Optimum OPTIsaw S 131GH User manual

GB
OPTIMUM
MASCHINEN - GERMANY
Operating manual
Version 1.0.2
Metal belt saw

OPTIMUM
MASCHINEN - GERMANY
Version 1.0.2 dated 2013-07-15Page 2 Original operating instructions
S 131 GHGB
Table of contents
1 Safety
1.1 Safety warnings (warning notes) ..............................................................................................................6
1.1.1 Classification of hazards ...............................................................................................................6
1.1.2 Further ideograms.........................................................................................................................7
1.2 Proper use................................................................................................................................................7
1.3 Possible dangers caused by the metal belt saw.......................................................................................8
1.4 Qualifications of the staff ..........................................................................................................................8
1.4.1 Target group..................................................................................................................................8
1.4.2 Authorized persons .......................................................................................................................9
1.5 User positions...........................................................................................................................................9
1.6 Safety devices ........................................................................................................................................10
1.6.1 EMERGENCY-STOP pushbutton ...............................................................................................10
1.7 Saw arch.................................................................................................................................................11
1.7.1 Prohibition, warning and mandatory labels .................................................................................11
1.8 Safety check...........................................................................................................................................12
1.9 Personal protective equipment ...............................................................................................................12
1.10 Safety during work..................................................................................................................................13
1.11 Safety during maintenance.....................................................................................................................13
1.11.1 Switching off and securing the metal belt saw ............................................................................13
1.11.2 Use of the lifting equipment.........................................................................................................13
1.11.3 Mechanical maintenance work....................................................................................................14
1.12 Accident report........................................................................................................................................14
1.13 Electric....................................................................................................................................................14
2 Technical data
2.1 Power connection...................................................................................................................................15
2.2 Cutting field.............................................................................................................................................15
2.3 General...................................................................................................................................................15
2.4 Dimensions.............................................................................................................................................15
2.5 Saw blade speed....................................................................................................................................15
2.6 Environmental conditions........................................................................................................................15
2.7 Operating material..................................................................................................................................16
2.8 Emissions ...............................................................................................................................................16
2.9 Installation plan.......................................................................................................................................17
3 Assembly
3.1 Delivery volume......................................................................................................................................18
3.2 Storage...................................................................................................................................................18
3.3 Installation and assembly .......................................................................................................................18
3.3.1 Requirements to the installation site ...........................................................................................18
3.3.2 Mounting the machine stand .......................................................................................................18
3.3.3 Transport lock..............................................................................................................................20
3.3.4 Material stop and protective plate ...............................................................................................20
3.3.5 Mounting the V-belt housing........................................................................................................20
3.3.6 Mounting the V-belt .....................................................................................................................21
3.4 First use..................................................................................................................................................21
3.4.1 Checks ........................................................................................................................................21
3.4.2 Guide bearing saw blade.............................................................................................................22
3.4.3 Saw blade tension.......................................................................................................................22
4 Installation and function
4.1 Hydraulic feed.........................................................................................................................................23
4.2 Saw band guiding...................................................................................................................................23
4.3 Machine vice...........................................................................................................................................23
4.2 Saw belt tension .....................................................................................................................................24

OPTIMUM
MASCHINEN - GERMANY
Version 1.0.2 dated 2013-07-15 Page 3Original operating instructions
S 131 GH GB
4.3 Saw belt speed.......................................................................................................................................24
4.3.1 V-belts.........................................................................................................................................24
4.4 Belt guide bearings.................................................................................................................................24
5Operation
5.1 Safety.....................................................................................................................................................25
5.2 Control and indicating elements.............................................................................................................25
5.3 Insert work piece....................................................................................................................................26
5.4 Switching on metal belt saw...................................................................................................................26
5.5 Switching off the metal belt saw.............................................................................................................26
5.6 Re-starting metal belt saw......................................................................................................................26
5.7 Sawing of angles....................................................................................................................................27
5.8 Setting saw belt guiding .........................................................................................................................27
5.9 Speed of saw belt...................................................................................................................................27
5.9.1 Setting speed..............................................................................................................................28
5.9.2 Indicators for saw belt speeds.....................................................................................................29
6 Maintenance
6.1 Safety.....................................................................................................................................................30
6.1.1 Preparation..................................................................................................................................30
6.1.2 Restarting....................................................................................................................................31
6.2 Revision and maintenance.....................................................................................................................31
6.3 Repair.....................................................................................................................................................35
7 Ersatzteile - Spare parts - S131 GH
7.1 Ersatzteilzeichnung 1 von 4 - Parts drawing 1 of 4 ................................................................................36
7.2 Ersatzteilzeichnung 2 von 4 - Parts drawing 2 of 4................................................................................37
7.3 Ersatzteilzeichnung 3 von 4 - Parts drawing 3 of 4 ................................................................................38
7.4 Ersatzteilzeichnung 4 von 4 - Parts drawing 4 of 4................................................................................38
7.4.1 Ersatzteilliste - Spare parts list....................................................................................................39
7.5 Schaltplan - Wiring diagram...................................................................................................................42
7.5.1 Ersatzteilliste Elektrische Bauteile - Spare parts electrical components.....................................43
8 Malfunctions
8.1 Malfunctions on the metal belt saw........................................................................................................44
9 Appendix
9.1 Copyright................................................................................................................................................45
9.2 Terminology / Glossary ..........................................................................................................................45
9.3 Change information manual ...................................................................................................................45
9.4 Liability claims for defects / warranty......................................................................................................46
9.5 Note regarding disposal / options to reuse:............................................................................................46
9.5.1 Decommissioning........................................................................................................................47
9.5.2 Disposal of the packaging of new devices..................................................................................47
9.5.3 Disposing of the old device.........................................................................................................47
9.5.4 Disposal of electrical and electronic components.......................................................................47
9.5.5 Disposal of lubricants and coolants.............................................................................................48
9.6 Disposal..................................................................................................................................................48
9.7 RoHS , 2002/95/CE................................................................................................................................48
9.8 Product follow-up....................................................................................................................................49
9.9 EC - declaration of conformity................................................................................................................50

OPTIMUM
MASCHINEN - GERMANY
Version 1.0.2 dated 2013-07-15Page 4 Original operating instructions
S 131 GHGB
Preface
Dear customer,
Thank you very much for purchasing a product made by OPTIMUM.
OPTIMUM metal working machines offer a maximum of quality, technically optimum solutions and con-
vince by an outstanding price performance ratio. Continuous enhancements and product innovations
guarantee state-of-the-art products and safety at any time.
Before commissioning the machine please thoroughly read these operating instructions and get familiar with
the machine. Please also make sure that all persons operating the machine have read and understood
the operating instructions beforehand.
Keep these operating instructions in a safe place nearby the machine.
Information
The operating instructions include indications for safety-relevant and proper installation, operation and
maintenance of the machine. The continuous observance of all notes included in this manual guarantee the
safety of persons and of the machine.
The manual determines the intended use of the machine and includes all necessary information for its eco-
nomic operation as well as its long service life.
In the paragraph "Maintenance" all maintenance works and functional tests are described which the opera-
tor must perform in regular intervals.
The illustration and information included in the present manual can possibly deviate from the current state of
construction of your machine. Being the manufacturer we are continuously seeking for improvements and
renewal of the products. Therefore, changes might be performed without prior notice. The illustrations of the
metal belt saw may be different from the illustrations in these instructions with regard to a few details.
However, this does not have any influence on the operability of the metal belt saw.
Therefore, no claims may be derived from the indications and descriptions. Changes and errors are reser-
ved!
Your suggestion with regard to these operating instructions are an important contribution to optimising our
work which we offer to our customers. For any questions or suggestions for improvement, please do not
hesitate to contact our service department.
If you have any further questions after reading these operating instructions and you are not able to
solve your problem with a help of these operating instructions, please contact your specialised
dealer or directly the company OPTIMUM.
Optimum Maschinen Germany GmbH
Dr.- Robert - Pfleger - Str. 26
D-96103 Hallstadt
Fax (+49) 0951 / 96 555 - 888
Mail: [email protected]
Internet: www.optimum-maschinen.de

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15 Page 5Original operating instructions
S 131 GH GB
1 Safety
Glossery of symbols
This part of the operation manual
does explain the meaning and how to use warning references contained in this operation
manual,
does explain how to use the metal belt saw,
highlights the dangers that might arise for you and others if these instructions are not fol-
lowed thoroughly,
informs you on how to prevent dangers.
In addition to this operating manual, please note
applicable laws and regulations,
legal regulations for preventing an accident,
the prohibition, warning and mandatory signs as well as the warning notes on the metal belt
saw.
European standard must be kept during installation, operation, maintenance and repair of the
metal belt saw.
If European standards are not applied at the national legislation of the country of destination,
the specific applicable regulations of each country are to be observed.
If necessary, the required measures must be taken to comply with the specific regulations of
each country before the metal belt saw is used for the first time.
ALWAYS KEEP THE OPERATING MANUAL CLOSE TO THE METAL BELT SAW FOR
FURTHER REFERENCE.
INFORMATION
If you are not able to solve a problem using this manual, please do not hesitate to contact us for
further professional advice:
Optimum Maschinen Germany GmbH
Dr. Robert-Pfleger-Str. 26
D- 96103 Hallstadt
E-Mail: [e-mail]
gives further advice
 calls on to get in action
enumeration

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15Page 6 Original operating instructions
S 131 GHGB
1.1 Safety warnings (warning notes)
1.1.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (ideogram) and warning signs for each specific danger and its (possi-
ble) consequences.
ideogram warning alert definition/consequences
DANGER! Threatening danger that will cause serious injury or death to
people.
WARNING! Risk: A danger might cause serious injury or death to a person.
CAUTION! Danger or unsafe procedure that might cause injury to people or
damage to property.
ATTENTION!
Situation that could cause damage to the machine and to the
product and other types of damages.
No risk of injury to people.
INFORMATION
Application advice and other important or useful information and
notes.
No dangerous or harmful consequences for people or objects.
In case of certain dangers, we replace the ideogram by
or
general
danger with a warning of injuries of hands hazardous electrical
voltage
rotating parts.

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15 Page 7Original operating instructions
S 131 GH GB
1.1.2 Further ideograms
1.2 Proper use
Use
WARNING!
Improper use of the metal belt saw
will endanger personnel,
will endanger the machine and other property of the operator,
may affect proper operation of the machine.
The metal belt saw is designed and manufactured to be used in environments in which there is
no potential danger of explosion.
The metal belt saw is designed and manufactured to saw cold metal, cast material and plastics
or other material that are not health hazardous and do not generate dust.
The metal belt saw must not be used on wood.
The pieces to be cut must be of a shape that will allow them to be securely attached in the
workholder vice and ensure that the piece does not come loose when it is being sawed.
The metal belt saw must only be installed and operated in a dry and well-ventilated place.
Improper use!If the metal belt saw is used in any way other than prescribed above, modified without autoriza-
tion of Optimum Maschinen Germany GmbH, then the metal belt saw is being used improperly.
We do not take liability for any damages caused through improper use.
We would like to stress that any modifications to the construction, or technical or technological
modifications that have not been authorized by Optimum Maschinen Germany GmbH will also
render the guarantee null and void.
It is also part of proper use that
the maximum values of the metal belt saw are complied with,
the operating manual is constantly observed,
inspection and maintenance instructions are observed.
 „Technical data“ on page 15
The decisive factor for achieving efficient cutting and the necessary angular tolerance is the
correct choice of parameters such as the saw belt, feed, cutting pressure, cutting speed and
cooling agent.
Activation forbidden! Pull the main plug! Use safety glasses! Use ear protection! Use protective gloves!
Use protective boots! Wear a safety suit! Protect the
environment! Contact address

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15Page 8 Original operating instructions
S 131 GHGB
WARNING!
Very serious injury.
It is forbidden to make any modifications or alternations to the operating values of the
metal belt saw! They could endanger employees and cause damage to the metal belt
saw.
1.3 Possible dangers caused by the metal belt saw
The metal belt saw has undergone a safety inspection (analysis of danger with assessment of
risks). Design and construction based on this analysis were carried out with the latest techno-
logical advances.
Nonetheless, there remains a residual risk, since the metal belt saw operates
with electrical voltage and current,
with a continous saw belt.
We have used construction resources and safety techniques to minimize the health risk to per-
sons resulting from these hazards.
If the metal belt saw is used and maintained by employees who are poorly qualified, then there
might be a risk resulting from incorrect operation and unsuitable maintenance of the metal belt
saw.
INFORMATION
Everyone involved in the assembly, commissioning, operation and maintenance must
be duly qualified,
strictly follow this operating manual.
Due to improper use
there is a risk for the employee,
the metal belt saw and further property might be endangered,
the function of the metal belt saw could be affected.
Always disconnect the metal belt saw if cleaning or maintenance work is being carried out.
WARNING!
THE METAL BELT SAW IS TO BE USED ONLY WITH THE SAFETY DEVICES ACTIVATED.
Disconnect the metal belt saw immediately whenever you detect a failure in the safety
device or when they are not mounted!
All additional installations carried out by the operator must incorporate the safety
devices prescribed.
This is your responsibility being the operator!
 „Safety devices“ on page 10
1.4 Qualifications of the staff
1.4.1 Target group
This manual applies to
the operators,
the users,
the maintenance staff.
Therefore, the warning notes refer to both operation and maintenance of the metal belt saw.
Determine clearly and make a permament decision in who will be responsible for the different
activities on the machine (operation, maintenance, and repair).
Vague and unclear assignment of responsibilities constitute a safety hazard!

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15 Page 9Original operating instructions
S 131 GH GB
Always diconnect the main plug of the metal belt saw and secure the metal belt saw against
being restarted.
1.4.2 Authorized persons
WARNING!
Incorrect use and maintenance of the metal belt saw constitute a danger for the staff,
objects and the environment.
Only authorized persons may operate on the metal belt saw!
Persons authorized to operate and maintain should be trained technical staff and instructed by
the ones who are working for the operator and for the manufacturer.
The operator must
Obligations of
the operator
train the staff,
instruct the staff in regular intervals (at least once a year) on
- all safety standards that apply to the machine,
- the operation,
- accredited technical guidelines,
check the knowledge of the staff,
document training/instructions,
require the staff to confirm participation in training/instructions by means of signature,
check if the staff is aware of safety rules and dangers in the workplace so that they observe
the operating manual.
The user must
Obligations of
the user
have followed a training on the operation of the metal belt saw,
know the function and performance,
before commissioning
- have read and understand the operating manual,
- be familiar with all safety devices and regulations.
further
requirements
to the qualifi-
cation
For working on the following machine parts, additional requirements are being applied:
Electrical parts or operating agents: shall only be performed by an electrician or under the
guidance and supervision of an electrician.
Before starting work on electrical parts or operating agents, following measures are to be
performed in the following order.
- disconnect all poles
- secure against switching on
- check dead circuit
1.5 User positions
The user must stand beside the metal belt saw.
INFORMATION
The mains plug of the metal belt saw has to be freely
accessible.
Img.1-1: User positions

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15Page 10 Original operating instructions
S 131 GHGB
1.6 Safety devices
Only operate the metal belt saw with properly functioning safety devices.
Stop the metal belt saw immediately if there is a failure in safety device or if it is not functioning
for any reason.
It is your responsibility!
If a safety device has been activated or has failed, the metal belt saw must only be used when
the cause of the failure has been removed,
it has been verified that there is no resulting danger for personnel or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other persons working on the metal belt saw. The possible consequences
are the following
injuries due to components or parts of components flying off at high speed,
contact with rotating and revolting parts,
fatal electrocution,
The metal belt saw includes the following safety devices:
• An EMERGENCY STOP pushbutton,
• A protective cover of the V-belts,
• A saw blade housing including protective cover at the rear side.
WARNING!
The separating protective covers which are made available and delivered together with
the machine are designed to reduce the risk of workpieces or fragments of tools or
workpieces flying off at high speed - however, this cannot be completely avoided.
1.6.1 EMERGENCY-STOP pushbutton
The EMERGENCY STOP pushbutton
switches off the metal belt saw.
INFORMATION
Turn the EMERGENCY STOP pushbutton
clockwise after actuating it in order to be
able to switch the metal belt saw on again.
Img.1-2: EMERGENCY-STOP pushbutton
EMERGENCY-STOP
pushbutton

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15 Page 11Original operating instructions
S 131 GH GB
1.7 Saw arch
The arch of the metal belt saw is provided
with a protective cover. The protective
cover covers the belt guide reels and the
revolting saw blade.
WARNING!
Danger of injury! The teeth of the saw
blade are sharp. Take great care when
opening the protective cover at the rear
to change the saw blade.
Img.1-3: saw arch housing
Close and screw all protective covers before restarting the metal belt saw.
1.7.1 Prohibition, warning and mandatory labels
INFORMATION
All warning labels must be legible.
Check them regularly.
Positions of labels on the metal belt saw:
Img.1-4: Metal belt saw S 130 GH
Check the metal belt saw once per shift. Inform the person responsible immediately of any
defect or change in the operating function.
Check all safety devices
at the beginning of each shift (with the machine stopped),
once a week (with the machine in operation),
after every maintenance and repair work.
Check that the prohibition, warning and information labels as well as the markings on the metal
belt saw
are legible (clean them, if necessary),
are complete.
saw arch

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15Page 12 Original operating instructions
S 131 GHGB
1.8 Safety check
Check the metal belt saw at least once per shift. Immediately inform the person responsible of
any damage, defect or change in operating function.
Check all safety devices
• at the beginning of each shift (at continuous operation),
• once a week (with the machine in operation),
• after any maintenance and repair work.
Check that prohibition, warning and information signs and the labels on the metal belt saw
• can be legible (clean them, if necessary),
• are complete.
INFORMATION
Use the following table for organizing the checking.
1.9 Personal protective equipment
For certain work, personal protective equipment is required, such as:
safety helmet,
protective glasses or face guard,
protective gloves,
safety shoes with steel caps,
ear protection.
Before starting work, make sure that the prescribed personal protective equipment is available
at the workplace.
CAUTION!
Dirty or eventually contaminated personal equipment might cause desease. Clean your
personal protective equipment after each use and regularly once a week.
Personal protective equipment for special work
Protect your face and your eyes: Wear a safety helmet with a face guard for every work, espe-
cially for the kind of work where your face and eyes are exposed to hazards.
General check
Equipment Check OK
Protective covers Fitted, firmly bolted and not damaged
Labels,
markings Installed and legible
Date: Checked by (signature):
Run test
Equipment Check OK
EMERGENCY-STOP
switch The metal belt saw has to switch off when the EMERGENCY- STOP switch is activated.
Date: Checked by (signature):

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15 Page 13Original operating instructions
S 131 GH GB
Use protective gloves when lifting or handling pieces with sharp edges.
Wear safety shoes when fitting, dismatelling or transporting heavy compenents.
1.10 Safety during work
In the description of work with and on the metal belt saw we highlight the dangers specific to
that work.
CAUTION!
Before activating the metal belt saw, double check that this will
not endanger other people,
not cause damage to equipment.
Avoid unsafe working practice:
Make sure that your work does not endanger anyone.
The instructions of this manual must be observed strictly during assembly, operation, main-
tenance and repair.
Do not work on the metal belt saw if your concentration is reduced, for example, because
you are taking medication.
Observe the regulations for the prevention of accidents issued by your association for the
prevention of accidents and safety in the workplace or other inspection authorities.
Stay at the metal belt saw until all rotating parts have come to a halt.
Use the prescribed personal protective equipment. Make sure you wear a well-fitting work
suit and hairnet, if necessary.
Inform the inspector of any danger and failure.
1.11 Safety during maintenance
Report and
documentany
changes
Inform the operators on time of any maintenance and repair work.
Report all safety relevant changes or performance details of the metal belt saw. Document all
changes, have the operation manual changed accordingly and train the machine operators.
1.11.1 Switching off and securing the metal belt saw
Unplug the metal belt saw from electrical supply and secure the metal belt saw against restart-
ing by a padlock on the main switch.
Place a warning sign on the machine.
1.11.2 Use of the lifting equipment
WARNING!
Use of unstable lifting and load-suspension gear that might break under load can cause
very serious injuries or even death.
Check the lifting and load-suspension gear on
sufficient load capacity,
perfect condition.
Observe the regulations for the prevention of accidents issued by your accociation for
the prevention of occupational accidents and safety in the workplace or other inspection
authorities.
Fasten the loads properly.
Do not walk under lifted loads!

OPTIMUM
MASCHINEN - GERMANY
Safety
Version 1.0.2 dated 2013-07-15Page 14 Original operating instructions
S 131 GHGB
1.11.3 Mechanical maintenance work
Remove all protection and safety devices before starting maintenance work and re-install them
once the work has been completed, such as
covers,
safety indications and warning signs,
earth (ground) cables.
If you remove protection or safety devices, refit them immediately after completing the work.
Check if they are working properly!
1.12 Accident report
Inform your superiors and Optimum Maschinen Germany GmbH immediately in case of acci-
dents, possible sources of danger and any action which almost lead to an accident "near
misses".
"Near misses" may have many possible causes.
The sooner they are notified, the faster these causes can be eleminated.
INFORMATION
In the description of execution of work with and on the metal belt saw we highlight the dangers
specific to that kind of work.
1.13 Electric
Have the machine and/or the electrical equipment checked regularly, at least every six months.
Eliminate immediately all defects such as loose connections, defective wires, etc.
A second person must be present during work on live components, to disconnect the power in
case of an emergency.
Disconnect the metal belt saw immediately if there is a malfunction in the power supply!
 „Maintenance“ on page 30

OPTIMUM
MASCHINEN - GERMANY
Technical data
Version 1.0.2 dated 2013-07-15 Page 15Original operating instructions
S 131 GH GB
2 Technical data
The following information give the dimensions and weight and is the manufacturer‘s authorized
machine data.
2.1 Power connection
total connection rate 230 V; 50 Hz; 0,5 kW
protection mode IP 54
2.2 Cutting field
900round max. 130 mm
900rectangular max. 100 x 150 mm
450round max. 94 mm
450rectangular max. 94 x 78 mm
600round max. 45 mm
600rectangular max. 56 x 45 mm
cutting angle -450- 600
2.3 General
Cutting angle adjustment Using the rotating saw arch
Saw belt guide Belt guiding reels on ball bearings
Raising the saw arm Manually
Feed Variable adjustable
Tension of saw belt Manually using th hand wheel
Material tension Manual with quick-action vice
2.4 Dimensions
Height of working area [mm] 1750
Weight of metal belt saw [kg] 81
Dimensions of saw band [mm] 1638 x 13 x 0,65
2.5 Saw blade speed
[m/min] 22 31
55
2.6 Environmental conditions
temperature 5-35 °C
humidity 5 - 80 %

OPTIMUM
MASCHINEN - GERMANY
Technical data
Version 1.0.2 dated 2013-07-15Page 16 Original operating instructions
S 131 GHGB
2.8 Emissions
The emission of the metal belt saw is below 78 dB(A). If the metal belt saw is installed in an
area where various machines are in operation, the acoustic influence (immission) on the opera-
tor of the metal belt saw may exceed 85 dB(A).
INFORMATION
This numeric value had been measured on a new machine under conventional operating condi-
tions. Depending on the age or wear of the machine, the noise behavior of the machine might
change.
Furthermore, the extent of the noise emission is also depending on manufacturing
influence factors, such as speed, material and clamping conditions.
INFORMATION
The mentioned numerical value is an emission level and not necessarily a safe
working level.
Unless the degree of noise emission and the degree of noise disturbance are depending on
one another it is not possible to use it in order to reliably determine if it is necessary to take fur-
ther preventive measures or not.
The following factors influence the actual degree of the noise disturbance of the
operator:
Characteristics of the working chamber, e.g. size or damping behavior,
Other noise sources, e.g. the number of machines,
Other processes proceeding nearby and the period during which the operator is exposed to
the noise.
Furthermore, the admissible pollution level may be different from one country to another due to
the national regulations.
This information regarding the noise emission should allow the operator of the machine to per-
form a better evaluation of the endangerments and risks.
CAUTION!
The machine operator has to wear an appropriate ear protection depending on the
overall stress caused by noise and on the basic limit values.
We generally recommend using a sound and ear protection.
2.7 Operating material
Hydraulic cylinder Hydraulic oil, viscosity from 32 to 46
according to DIN 51519, quality HLP
Spindle of the machine vice Commercial friction bearing grease
Friction bearing Commercial friction bearing grease

OPTIMUM
MASCHINEN - GERMANY
Technical data
Version 1.0.2 dated 2013-07-15 Page 17Original operating instructions
S 131 GH GB
2.9 Installation plan
Img.2-1: Installation plan

OPTIMUM
MASCHINEN - GERMANY
Assembly
Version 1.0.2 dated 2013-07-15Page 18 Original operating instructions
S 131 GHGB
3 Assembly
INFORMATION
The metal belt saw is delivered pre-assembled.
3.1 Delivery volume
Check immediately upon delivery of the metal belt saw if there are any transport damages or
loosened fastening screws.
Metal belt saw
Saw belt
Material stop
Protective cover for V-belts
V-belt
Fixing material
Operating instructions
3.2 Storage
ATTENTION!
Improper storage may cause importants parts to be damaged or destroyed.
Store packed or unpacked parts only under the provided external conditions
 „Environmental conditions“ on page 15
Consult Optimum Maschinen Germany GmbH if the metal belt saw and accessories have to be
stored for a period of over three months or under different ambience conditions to those given
here.
3.3 Installation and assembly
3.3.1 Requirements to the installation site
Organize the work area around the metal belt saw in accordance with the local safety regula-
tions.  „Dimensions“ on page 15
Operation, maintenance and repair in the work area must not be hindered.
INFORMATION
The mains plug of the metal belt saw has to be freely accessible.
3.3.2 Mounting the machine stand
CAUTION!
Danger of crushing and tilting.
When performing the below described, please act with caution.

OPTIMUM
MASCHINEN - GERMANY
Assembly
Version 1.0.2 dated 2013-07-15 Page 19Original operating instructions
S 131 GH GB
Screw the rubber feet into the side parts.
Screw the side parts together. To do so,
use the fixing material included in the
delivery.
Screw the side parts together. To do so,
use the fixing material included in the
delivery.
After mounting check if the machine
stand is stable.
Img.3-1: Assembly 1
Mount the axle suspension on the side
part. To do so, use the fixing material
included in the delivery.
Img.3-2: Assembly 2
Position the collecting tray on the material stand.
Make sure that the holes of the collecting tray and of
the material stand are superposed.
Lift the metal belt saw on the machine stand.
Fix a load suspension gear around the machine vice
and the lateral part of the metal belt saw. Make sure
that the load attachment is balanced.
Use an appropriate hoisting device, e.g. a crane.
Make sure that the load attachment does not damage
any attachments or cause defects in paintwork.
Img.3-3: Assembly 3

OPTIMUM
MASCHINEN - GERMANY
Assembly
Version 1.0.2 dated 2013-07-15Page 20 Original operating instructions
S 131 GHGB
Fix the metal belt saw on the machine stand using
hexagon bolts. To do so, use the fixing material
included in the delivery.
CAUTION!
Danger of crushing and tilting. The assembly of the
metal belt saw must be performed by at least 2
persons.
Img.3-4: Assembly 4
3.3.3 Transport lock
Disassemble the transportation lock at the front side of
the saw bow.
Img.3-5: Disassembly of the transportation lock
3.3.4 Material stop and protective plate
Mount the material stop.
Fix the material stop on the vice using a threaded pin.
Shift the saw stop on the stop bar.
Fix the saw stop using the stop fixture.
Mount the protective plate onto the vice.
Img.3-6: Assembly of material stop and protective
plate
3.3.5 Mounting the V-belt housing
Mount the V-belt housing on the metal belt saw.
To do so, use the fixing material included in
the delivery.
Img.3-7: Assembly V-belt housing
