Optimuss os 2+ User manual

Quick Start Guide
Please read the safety instructions carefully before using the OPTIMUSS OS2+.
The manufacturer takes no responsibility for incorrect handling of the OPTIMUSS OS2+.
* For sufficient ventilation,leave enough space.
* If unused for a prolonged amount of time,turn the power OFF.
* Do not cover the OPTIMUSS OS 2's+ ventilation openings with items such as newpapers,tablecloths, curtains etc.
* Do not expose the OPTIMUSS OS2+ to liquid,moisture,direct sunlight and extreme weather.
* Do not place open flame sources,such as lighted candles, near or on the OPTIMUSS OS2+.
* Do not place any containers with liquid,such as vases, on the OPTIMUSS OS2+.
* Do not connect or modify cables while the OPTIMUSS OS2+ is connected to the power.
* Do not remove the cover. Risk of electric shock!
* Do not touch the OPTIMUSS OS2+ with wet hands. Risk of electric shock!
* Do not put any metal items into the slots or ventilation openings.
* Please disconnect your OPTIMUSS OS2+ from the main power during thunder or heavy storms.
* Disconnect the main power cable if the power cord is damaged.
* Cleaning : Disconnect the main power cord before cleaning the cover. Use a slightly damp cloth without cleaning agents.
* Connect the OPTIMUSS OS2+ only to suitable sockets. Do not allow overloads to occur.
* The socket-outlet shall be installed near the equipment and shall be easily accessible.
WARNING!
* Modifications and changes to the OPTIMUSS OS2+ lead to loss of warranty.
* Incorrect software installation leads to loss of warranty.
* This instruction might be modified without prior notice.
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered
by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste stream
via designated collection facilities appointed by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city office,
waste disposal service or the shop where you purchased the product.
SAFETY INSTRUCTIONS
DISPOSAL INSTRUCTIONS
- 2 x HD DVB-S / DVB-S2 Satellite Tuner
- MPEG-4, H.264 & MPEG-2 Compliant
-
Broadcom 1300 MHz Mips processor(BCM 7356)
- 256 MB NAND Flash /
8MB NOR Flash / 1 GB DDR3 RAM
- Advanced Linux Operating System
-
10/100/1000 Mbps Full Duplex Ethernet Interface
- 1 Common Interface & 1 Smart Card Reader
- 3 USB 2.0 Port (1 x in Front & 2 x Rear)
- Support Internal 2.5" SATA HDD
- HDMI & Component Output(YPbPr)
- 12 character VFD display with scrolling for local time or channel name
- Unlimited Channel Memory
- Super Sensitive Tuner
- Dolby Digital Plus, Dolby True HD supported
- S/PDIF Output for Digital Audio and Dolby AC-3 Bit Stream Output
- Firmware/ Software Upgrade: Through (Ethernet, USB Memory Stick)
- Multi-Language OSD Menus
- User Friendly EPG (Electronic Program Guide)
- External Power Supply
- Very Low stand-by Power Consumption (<0.5W)
ACCESSORIES
Please check that the following contents are enclosed :
AAA X 2 BATTERIES
Power Supply
Remote control unit
SATA Cable
Twin tuner HD satellite receiver
Quick Start Guide
Quick Start Guide
OS 2plus
OS 2
plus
OS 2plus

Quick Start Guide
Please read the safety instructions carefully before using the OPTIMUSS OS2+.
The manufacturer takes no responsibility for incorrect handling of the OPTIMUSS OS2+.
* For sufficient ventilation,leave enough space.
* If unused for a prolonged amount of time,turn the power OFF.
* Do not cover the OPTIMUSS OS 2's+ ventilation openings with items such as newpapers,tablecloths, curtains etc.
* Do not expose the OPTIMUSS OS2+ to liquid,moisture,direct sunlight and extreme weather.
* Do not place open flame sources,such as lighted candles, near or on the OPTIMUSS OS2+.
* Do not place any containers with liquid,such as vases, on the OPTIMUSS OS2+.
* Do not connect or modify cables while the OPTIMUSS OS2+ is connected to the power.
* Do not remove the cover. Risk of electric shock!
* Do not touch the OPTIMUSS OS2+ with wet hands. Risk of electric shock!
* Do not put any metal items into the slots or ventilation openings.
* Please disconnect your OPTIMUSS OS2+ from the main power during thunder or heavy storms.
* Disconnect the main power cable if the power cord is damaged.
* Cleaning : Disconnect the main power cord before cleaning the cover. Use a slightly damp cloth without cleaning agents.
* Connect the OPTIMUSS OS2+ only to suitable sockets. Do not allow overloads to occur.
* The socket-outlet shall be installed near the equipment and shall be easily accessible.
WARNING!
* Modifications and changes to the OPTIMUSS OS2+ lead to loss of warranty.
* Incorrect software installation leads to loss of warranty.
* This instruction might be modified without prior notice.
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered
by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste stream
via designated collection facilities appointed by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city office,
waste disposal service or the shop where you purchased the product.
SAFETY INSTRUCTIONS
DISPOSAL INSTRUCTIONS
- 2 x HD DVB-S / DVB-S2 Satellite Tuner
- MPEG-4, H.264 & MPEG-2 Compliant
-
Broadcom 1300 MHz Mips processor(BCM 7356)
- 256 MB NAND Flash /
8MB NOR Flash / 1 GB DDR3 RAM
- Advanced Linux Operating System
-
10/100/1000 Mbps Full Duplex Ethernet Interface
- 1 Common Interface & 1 Smart Card Reader
- 3 USB 2.0 Port (1 x in Front & 2 x Rear)
- Support Internal 2.5" SATA HDD
- HDMI & Component Output(YPbPr)
- 12 character VFD display with scrolling for local time or channel name
- Unlimited Channel Memory
- Super Sensitive Tuner
- Dolby Digital Plus, Dolby True HD supported
- S/PDIF Output for Digital Audio and Dolby AC-3 Bit Stream Output
- Firmware/ Software Upgrade: Through (Ethernet, USB Memory Stick)
- Multi-Language OSD Menus
- User Friendly EPG (Electronic Program Guide)
- External Power Supply
- Very Low stand-by Power Consumption (<0.5W)
ACCESSORIES
Please check that the following contents are enclosed :
AAA X 2 BATTERIES
Power Supply
Remote control unit
SATA Cable
Twin tuner HD satellite receiver
Quick Start Guide
Quick Start Guide
OS 2plus
OS 2plus
OS 2plus

Quick Start Guide
Please read the safety instructions carefully before using the OPTIMUSS OS2+.
The manufacturer takes no responsibility for incorrect handling of the OPTIMUSS OS2+.
* For sufficient ventilation,leave enough space.
* If unused for a prolonged amount of time,turn the power OFF.
* Do not cover the OPTIMUSS OS 2's+ ventilation openings with items such as newpapers,tablecloths, curtains etc.
* Do not expose the OPTIMUSS OS2+ to liquid,moisture,direct sunlight and extreme weather.
* Do not place open flame sources,such as lighted candles, near or on the OPTIMUSS OS2+.
* Do not place any containers with liquid,such as vases, on the OPTIMUSS OS2+.
* Do not connect or modify cables while the OPTIMUSS OS2+ is connected to the power.
* Do not remove the cover. Risk of electric shock!
* Do not touch the OPTIMUSS OS2+ with wet hands. Risk of electric shock!
* Do not put any metal items into the slots or ventilation openings.
* Please disconnect your OPTIMUSS OS2+ from the main power during thunder or heavy storms.
* Disconnect the main power cable if the power cord is damaged.
* Cleaning : Disconnect the main power cord before cleaning the cover. Use a slightly damp cloth without cleaning agents.
* Connect the OPTIMUSS OS2+ only to suitable sockets. Do not allow overloads to occur.
* The socket-outlet shall be installed near the equipment and shall be easily accessible.
WARNING!
* Modifications and changes to the OPTIMUSS OS2+ lead to loss of warranty.
* Incorrect software installation leads to loss of warranty.
* This instruction might be modified without prior notice.
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered
by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste stream
via designated collection facilities appointed by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city office,
waste disposal service or the shop where you purchased the product.
SAFETY INSTRUCTIONS
DISPOSAL INSTRUCTIONS
- 2 x HD DVB-S / DVB-S2 Satellite Tuner
- MPEG-4, H.264 & MPEG-2 Compliant
-
Broadcom 1300 MHz Mips processor(BCM 7356)
- 256 MB NAND Flash /
8MB NOR Flash / 1 GB DDR3 RAM
- Advanced Linux Operating System
-
10/100/1000 Mbps Full Duplex Ethernet Interface
- 1 Common Interface & 1 Smart Card Reader
- 3 USB 2.0 Port (1 x in Front & 2 x Rear)
- Support Internal 2.5" SATA HDD
- HDMI & Component Output(YPbPr)
- 12 character VFD display with scrolling for local time or channel name
- Unlimited Channel Memory
- Super Sensitive Tuner
- Dolby Digital Plus, Dolby True HD supported
- S/PDIF Output for Digital Audio and Dolby AC-3 Bit Stream Output
- Firmware/ Software Upgrade: Through (Ethernet, USB Memory Stick)
- Multi-Language OSD Menus
- User Friendly EPG (Electronic Program Guide)
- External Power Supply
- Very Low stand-by Power Consumption (<0.5W)
ACCESSORIES
Please check that the following contents are enclosed :
AAA X 2 BATTERIES
Power Supply
Remote control unit
SATA Cable
Twin tuner HD satellite receiver
Quick Start Guide
Quick Start Guide
OS 2plus
OS 2plus
OS 2plus

REMOTE CONTROL UNIT
MUTE : Mutes or unmutes the audio temporarily.
POWER : Switches between operation and standby.
HELP : This provides users with a quick guide of using OPTIMUSS OS2+.
HOME : Instantly moves to the top of the menu list.
END : Instantly moves to the bottom of the menu list.
TELETEXT : Switch between the teletext and TV modes.
SUBTITLE : Display the subtitle language list.
Zoom : To zoom the screen In/Out.
LIST: Open recorded file menu.
MEDIA : Open media file list.
TIMER : Start timer function.
VOL. +/- : Increase/Decrease the volume (Volume up/down).
EPG : Displays the Electronic Program Guide (EPG) information if provided.
AUDIO : Select an audio track and a sound mode.
PROGRAM +/- : Navigates through the scanned channel list.
MENU : Open main menu & select sub menu using by navigation buttons.
EXIT : Close and return to the previous menu and screen.
Navigation Keys : Navigates up/down and left/right on the menu options. Up/down keys are used to call up the channel list.
OK : Select a menu, or confirms the selected operation. Also displays the channel list while watching a programme.
SAT : Open channel list according to satellite.
INFO : Displays the Electronic Program Guide (EPG) information if provided.
NUMERIC KEY (0~9) : Control the numerical operation and change the Channel/Service number directly.
PREV (<) : Return to the previous channel/service or move to the end of the Service List or the Play List.
NEXT (>) : Go to the next channel/service or move to the beginning of the Service List or the Play List.
COLOR BUTTONS : Activates certain menu functions. Usage instructions are shown in each OSD menu.
PVR FUNCTIONS : Control the PVR functions in PVR Mode.
TV : Switch to TV mode.
RADIO : Switch to Radio mode.
VIEWS
INSTALLATION
1 Power Button
Switch between operation and standby modes.
2 Display (VFD)
Display current menu information and channel name etc.
3 Program Up/Down Button
Navigates through the scanned channel list.
4 Volume Up/Down Button
Increase/Decrease the volume (Volume up/down).
5 USB
Connect to the External HDD or USB storage
with USB cable. (Max. 500mA)
6 Smart card reader
To insert smart card
7 Common Interface Slot
A slot for one CI module with a Smartcard.
Front view
1LNB1 INPUT
1st satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
2LNB2 INPUT
2nd satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
3S/PDIF
Connect with an appropriate optical cable to your HiFi system.
4Audio / Video Output
Connect to TV using RCA cable.
5Component (YPbPr)
Connect to TV using Component cable.
6HDMI
To connect HDMI cable for your HD TV.
7Ethernet
Communication port via HTTP, FTP, NFS, Telnet and
Samba to access your Hard Drive or to upload channel lists.
This is also used to update OPTIMUSS OS 2's + software.
8 2x USB
Connect to the External HDD or USB storage
with USB cable (Max. 500mA).
9 RS232
RS232C serial data port.
10 External Power Supply
Connect the power Supply (12V / 3.5A).
11 Power Switch
Turn AC Power On/Off.
12 Cooling Fan
with speed control function
Rear view
1. Please refer to the Safety Instruction before powering on the device.
2. Connect OPTIMUSS OS2+ to your TV set using HDMI cable or a RCA cable, etc.
3. Connect the coaxial cable (from the satellite dish) to the LNB INPUT of OPTIMUSS OS2+.
4. Power on the OPTIMUSS OS2+.
5. After booting up, Initial setup menu comes up for the installation according to your TV settings and
Antenna settings.
Use an HDMI or Component cable in order to view HD.
16
7
89
11
10 12
4
3
5
HDMI RCA

REMOTE CONTROL UNIT
MUTE : Mutes or unmutes the audio temporarily.
POWER : Switches between operation and standby.
HELP : This provides users with a quick guide of using OPTIMUSS OS2+.
HOME : Instantly moves to the top of the menu list.
END : Instantly moves to the bottom of the menu list.
TELETEXT : Switch between the teletext and TV modes.
SUBTITLE : Display the subtitle language list.
Zoom : To zoom the screen In/Out.
LIST: Open recorded file menu.
MEDIA : Open media file list.
TIMER : Start timer function.
VOL. +/- : Increase/Decrease the volume (Volume up/down).
EPG : Displays the Electronic Program Guide (EPG) information if provided.
AUDIO : Select an audio track and a sound mode.
PROGRAM +/- : Navigates through the scanned channel list.
MENU : Open main menu & select sub menu using by navigation buttons.
EXIT : Close and return to the previous menu and screen.
Navigation Keys : Navigates up/down and left/right on the menu options. Up/down keys are used to call up the channel list.
OK : Select a menu, or confirms the selected operation. Also displays the channel list while watching a programme.
SAT : Open channel list according to satellite.
INFO : Displays the Electronic Program Guide (EPG) information if provided.
NUMERIC KEY (0~9) : Control the numerical operation and change the Channel/Service number directly.
PREV (<) : Return to the previous channel/service or move to the end of the Service List or the Play List.
NEXT (>) : Go to the next channel/service or move to the beginning of the Service List or the Play List.
COLOR BUTTONS : Activates certain menu functions. Usage instructions are shown in each OSD menu.
PVR FUNCTIONS : Control the PVR functions in PVR Mode.
TV : Switch to TV mode.
RADIO : Switch to Radio mode.
VIEWS INSTALLATION
1 Power Button
Switch between operation and standby modes.
2 Display (VFD)
Display current menu information and channel name etc.
3 Program Up/Down Button
Navigates through the scanned channel list.
4 Volume Up/Down Button
Increase/Decrease the volume (Volume up/down).
5 USB
Connect to the External HDD or USB storage
with USB cable. (Max. 500mA)
6 Smart card reader
To insert smart card
7 Common Interface Slot
A slot for one CI module with a Smartcard.
Front view
1LNB1 INPUT
1st satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
2LNB2 INPUT
2nd satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
3S/PDIF
Connect with an appropriate optical cable to your HiFi system.
4Audio / Video Output
Connect to TV using RCA cable.
5Component (YPbPr)
Connect to TV using Component cable.
6HDMI
To connect HDMI cable for your HD TV.
7Ethernet
Communication port via HTTP, FTP, NFS, Telnet and
Samba to access your Hard Drive or to upload channel lists.
This is also used to update OPTIMUSS OS 2's + software.
8 2x USB
Connect to the External HDD or USB storage
with USB cable (Max. 500mA).
9 RS232
RS232C serial data port.
10 External Power Supply
Connect the power Supply (12V / 3.5A).
11 Power Switch
Turn AC Power On/Off.
12 Cooling Fan
with speed control function
Rear view
1. Please refer to the Safety Instruction before powering on the device.
2. Connect OPTIMUSS OS2+ to your TV set using HDMI cable or a RCA cable, etc.
3. Connect the coaxial cable (from the satellite dish) to the LNB INPUT of OPTIMUSS OS2+.
4. Power on the OPTIMUSS OS2+.
5. After booting up, Initial setup menu comes up for the installation according to your TV settings and
Antenna settings.
Use an HDMI or Component cable in order to view HD.
16
7
89
11
10 12
4
3
5
HDMI RCA

REMOTE CONTROL UNIT
MUTE : Mutes or unmutes the audio temporarily.
POWER : Switches between operation and standby.
HELP : This provides users with a quick guide of using OPTIMUSS OS2+.
HOME : Instantly moves to the top of the menu list.
END : Instantly moves to the bottom of the menu list.
TELETEXT : Switch between the teletext and TV modes.
SUBTITLE : Display the subtitle language list.
Zoom : To zoom the screen In/Out.
LIST: Open recorded file menu.
MEDIA : Open media file list.
TIMER : Start timer function.
VOL. +/- : Increase/Decrease the volume (Volume up/down).
EPG : Displays the Electronic Program Guide (EPG) information if provided.
AUDIO : Select an audio track and a sound mode.
PROGRAM +/- : Navigates through the scanned channel list.
MENU : Open main menu & select sub menu using by navigation buttons.
EXIT : Close and return to the previous menu and screen.
Navigation Keys : Navigates up/down and left/right on the menu options. Up/down keys are used to call up the channel list.
OK : Select a menu, or confirms the selected operation. Also displays the channel list while watching a programme.
SAT : Open channel list according to satellite.
INFO : Displays the Electronic Program Guide (EPG) information if provided.
NUMERIC KEY (0~9) : Control the numerical operation and change the Channel/Service number directly.
PREV (<) : Return to the previous channel/service or move to the end of the Service List or the Play List.
NEXT (>) : Go to the next channel/service or move to the beginning of the Service List or the Play List.
COLOR BUTTONS : Activates certain menu functions. Usage instructions are shown in each OSD menu.
PVR FUNCTIONS : Control the PVR functions in PVR Mode.
TV : Switch to TV mode.
RADIO : Switch to Radio mode.
VIEWS
INSTALLATION
1 Power Button
Switch between operation and standby modes.
2 Display (VFD)
Display current menu information and channel name etc.
3 Program Up/Down Button
Navigates through the scanned channel list.
4 Volume Up/Down Button
Increase/Decrease the volume (Volume up/down).
5 USB
Connect to the External HDD or USB storage
with USB cable. (Max. 500mA)
6 Smart card reader
To insert smart card
7 Common Interface Slot
A slot for one CI module with a Smartcard.
Front view
1LNB1 INPUT
1st satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
2LNB2 INPUT
2nd satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
3S/PDIF
Connect with an appropriate optical cable to your HiFi system.
4Audio / Video Output
Connect to TV using RCA cable.
5Component (YPbPr)
Connect to TV using Component cable.
6HDMI
To connect HDMI cable for your HD TV.
7Ethernet
Communication port via HTTP, FTP, NFS, Telnet and
Samba to access your Hard Drive or to upload channel lists.
This is also used to update OPTIMUSS OS 2's + software.
8 2x USB
Connect to the External HDD or USB storage
with USB cable (Max. 500mA).
9 RS232
RS232C serial data port.
10 External Power Supply
Connect the power Supply (12V / 3.5A).
11 Power Switch
Turn AC Power On/Off.
12 Cooling Fan
with speed control function
Rear view
1. Please refer to the Safety Instruction before powering on the device.
2. Connect OPTIMUSS OS2+ to your TV set using HDMI cable or a RCA cable, etc.
3. Connect the coaxial cable (from the satellite dish) to the LNB INPUT of OPTIMUSS OS2+.
4. Power on the OPTIMUSS OS2+.
5. After booting up, Initial setup menu comes up for the installation according to your TV settings and
Antenna settings.
Use an HDMI or Component cable in order to view HD.
16
7
89
11
10 12
4
3
5
HDMI RCA

REMOTE CONTROL UNIT
MUTE : Mutes or unmutes the audio temporarily.
POWER : Switches between operation and standby.
HELP : This provides users with a quick guide of using OPTIMUSS OS2+.
HOME : Instantly moves to the top of the menu list.
END : Instantly moves to the bottom of the menu list.
TELETEXT : Switch between the teletext and TV modes.
SUBTITLE : Display the subtitle language list.
Zoom : To zoom the screen In/Out.
LIST: Open recorded file menu.
MEDIA : Open media file list.
TIMER : Start timer function.
VOL. +/- : Increase/Decrease the volume (Volume up/down).
EPG : Displays the Electronic Program Guide (EPG) information if provided.
AUDIO : Select an audio track and a sound mode.
PROGRAM +/- : Navigates through the scanned channel list.
MENU : Open main menu & select sub menu using by navigation buttons.
EXIT : Close and return to the previous menu and screen.
Navigation Keys : Navigates up/down and left/right on the menu options. Up/down keys are used to call up the channel list.
OK : Select a menu, or confirms the selected operation. Also displays the channel list while watching a programme.
SAT : Open channel list according to satellite.
INFO : Displays the Electronic Program Guide (EPG) information if provided.
NUMERIC KEY (0~9) : Control the numerical operation and change the Channel/Service number directly.
PREV (<) : Return to the previous channel/service or move to the end of the Service List or the Play List.
NEXT (>) : Go to the next channel/service or move to the beginning of the Service List or the Play List.
COLOR BUTTONS : Activates certain menu functions. Usage instructions are shown in each OSD menu.
PVR FUNCTIONS : Control the PVR functions in PVR Mode.
TV : Switch to TV mode.
RADIO : Switch to Radio mode.
VIEWS INSTALLATION
1 Power Button
Switch between operation and standby modes.
2 Display (VFD)
Display current menu information and channel name etc.
3 Program Up/Down Button
Navigates through the scanned channel list.
4 Volume Up/Down Button
Increase/Decrease the volume (Volume up/down).
5 USB
Connect to the External HDD or USB storage
with USB cable. (Max. 500mA)
6 Smart card reader
To insert smart card
7 Common Interface Slot
A slot for one CI module with a Smartcard.
Front view
1LNB1 INPUT
1st satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
2LNB2 INPUT
2nd satellite tuner input from the LNB on a dish antenna.
Turn the receiver OFF first before connecting.
3S/PDIF
Connect with an appropriate optical cable to your HiFi system.
4Audio / Video Output
Connect to TV using RCA cable.
5Component (YPbPr)
Connect to TV using Component cable.
6HDMI
To connect HDMI cable for your HD TV.
7Ethernet
Communication port via HTTP, FTP, NFS, Telnet and
Samba to access your Hard Drive or to upload channel lists.
This is also used to update OPTIMUSS OS 2's + software.
8 2x USB
Connect to the External HDD or USB storage
with USB cable (Max. 500mA).
9 RS232
RS232C serial data port.
10 External Power Supply
Connect the power Supply (12V / 3.5A).
11 Power Switch
Turn AC Power On/Off.
12 Cooling Fan
with speed control function
Rear view
1. Please refer to the Safety Instruction before powering on the device.
2. Connect OPTIMUSS OS2+ to your TV set using HDMI cable or a RCA cable, etc.
3. Connect the coaxial cable (from the satellite dish) to the LNB INPUT of OPTIMUSS OS2+.
4. Power on the OPTIMUSS OS2+.
5. After booting up, Initial setup menu comes up for the installation according to your TV settings and
Antenna settings.
Use an HDMI or Component cable in order to view HD.
16
7
89
11
10 12
4
3
5
HDMI RCA

Quick Start Guide
Please read the safety instructions carefully before using the OPTIMUSS OS2+.
The manufacturer takes no responsibility for incorrect handling of the OPTIMUSS OS2+.
* For sufficient ventilation,leave enough space.
* If unused for a prolonged amount of time,turn the power OFF.
* Do not cover the OPTIMUSS OS 2's+ ventilation openings with items such as newpapers,tablecloths, curtains etc.
* Do not expose the OPTIMUSS OS2+ to liquid,moisture,direct sunlight and extreme weather.
* Do not place open flame sources,such as lighted candles, near or on the OPTIMUSS OS2+.
* Do not place any containers with liquid,such as vases, on the OPTIMUSS OS2+.
* Do not connect or modify cables while the OPTIMUSS OS2+ is connected to the power.
* Do not remove the cover. Risk of electric shock!
* Do not touch the OPTIMUSS OS2+ with wet hands. Risk of electric shock!
* Do not put any metal items into the slots or ventilation openings.
* Please disconnect your OPTIMUSS OS2+ from the main power during thunder or heavy storms.
* Disconnect the main power cable if the power cord is damaged.
* Cleaning : Disconnect the main power cord before cleaning the cover. Use a slightly damp cloth without cleaning agents.
* Connect the OPTIMUSS OS2+ only to suitable sockets. Do not allow overloads to occur.
* The socket-outlet shall be installed near the equipment and shall be easily accessible.
WARNING!
* Modifications and changes to the OPTIMUSS OS2+ lead to loss of warranty.
* Incorrect software installation leads to loss of warranty.
* This instruction might be modified without prior notice.
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered
by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste stream
via designated collection facilities appointed by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city office,
waste disposal service or the shop where you purchased the product.
SAFETY INSTRUCTIONS
DISPOSAL INSTRUCTIONS
- 2 x HD DVB-S / DVB-S2 Satellite Tuner
- MPEG-4, H.264 & MPEG-2 Compliant
-
Broadcom 1300 MHz Mips processor(BCM 7356)
- 256 MB NAND Flash /
8MB NOR Flash / 1 GB DDR3 RAM
- Advanced Linux Operating System
-
10/100/1000 Mbps Full Duplex Ethernet Interface
- 1 Common Interface & 1 Smart Card Reader
- 3 USB 2.0 Port (1 x in Front & 2 x Rear)
- Support Internal 2.5" SATA HDD
- HDMI & Component Output(YPbPr)
- 12 character VFD display with scrolling for local time or channel name
- Unlimited Channel Memory
- Super Sensitive Tuner
- Dolby Digital Plus, Dolby True HD supported
- S/PDIF Output for Digital Audio and Dolby AC-3 Bit Stream Output
- Firmware/ Software Upgrade: Through (Ethernet, USB Memory Stick)
- Multi-Language OSD Menus
- User Friendly EPG (Electronic Program Guide)
- External Power Supply
- Very Low stand-by Power Consumption (<0.5W)
ACCESSORIES
Please check that the following contents are enclosed :
AAA X 2 BATTERIES
Power Supply
Remote control unit
SATA Cable
Twin tuner HD satellite receiver
Quick Start Guide
Quick Start Guide
OS 2plus
OS 2plus
OS 2plus
