Optoma EW533ST User manual

www.optoma.co.uk
EW533ST
DLP®Projector Project in the
smallest of spaces
5
5
64
64
64
64
64
4
4
”
”
Widescreen 64” image from just 1m away
Widescreen presentations and HD entertainment
3000:1 contrast ratio for sharp, detailed presentations
and graphics
Bright projection – 2500 ANSI Lumens
Digital and Analogue connectivity includes: HDMI, VGA
Cable free presentations with wireless convenience
Low ownership costs – up to 5000hrs lamp life
10W speaker – all-in-one multimedia set-up
Portable – carry bag provided for easy transportation
Environmentally friendly design <1W standby mode
�
Optoma EW533ST filter-free design – virtually no maintenance

1m
27”
Without Short Throw
EW533ST
1m
64”
With Short Throw
Widescreen 64” image from just 1m away
Project in the smallest of rooms with the widescreen, HD Ready EW533ST. Installed or on the move, the versatile
EW533ST incorporates extensive connectivity and powerful 10W stereo speakers. At 2500L, the EW533ST is easy
to use and ensures crystal clear, bright projection for the best business and education presentations.
The environmentally friendly EW533ST has energy saving features including <1W standby mode and auto power off
saving you both time and money. Long lamp life of 5000hrs combined with our unique Optoma Colour and Imager
guarantees ensure hassle-free, long-lasting projection.
SHORT THROW LENS
The EW533ST can project an impressive 64-inch diagonal image from just 1m from the screen. Stand-alone or ceiling mounted the EW533ST
eliminates shadows on the screen and allows you to present with ease.
Current Projectors EW533ST – Shadow-free Images
WIRELESS PRESENTING (OPTIONAL EXTRA)
Making presentations couldn’t be easier using the optional wireless features of the EW533ST. Cable
free presenting saves time and facilitates effortless switching between presentations from different
sources. Simply download the software and start presenting instantly. WPS-Dongle, lets you connect
and display presentation material wirelessly.

EW533ST
TRUE WXGA RESOLUTION
The EW533ST is the perfect companion for widescreen laptops. Your
presentations will appear as sharp and detailed as they do on your
widescreen laptop in WXGA (1280 x 800). WXGA resolution gives
30% more pixels than XGA.
XGA WXGA
TRUE HDMI
Project crystal clear images using the latest HDMI v1.3 input. Hassle-
free projection from a widescreen computer/HD source with a single
HDMI cable – no need for separate audio cables.
CONTROL
The extensive RS232 command set makes it simple and easy
to control the EW533ST with any control system.
AMX Compatibility – Dynamic Discovery Protocol is
incorporated into the EW533ST. This feature allows
for easy installation with AMX control systems.
EXTENSIVE CONNECTIVITY
This native WXGA projector accepts a wide variety of computer and
video input signals.
Connectivity includes: HDMI, VGA–Wireless/ Component, S-Video,
Composite and RS232.
CLEAR, FOCUSED IMAGES
DarkChip3™ technology from Texas Instruments produces a
stunning 3000:1 contrast ratio for pin sharp graphics and crystal
clear text. Crisper whites, ultra-rich blacks makes images come
alive and text easier to read - ideal for business and education
presentations.
o read
1000:1 contrast ratio 3000:1 contrast ratio
‡Simulated Image
AMAZING COLOURS
The EW533ST incorporates BrilliantColor™ technology to produce
stunningly bright images with perfectly balanced life-like colours.
Preset display modes allow you to achieve a perfect image on
a variety of surfaces including screens and interactive whiteboards.
COLOUR AND IMAGER GUARANTEE
Bright colours and fantastic image quality are guaranteed for an amazing
5 years after purchase - giving piece of mind that the technology inside
the Optoma EW533ST projector won’t fade or degrade.
5
VIRTUALLY MAINTENANCE FREE = LOWER
COST OF OWNERSHIP
EW533ST provides lower cost of ownership, longer life and improved
reliability. The filter-free projector design does not require regular
filter cleaning or filter replacement, saving you time and money.
ENVIROMENTALLY FRIENDLY
The EW533ST incorporates energy saving features to conserve
power and extend the lamp life:
To achieve the maximum 5000hrs** lamp life time the
projector should be operating in STD mode and the shut
down timer should be enabled to automatically switch off the
projector if it is accidentally left on when no longer required.
Enabling the <1W Standby mode will ensure the minimum
energy consumption when the projector is not being used.
It takes less than 10 seconds for the projector to power
up and shutdown, saving both time and energy.
FEATURES
6 preset display modes
Security bar and password protection for added security
Easy to use remote with direct source selecting

Optoma Europe Ltd.
42 Caxton Way, Watford Business Park, Watford, Hertfordshire, UK. WD18 8QZ
www.optoma.co.uk
*Optoma guarantees that in normal use, Optoma DLP® colour quality will be indistinguishable from when new. Please note that worn lamps will give slight variance. Exclusions: (1) Guarantee is voided if the projector is subject to damage through mis-use.
(2) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is particularly excessive (3) Guarantee will not apply if lamp brightness is below 50% due to wear or if the projector is not working due to other fault.
**Typical lamp life achieved through testing. Will vary according to operational use and environment conditions. *** Optoma guarantees that in normal use, the DLP® imager guarantee will retain quality for at least 5 years providing consistent pixel performance.
Exclusions: (1) Guarantee is voided if the projector is subject to damage through mis-use. (2) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is particularly excessive.
Copyright © 2010, Optoma Europe Ltd.All other product names and company names used herein are for identifications purposes only and may be trademarks or registered trademarks of their respective owners. Errors and omissions excepted,
all specifications are subject to change without notice. DLP®, BrilliantColor™ and the DLP logo are registered trademarks of Texas Instruments.
Optoma recommended Screens
www.panoview.eu
EW533ST
EW533ST SPECIFICATIONS
Native Resolution WXGA 1280 x 800
Display Technology Single 0.65” WXGA DC3 DMD chip DLP®Technology
by Texas Instruments
Brightness - BRIGHT mode 2500 ANSI Lumens
Contrast 3000:1
Noise Level - STD mode 27dB
Lamp Life** 5000/3000 (STD/BRIGHT mode)
Projections Lens F Number 2.55
Focus Length 10.19mm
Focus / Zoom Type Manual Focus / 2.0x Digital Zoom
Throw Ratio 0.72:1 (Projection Distance: Image Width)
Projection Distance 0.5 - 5m
Image Size 0.82 – 8.19m (32.24” - 322.41”) Diagonal 16:10
Offset 112.4%
Weight / Dimensions (W x D x H) 2.9 kg / 324 x 234 x 97mm
Lamp Life* 5000/3000 (STD/BRIGHT mode)
Remote Control Full function remote with direct source selecting
INPUTS HDMI (HDCP) - audio supported
15 Pin D-Sub VGA (Wireless/Component via adaptor)
S-Video 4 Pin Mini Din
Composite RCA
Stereo RCA-Audio video inputs
CONTROL RS232 - 9 Pin D-sub
OUTPUT Stereo Audio Mini Jack
Audio 10W Speaker
Aspect Ratio 16:10 Native, 16:9/4:3 Compatible
Keystone Correction ± 15° Vertical
On Screen Display 17 Languages: English, German, French, Italian, Spanish,
Portuguese, Polish, Dutch, Russian, Finnish, Swedish, Greek,
Norwegian/Danish, Hungarian, Czech, Turkish & Arabic
Compatible Resolutions UXGA, SXGA, WXGA, HD, XGA, SVGA
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
Uniformity 85%
Displayable Colours 1.07 Billion
Horizontal Scan Rate 15 - 91kHz
Vertical Scan Rate 25 - 120Hz
Power Supply 100 - 240V, 50 - 60Hz
Power Consumption 230W BRIGHT mode < 1W Standby mode
212W STD mode < 1W Standby mode”
Operating Conditions Operating: 5 - 40˚C, 85% Humidity (Max),
3000m Altitude (Max)
Security Security Bar, Kensington Lock Port, Password Protection
Standard Accessories Soft Carry Bag, Lens Cover, AC Power Cord, VGA Cable,
Full Function Remote, Batteries x 2, Quick Start Guide,
CD User Manual, Warranty Card, WEEE Card
Optional Accessories Wireless Dongle, SCART & Component adapter,
Ceiling Mount
RoHS Compliant
Lamp Warranty 6 months or 1000 hours - whichever comes sooner
Warranty Warranty may vary by country.
Please see www.optomaeurope.com or ask your local
supplier for details
Colour Guarantee* 5 Years
Imager Guarantee*** 5 Years
3D Support 120Hz frame sequential 3D for resolutions up to 720p.
60Hz field sequential 3D for resolutions up to 480i
3D Viewing Requires Optoma DLP®Link™ active shutter glasses
– sold separately
3D Compatibility The 3D features of the EW533ST can only be used
with compatible 3D content and do not support 3D TV
broadcast systems, including the 3D SKY service in the
UK, or 3D Blu-ray. Support for these applications may
be added in future using additional hardware
EW533ST Remote Control
1Vertical Keystone Correction
2Volume Control
3Brightness Adjustment
4AV Mute
5Direct Input Source Selection
EW533ST Connections
6HDMI (audio supported)
7 VGA In - Wireless & Component
8S-Video
9Composite Video
10 Audio Out
11 RS232
12 Audio In
13 Kensington™ Lock
14 Security Bar
EASY TO USE REMOTE CONTROL
12
3
4
5
Exceptional Connectivity/ Multiple Terminals
6 8
11
9 10
14
7
Easy to use remote
with buttons to
change the input
sources
EW533ST Projection Distance 0.5 - 5.0m (16:10 Aspect Ratio)
Projection Distance (m) Horizontal Image Size (m) Vertical Image Size (m) Diagonal Image Size (m) Diagonal Image Size (inch) Image Offset (m)
0.50
0.70
0.80
0.90
1.00
1.50
2.00
2.50
3.00
3.50
4.00
4.50
5.00
0.69
0.97
1.10
1.25
1.39
2.08
2.78
3.47
4.17
4.86
5.56
6.25
6.94
0.43
0.61
0.69
0.78
0.87
1.30
1.74
2.17
2.60
3.04
3.47
3.91
4.34
0.82
1.15
1.30
1.47
1.64
2.46
3.28
4.09
4.91
5.73
6.55
7.37
8.19
32.24
45.14
51.26
58.03
64.48
96.72
128.96
161.21
193.45
225.69
257.93
290.17
322.41
0.05
0.08
0.09
0.10
0.11
0.16
0.22
0.27
0.32
0.38
0.43
0.48
0.54
For guide purposes only
EW533ST is capable of 4:3 and 16:9 aspect ratio projection. When projecting a 4:3/16:9 image the image sizes, screen height and offset information
will differ from the above.
12 13
