ORACLE LIGHTING OFL-102-LED User manual

OFL-102-LED INSTRUCTIONS
LED Floodlight
3.
Screw up the knuckle mout into junction-box.
7"
7.2"
3.3"
2"
PAGE 1 OF 2
O.R.-Revision A: 4/1/20
323-888-1973 [email protected] www.iuseelite.com
Caution:
Disconnect AC power before servicing and installation.
All electrical connections must be in accordance with
NEC/CEC or your local code.
PRODUCT DIMENSIONS
2.
Put the wires of lamp into the junction-box.
PRODUCT SPECIFICATION
INSTALLATION STEPS (KNUCKLE)
1.
Use screw key to open the junction-box
SAFETY INSTRUCTIONS
1. Equipment should be mounted securely in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel. 2. Do not mount near gas or electric heaters. 3. Cap unused wires with enclosed wire nuts or other approved
method. 4. Do not use this equipment for anything other than its intended use. 5. The use of accessory equipment not recommended
by the manufacturer will void product listing and warranty and may cause an unsafe condition. 6. Any service on this equipment should be
performed by qualified personnel only. 7. Make sure wire terminations are secure and leads are properly tucked in appropriate wire channels.
8. Damaged by corrosion will not be honored as a materials defect claim. It is the user's responsibility to provide suitable protection against
corrosive agents such as moisture and condensation and other harmful elements. 9. Electrical connection should be in a dry area unless
adequately sealed. CONSULT A QUALIFIED ELECTRICIAN BEFORE INSTALLING
PRODUCT SPECIFICATION
Input Voltage
120-277 VAC
Input Current
0.275 A
Frequency
50/60 Hz
Rated Power
30W
Suitable For
Wet Location
Note:
1. This fixture should not be used in areas with limited ventilation or high ambient temperature exceeding 45°C. 2. Keep enough length
wires to ensure adjusting angle inhindered. 3. This product series emits high light output. DO NOT look directly into the light emitting
area. Direct exposure to the light over an extended time period may harm eyes 4. Operating ambient temperature range -40°C to 45°C

OFL-102-LED INSTRUCTIONS
LED Floodlight
8.
Use hex-key to screw up the hex-screw. Installation completed.
7.
Adjust the lamp into suitable angle.
4.
Use wire-nuts to connect the wires of lamp and junction-box
6.
Use hex-key to screw offthe hex-screw in knuckle mount.
5.
Lock the junction-box with screw key.
PAGE 2 OF 2
O.R.-Revision A: 4/1/20
323-888-1973 [email protected] www.iuseelite.com
