Optimum 3300260 User manual

EN
Operating Manual
Version 1.2.4
Metal band saw
Item no. 3300260
Item no. 3300265

Version 1.2.4 - 2022-10-262 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GBIVZ.fm
Table of contents
1 Safety
1.1 Type plates .................................................................................................................................................... 5
1.2 Safety instructions (warning notes)................................................................................................................ 6
1.2.1 Classification of hazards .................................................................................................................. 6
1.2.2 Other pictograms.............................................................................................................................. 6
1.3 Intended use.................................................................................................................................................. 7
1.4 Reasonably foreseeable misuse.................................................................................................................... 8
1.4.1 Avoiding misuse............................................................................................................................... 8
1.5 Possible dangers caused by the metal band saw.......................................................................................... 9
1.6 Qualification of personnel .............................................................................................................................. 9
1.6.1 Target group..................................................................................................................................... 9
1.6.2 Authorized personnel ..................................................................................................................... 10
1.7 Safety devices ............................................................................................................................................. 11
1.7.1 Emergency-stop button.................................................................................................................. 11
1.7.2 Saw arch ........................................................................................................................................ 11
1.7.3 Saw belt guide................................................................................................................................ 11
1.7.4 Prohibition, warning and mandatory signs ..................................................................................... 11
1.8 Safety check ................................................................................................................................................ 12
1.9 Personal protective equipment .................................................................................................................... 12
1.10 Safety during operation................................................................................................................................ 13
1.11 Safety during maintenance.......................................................................................................................... 13
1.11.1 Disconnecting and securing the metal band saw........................................................................... 13
1.11.2 Using lifting equipment................................................................................................................... 14
1.11.3 Mechanical maintenance work....................................................................................................... 14
1.12 Accident report............................................................................................................................................. 14
1.13 Electronics ................................................................................................................................................... 14
1.14 Inspection deadlines.................................................................................................................................... 15
2 Technical data
2.1 Emissions .................................................................................................................................................... 17
3 Delivery, interdepartmental transport, assembly and commissioning
3.1 Notes on transport, installation, commissioning .......................................................................................... 18
3.1.1 General risks during internal transport ........................................................................................... 18
3.2 Unpacking the machine ............................................................................................................................... 19
3.3 Requirements regarding the installation site................................................................................................ 19
3.4 Dimensions S275N │ S275NV ................................................................................................................... 20
3.5 Assembly ..................................................................................................................................................... 21
3.5.1 Assembling the machine stand - V1............................................................................................... 21
3.5.2 Assembling the machine stand - V2............................................................................................... 22
3.5.3 Fit optional levelling disc SE2 ........................................................................................................ 22
3.5.4 Load suspension point ................................................................................................................... 22
3.5.5 Drip pan.......................................................................................................................................... 24
3.5.6 Material stop................................................................................................................................... 24
3.6 Electrical connection.................................................................................................................................... 24
3.6.1 Electrical connection S275N .......................................................................................................... 24
3.6.2 Electrical connection S275NV........................................................................................................ 25
3.7 First commissioning..................................................................................................................................... 25
4Operation
4.1 Control and indicating elements .................................................................................................................. 27
4.2 Safety........................................................................................................................................................... 28
4.3 Inserting the workpiece................................................................................................................................ 28
4.4 Setting of angle cut...................................................................................................................................... 28
4.5 Adjusting the saw belt guide ........................................................................................................................ 29
4.6 Switching on the machine............................................................................................................................ 29
4.7 Switching off the machine............................................................................................................................ 29
4.8 Resetting an emergency stop condition....................................................................................................... 29
4.9 Adjusting the speed of the saw belt............................................................................................................. 29
4.9.1 Selector switch / speed controller .................................................................................................. 29
4.9.2 Saw belt speeds............................................................................................................................. 30

Version 1.2.4 - 2022-10-26 3Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GBIVZ.fm
4.10 Coolant equipment .......................................................................................................................................30
4.11 Starting the metal band saw.........................................................................................................................30
4.12 Hydraulic feed ..............................................................................................................................................31
4.13 Cutting area..................................................................................................................................................31
4.14 General information concerning saw bands .................................................................................................32
4.14.1 Spacing...........................................................................................................................................32
4.14.2 Set of saw teeth..............................................................................................................................33
4.14.3 Recommended saw band speeds ..................................................................................................35
5 Maintenance
5.1 Safety ...........................................................................................................................................................37
5.1.1 Preparation .....................................................................................................................................37
5.1.2 Restarting .......................................................................................................................................37
5.1.3 Cleaning..........................................................................................................................................37
5.2 Checkup, inspection and maintenance ........................................................................................................37
5.3 Repair...........................................................................................................................................................43
5.3.1 Customer service technician...........................................................................................................43
5.4 Cooling lubricants and tanks ........................................................................................................................44
5.4.1 Inspection plan for water-mixed cooling lubricants .........................................................................45
6 Ersatzteile - Spare parts
6.1 Ersatzteilbestellung - Ordering spare parts..................................................................................................46
6.2 Hotline Ersatzteile - Spare parts Hotline ......................................................................................................46
6.3 Service Hotline .............................................................................................................................................46
6.4 Ersatzteilzeichnungen - Spare part drawings...............................................................................................47
6.5 Schaltplan - Wiring diagram 400V - S275N - Einkanalig - Single channel ...................................................55
6.6 Schaltplan - Wiring diagram 400V - S275N - Zweikanalig - Double channel ...............................................56
6.7 Schaltplan - Wiring diagram - S275NV.........................................................................................................57
7 Malfunctions
7.1 Malfunctions on the metal band saw ............................................................................................................62
8 Appendix
8.1 Copyright ......................................................................................................................................................63
8.2 Terminology/Glossary ..................................................................................................................................63
8.3 Change information manual .........................................................................................................................63
8.4 Liability Claims for Defects / Warranty .........................................................................................................64
8.5 Storage.........................................................................................................................................................65
8.6 Advice for disposal / Options of re-use.........................................................................................................65
8.6.1 Decommissioning ...........................................................................................................................65
8.6.2 Disposal of new device packaging..................................................................................................66
8.6.3 Disposing of the old device.............................................................................................................66
8.6.4 Disposal of electrical and electronic components...........................................................................66
8.6.5 Disposal of lubricants and coolants ................................................................................................67
8.7 Disposal via municipal collection facilities ....................................................................................................67
8.8 Product follow-up..........................................................................................................................................67

Version 1.2.4 - 2022-10-264 Originalbetriebsanleitung
S275N | S275NV
EN
_preface_GB.fm
Preface
Dear customer,
Thank you very much for purchasing a product made by OPTIMUM.
OPTIMUM metal working machines offer a maximum of quality, technically optimum solutions
and convince by an outstanding price performance ratio. Continuous enhancements and
product innovations guarantee state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get
familiar with the machine. Please also make sure that all persons operating the machine have
read and understood the operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation,
operation and maintenance of the machine. The continuous observance of all notes included in
this manual guarantee the safety of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information
for its economic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which
the operator must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the
current state of construction of your machine. Being the manufacturer we are continuously
seeking for improvements and renewal of the products. Therefore, changes might be performed
without prior notice. The illustrations of the machine may be different from the illustrations in
these instructions with regard to a few details. However, this does not have any influence on the
operability of the machine.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors
are reserved!
Your suggestion with regard to these operating instructions are an important contribution to
optimising our work which we offer to our customers. For any questions or suggestions for
improvement, please do not hesitate to contact our service department.
If you have any further questions after reading these operating instructions and you are
not able to solve your problem with a help of these operating instructions, please
contact your specialised dealer or directly the company OPTIMUM.
Optimum Maschinen Germany GmbH
Dr.- Robert - Pfleger - Str. 26
D-96103 Hallstadt
Mail: [e-mail]
Internet: www.optimum-maschinen.com

Safety
Version 1.2.4 - 2022-10-26 5Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_1.fm
1 Safety
Glossary of symbols
This part of the operating instructions
explains the meaning and use of the warning notes included in these operating instructions,
defines the intended use of the metal band saw ,
points out the dangers that might arise for you or others if these instructions are not
observed,
informs you about how to avoid dangers.
In addition to these operation instructions, please observe
the applicable laws and regulations,
the statutory provisions for accident prevention,
the prohibition, warning and mandatory signs as well as the warning notes on the metal
band saw.
European standards must be kept during installation, operation, maintenance and repair of the
circular metal saw.
If European standards have not yet been incorporated in the national legislation of the country
of destination, the specific applicable regulations of each country must be observed.
If required it is necessary to take the corresponding measures to comply with the country-
specific regulations before commissioning the metal band saw.
Always keep this documentation close to the metal band saw.
INFORMATION
If you are unable to rectify an issue using these operating instructions, please contact us for
advice:
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D- 96103 Hallstadt
Email: [e-mail]
1.1 Type plates
provides further instructions
calls on you to act
enumerations

Safety
Version 1.2.4 - 2022-10-266 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_1.fm
1.2 Safety instructions (warning notes)
1.2.1 Classification of hazards
We classify the safety warnings into different categories. The table below gives an overview of
the classification of symbols (ideogram) and the warning signs for each specific danger and its
(possible) consequences.
1.2.2 Other pictograms
Symbol Warning alert Definition / consequence
DANGER! Impending danger that will cause serious injury or death to people.
WARNING! A danger that can cause serious injury or death.
CAUTION! A danger or unsafe procedure that can cause personal injury or damage to
property.
ATTENTION!
Situation that could cause damage to the machine and product and other
types of damage.
No risk of injury to people.
INFORMATION
Practical tips and other important or useful information and notes.
No dangerous or harmful consequences for people or objects.
In case of specific dangers, we replace the pictogram with
or
general danger with a warning of injury to hands, hazardous
electrical voltage,
rotating parts.
Warning: danger of
slipping! Warning: risk of stumbling! Warning: hot surface! Warning: biological hazard!
Warning: automatic start-
up!
Warning: tilting danger! Warning: suspended loads! Caution, danger of
explosive substances!

Safety
Version 1.2.4 - 2022-10-26 7Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_1.fm
1.3 Intended use
WARNING!
In the event of improper use, the metal band saw
will endanger personnel,
will endanger the machine and other material property of the operating company,
the correct function of the machine may be affected.
The machine is designed and manufactured to be used in environments where there is no
potential danger of explosion.
The metal band saw is designed and manufactured to saw cold metal, cast material and
plastics or other material that are not health hazardous and do not generate dust.
The metal band saw must not be used on wood.
The pieces to be cut must be of a shape that will allow them to be securely attached in the
workholder vice and ensure that the piece does not come loose when it is being sawed.
The metal band saw must only be installed and operated in a dry and ventilated place.
If the metal band saw is used in any way other than described above, modified without
authorization of Optimum Maschinen Germany GmbH, then the metal band saw is being used
improperly.
We will not be held liable for any damages resulting from any operation which is not in
accordance with the intended use.
We expressly point out that the guarantee or CE conformity will expire due to any constructive
technical or procedural changes which had not been performed by the company Optimum
Maschinen Germany GmbH.
It is also part of intended use that you
observe the limits of the metal band saw,
the operating manual is observed,
the inspection and maintenance instructions are observed.
 Technical data on page 16
The decisive factor for achieving efficient cutting and the necessary angular tolerance is the
correct choice of parameters such as the saw blade, feed, cutting pressure, cutting speed and
cooling agent.
Activation forbidden! Read the operating
instructions before
commissioning!
Pull the main plug! Wear protective glasses!
Wear protective gloves! Wear safety shoes! Wear a protective suit! Use ear protection!
Protect the environment! Contact address

Safety
Version 1.2.4 - 2022-10-268 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_1.fm
WARNING!
Extremely severe injuries. It is forbidden to make any modifications or alternations to the
operation values of the metal band saw! They could endanger the staff and cause
damage to the metal band saw.
1.4 Reasonably foreseeable misuse
Any other use other than that specified under "Intended use" or any use beyond the described
use shall be deemed as non-intended use and is not permissible.
Any other use has to be discussed with the manufacturer.
In order to avoid misuse, it is necessary to read and understand the operating instructions
before first commissioning. Operators must be qualified.
1.4.1 Avoiding misuse
INFORMATION
The metal band saw S275NV with frequency converter for adjusting the saw band speed is built
according to the standard EN 61800-3 class C3.
WARNING!
This type is not suitable for connection to a public low-voltage network supplying
residential buildings. When connecting to a public low voltage network, radio frequency
interference is expected.
Overview of the EMC categories:
Categorie C1
required limit values Class B Group 1 according to EN 55011
Categorie C2
Required limit values class A Group 1 according to EN 55011, Installation by EMC experts
and warning: “This is a product of category C2 according to EN 61800-3. This product may
cause radio interference in a residential area. In this case, it may be necessary for the
operator to take appropriate action.“
Categorie C3
Required limit values class A group 2 according to EN 55011, whereby these limit values are
below those of class A group 1, plus warning: „This type is not suitable for connection to a
public low-voltage network supplying residential buildings. When connecting to a public low
voltage network, radio frequency interference is expected. "
This machine
Categorie C1 C2 C3 C4
Environment
Residential area
Business area
Industrial area
Industrial area
Voltage / Current < 1000 V > 1000 V
EMC knowledge no requirement Installation and commissioning by an EMC expert

Safety
Version 1.2.4 - 2022-10-26 9Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_1.fm
1.5 Possible dangers caused by the metal band saw
The metal band saw has been tested for operational safety. The construction and type are state
of the art.
Nevertheless, there is a residual risk as the metal band saw operates with
electrical voltage and currents,
a circulating saw belt.
We have used construction resources and safety techniques to minimize the health risk to
personnel resulting from these hazards.
If the metal band saw is used and maintained by personnel who are not duly qualified, there
may be a risk resulting from incorrect or unsuitable maintenance of the metal band saw.
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must
be duly qualified,
and strictly follow these operating instructions.
In the event of improper use
there may be a risk to personnel,
the metal band saw and further property might be endangered,
the correct function of the metal band saw may be affected.
Always disconnect the metal band saw from the electrical power supply when performing
cleaning or maintenance works.
WARNING!
The metal band saw may only be used with the safety devices activated.
Disconnect the metal band saw immediately whenever you detect a failure in the safety
devices or when they are not mounted!
All additional devices installed by the operator have to be equipped with the prescribed
safety devices. This is your responsibility being the operating company!
 Safety devices on page 11
1.6 Qualification of personnel
1.6.1 Target group
This manual is addressed to
the operating companies,
the operators,
the maintenance personnel.
Therefore, the warning notes refer to both operation and maintenance of the metal band saw.
Determine clearly and explicitly who will be responsible for the different activities on the
machine (operation, maintenance and repair).
Unclear responsibilities constitute a safety risk!
Disconnect the main plug of the metal band saw and secure the metal band saw against
restarting.
The qualifications of the personnel for the different tasks are mentioned below:
Operator
The operator has been instructed by the operating company regarding the assigned tasks and
possible risks in case of improper behaviour. Any tasks which need to be performed beyond the
operation in standard mode must only be performed by the operator, if so indicated in these
instructions and if the operator has been expressively commissioned by the operating company.

Safety
Version 1.2.4 - 2022-10-2610 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_1.fm
Qualified electrician
With professional training, knowledge and experience as well as knowledge of respective
standards and regulations, qualified electricians are able to perform work on the electrical
system and recognise and avoid any possible dangers.
Qualified electricians have been specially trained for the working environment, in which they are
working and know the relevant standards and regulations.
Qualified personnel
Thanks to professional training, knowledge and experience as well as knowledge of relevant
regulations the qualified personnel is able to perform the assigned tasks and to independently
recognise and avoid any possible dangers themselves.
Instructed person
Instructed persons were instructed by the operating company regarding the assigned tasks and
any possible risks of improper behaviour.
1.6.2 Authorized personnel
WARNING!
Inappropriate operation and maintenance of the metal band saw constitutes a danger for
the personnel, objects and the environment.
Only authorized staff may operate the metal band saw!
Persons authorized to operate and maintain should be trained technical personnel and
instructed by the ones who are working for the operating company and for the manufacturer.
The operating company must
train the personnel,
instruct the personnel in regular intervals (at least once a year) on
- all safety standards that apply to the machine,
- the operation,
- generally accepted engineering standards.
check the personnel‘s knowledge level,
document the training/instruction,
require personnel to confirm participation in training/instructions by means of a signature,
check whether the personnel is working safety and risk-conscious and observes the
operating instructions.
The operator must
have obtained a training regarding the handling of the metal band saw,
know the function and mode of action,
before taking the machine in operation
- have read and understood the operating manual,
- be familiar with all safety devices and instructions.
Additional requirements apply for work on the following machine components:
Electric components or operating materials: Must only be worked on by a qualified
electrician or person working under the instructions and supervision of a qualified
electrician.
Before starting work on electrical parts or operating agents, following measures are to be
performed in the following order:
- disconnect all poles
- secure against restarting
- check that there is no voltage

Safety
Version 1.2.4 - 2022-10-26 11Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_1.fm
1.7 Safety devices
Use the metal band saw only with properly functioning safety devices.
Stop the drilling machine immediately if there is a failure on the safety device or if it is not
functioning for any reason.
It is your responsibility!
If a safety device has been activated or has failed, the metal band saw must only be used if you
the cause of the fault has been eliminated,
you have verified that there is no danger to personnel or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other persons working on the metal band saw. The possible consequences
are:
injuries due to components or parts of components flying off at high speed,
contact with rotating and revolting parts,
fatal electrocution,
The metal band saw includes the following safety devices:
an Emergency-stop button
a saw blade casing with protective cover and position switch,
protective covers of the saw blade guide.
1.7.1 Emergency-stop button
The Emergency-stop button switches the metal band saw off.
INFORMATION
After actuation, turn the Emergency-stop push button clockwise in order to switch the metal
band saw on again.
1.7.2 Saw arch
The arch of the metal band saw is provided with a protective cover. The protective cover
protects the belt guide pulleys and the rotating saw belt.
INFORMATION
The metal band saw only switches on when the protective cover is being closed.
WARNING!
Danger of injury! The teeth of the saw belt are sharp. Take great care when opening the
protective cover to change the saw blade.
Close and mount all protective covers before restarting the metal band saw.
1.7.3 Saw belt guide
Refit the protective covers after each exchange of the saw blade.
1.7.4 Prohibition, warning and mandatory signs
INFORMATION
All warning signs must be legible. They must be checked regularly.

Safety
Version 1.2.4 - 2022-10-2612 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_1.fm
1.8 Safety check
Check the metal band saw at least once per shift. Inform the person responsible immediately of
any damage, defects or changes in the operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped),
once a week (with the machine in operation),
after all maintenance and repair work.
Check that prohibition, warning and information signs and the labels on the metal band saw
are legible (clean them, if necessary)
are complete.
INFORMATION
Organise the checks according to the following table;
1.9 Personal protective equipment
For some works you need personnel protective equipment as protective equipment. This
includes:
Safety helmet,
protective glasses or face guard,
protective gloves,
safety shoes with steel toe caps,
ear protection.
Before starting work make sure that the required personnel protective equipment is available at
the work place.
CAUTION!
Dirty or contaminated personnel protective equipment can cause illness.
Clean your personal protective equipment
after each use,
regularly once a week.
General check
Equipment Check OK
Guards Mounted, firmly bolted and not damaged
Signs,
Markers
Installed and legible
Date: checked by (signature):
Functional check
Equipment Check OK
Emergency-stop button When the Emergency-stop push button is activated, the metal band
saw must switch off.
Position switch
Protective cover saw
arch
The metal band saw only switches on when the protective cover is
being closed.
Date: checked by (signature):

Safety
Version 1.2.4 - 2022-10-26 13Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_1.fm
Personal protective equipment for special works
Protect your face and your eyes: Wear a safety helmet with facial protection when performing
work where your face and eyes are exposed to hazards.
Wear protective gloves when handling pieces with sharp edges.
Wear safety shoes when you assemble, disassemble or transport heavy components.
1.10 Safety during operation
CAUTION!
Danger due to inhaling dust and mist that is hazardous to health.
Dependent on the material which need to be processed and the used auxiliaries dusts
and mist may be caused which might impair you health.
Make sure that the generated health hazardous dusts and mist are safely sucked off at
the point of origin and is dissipated or filtered from the working area. To do so, use a
suitable extraction unit.
WARNING!
Before switching on the metal band saw make sure that there are
no dangers generated for persons,
no objects are damaged.
Avoid any unsafe work methods:
Make sure that nobody is endangered by your work.
The instructions mentioned in these operating instructions have to be strictly observed
during assembly, operation, maintenance and repair.
Do not work on the metal band saw, if your concentration is reduced, for example, because
you are taking medication.
Observe the accident prevention regulations issued by your Employers Liability Insurance
Association or other supervisory authorities responsible for your company.
Stay at the metal band saw until all movements have come to a complete standstill.
Use the prescribed personnel protective equipment. Make sure to wear a well-fitting work
suit and, if necessary, a hairnet.
Inform the supervisor about all hazards or faults.
1.11 Safety during maintenance
Inform the operators in good time of any maintenance and repair works.
Report all safety relevant changes and performance details of the metal band saw. Any
changes must be documented, the operating instructions updated and machine operators
instructed accordingly.
1.11.1 Disconnecting and securing the metal band saw
Disconnect the metal band saw from the electrical supply.
Attach a warning sign on the machine.

Safety
Version 1.2.4 - 2022-10-2614 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_1.fm
1.11.2 Using lifting equipment
WARNING!
The use of unstable lifting and load suspension equipment that might break under load
can cause severe injuries or even death.
Check that the lifting and load suspension gear has
sufficient load capacity
and that it is in perfect condition.
Observe the accident prevention regulations issued by your Employers Liability
Insurance Association or other supervisory authorities responsible for your company.
Fasten the loads properly.
Never walk under suspended loads!
1.11.3 Mechanical maintenance work
Remove or install protection safety devices before starting or after completing any maintenance
work; this include:
covers,
safety instructions and warning signs,
grounding cables.
If you remove protection or safety devices, refit them immediately after completing the work.
Check if they are working properly!
1.12 Accident report
Inform your supervisors and Optimum Maschinen Germany GmbH immediately in the event of
accidents, possible sources of danger and any actions which almost led to an accident (near
misses).
There are many possible causes for "near misses".
The sooner they are notified, the quicker the causes can be eliminated.
INFORMATION
We provide information about the dangers of working with and on the metal band saw in these
work descriptions.
1.13 Electronics
Have the machine and/or the electric equipment checked regularly. Immediately eliminate all
defects such as loose connections, defective wires, etc.
A second person must be present during work on live components to disconnect the power in
the event of an emergency. Disconnect the metal band saw immediately if there is a
malfunction in the power supply !
Comply with the required inspection intervals in accordance with the factory safety directive,
operating equipment inspection.
The operator of the machine must ensure that the electrical systems and operating equipment
are inspected with regards to their proper condition, namely,
by a qualified electrician or under the supervision and direction of a qualified electrician,
prior to initial commissioning and after modifications or repairs, prior to recommissioning
and at certain intervals.
The deadlines must be set so that arising, foreseeable defects can be detected in a timely
manner.
The relevant electro-technical rules must be followed during the inspection.

Safety
Version 1.2.4 - 2022-10-26 15Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_1.fm
The inspection prior to initial commissioning is not required if the operator receives confirmation
from the manufacturer or installer that the electrical systems and operating equipment comply
with the accident prevention regulations.
Permanently installed electrical systems and operating equipment are considered constantly
monitored if they are continually serviced by qualified electricians and inspected by means of
measurements in the scope of operation (e.g. monitoring the insulation resistance).
1.14 Inspection deadlines
Define and document the inspection deadlines for the machine in accordance with § 3 of the
Factory Safety Act and perform an operational risk analysis in accordance with § 6 of the Work
Safety Act. Also use the inspection intervals in the maintenance section as reference values.

Technical data
Version 1.2.4 - 2022-10-2616 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_2.fm
2 Technical data
The following information represents the dimensions and indications of weight and the
manufacturer‘s approved machine data.
Electrical connection S275N S275NV
Connection 3 x 400 V; 50 Hz; 1.1 KW 230 V; ~50 Hz; 1.5 KW
Cutting area S275N S275NV
 Possible cutting areas S275N and S275NV on page 31
General S275N S275NV
Cutting angle adjustment using the rotating saw arch 0° - 60°
Saw belt guide Saw belt guides supported on ball bearings
Raising the saw arch manually
Feed continuously adjustable
Saw band tension Manually using the hand wheel
Dimensions S275N S275NV
Weight of the metal band saw [kg] 185
Dimensions of saw blade [mm] 2480 x 27 x 0.9
 Dimensions S275N │ S275NV on page 20
Speed of saw belt S275N S275NV
[m/min] 45 | 90 20 - 90
Transmission ratio drive / saw belt pul-
ley [~50 Hz ]
1.30 1:20
Transmission ratio drive / saw belt pul-
ley [~60 Hz ]
01:40 1:20
Coolant pump S275N S275NV
Power 90 W 90 W
Speed [ min-1 ] 2850 2850
Tank capacity [ liter ] 10 10
Operating material S275N S275NV
Hydraulic cylinder Hydraulic oil, viscosity 32 - 46 as per DIN 51519, HLP Quality
Helical gear Mobilgear 636, viscosity 680 mm2/s (about 0,33 liters)
Spindle of the machine vice Commercial lubricating grease

Technical data
Version 1.2.4 - 2022-10-26 17Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_2.fm
2.1 Emissions
The generation of noise emitted by the metal band saw is 73 dB(A) at idle.
If the metal band saw is installed in an area where various machines are in operation, the noise
exposure (immission) on the operator of the metal band saw at the working place may exceed
80 dB(A).
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Furthermore, the noise emission depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The specified numerical value represents the emission level and does not necessarily a safe
working level.
Though there is a dependency between the degree of the noise emission and the degree of the
noise disturbance it is not possible to use it reliably to determine if further precaution measures
are required or not.
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations.
This information about the noise emission should, however, allow the machine operator to
evaluate the hazards and risks more easily.
CAUTION!
Depending on the overall noise exposure and the basic threshold values, machine
operators must wear appropriate hearing protection.
We generally recommend the use of noise protection and hearing protection.
Slide bearing Commercial lubricating grease
Coolant equipment Commercial lubricating and cooling agent
Environmental conditions S275N S275NV
Temperature 5-35 °C
Humidity 25 - 80 %
Operating material S275N S275NV

Delivery, interdepartmental transport, assembly and commissioning
Version 1.2.4 - 2022-10-2618 Translation of original instruction
EN
in-house_transport_en.fm
3 Delivery, interdepartmental transport, assembly and
commissioning
3.1 Notes on transport, installation, commissioning
Improper transport, installation and commissioning is liable to accidents and can cause damage
or malfunctions to the machine for which we do not assume any liability or guarantee.
Transport the scope of delivery secured against shifting or tilting with a sufficiently dimen-
sioned industrial truck or a crane to the installation site.
WARNING!
Severe or fatal injuries may occur if parts of the machine tumble or fall down from the
forklift truck or from the transport vehicle. Follow the instructions and information on the
transport box.
Note the total weight of the machine. The weight of the machine is indicated in the "Tech-
nical data" of the machine. When the machine is unpacked, the weight of the machine
can also be read on the rating plate.
Only use transport devices and load suspension gear that can hold the total weight of
the machine.
WARNING!
The use of unstable lifting and load suspension equipment that might break under load
can cause severe injuries or even death. Check that the lifting and load suspension gear
has sufficient load-bearing capacity and that it is in perfect condition.
Observe the accident prevention regulations issued by your Employers Liability Insur-
ance Association or other competent supervisory authority, responsible for your com-
pany. Fasten the loads properly.
3.1.1 General risks during internal transport
WARNING: TILTING DANGER!
The machine may be lifted unsecured by a maximum of 2 cm.
Employees must be outside the danger zone, i.e. the reach of the load.
Warn employees and advise them of the hazard.
Machines may only be transported by authorized and qualified persons. Act responsibly during
transport and always consider the consequences. Refrain from daring and risky actions.
Gradients and descents (e.g. driveways, ramps and the like) are particularly dangerous. If such
passages are unavoidable, special caution is required.
Before starting the transport check the transport route for possible danger points, unevenness
and faults.
Danger points, unevenness and disturbance points must be inspected before transport. The
removal of danger spots, disturbances and unevenness at the time of transport by other
employees leads to considerable dangers.
Careful planning of interdepartmental transport is therefore essential.

Version 1.2.4 - 2022-10-26 19Translation of original instruction
S275N | S275NV EN
S275N_S275NV_GB_3.fm
3.2 Unpacking the machine
Transport the metal band saw in its packing crate to a place near its final installation location
with a forklift before unpacking it.
If the packaging shows signs of possible transport damage, take the necessary precautions not
to damage the machine when unpacking. If any damage is discovered, the carrier and/or
shipper must immediately be notified of this fact to establish any claim which might arise.
Inspect the machine completely and carefully, making sure that all materials, such as shipping
documents, manuals and accessories supplied with the machine have been received.
Compare the delivery volume with the delivery note.
3.3 Requirements regarding the installation site
Organize the working area around the metal band saw according to the local safety regulations.
INFORMATION
In order to attain good functionality and a high processing accuracy as well as a long service life
of the machine, the place of installation should fulfil certain criteria.
Please observe the following points:
The device must only be installed and operated in a dry and well-ventilated place.
Avoid places nearby machines generating chips or dust.
The installation site must be free from vibrations also at a distance of presses, planing
machines, etc.
The substructure must be suitable for the metal band saw. Also make sure that the floor has
sufficient load bearing capacity and is level.
The ground must be prepared in a way that potential coolants cannot penetrate the floor.
Any parts sticking out such as stops, handles, etc. have to be secured by measures taken
by the customer if necessary in order to avoid endangering persons.
Provide sufficient space for the personnel preparing and operating the machine and
transporting the material.
Also make sure the machine is accessible for setting and maintenance works.
Provide for sufficient backlight (Minimum value: 500 lux, measured at the tool tip). At lower
illumination intensities, additional illumination has to be ensured e.g. by means of a
separate workplace lamp.
INFORMATION
The mains plug of the metal band saw must be freely accessible.

Version 1.2.4 - 2022-10-2620 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_3.fm
3.4 Dimensions S275N │ S275NV
A-A
AA
685
945
1400
985
510
550
815
1700
230
12
510
550
482
940
225
Schwerpunkt / Centre of gravity
910
