Optiview OV23X User manual

Optiview - OV23X Speed Dome
User’s Manual
Version 1.0

ii
Table of Contents
1FEATURES AND FUNCTIONS .................................................................................... 3
1.1 General Introduction ....................................................................................................................................3
1.2 Features........................................................................................................................................................3
1.2.1 On-Screen Menu.....................................................................................................................................3
1.2.2 On-screen Tips........................................................................................................................................3
1.2.3 Support multiple protocols ......................................................................................................................3
1.2.4 Proportional Pan and Tilt.........................................................................................................................3
1.2.5 Preset Setup............................................................................................................................................3
1.2.6 Auto Scan.................................................................................................................................................3
1.2.7 Auto Pattern.............................................................................................................................................4
1.2.8 Auto Touring.............................................................................................................................................4
1.2.9 Auto Flip...................................................................................................................................................4
1.2.10 Self-diagnosis......................................................................................................................................4
1.2.11 Day/Night Mode (B/W & Color Mode)................................................................................................4
1.2.12 Auto Focus...........................................................................................................................................4
1.2.13 Backlight Compensation.....................................................................................................................4
1.2.14 Pan Tilt and Zoom...............................................................................................................................4
1.2.15 3D Intelligent Location........................................................................................................................4
1.2.16 Idle Motion...........................................................................................................................................5
1.2.17 Image Flip............................................................................................................................................5
1.3 Specifications ...............................................................................................................................................5
1.3.1 Technical Specifications..........................................................................................................................5
1.3.2 Performance Specifications....................................................................................................................6
2ADDRESS, BAUD RATE AND PARITY SETUP .......................................................... 7
2.1 Address, Baud Rate and Parity Setup........................................................................................................7
2.2 Set address dial switch ................................................................................................................................8

iii
3CABLE CONNECTION............................................................................................... 10
3.1 Multiple-function Composite Cable ...........................................................................................................10
3.1.1 System Layout.......................................................................................................................................10
3.1.2 Keyboard Connection............................................................................................................................11
4MENU......................................................................................................................... 13
4.1 Screen Menu Index ..................................................................................................................................13
4.1.1 Self-diagnosis System Information ...........................................................................................................13
4.1.2 Main Menu ..............................................................................................................................................14
4.2 Menu Operation........................................................................................................................................14
4.2.1 System Information................................................................................................................................15
4.2.2 Display Setting.......................................................................................................................................16
4.2.3 Camera Setting......................................................................................................................................16
4.2.4 Function Setting.....................................................................................................................................20
4.3 Dome Abnormal Phenomenon Operation............................................................................................25
4.3.1 Restore to Factory Default Setup.........................................................................................................25
4.3.2 PTZ Movement is not smooth...............................................................................................................25
5FAQ ............................................................................................................................ 26
5.1 Daily Maintenance....................................................................................................................................26
5.2 Problems and Solutions .........................................................................................................................26
6APPENDIX ⅠTHUNDER PROOF AND SURGE PROTECTION................................. 27
7APPENDIX ⅡABOUT RS485 BUS............................................................................ 28
7.1 RS485 Bus Main Feature ..........................................................................................................................28
7.2 RS485 Bus Transmission Distance ..........................................................................................................28
7.3 Connection Methods and Terminal Resistance.......................................................................................28

iv
7.4 The Problem in Practical Use....................................................................................................................29
7.5 The Problem in Practical Use....................................................................................................................29
7.6 RS485 Bus FAQ.........................................................................................................................................30
8APPENDIX TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS........................ 31

Welcome
Thank you for purchasing our product!
This user’s manual is designed to be a reference tool for the operation of your system.
Here you can find information about this speed dome features and functions, as well as a
detailed menu tree.
Please keep it well for future reference!
Before installation and operation, please read the following safeguards and warnings
carefully!

2
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation Security
No heavy stress, violent vibration or water splash are allowed during transportation, storage
and installation.
Please use the original packing material (or the material of the same quality) when you ship
it back to the manufacturer.
3．Installation/Unstallation
Do not apply power to the product before completing installation.
Do not put object on the product.
Do not unscrew screws or housing, please contact qualified professionals to maintain.
4．Environment
This series product should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the device, (IP67)
Do not shoot light object, no matter the dome is in use or not, or the image may be blur or
unclear.

3
1Features and Functions
1.1 General Introduction
This series speed dome product is an integrated high intelligent speed dome. It adopts water
drop configuration design for the first time and has small and delicate shape. This is a digital and
intelligent product of vivid video. The installation is convenient.
These series product external ports adopt the PTZ to realize the quick installation. There is
waterproof interface for the pipe thread. All of these make the installation easier. It supports
various languages and protocol auto recognition. It supports 360°continuously pan, 92°tilt and
180°auto flip. It can realize no blind spot monitor.
This series product can be widely used in remote monitor environment such as electric power,
customs, water conservancy, banking sector and etc.
1.2 Features
This series speed dome has the following features:
1.2.1 On-Screen Menu
This series product menu supports multiple languages.
It is easy for you to view dome information and configure dome, camera parameters.
1.2.2 On-screen Tips
Here you can view:
Preset number/title and system version (Software and hardware)
Dome position. (Optional. You can disable this function)
1.2.3 Support multiple protocols
This series speed dome supports universally used protocols such as DH-SD1, PELCO-P and
PELCO-D. You can use various devices (such as matrix, control keyboard and DVR) and
protocols to operate speed dome.
1.2.4 Proportional Pan and Tilt
This function keeps the image from moving too fast when there is a large amount of zoom.
Speed dome continually decreases or increases pan and tilt speeds in proportion to depth of
zoom. When zooms speed is increasing, the camera moving speed becomes slow. When zooms
speed is decreasing, the camera moving speed becomes fast.
1.2.5 Preset Setup
Preset function is to save the address information (such as PTZ pan/tilt, focus and etc) to the
memory so that you can quickly adjust the dome and PTZ to the correct position. This series
speed dome max supports 255 presets.
1.2.6 Auto Scan

4
Camera scans back and forth regularly in a horizontal field. Here you need to set left and right
limit and scan speed. You can set 5 scanning paths.
1.2.7 Auto Pattern
Memorize dome operation such as pan, tilt, and zoom to repeat. Focus and iris are in auto mode
during auto pattern. For each pattern, the time should be less than 60 seconds. You can set 5
pattern paths.
1.2.8 Auto Touring
Add addresses into a routine in a desired order and then set time and stop duration for each
address. The dome will begin an auto touring between these addresses. You can set 8 touring
paths.
1.2.9 Auto Flip
As long as you continue to hold the keyboard joystick in the down position, the dome rotates 180
degrees and repositions itself for uninterrupted viewing of any subjects that passes directly
beneath the dome.
1.2.10 Self-diagnosis
There is a self diagnosis procedure when dome boots up.
Tilt and vertical engine check
Camera diagnostics
Display dome information and diagnosis information such as address, protocol, baud
rate, type.
1.2.11 Day/Night Mode (B/W & Color Mode)
System supports auto/manual switch in low illumination.
In the auto mode, the camera can automatically switch the CCD level according to the light
change. In the manual mode, it can use the menu or the button to realize the color display, black
and white display,
1.2.12 Auto Focus
Auto focus allows the lens to remain in focus during zoom-in, zoom-out and motion functions to
get vivid image. You can use FAR or NEAR button to adjust focus manually.
1.2.13 Backlight Compensation
Balance the brightest and darkest sections of a scene to make a more vivid picture.
1.2.14 Pan Tilt and Zoom
Supports zoom in and zoom out during tilt and pan movement.
In this period focus and iris are both in auto mode to get vivid image.
1.2.15 3D Intelligent Location
Working with DVR, just click part of the current scene will be displayed in the central window and
automatically zooms. All of these allow you to trace precisely.

5
1.2.16 Idle Motion
When there is no available order, you can use menu to set dome idle status after specified
duration. The idle status includes turn to specified preset or go to scan, tour or pattern function.
1.2.17 Image Flip
You can enable image flip in the menu.
The flip function meets more applicable requirements.
1.3 Specifications
1.3.1 Technical Specifications
Power
AC 24V/1.5A（±20%）(Includes temperature control circuit)
Camera Driver
Consumption
11W
Heater Consumption
12W
Decoder
Built-in
Engine
stepper motor
Preset
255( in PELCO protocol)
Auto Tour
8
Auto Pattern
5
Auto Scan
5
Information
Position，dome title, dome coordinates, and etc.
Lens
Adjust speed in accordance with lens
Auto Rotation
Tilt 92º auto rotates to pan 180 º
Auto Pan
0 º-360ºcontinuously
Manual Pan Motion
Speed
0.1º—300º/S
Preset Maximum
Speed
60 º～400º/s. There are 16-level. You can set from the menu.
Manual Tilt Motion
0.1º—120º/S
Manual Tilt Scan
Section
0º—180º
Control Port
RS485 BUS
Baud Rate
1200/2400/4800/9600 (Optional)
PTZ Scan Accuracy
0.06 ±0.015º
Signal Format
PAL/NTSC (Camera mode)
S/N Ratio
> 50dB
Effective Pixel
768(H)*494(V) / 795(H)*596(V)
Horizontal Resolution
480TVL/540TVL/700TVL
Fan
Fan works continuously, heater auto controls (auto on when the
temperature under 5℃)
Humidity
＜90%
Environment
-40℃—60℃（Outdoor）

6
1.3.2 Performance Specifications
Built-in
Decode
All digital design. All data are in the connection board. No data loss
when power off occurs.
Integrated design, high stability.
This speed dome max support 255 presets. Support 8 auto touring.
Each touring max has 32 presets.
5 auto scan.
5 auto pattern. Each pattern can max support 400 commands and
the interval shall be less than 60s.
Built-in direction indicator.
Built-in various adjustable protocols, baud rate
RS485 BUS control
Built-in PTZ
Fine stepper driver, stable performance, react quickly, precisely
positioning.
Integrated design, tight structure.
Elegant mechanical driver device. Support 360 degrees continuous
rotation, no monitor blind spot.
0.1°/s rotation speed while maintain stable image.
180 degrees tilt continuous monitor.
Built-in zoom
lens, high
sensitive,
high
resolution
integrated
digital
process
color
camera.
Auto focus
Auto iris control
Auto brightness control
Auto white balance
Auto day/night switch
OSD
Preset title display
View dome initial setup information
Modify camera parameter
Set preset
Set auto scan
Set auto pattern
Set auto day/night switch (Auto B/W & color switch)
