Opus MasterPress 01 Manual

Operating, Maintenance and Health Safe
Manual
MasterPress 01
Safety instructions:
Before putting the equipment into operation, please read the Health & Safety
precautions, manufacturer recommendations and the operation manual.
The user’s guide should be easily available at any time for the operator.
The equipment should be fixed to the stand supplied and placed on a strong
solid flat level floor, to ensure safe operation. We recommended that you
screw down the base to the floor were possible.
The equipment should be protected against dust and moisture
= must not be placed near heating or ventilation units
= must not be used in vicinity of inflammable liquids or gases
= may be supplied with power only through the original cord.
A mains socket should be provided with in accordance with electrical and
earthing regulation.
The supply voltage should be consistent with the specifications on the
technical plate located on the machine housing and in the technical data
sheet.
Failure to do so may result in electrical shock or fire and cancel guarantee.
The electrical supply cable should be protected against damage, and must not
be used to pull the machine or to remove the plug from a socket
Making any changes to the electrical installation of the equipment or supply
cable can causes a fire hazard or electric shock and cancel the guarantee.
During long none use of the equipment, the plug should be removed from the
mains socket
Before removing the housing from the equipment, remove the plug from the
socket.
The electrical system is protected by a 8A fuse next to the power-switch at the
rear.
Before replacing the fuse, remove the plug from the mains socket.
When replacing the fuse it must be of the same type.
If the new fuse goes when replaced contact the service team.
Do not touch the heater –burn hazard!
Before fitting new typeface fonts in the frame wait for 5 –10 minutes to make
sure that they have cooled down –burn hazard!
The equipment must be kept away from children and animals.
The equipment must not be used for any other purposes other than those
indicated in the user’s guide
It is necessary to check that the equipment is being operated correctly. In case
of any malfunctions, contacting the service team is required.
The machine must not be located outside, should be operated in a room
temperature higher than 8oC
The equipment should be operated in accordance with general Health & Safety
rules
Any repairs can be made only by trained and qualified staff.
Do not use any solvents when clearing the equipment

Please take care during machine operation –pressing the hand, even with the
cold heater, can cause body injuries
Turn off the machine using main switch after finished work. The machine is
turned off completely after removing the plug from a socket
General Information:
The Master-Press was designed to make embossing and/or foil stamping on paper
or cardboard covers, as well as on covers coated with paper veneer. It is also
possible to make hot stamps on plastic or plastic coated covers, however
previously the tests should be carried out to check if the material is suitable for foil
stamping/embossing.
The use of fonts makes possible composing any inscription (there are available
various kinds of fonts, also in various languages and sizes) and marking it on the
cover or other surface. It is also possible to prepare a special matrix (e.g. a logo)
consistent with the GOLDCOVER standard. The detailed information concerning
extension of the possibilities of the machine can be obtained from the supplier.
Operation of the machine does not need special qualifications, however:
Before starting the work operator should read the user’s guide carefully
In separate offer they are also available:
O.Matrix Frameworks MP was designed to install matrixes into Masterpress
hot stamping equipment. You can order a special, customized logos/cliché
(O.Matrix MP) from OPUS, of your own design or you can use your own
logos/cliché. In both cases O.Matrix Frameworks are necessary to put the
matrix into the heating slot, however to fit your own matrix a special tape
(O.Mounting Tape) and a plate called (O.Matrix Base MP) are also required.
A. Preparing the customer matrix (using O.Matrix Base MP)
1. Remove the protection layer and stick the O.Matrix tape to
the back of your matrix then cut it along the matrix edge.
2. Remove second protection paper and stick the matrix to
the O.Matrix Base MP.
Note!
Before sticking the matrix, make sure that the inscription/logo on the matrix is
parallel to the bottom edge of the plate (O.Matrix Base MP).
B. Assembling the O.Matrix Framework MP (both to O.Matrix and O.Matrix
Plate MP)
1. Screw down O.Matrix Frameworks MP to the O.Matrix MP or O.Matrix Base MP
with 4 bolts.
Note!
In order to screw down the bolts please use the screwdriver, which is supplied to
the Master Press Hot Stamping equipment and also is use to adjusting guides in
frames for fonts.
Note!
The heating time of a matrix depends on its size and can vary from 5 to 10
minutes. It is necessary to conduct a test to check if the matrix is hot enough.
Design of the machine:

Master-Press is a manual eccentric press. It is fitted with a heater enabling hot
print stamping, with a plc microprocessor controller, a LCD digital display to
maintain precise temperatures and stamping times, which ensures consistent work
conditions. A matrix or typeface fonts with a matrix in a MP frame can be fitted
over the heater. Side guides enable the precise positioning a cover in relation to
the frame. The adjusting screws under the table/stamping table enables the
changing of height of the table in different points, which can help to emboss
complicated patterns. The foil holder has an electric motor to feed the foil when
doing large run and make it possible to use a roll of foil 122m long (max width of
230mm). Foil feeding is automatically, you can also use single pre-cut sheets of
foil. It is recommended to use foil supplied by good quality manufacturers or from
Opus with this equipment. Using low quality types of foil may affect the outcome in
a bad way of your cover and documents. Ask your supplier about foils.
Transport and storage:
Master-Press has electric and electronic components. Both the equipment and
the package should be kept away from the damp and the wet (i.e. rain).
In the case of flooding or severe wetting of the equipment, contact the
service team and have the technical survey to avoid damage and
electrical shock!
The equipment should not be transported or stored in temperatures below 0˚C
The packing protects the equipment from shock, however it is recommended
to be careful when transporting.
The equipment is bolted to a wooden pallet.
Because of the weight of the equipment it is recommended to move or
transport it by pallet or fork-lift truck.
Installation:
The package contains: Masterpress 1 equipment, table top, legs, and a box of
accessories and parts and tools to assemble.
It is recommended to store the original package through the guarantee period.
The equipment should be placed on a strong solid flat surface, to ensure safe
and operation, We recommended that you screw down the base to the floor
were possible.
Inside the carton is one pole for lifting the main press unit on to the base legs.
The pole have one fixed collar and one adjustable. Insert it at the second hole
in housing from the front. Then fit the adjustable collars tighten firmly with the
Allen key supplied how it is safe to lift. We recommend that you use 4 people
to lift the equipment.
Table top
Using Allen key 4 mm unscrew the
grappled screws from the pallet and partly
assembled table. Fasten on its legs small
regulated sockets.
2 sets of catches mechanizm are
attached to the table. One set contains: 2 pins,
and one smaller and one bigger set of catches
Slide on two pins smaller elements of
catches. Next put the pins into holes of beam
and from the other side of pins put the bigger
catches mechanism.
Elements of catches must be faced
with flat side to the ground
Put the table top on the stand
Level the stand using regulated
sockets in legs.
Bigger set of catches
Pins smaller set of catches

Putting and fixing the equipment on to the stand with the 4 M10 setscrews
Screw through the bottom of MasterPress stand the 12 long regulator screws
string them through the holes of catches
Smaller set of catches
catches
regulated screws
screws M10
If the machine was exposed to temperatures below 0˚C, care should be taken
to warm the equipment up slowly in normal room temperature to avoid
condensation and damage to the electrical circuits and processor
it may be connected to mains after a reasonable time.
To ensure operator’s safety, the equipment must be connected to the
mains power only through the original cord. The mains socket must be
in accordance with electrical and earthing regulations and the supply
voltage specified on the equipment and technical data.
Failure to do so can cause electrical shock or fire and cancelling the
guarantee.
Preparation for work:
1. Insert the plug into the mains socket
2. Mount the roll of foil on the foil holder, feed it over the heater and fix it to the
foil winding roller. Foil width must not exceed 230mm.
2. Switch the power supply on (the main switch is located at the back of the
machine) –after few seconds the temperature starts increasing
NOTE!
The equipment has a factory setting temperature of 100˚C. This setting on average
provides the best results for hot print stamping and embossing. However, if the
stamping results are not satisfactory which depend on the type of foil and cover,
it may be necessary to change the settings by pressing [▲] or [▼] button to raise
or lower the temperature using button marked (Stemp). Current temperature is
indicated on the right side of display (Temp).
1. Wait until the set heater temperature is reached, „READY” will appear on
display and a sound, a bleep which means that it is ready for operation).
2. The machine reached required temperature and is ready to operation
Hot print stamping and embossing:
1. Take the frame out of the heating slot
NOTE! If the frame was previously used or on the heater unit, remove and
wait 5-10 minutes until it gets cold enough to handle. Burn Hazard
2. Put the MP frame on the frame holder. It is safer, easier and quicker to put
and remove typeface fonts into the MP frame.
3. Compose the required text in the MP frame lines with the typeface and
suitable fonts using the tweezers supplied.
4. NOTE! The fonts should be put in and taken out using the special
tweezers. the ends of the tweezers fit into the holes on the typeface
fonts which makes it easy to lift. The holes and the letters show you the
correct way and help to distinguish between the top and bottom of the
letter. The bottom hole is closer to the bottom of the letter. On the
smaller typeface there is only 1 at the bottom for the letter.
5. Lock the text in the frame by the stops at each end.
6. Insert the frame to the heating slot and wait about 1 minute until the typeface
fonts are hot check the temperature on the led display.
7. Set the side guides to position the cover in suitable to the frame
8. There is no need to put anything under the cover. The equipment
automatically adjusts heater height for the material thickness.
9. Set the pressure required by adjustment large black knob on the front of the
equipment to the required pressure 1-10, 10 is the maximum pressure.
10. You must adjust the pressure to the cover type.
11. Insert the cover under the heater in the guides. If it is necessary, use
additional resistance angels by putting them under the sidegauges with
straight side face to cover.
12. Slowly pull the handle down till it stops.
13. There will be a bleep signal and on the LCD you will see END.
14. Lift the handle to the fully open position. The foil will wind on ready for the
next. The amount of foil movement can be adjusted to suit the job.
15. Take the cover out –your documentation is ready!

NOTE! Do not let go the arm until in the fully open and off position.
(Indicated in the picture on page 3)
NOTE! In the case of embossing complicated and uneven patterns,
you can adjust the stamping table top using the 12 screws for regulation.
1. Using the regulation screws under the table-top on the stand you can correct
differences in embossing (where the embossing is too shallow), by tightening
the proper screw.
2. Screwing of regulation screws about 60° causes rising or lowering part of table
top about 0.3 mm. You will hear characteristic leap of the screw
Operation of the programmer:
After connecting to the mains, the programmer displays information about actual
settings of the equipment (program version, language and temperature units F°
C°). The settings can be changed with SET button and arrows.
MAIN MENU is shown on display after reading in the current settings.
STemp: Temperature settings from: 0˚C to 150˚C
Temp: Current heater temperature
STime Stamping time settings from: 0 to 5sec
Time Stamping time (counted during stamping)
SFoil Set foil winding time (possible settings: 0-30 units)
Program number of current programme (“-”means that the settings do not
correspond to any programme)
Count counter of pieces (it is possible to set addition from 0 (UP) or
subtraction from set number to 0 (DOWN); counter can be cleared
READY information that the machine is ready to operation
Temp LO heater temperature is too low
Temp HI heater temperature is too high
The settings of the machine can be changed by suitable positioning the blinking
cursor using “SET” button, value is changed by the arrows.
If the cursor is set on “Program” and the arrow is pressed, MAIN MENU will appear
on the display. There are 10 programmes where temperature and time parameters
can be saved (there is also a possibility of writing down the description of the
programme). Settings of the programme can be changed using “SET” button and
the arrows.
If the programmer is not used for 5 seconds, the cursor stops blinking and MAIN
MENU is shown on the display.
If the „SET” button is not pressed in MAIN MENU, pressing the arrow will start foil
winding (until the arrow button will be released).
Possible malfunctions:
PROBLEM
POSSIBLE CAUSE
SOLUTION
Know display of settings
or indication of power.
Probable cause power
plug is not in properly.
Is not switched on or fuse
has gone.
Equipment is damaged
Check the plug is in properly.
Check if the switch is on
check fuse on socket and on
equipment if all are OK.
Contact service support
not achieving desired
temperature or over
heating
check temperature has
been set correctly
or problem with PCB
set suitable temperature
if it continues
Contact service support
pale dots appear within
hot stamped inscription
too low temperature
too short a time of
stamping
too low pressure
uneven stamping
increase temperature
increase stamping time
reset pressure by adjusting
knob into suitable position
readjust the table
stamped letters are not
solid and clear, foil is
visible beyond letter
edges
too high temperature
too long a time of
stamping
or too higher pressure
reduce temperature
reduce stamping time
adjust the pressure
after stamping some foil
appear on other parts of
the cover
too high pressure
adjust the pressure lower
Note –The heater is fixed to the guiding system with appropriate backlash. In case
of enlargement the backlash, what appears by uncontrolled horizontal movement
of heater, it is necessary to reduce it by tightening regulated screws on one side of
housing. In this order remove from the screws black caps and loosen nuts. With
allen key tighten the regulated screws so as during lowering and lifting the lever,
the heater moves up and down freely and without any resistance.
Maintenance:
The equipment does not need lubricating or servicing. The points to be lubricated
are sealed in the factory.
The equipment is powder coated and baked hard in office grey. It can be cleaned
with detergents commonly available on the market. Do not use any solvents!

Accessories:
The following accessories are supplied with the MasterPress 01:
Stand: Flat packed for assembly on site by purchaser.
Tool set ( Allen key screwdriver 8mm. for removing equipment from the pallet,
small screwdriver frame screws and tweezers holding typeface letters.)
Standard Frame size 174x300mm with 4 guides
Components & parts supplied with equipment
5 off. Standard Base Frame
5 off. Set of Singe Frames 4mm
5 off. Set of Singe Frames 5,5mm
5 off. Set of Singe Frames 9mm
1 off. Single Frame holder
2 off. Additional resistance angles for side guides
12 off. Screws for regulating print & stamp bed
4 off. pins,2 smaller and 2 bigger sets of catches
1 off. metal pole
Technical data:
Rated voltage: AC. 220-240V 50-60 Hz
Maximum power load: 1800W
Average power load: 400W
Dimensions of the equipment: D 528 x W 408 x H 680 mm
Dimensions of the package: D 745 x W 450 x H 835 mm
Dimensions of the stand: D 510 x W 490 x H 625 mm
Net weight of the machine: 100kg
Gross weight of the machine: 107kg
Net weight of the stand: 25kg
Heater surface: 218 x 308 mm.
Maximum stamping pressure: 5T
Operating temperature: 100°C
Temperature adjustment range: 0°C -150°C
Temperature stabilization: microprocessor
