No risk of injury to persons.
Information
Practical tips and other important or useful information and notes.
No dangerous or harmful consequences for people or objects.
In case of specific dangers, we replace the pictogram with
or
general danger with a warning of injury to hands, hazardous
electrical voltage, rotating parts.
Warning: danger of
slipping! Warning: risk of stumbling! Warning: hot surface! Warning: biological hazard!
Warning: automatic start-
up! Warning: tilting danger! Warning: suspended loads! Caution, danger of explosive substances!

Safety
Version 1.0.1 - 2021-01-28 7Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_1.fm
1.3 Intended use
WARNING!
If the drilling machine is not used as intended or if the safety directives or the operating
instructions are ignored the liability of the manufacturer for any damages to persons or
objects resulting hereof is excluded and the claim under guarantee is becoming null and
avoid!
The drilling machine is designed and manufactured to be used in a non-explosive environment.
The drilling machine is designed and manufactured for holes in cold metals or other non flam-
mable materials or that not constitute a health hazard using a rotating filing-stripping tool that
has a number of grooves for collecting the filings. The drilling machine is equipped with a drill
chuck protection. The drill may only be operated with this chuck guard.
If the drilling machine is used in any way other than described above, modified without authori-
zation of Optimum Maschinen Germany GmbH, then the geared drill is being used improperly.
We will not be held liable for any damages resulting from any operation which is not in accord-
ance with the intended use.
We explicitly point out that any construction, technical or process engineering changes that
have not been approved by Optimum Maschinen Germany GmbH will render the warranty null
and void
It is also part of intended use that the maximum values for the drilling machine are complied
with and the operating manual is observed.
ATTENTION!
If the drilling machine is not used as intended or if the safety directives or the operating
instructions are ignored the liability of the manufacturer for any damages to persons or
objects resulting hereof is excluded and the claim under guarantee is becoming null and
avoid!
1.4 Reasonably foreseeable misuses
Any use other than that specified under "Intended use" or any use beyond that described will be
deemed non-intended use and is not permissible. Any other use has to be discussed with the
manufacturer.
It is only allowed to process metal, cold and non-inflammable materials with the drilling
machine.
In order to avoid misuse, it is necessary to read and understand the operating instructions
before first commissioning.
Switching on forbidden! Use ear protection! Read the operating
instructions before
commissioning!
Pull out the mains plug!
Wear protective glasses! Wear protective gloves! Wear safety shoes! Wear a protective suit!

Safety
Version 1.0.1 - 2021-01-288 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_1.fm
Operators must be qualified.
1.4.1 Avoiding misuse
Use of suitable cutting tools.
Adapting the speed setting and feed to the material and workpiece.
Clamp workpieces firmly and free of vibration.
ATTENTION!
The workpiece is always to be fixed by a machine vice, jaw chuck or by another
appropriate clamping tool such as for the clamping claws.
WARNING!
Risk of injury caused by flying workpieces.
The table height adjustment must not be used as a drill feed. The clamping of the table is
released, the possible load capacity of the table height adjustment is not intended for
this.
Clamp the workpiece in the machine vice. Make sure that the workpiece is firmly clamped in
the machine vice and that the machine vice is firmly clamped onto the drill table.
Use cooling and lubricating agents to increase the durability of the tool and to improve the
surface quality.
Clamp the cutting tools and workpieces on clean clamping surfaces.
Sufficiently lubricate the machine.
Set the bearing clearance and guides correctly.
Recommendations:
Insert the drill in a way that it is positioned exactly between the three clamping jaws of the
drill chuck.
When drilling, make sure that
the suitable speed is set depending on the diameter of the drill,
the pressure must only be such that the drill can cut without load,
if there is too much pressure, the drill will wear quickly and may even break or jam in the
borehole. If the drill gets jammed immediately stop the main motor by pressing the emer-
gency stop button,
For hard materials, e.g. steel, it is necessary to use commercial cooling/lubricating
agents.Basically, always pull out the drill with rotating spindle from the workpiece.
The processing of plastics on the drilling machine leads to static charging. The static charg-
ing of machine parts due to the processing of plastics cannot be safely dissipated by the
drilling machine.
1.5 Possible dangers posed by the drilling machine
The drilling machine was built using state-of-the-art technology. Nevertheless, there is a resid-
ual risk as the drilling machine operates with
at high speeds,
rotating parts,
electrical voltage and currents.
We have used design and safety engineering to minimize the health risk to personnel
resulting from these hazards.
If the drilling machine is used and maintained by personnel who are not duly qualified, there
may be a risk resulting from incorrect or unsuitable maintenance of the geared drill.
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must

Safety
Version 1.0.1 - 2021-01-28 9Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_1.fm
be duly qualified
and strictly follow these operating instructions.
In the event of improper use
there may be a risk to personnel,
there may be a risk to the machine and other material values,
the correct function of the drilling machine may be affected.
Always disconnect the drilling machine when cleaning or maintenance work is being carried
out.
WARNING!
The drilling machine may only be operated with functional safety devices.
Disconnect the drilling machine immediately, whenever you detect a failure in the safety
devices or when they are not fitted!
This is your responsibility being the operator!
1.6 Qualification
1.6.1 Target group private users
The machine can be used in the private domain. The acumen of people in the private sector
with training in metal working was taken into consideration for creating this operation manual.
Vocational training or further instruction in a metal working profession is a prerequisite for safe
operation of the machine. It is essential that the private user is aware of the dangers involved in
operating this machine. We recommend attending a training course in the use of drills. Your
specialist dealer can offer you an appropriate training course. These courses are also offered at
adult education centres in Germany.
1.6.2 Obligations of the User
The user must
have read and understood the operating manual,
be familiar with all safety devices and regulations,
be able to operate the drilling machine.
1.6.3 Additional requirements regarding the qualification
The following additional requirements apply for work on electrical components or equipment:
They must only be performed by a qualified electrician or person working under the instruc-
tions and supervision of a qualified electrician.
Before starting work on electrical parts or operating agents, the following actions must be taken
in the order given:
disconnect all poles,
secure against restarting,
check that there is no voltage.
1.7 User positions
The operator position is in front of the drilling machine.
INFORMATION
The mains plug of the drilling machine must be freely accessible.

Safety
Version 1.0.1 - 2021-01-2810 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_1.fm
1.8 Safety measures during operation
CAUTION!
Danger due to inhaling dust and mist that is hazardous to health. Dependent on the
material which need to be processed and the used auxiliaries dusts and mist may be
caused which might impair you health. Ensure that the harmful dust and mist generated
are safely sucked off at the point of origin and routed away from the working area or
filtered. To do so, use a suitable extraction unit.
CAUTION!
Risk of fire and explosion by using flammable materials or cooling lubricants.
Before processing inflammable materials (e.g. aluminium, magnesium) or using
inflammable auxiliary materials (e.g. spirit) it is necessary to take additional preventive
measures in order to safely avoid health risks.
1.9 Safety devices
Use the drilling machine only with properly functioning safety devices.
Stop the drilling machine immediately, if a safety device fails or is faulty or becomes ineffective.
It is your responsibility!
If a safety device has been activated or has failed, the drilling machine must only be used if you
the cause of the fault has been eliminated,
have verified that there is no danger to personnel or objects.
WARNING!
If you bypass, remove or deactivate a safety device in any other way, you are
endangering yourself and other personnel working with the drilling machine. The
possible consequences are
injuries due to components or workpieces flying off at high speed,
contact with rotating parts and
fatal electrocution.
The drilling machine features the following safety devices:
an emergency stop push button,
a drilling table with grooves for fixing the workpiece or a vice,
a fixed protective cover for the pulleys with position switch,
a foldable drill chuck guard.
WARNING!
Although the isolating safety devices provided and delivered with the machine are
designed to reduce the risks of workpieces being ejected or parts of tools or workpieces
breaking off, they cannot eliminate these risks completely. Always work carefully and
observe the limits of the machining process.
1.10 Personal protective equipment
For certain work, personal protective equipment is required.
Protect your face and your eyes: Wear a safety helmet with facial protection when performing
work where your face and eyes are exposed to hazards.
Wear protective gloves when handling pieces with sharp edges.

Safety
Version 1.0.1 - 2021-01-28 11Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_1.fm
Wear safety shoes when you assemble, disassemble or transport heavy components.
Use ear protection if the noise level (emission) in the workplace exceeds 80 dB (A).
Before starting work make sure that the required personal protective equipment is available at
the work place.
CAUTION!
Soiled personal protection equipment that may be contaminated may cause illness. It
must be cleaned after each use and at least once a week.
1.11 Safety check
Check the drilling machine before each start-up or at least once per shift. Inform the person
responsible immediately of any damage, defects or changes in the operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped),
once a week (with the machine in operation) and
after all maintenance and repair work.
Check that prohibition, warning and information signs and the labels on the drilling machine
are legible (clean them, if necessary)
are complete (replace if necessary).
INFORMATION
Organise the checks according to the following table;
General check
Equipment check OK
Guards Mounted, firmly bolted and not damaged
Signs,
Markers Installed and legible
Date: Checked by (signature):
Functional check
Equipment check OK
Drill chuck guard After opening the drill chuck guard, the drill must
switch off. The drill must not start when the chuck
guard is open.
Emergency stop button After the emergency stop button is pressed, the
drilling machine must switch off.
Position switch of protective cover
V-belt The drilling machine must not be switched on, if the protective cover of the V-belts is opened.
Date: Checked by (signature):

Safety
Version 1.0.1 - 2021-01-2812 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_1.fm
1.12 Emergency stop switch
CAUTION!
The drilling spindle keeps turning for a short time even after actuating the emergency
stop switch depending on the preset speed.
1.12.1 Drilling table
Seats for T-slots are attached to the clamping table.
WARNING!
Risk of injury due to workpieces flying off at high speed. Securely fix the workpiece on
the drilling table.
1.13 Separating protective devices
1.13.1 Drill chuck guard
Adjust the guard to the correct height before you start working. To do this, loosen the clamping
screw, set the required height and tighten the clamping screws again.
1.13.2 Protective cover of the V-belts
A protective cover for the belt pulleys is mounted on the drilling head. There is a switch inte-
grated in the protective cover which monitors that the cover is closed.
INFORMATION
The machine cannot be started, if the protective cover is not closed.
1.13.3 Prohibition, warning and mandatory signs
INFORMATION
All warning signs must be legible. They must be checked regularly.
1.14 Personal protective equipment
For some works you need personnel protective equipment as protective equipment. These are
safety helmet,
protective glasses or face guard,
protective gloves,
safety shoes with steel toe caps,
ear protection.
Before starting work make sure that the required personnel protective equipment is available at
the work place.
CAUTION!
Soiled personal protection equipment that may be contaminated may cause illness. It
must be cleaned after each use and at least once a week.
Personal protective equipment for special works
Protect your face and your eyes: Wear safety glasses for all work where your eyes are at risk.
Wear protective gloves when handling pieces with sharp edges.
Wear safety shoes when you assemble, disassemble or transport heavy components.

Safety
Version 1.0.1 - 2021-01-28 13Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_1.fm
1.15 Safety during operation
We provide information about the specific dangers when working with and on the drilling
machine in the descriptions for these types of work.
WARNING!
Before activating the drilling machine, double-check that make sure that there are no
dangers generated for persons, not cause damage to equipment.
Avoid any unsafe work methods.
Make sure that your work does not endanger anyone.
The instructions described in these operating instructions must be strictly observed during
assembly, operation, maintenance and repair.
Do not work on the drilling machine if your concentration is reduced, for example, because
you are taking medication.
Inform the supervisor about all hazards or faults.
Stay on the drilling machine until the machine completely stopped moving.
Use the specified personal protective equipment. Ensure you wear close-fitting clothing
and, if necessary, a hairnet.
Do not use protective gloves when drilling.
1.16 Safety during maintenance
Inform the operators in good time of any maintenance and repair works.
Report all safety relevant changes and performance details of the drilling machine or their oper-
ational behavior. Any changes must be documented, the operating instructions updated and
machine operators instructed accordingly.
1.16.1 Disconnecting and securing the drilling machine
Disconnect the mains plug before starting maintenance and repairs.
All machine parts as well as all dangerous voltages are switched off. Excepted are only the
positions which are marked with the adjoining pictogram.
Attach a warning sign to the machine.
1.16.2 Mechanical maintenance
Remove or install protection safety devices before starting or after completing any mainte-
nance work; this include:
covers,
safety instructions and warning signs,
grounding cables.
If you remove protection or safety devices, refit them immediately after completing the work.
Check that they are working properly!
1.17 Electronics
Craftsman or industrial use
Have the machine and/or the electric equipment checked regularly. Immediately eliminate all
defects such as loose connections, defective wires, etc.
A second person must be present during work on live components to disconnect the power in
the event of an emergency. If there is a fault in the power supply, switch off the drilling machine
immediately!
Comply with the required inspection intervals in accordance with the factory safety directive,
operating equipment inspection.

Safety
Version 1.0.1 - 2021-01-2814 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_1.fm
The operator of the machine must ensure that the electrical systems and operating equipment
are inspected with regards to their proper condition, namely,
by a qualified electrician or under the supervision and direction of a qualified electrician,
prior to initial commissioning and after modifications or repairs, prior to recommissioning
and at set intervals.
The deadlines must be set so that arising, foreseeable defects can be detected in a timely man-
ner.
The relevant electro-technical rules must be followed during the inspection.
No check is required before first commissioning, if the manufacturer or installer has confirmed
to the operator that the electrical system and operating materials have been procured in
accordance with the stipulations of the accident prevention regulations.
Permanently installed electrical systems and operating materials are considered constantly
monitored if they are continually serviced by qualified electricians and inspected by means of
measurements during operation (e.g. monitoring the insulation resistance).
1.18 Inspection deadlines
Technical or Industrial Use
Define and document the inspection deadlines for the machine in accordance with § 3 of the
Factory Safety Act and perform an operational risk analysis in accordance with § 6 of the Work
Safety Act. Also use the inspection intervals in the maintenance section as reference values.

Technical specification
Version 1.0.1 - 2021-01-28 15Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_2.fm
2 Technical specification
The following information represents the dimensions and indications of weight and the manu-
facturer‘s approved machine data.
DQ 25 DQ 32
Electrical connection 400V~50 Hz (~60Hz) 400V~50 Hz (~60Hz)
Spindle drive motor power 750 W 1.1 kW
Drilling capacity in steel (ST60 - E335) [ mm ] Ø 25 Ø 30
Continuous drilling capacity in steel (ST60 - E335) [ mm ] Ø 20 Ø 25
181.5 mm 254 mm
Spindle sleeve travel [mm] 80 120
Spindle seat MT3 MT4
Table size
Length x Width of the working surface 280 mm x 280 mm 355 mm x 355 mm
Table load max. 40 kg 55 kg
Table side tilt / Turning the table ± 45° / 360° ± 45° / 360°
Drilling table T-slot size [mm] 14 mm diagonal 14 mm diagonal
T-slot size machine base 15 mm 15 mm
Distance spindle - table [mm] max. 690 mm max. 640 mm
Distance [mm] spindle - base 1200 1170
Machine stand [mm] 500 mm x 300 mm 575 mm x 350 mm
Working surface machine stand [mm]
Length x Width of the working surface 200 mm x 260 mm 230 mm x 295 mm
Dimensions of the machine Page 17 Page 18
Required space
Machine net weight [ kg ] 71 120.5
Spindle speeds [ rpm ]  DQ25 spindle speeds
on page 28  DQ32 spindle speeds on page 28
Column diameter [mm] Ø 73 Ø 92
Environmental conditions temperature 5 - 35 °C 5 - 35 °C
Environmental conditions
Relative humidity 25 - 80 % 25 - 80 %
Operating material
Toothed rod and oiler Acid-free lubricating oil Acid-free lubricating oil
Throat depth

Technical specification
Version 1.0.1 - 2021-01-2816 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_2.fm
2.1 Emissions
CAUTION!
Depending on the overall noise exposure and the basic threshold values, machine
operators must wear appropriate hearing protection.
We generally recommend the use of noise and ear protection.
The A-weighted sound pressure level LpA is 73 to 75 dB.
The A-weighted sound power level LWA is 98 to 102 dB.
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Furthermore, the noise emission also depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size of damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations.
This information about the noise emission should, however, allow the operator of the machine
to more easily evaluate the hazards and risks.

Technical specification
Version 1.0.1 - 2021-01-28 17Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_2.fm
2.2 Dimensions DQ25
A-A B-B
AA
BB
1620
350 700
181,5
14
15
max. 1200
73Ø
max. 690
500
120
246
200
P
14
280
280
300
1070
Schwerpunkt / Centre of gravity

Technical specification
Version 1.0.1 - 2021-01-2818 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_2.fm
2.3 Dimensions DQ32
A-A
B-B
AA
BB
1660
390 850
254
max. 640
max. 1170
14
16
138
575
283
230
P
16
355
355
350
1195
Schwerpunkt / Centre of gravity

Delivery, internal transport and commissioning
Version 1.0.1 - 2021-01-28 19Translation of original instruction
DQ25 | DQ32 EN
DQ25_DQ32_GB_3.fm
3 Delivery, internal transport and commissioning
CAUTION!
Injuries caused by parts falling over or off a forklift, pallet truck or transport vehicle. Only
use means of transport that can carry the total weight and are suitable for it.
3.1 Notes on transport, installation and commissioning
Improper transport of individual devices, unsecured devices stacked on top of each other or
next to each other in packed or already unpacked condition is accident-prone and can cause
damage or malfunctions for which we do not grant any liability or guarantee.
Transport the scope of delivery secured against shifting or tilting with a sufficiently dimen-
sioned industrial truck to the installation site.
3.1.1 General risks during internal transport
CAUTION: DANGER OF TIPPING!
The machine may be lifted unsecured by a maximum of 2 cm.
Employees must be outside the danger zone, the reach of loads. Warn employees and, if
necessary, advise employees of the hazard.
Act responsibly during transport and always consider the consequences. Refrain from daring
and risky actions.
Gradients and descents (e.g. driveways, ramps and the like) are particularly dangerous. If such
passages are unavoidable, special caution is required.
Before starting the transport check the transport route for possible danger points, unevenness
and disturbances as well as for sufficient strength and load capacity.
Danger points, unevenness and disturbance points must be inspected before transport. The
removal of danger spots, disturbances and unevenness at the time of transport by other
employees leads to considerable dangers.
3.2 Delivery
Check the status of the machine immediately upon receipt and claim possible damages at the
last carrier also if the packing is not being damaged. In order to ensure claims towards the
freight carrier we recommend you to leave the machines, devices and packing material for the
time being in the status at which you have determined the damage or to take photos of this sta-
tus. Please inform us about any other claims within six days after receipt of delivery.
3.3 Unpacking
Install the machine close to its final position before unpacking. If the packaging shows signs of
having possibly been damaged during transport, take the appropriate precautions to prevent
the machine being damaged when unpacking. If damage is discovered, the carrier and/or ship-
per must be notified immediately so the necessary steps can be taken to register a complaint.
Examine the complete machine carefully and check whether all materials, such as shipping
documents, instructions and accessories have been delivered with the machine.
3.3.1 Standard accessories
1 x Drill chuck B16 / 0-16mm
1 x Morse taper MT3 - B16 (DQ25)
1 x Morse taper MT4 - B16 (DQ32)
2 pcs T-nuts
1 x drill drift for morse taper

Delivery, internal transport and commissioning
Version 1.0.1 - 2021-01-2820 Translation of original instruction
DQ25 | DQ32
EN
DQ25_DQ32_GB_3.fm
3.4 Assembly
WARNING!
Danger of crushing when assembling and installing the machine components.
The drilling machine must be installed by at least 2 people, because various elements
and individual parts have to be sustained and joined during assembly.
INFORMATION
The following description of the assembly refers to the DDQ32 drilling machine. It was chosen
for the description of the following work because of its similarity to the DQ25 drill.
Mounting of base and drill column
Position the base on the floor and
attach the column to the base. Fasten-
ing screws for the column have been
provided on the base.
Loosen the screw on the retaining ring
and remove the retaining ring and
toothed rack.
Img.3-1: Assembly of the base
Mounting of the drilling table support
Position the worm gear in the support
of the drilling table.
Adjust the toothed rack within the table
support in a way that the teeth of the
toothed rack cam into the spiral wheel
of the support for the drilling machine
table.
Img.3-2: Mounting of the drilling table support
INFORMATION
The longer untoothed end of the rack must point upward.
Push the drilling table support with the toothed rack on the drill column.
Push the retaining ring onto the upright and the rack.
Tighten the screw of the retaining ring slightly. Make sure that the drilling table support still
can be easily turned around the column.
Attach the clamping lever for drilling table fastening.
Screw
Retaining ring
Toothed rod
Drilling column
Stand
Toothed rod
Clamping lever
Drilling table sup-
port
