Optimum OPTIdrill B 16H User manual

GB
Operating Manual
Version 2.0.1
Bench drill
Part no. 3020217

Version 2.0.1 - 2020-7-172 Translation of the original instructions
B16H
GB
B16H_GBIVZ.fm
Table of contents
1 Safety
1.1 Type plate...................................................................................................................................................... 5
1.2 Safety instructions (warning notes)................................................................................................................ 6
1.2.1 Classification of hazards.................................................................................................................. 6
1.2.2 Other pictograms.............................................................................................................................. 6
1.3 Intended use.................................................................................................................................................. 7
1.4 Reasonably foreseeable misuse.................................................................................................................... 7
1.4.1 Avoiding misuse............................................................................................................................... 8
1.5 Possible dangers caused by the bench drill .................................................................................................. 8
1.6 Qualification of personnel.............................................................................................................................. 9
1.6.1 Target group..................................................................................................................................... 9
1.6.2 Authorized persons........................................................................................................................ 10
1.7 User positions.............................................................................................................................................. 10
1.8 Safety measures during operation............................................................................................................... 11
1.9 Safety devices ............................................................................................................................................. 11
1.10 Safety check................................................................................................................................................ 11
1.11 Emergency-stop switch................................................................................................................................ 12
1.12 Drilling table................................................................................................................................................. 13
1.13 Separating protective devices...................................................................................................................... 13
1.13.1 Protective cover of the V-belts....................................................................................................... 13
1.13.2 Drill chuck guard ............................................................................................................................ 13
1.14 Personal protective equipment.................................................................................................................... 14
1.15 Safety during operation................................................................................................................................ 14
1.16 Safety during maintenance.......................................................................................................................... 14
1.16.1 Disconnecting and securing the bench drill.................................................................................... 15
1.16.2 Using lifting equipment................................................................................................................... 15
1.16.3 Mechanical maintenance ............................................................................................................... 15
1.17 Accident report............................................................................................................................................. 15
1.18 Electronics................................................................................................................................................... 15
2 Technical specification
2.1 Electrical connection.................................................................................................................................... 16
2.2 Drilling capacity............................................................................................................................................ 16
2.3 Spindle seat................................................................................................................................................. 16
2.4 Drilling table................................................................................................................................................. 16
2.5 Required space............................................................................................................................................ 16
2.6 Speeds......................................................................................................................................................... 16
2.7 Environmental conditions............................................................................................................................. 17
2.8 Operating material....................................................................................................................................... 17
2.9 Emissions .................................................................................................................................................... 17
2.10 Dimensions.................................................................................................................................................. 18
3 Delivery, interdepartmental transport, assembly and commissioning
3.1 Notes on transport, installation, commissioning .......................................................................................... 19
3.1.1 General risks during internal transport........................................................................................... 19
3.2 Scope of delivery......................................................................................................................................... 20
3.3 Set-up and assembly................................................................................................................................... 20
3.3.1 Installation site requirements ......................................................................................................... 20
3.3.2 Assembly of the drilling machine.................................................................................................... 20
3.4 Installation.................................................................................................................................................... 20
3.4.1 Fixing.............................................................................................................................................. 21
3.4.2 Installation drawings....................................................................................................................... 21
3.4.3 First commissioning22
3.4.4 Electrical connection...................................................................................................................... 22
3.4.5 Warming up the machine............................................................................................................... 22
4Operation
4.1 Safety........................................................................................................................................................... 23
4.2 Control and indicating elements .................................................................................................................. 23
4.2.1 Control panel.................................................................................................................................. 24
4.3 Switching on the machine............................................................................................................................ 24

Version 2.0.1 - 2020-7-17 3Translation of the original instructions
B16H GB
B16H_GBIVZ.fm
4.4 Switching off the machine ............................................................................................................................24
4.5 Speed variation ............................................................................................................................................25
4.6 Drill depth stop .............................................................................................................................................25
4.6.1 Table height adjustment .................................................................................................................26
4.7 Disassembly, assembly of drill chucks and drill bits.....................................................................................26
4.7.1 Fitting the drill chuck.......................................................................................................................26
4.7.2 Function of quick action drill chuck.................................................................................................27
4.7.3 Unfitting the drill chuck....................................................................................................................27
4.8 Cooling.........................................................................................................................................................28
4.9 Before starting work .....................................................................................................................................28
4.10 During work..................................................................................................................................................28
5 Determining the cutting speed and the speed
5.1 Table cutting speeds / infeed .......................................................................................................................30
5.2 Speed table..................................................................................................................................................30
5.3 Examples to calculatory determine the required speed for your drilling machine ........................................32
6 Maintenance
6.1 Safety...........................................................................................................................................................33
6.1.1 Preparation.....................................................................................................................................33
6.1.2 Restarting .......................................................................................................................................33
6.2 Inspection and maintenance ........................................................................................................................34
6.3 Repair...........................................................................................................................................................38
6.3.1 Customer service technician...........................................................................................................38
7 Ersatzteile - Spare parts
7.1 Ersatzteilbestellung - Ordering spare parts..................................................................................................39
7.2 Hotline Ersatzteile - Spare parts Hotline ......................................................................................................39
7.3 Service Hotline.............................................................................................................................................39
7.4 Bohrkopf - Drilling head................................................................................................................................40
7.5 Keilriemenscheiben - Pulleys .......................................................................................................................40
7.6 Säule und Bohrtisch - Column and drilling table ..........................................................................................41
7.7 Säule und Bohrtisch - Column and drilling table - ab / from 2019................................................................42
7.7.1 Ersatzteilliste - Parts list43
7.8 Maschinenschilder - Machine labels ............................................................................................................47
7.9 Schaltplan - Wiring diagram.........................................................................................................................48
7.9.1 Ersatzteilliste elektrische Komponenten - Parts list electrical components ....................................49
8 Malfunctions
9 Appendix
9.1 Copyright......................................................................................................................................................52
9.2 Terminology/Glossary ..................................................................................................................................52
9.3 Change information operating manual .........................................................................................................52
9.4 Liability claims/warranty ...............................................................................................................................53
9.5 Storage.........................................................................................................................................................54
9.6 Advice for disposal / Options of reuse:.........................................................................................................54
9.6.1 Decommissioning55
9.6.2 Disposal of new device packaging..................................................................................................55
9.6.3 Disposal of the old device...............................................................................................................55
9.6.4 Disposal of electrical and electronic components...........................................................................55
9.6.5 Disposal of lubricants and coolants56
9.7 Disposal via municipal collection facilities....................................................................................................56
9.8 Product follow-up..........................................................................................................................................56

Version 2.0.1 - 2020-7-174 Translation of the original instructions
B16H
GB
_preface_GB.fm
Preface
Dear customer,
Thank you very much for purchasing a product made by OPTIMUM.
OPTIMUM metal working machines offer a maximum of quality, technically optimum solutions
and convince by an outstanding price performance ratio. Continuous enhancements and pro-
duct innovations guarantee state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get
familiar with the machine. Please also make sure that all persons operating the machine have
read and understood the operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation, opera-
tion and maintenance of the machine. The continuous observance of all notes included in this
manual guarantee the safety of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information
for its economic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which
the operator must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the
current state of construction of your machine. Being the manufacturer we are continuously see-
king for improvements and renewal of the products. Therefore, changes might be performed
without prior notice. The illustrations of the machine may be different from the illustrations in
these instructions with regard to a few details. However, this does not have any influence on
the operability of the machine.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors
are reserved !
Your suggestion with regard to these operating instructions are an important contribution to
optimising our work which we offer to our customers. For any questions or suggestions for
improvement, please do not hesitate to contact our service department.
If you have any further questions after reading these operating instructions and you are
not able to solve your problem with a help of these operating instructions, please
contact your specialised dealer or directly the company OPTIMUM.
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D-96103 Hallstadt
Fax (+49)0951 / 96555 - 888
Email: in[email protected]
Internet: www.optimum-machines.com

Safety
Version 2.0.1 - 2020-7-17 5Translation of the original instructions
B16H GB
B16H_GB_1.fm
1 Safety
Glossary of symbols
This part of the operating instructions
explains the meaning and use of the warning notes included in these operating instructions,
defines the intended use of the drilling machine,
points out the dangers that might arise for you or others if these instructions are not obser-
ved,
informs you about how to avoid dangers.
In addition to these operation instructions, please observe
the applicable laws and regulations,
the statutory provisions for accident prevention,
the prohibition, warning and mandatory signs as well as the warning notes on the drilling
machine.
Always keep this documentation close to the drilling machine.
INFORMATION
If you are unable to rectify an issue using these operating instructions, please contact us for
advice:
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D-96103 Hallstadt
email: [e-mail]
1.1 Type plate
provides further instructions
calls on you to act
listings
Optimum Maschinen
Germany GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
302 0217
65 kg
550 W 400 V ~50 Hz
B 16 H
3500 U/min
NO.
SN
Year 20
J
Master Labels
Tischbohrmaschine
Bench drilling machine
Taladro de sobremesa
Perceuse modèle établi
Trapani da banco
Stolní vrtačka
Table boremaskine
Penkkiporakone
Asztali fúrógép
Boormachine tafelmodel
Wiertarki
Engenho de Furarde Bancada
Masina de gaurit
Bänkborrmaskin
Namizni vrtalni stroj
Sütunlu Matkap
ΔΡΑΠΑΝΟ ΠΑΓΚΟΥ

Safety
Version 2.0.1 - 2020-7-176 Translation of the original instructions
B16H
GB
B16H_GB_1.fm
1.2 Safety instructions (warning notes)
1.2.1 Classification of hazards
We classify the safety warnings into different categories. The table below gives an overview of
the classification of symbols (ideogram) and the warning signs for each specific danger and its
(possible) consequences.
1.2.2 Other pictograms
Symbol Alarm expres-
sion Definition / consequence
DANGER! Impending danger that will cause serious injury or death to people.
WARNING! A danger that can cause serious injury or death.
CAUTION!
A danger or unsafe procedure that can cause personal injury or damage to
property.
ATTENTION!
Situation that could cause damage to the drilling machine and product, as
well as other types of damage.
No risk of injury to persons.
Information
Practical tips and other important or useful information and notes.
No dangerous or harmful consequences for people or objects.
In case of specific dangers, we replace the pictogram with
or
general danger with a warning of injury to hands, hazardous
electrical voltage, rotating parts.
Warning: danger of
slipping! Warning: risk of stumbling! Warning: hot surface! Warning: biological hazard!
Warning: automatic start-
up! Warning: tilting danger! Warning: suspended loads! Caution, danger of explosive substances!

Safety
Version 2.0.1 - 2020-7-17 7Translation of the original instructions
B16H GB
B16H_GB_1.fm
1.3 Intended use
WARNING!
In the event of improper use, the bench drill
will endanger personnel,
will endanger the machine and other material property of the operating company,
the correct function of the bench drill may be affected.
The bench drill is designed and manufactured to be used in a non-explosive environment. The
bench drill is designed and manufactured for holes in cold metals or other non flammable mate-
rials or that not constitute a health hazard using a rotating filing-stripping tool that has a num-
ber of grooves for collecting the filings.
If the bench drill is used in any way other than described above, modified without authorization
of Optimum Maschinen Germany GmbH, then the geared drill is being used improperly.
We will not be held liable for any damages resulting from any operation which is not in accor-
dance with the intended use.
We expressly point out that the guarantee will expire, if any constructive, technical or proce-
dural changes are not performed by the company Optimum Maschinen Germany GmbH.
It is also part of the intended use that you
observe the limits of the bench drill,
observe the operating instructions,
and comply with the inspection and maintenance instructions.
 Technical specification on page 16
WARNING!
Extremely severe injuries.
It is forbidden to make any modifications or alternations to the operating parameters
values of the bench drill. They could pose an accident hazard to persons and cause
damage to the bench drill.
ATTENTION!
If the bench drill is not used as intended or if the safety directives or the operating
instructions are ignored the liability of the manufacturer for any damages to persons or
objects resulting hereof is excluded and the claim under guarantee is becoming null and
avoid!
1.4 Reasonably foreseeable misuse
Any use other than that specified under "Intended use" or any use beyond that described will be
deemed non-intended use and is not permissible.
Switching on forbidden! Use ear protection! Read the operating
instructions before
commissioning!
Pull out the mains plug!
Wear protective glasses! Wear protective gloves! Wear safety shoes! Wear a protective suit!

Safety
Version 2.0.1 - 2020-7-178 Translation of the original instructions
B16H
GB
B16H_GB_1.fm
Any other use has to be discussed with the manufacturer.
It is only permissible to process metal, cold and non-inflammable materials with the bench drill.
In order to avoid misuse, it is necessary to read and understand the operating instructions
before first commissioning.
Operators must be qualified.
1.4.1 Avoiding misuse
Use of suitable cutting tools.
Adapting the speed setting and feed to the material and workpiece.
Clamp workpieces firmly and free of vibration.
ATTENTION!
The workpiece is always to be fixed by a machine vice, jaw chuck or by another
appropriate clamping tool such as for the clamping claws.
WARNING!
Risk of injury caused by flying workpieces.
Clamp the workpiece in the machine vice. Make sure that the workpiece is firmly clamped in the
machine vice and that the machine vice is firmly clamped onto the machine table.
Use cooling and lubricating agents to increase the durability of the tool and to improve the
surface quality.
Clamp the cutting tools and workpieces on clean clamping surfaces.
Sufficiently lubricate the machine.
Set the bearing clearance and guides correctly.
Recommendations:
Insert the drill in a way that it is exactly positioned between the three clamping jaws of the
quick action chuck.
When drilling, make sure that
the suitable speed is set depending on the diameter of the drill,
the pressure must only be such that the drill can cut without load,
if there is too much pressure, the drill will wear quickly and may even break or jam in the
borehole. If the drill jams, immediately stop the main motor by pressing the emergency stop
button,
use commercial cooling/lubricating agents for hard materials, e.g. steel and
generally always back the spindle out of the workpiece while it is still turning.
1.5 Possible dangers caused by the bench drill
The bench drill is state-of-the-art.
Nevertheless, there is a residual risk, as the bench drill operates with
high speeds,
rotating parts,
electrical voltage and currents.
We have used design and safety engineering to minimize the health risk to personnel resulting
from these hazards.
If the bench drill is used and maintained by personnel who are not duly qualified, there may be
a risk resulting from incorrect or unsuitable maintenance of the bench drill.

Safety
Version 2.0.1 - 2020-7-17 9Translation of the original instructions
B16H GB
B16H_GB_1.fm
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must
be duly qualified,
and strictly follow these operating instructions.
In the event of improper use
there may be a risk to personnel,
there may be a risk to the machine and other material values,
the correct function of the bench drill may be affected.
Always disconnect the bench drill if cleaning or maintenance work is being carried out, or is no
longer in use.
WARNING!
The bench drill may only be used with fully functional safety devices.
Disconnect the bench drill immediately, whenever you detect a failure in the safety
devices or when they are not fitted!
All additional devices installed by the operator must be equipped with the stipulated
safety devices.
This is your responsibility as the operator!
 Safety devices on page 11
1.6 Qualification of personnel
1.6.1 Target group
This manual is addressed to
the operating companies,
the operators,
the maintenance personnel.
Consequently, the warning notes refer both to the use of the bench drill and to its maintenance.
Determine clearly and explicitly who will be responsible for the different activities on the
machine (operation, maintenance and repair).
Unclear responsibilities constitute a safety risk!
Always disconnect plug of the bench drill from the electrical power supply. This will prevent it
from being used by unauthorized persons.
The qualifications of the personnel for the different tasks are mentioned below:
Operator
The operator is instructed by the operating company about the assigned tasks and possible
risks in case of improper behaviour. The operator may only carry out tasks that exceed normal
operation if this is stated in these instructions and the operating company has explicitly entru-
sted him with the task.
Qualified electrician
With professional training, knowledge and experience as well as knowledge of respective stan-
dards and regulations, qualified electricians are able to perform work on the electrical system
and recognise and avoid any possible dangers.
Qualified electricians have been specially trained for the working environment, in which they are
working and know the relevant standards and regulations.

Safety
Version 2.0.1 - 2020-7-1710 Translation of the original instructions
B16H
GB
B16H_GB_1.fm
Qualified personnel
Due to their professional training, knowledge and experience as well as knowledge of relevant
regulations, qualified personnel are able to perform the assigned tasks and to independently
recognise and avoid any possible dangers.
Instructed person
Instructed persons were instructed by the operating company regarding the assigned tasks and
any possible risks of improper behaviour.
1.6.2 Authorized persons
WARNING!
Inappropriate operation and maintenance of the bench drill constitutes a danger for the
personnel, objects and the environment.
Only authorized personnel may operate the bench drill!
Authorized operating and maintenance personnel are specialists instructed and trained by the
operator and the manufacturer.
The operating company must
Obligations of the
operating
company
train the personnel,
instruct the personnel in regular intervals (at least once a year) on
- all safety regulations relevant to the machine,
- its operation and
- generally accepted engineering standards.
check the personnel‘s knowledge level,
document the training/instruction,
have attendance at the training/instruction confirmed by signature and
check whether the personnel is working in a safety and risk-conscious manner and follo-
wing the operating instructions.
The operator must
Obligations of the
operator
have obtained a training regarding the handling of the radial drilling machine,
know the function and mode of action,
before taking the machine in operation
- have read and understood the operating manual,
- be familiar with all safety devices and instructions. Additional
requirements
regarding the
qualification
Additional requirements apply for work on the following machine components:
Electrical parts or operating agents: shall only be performed by an electrician or under the
guidance and supervision of an electrician.
Before starting work on electrical parts or operating agents, the following actions must be
taken in the order given:
disconnect all poles,
secure against restarting,
check that there is no voltage.
1.7 User positions
The operator position is in front of the bench drill.

Safety
Version 2.0.1 - 2020-7-17 11Translation of the original instructions
B16H GB
B16H_GB_1.fm
1.8 Safety measures during operation
CAUTION!
Danger due to inhaling dust and mist that is hazardous to health.
Dependent on the material which need to be processed and the used auxiliaries dusts
and mist may be caused which might impair you health.
Ensure that the harmful dust and mist generated are safely sucked off at the point of
origin and routed away from the working area or filtered. To do so, use a suitable
extraction unit.
CAUTION!
Risk of fire and explosion by using flammable materials or cooling lubricants.
Before processing inflammable materials (e.g. aluminium, magnesium) or using
inflammable auxiliary materials (e.g. spirit) it is necessary to take additional preventive
measures in order to safely avoid health risks.
1.9 Safety devices
The bench drill must only be operated with fully functional safety devices.
Stop the bench drill immediately if there is a failure on the safety device or becomes ineffective.
It is your responsibility!
If a safety device has been activated or has failed, the bench drill must only be used if you
the cause of the fault has been eliminated,
you have verified that there is no danger to personnel or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other persons working with the bench drill. The possible consequences
are:
injuries due to components or workpieces flying off at high speed,
contact with rotating parts,
fatal electrocution,
The bench drill includes the following safety devices:
an emergency stop push button,
a drilling table with T-slots to fix the workpiece or a vice,
a protective cover for the pulleys with positioning switch,
a drill chuck guard, in order to prevent interference with the rotating tool.
WARNING!
Although the isolating safety devices provided and delivered with the machine are desi-
gned to reduce the risks of workpieces being ejected or parts of tools or workpieces bre-
aking off, they cannot eliminate these risks completely. Always work carefully and
observe the limits of the machining process.
1.10 Safety check
Check the bench drill before each start-up or at least once per shift. Inform the person respon-
sible immediately of any damage, defects or changes in the operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped),
once a week (with the machine in operation) and
after all maintenance and repair work.

Safety
Version 2.0.1 - 2020-7-1712 Translation of the original instructions
B16H
GB
B16H_GB_1.fm
Check that prohibition, warning and information signs and the labels on the bench drill.
are legible (clean them, if necessary)
are complete (replace if necessary).
INFORMATION
Organise the checks according to the following table;
1.11 Emergency-stop switch
ATTENTION!
The drilling spindle keeps
turning for a short time
even after actuating the
emergency stop push but-
ton depending on the pre-
set speed.
Abb.1-1: Emergency-stop
General check
Equipment check OK
Guards Mounted, firmly bolted and not damaged
Signs,
Markers Installed and legible
Date: Checked by (signature):
Functional check
Equipment check OK
Emergency-stop
switch After actuating the emergency-stop push button the bench drill must be switched off.
Limit switch protective
cover
V-belt
The bench drill must not be switched on, if the protective cover
of the V-belts is opened. An opening of the protective cover
during machine operating turns off the machine.
Drill chuck guard The bench drill can only be switched on if the drill chuck guard is
closed. The engine must switch off when the drill chuck guard is
opened during operation.
Date: Checked by (signature):
Emergency-stop
switch

Safety
Version 2.0.1 - 2020-7-17 13Translation of the original instructions
B16H GB
B16H_GB_1.fm
1.12 Drilling table
Seats for T-slots are attached
to the clamping table.
WARNING!
Risk of injury due to
workpieces flying off at high
speed. Securely fix the
workpiece on the drilling
table.
Abb.1-2: Drilling table
1.13 Separating protective devices
1.13.1 Protective cover of the V-belts
A protective cover for the belt
pulleys is mounted on the dril-
ling head. There is a switch
integrated in the protective
cover which monitors that the
cover is closed.
INFORMATION
The machine cannot be star-
ted, if the protective cover is not
closed.
Abb.1-3: Protective cover
1.13.2 Drill chuck guard
Adjust the guard to the correct height
before you start working.
To do so, slacken the clamping
screw, set the required height and re-
tighten the clamping screw.
There is a switch integrated in the
spindle protection mounting which
monitors the closed position.
INFORMATION
The machine cannot be started, if the
drill chuck guard is not closed.
Abb.1-4: Drill chuck guard
Seat for
t-slot
Protective
cover
Clamping screw
Drill chuck guard

Safety
Version 2.0.1 - 2020-7-1714 Translation of the original instructions
B16H
GB
B16H_GB_1.fm
1.14 Personal protective equipment
For some works you need personnel protective equipment as protective equipment. These are
Safety helmet,
protective glasses or face guard,
protective gloves,
safety shoes with steel toe caps,
ear protection.
Before starting work make sure that the required personnel protective equipment is available at
the work place.
CAUTION!
Soiled personal protection equipment that may be contaminated may cause illness.
Clean your personal protective equipment
after each use,
regularly once a week.
Personal protective equipment for special works
Protect your face and your eyes: Wear a safety helmet with facial protection when performing
work where your face and eyes are exposed to hazards.
Wear protective gloves when handling pieces with sharp edges.
Wear safety shoes when you assemble, disassemble or transport heavy components.
1.15 Safety during operation
We specifically point out the dangers in the description of work with and on the bench drill.
WARNING!
Before switching on the bench drill make sure that there are
no dangers generated for persons,
no objects are damaged.
Avoid any unsafe work methods:
Make sure that your operation does not create a safety hazard.
The rules specified in these operating instructions must be observed during assembly, ope-
ration, maintenance and repair.
Do not work on the bench drill if your concentration is reduced, for example, because you
are taking medication.
Observe the accident prevention regulations issued by your Employers Liability Insurance
Association or other supervisory authorities applicable to your company.
Inform the supervisor about all hazards or faults.
Stay on the bench drill until the machine completely stopped moving.
Use the specified personal protective equipment. Ensure you wear close-fitting clothing
and, if necessary, a hairnet.
Do not use protective gloves when drilling.
1.16 Safety during maintenance
Inform the operators in good time of any maintenance and repair works.

Safety
Version 2.0.1 - 2020-7-17 15Translation of the original instructions
B16H GB
B16H_GB_1.fm
Report all safety relevant changes and performance details of the bench drill or their operatio-
nal behaviour. Any changes must be documented, the operating instructions updated and
machine operators instructed accordingly.
1.16.1 Disconnecting and securing the bench drill
The bench drill is equipped with a master
switch.
When the master switch is switched off, the
power supply to the machine is completely
interrupted.
Abb.1-5: Main switch B16H
Excepted are only the positions which are marked with the adjoining pictogram.
Disconnect the power plug to completely disconnect the drill from the power supply.
1.16.2 Using lifting equipment
WARNING!
The use of unstable lifting and load suspension equipment that might break under load
can cause severe injuries or even death.
Check that the lifting and load suspension gear
they have sufficient load carrying,
and that it is in perfect condition.
Observe the accident prevention regulations issued by your Employers Liability
Insurance Association or other supervisory authorities applicable to your company.
Fasten the loads carefully. Never walk under suspended loads!
1.16.3 Mechanical maintenance
Reinstall all protection and safety devices after any maintenance work once the work has been
completed.This includes:
covers,
safety instructions and warning signs,
grounding cables.
Check if they are working properly!
1.17 Accident report
Inform your supervisors and Optimum Maschinen Germany GmbH immediately in the event of
accidents, possible sources of danger and any actions which almost led to an accident (near
misses).
There are many possible causes for "near misses".
The sooner they are notified, the quicker the causes can be eliminated.
1.18 Electronics
Have the machine and/or the electric equipment checked regularly. Immediately eliminate all
defects such as loose connections, defective wires, etc.
Define and document the inspection deadlines for the machine in accordance with § 3 of the
Factory Safety Act and perform an operational risk analysis in accordance with § 6 of the Work
Safety Act.
Master switch

Technical specification
Version 2.0.1 - 2020-7-1716 Translation of the original instructions
B16H
GB
B16H_GB_2.fm
2 Technical specification
The following information represents the dimensions and indications of weight and the manu-
facturer‘s approved machine data.
2.1 Electrical connection
Connection 400V ~50 Hz
0.55 kW
2.2 Drilling capacity
Drilling capacity in steel [mm] 13
Drilling capacity in cast [mm] 16
Continuous drilling capacity in steel [mm] 11
Throat [mm] 130
Spindle sleeve stroke [mm] 65
2.3 Spindle seat
Spindle seat MT2
2.4 Drilling table
Table size [mm]
Length x Width of the working surface 230 x 245
T-slot size [mm] 12
Maximum distance [mm]
spindle - table 370
Maximum distance [mm]
spindle - stand 495
Working surface stand [mm]
Length x Width of the working surface 200 x 240
2.5 Required space
Height [mm] 1500
Depth [mm] 1200
Width [mm] 1000
Weight [kg] 54
2.6 Speeds
Spindle speeds [ rpm ] 450 - 3500
Number of stages 5

Technical specification
Version 2.0.1 - 2020-7-17 17Translation of the original instructions
B16H GB
B16H_GB_2.fm
2.9 Emissions
The generation of noise emitted by the bench drill is lower than 76 dB(A).
If the bench drill is installed in an area where various machines are in operation, the noise
exposure (immission) on the operator of the milling machine at the working place may exceed
80 dB(A).
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Furthermore, the noise emission also depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The specified numerical value represents the emission level and does not necessarily a safe
working level.
Though there is a dependency between the degree of the noise emission and the degree of the
noise disturbance it is not possible to use it reliably to determine if further precaution measures
are required or not.
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size of damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations.
This information about the noise emission should, however, allow the operator of the machine
to more easily evaluate the hazards and risks.
CAUTION!
Depending on the overall noise exposure and the basic threshold values, machine
operators must wear appropriate hearing protection.
We generally recommend the use of noise and ear protection.
2.7 Environmental conditions
Temperature 535 °C
Relative humidity 25 - 80 %
2.8 Operating material
toothed rod commercial lubricating grease
Column, bare steel parts acid-free oil, e.g. machine oil, motor oil

Technical specification
Version 2.0.1 - 2020-7-1718 Translation of the original instructions
B16H
GB
B16H_GB_2.fm
2.10 Dimensions
Abb.2-1:
A-A B-B
AA
BB
130
495
300
60P
550
850
240
9080
160
260
100
P12
260 365
220
500
Schwerpunkt / Centre of gravity
12
185
230
245
12
300

Delivery, interdepartmental transport, assembly and commissioning
Version 2.0.1 - 2020-07-17 19Translation of original instruction
EN
in-house_transport_en.fm
3 Delivery, interdepartmental transport, assembly and
commissioning
3.1 Notes on transport, installation, commissioning
Improper transport, installation and commissioning is liable to accidents and can cause damage
or malfunctions to the machine for which we do not assume any liability or guarantee.
Transport the scope of delivery secured against shifting or tilting with a sufficiently dimen-
sioned industrial truck or a crane to the installation site.
WARNING!
Severe or fatal injuries may occur if parts of the machine tumble or fall down from the
forklift truck or from the transport vehicle. Follow the instructions and information on the
transport box.
Note the total weight of the machine. The weight of the machine is indicated in the "Tech-
nical data" of the machine. When the machine is unpacked, the weight of the machine
can also be read on the rating plate.
Only use transport devices and load suspension gear that can hold the total weight of
the machine.
WARNING!
The use of unstable lifting and load suspension equipment that might break under load
can cause severe injuries or even death. Check that the lifting and load suspension gear
has sufficient load-bearing capacity and that it is in perfect condition.
Observe the accident prevention regulations issued by your Employers Liability Insur-
ance Association or other competent supervisory authority, responsible for your com-
pany. Fasten the loads properly.
3.1.1 General risks during internal transport
WARNING: TILTING DANGER!
The machine may be lifted unsecured by a maximum of 2 cm.
Employees must be outside the danger zone, i.e. the reach of the load.
Warn employees and advise them of the hazard.
Machines may only be transported by authorized and qualified persons. Act responsibly during
transport and always consider the consequences. Refrain from daring and risky actions.
Gradients and descents (e.g. driveways, ramps and the like) are particularly dangerous. If such
passages are unavoidable, special caution is required.
Before starting the transport check the transport route for possible danger points, unevenness
and faults.
Danger points, unevenness and disturbance points must be inspected before transport. The
removal of danger spots, disturbances and unevenness at the time of transport by other
employees leads to considerable dangers.
Careful planning of interdepartmental transport is therefore essential.

Version 2.0.1 - 2020-7-1720 Translation of the original instructions
B16H
GB
B16H_GB_3.fm
3.2 Scope of delivery
When the machine is delivered, please check immediately that it has not been damaged during
transport. Compare the scope of delivery with the attached packing list.
3.3 Set-up and assembly
3.3.1 Installation site requirements
Organise the working area around the bench drill according to the local safety regulations.
INFORMATION
In order to attain good functionality and a high processing accuracy as well as a long service life
of the machine, the place of installation should fulfil certain criteria.
Please observe the following points:
The device must only be installed and operated in a dry and well-ventilated place.
Avoid places close to machines which cause chips or dust.
The installation site must be vibration-free, i.e. located away from presses, planing machi-
nes, etc.
The substructure must be suitable for the bench drill. Pay attention also to the load-bearing
capacity and evenness of the floor.
The substructure must be prepared in such a way as to ensure that, if any lubricant is used,
it cannot penetrate the floor.
Any parts sticking out such as stops, handles, etc. have to be secured by measures taken
by the customer if necessary in order to avoid endangering persons.
Provide sufficient space for the personnel preparing and operating the machine and trans-
porting the material.
Also make sure the machine is accessible for setting and maintenance works.
Provide for sufficient backlight (Minimum value: 500 Lux, measured at the tool tip). In the
event of a lower level of lighting, additional illumination must be provided, e.g. by means of
a separate workplace light.
INFORMATION
The power plug of the bench drill must be readily accessible.
3.3.2 Assembly of the drilling machine
WARNING!
Danger of crushing when assembling and installing the
machine components.
INFORMATION
The drilling machine is delivered premounted.
Only put up the drilling machine at the installation site and pin up the drill chuck on the seat
cone.
3.4 Installation
Check the horizontal orientation of the base of the bench drill with a spirit level.
Check that the foundation has sufficient load-bearing capacity and rigidity.
Place the bench drill on the provided foundation.
