Oracle Sun Storage HBA User manual

Sun Storage 16 Gb Fibre Channel PCIe
Universal Host Bus Adapter, QLogic
Installation Guide For HBA Model
7101674
Part No: E24460-09
August 2018

Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model 7101674
Part No: E24460-09
Copyright © 2016, 2018, Oracle and/or its affiliates. All rights reserved.
This software and related documentation are provided under a license agreement containing restrictions on use and disclosure and are protected by intellectual property laws. Except
as expressly permitted in your license agreement or allowed by law, you may not use, copy, reproduce, translate, broadcast, modify, license, transmit, distribute, exhibit, perform,
publish, or display any part, in any form, or by any means. Reverse engineering, disassembly, or decompilation of this software, unless required by law for interoperability, is
prohibited.
The information contained herein is subject to change without notice and is not warranted to be error-free. If you find any errors, please report them to us in writing.
If this is software or related documentation that is delivered to the U.S. Government or anyone licensing it on behalf of the U.S. Government, then the following notice is applicable:
U.S. GOVERNMENT END USERS: Oracle programs, including any operating system, integrated software, any programs installed on the hardware, and/or documentation,
delivered to U.S. Government end users are "commercial computer software" pursuant to the applicable Federal Acquisition Regulation and agency-specific supplemental
regulations. As such, use, duplication, disclosure, modification, and adaptation of the programs, including any operating system, integrated software, any programs installed on the
hardware, and/or documentation, shall be subject to license terms and license restrictions applicable to the programs. No other rights are granted to the U.S. Government.
This software or hardware is developed for general use in a variety of information management applications. It is not developed or intended for use in any inherently dangerous
applications, including applications that may create a risk of personal injury. If you use this software or hardware in dangerous applications, then you shall be responsible to take all
appropriate fail-safe, backup, redundancy, and other measures to ensure its safe use. Oracle Corporation and its affiliates disclaim any liability for any damages caused by use of this
software or hardware in dangerous applications.
Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be trademarks of their respective owners.
Intel and Intel Xeon are trademarks or registered trademarks of Intel Corporation. All SPARC trademarks are used under license and are trademarks or registered trademarks of
SPARC International, Inc. AMD, Opteron, the AMD logo, and the AMD Opteron logo are trademarks or registered trademarks of Advanced Micro Devices. UNIX is a registered
trademark of The Open Group.
This software or hardware and documentation may provide access to or information about content, products, and services from third parties. Oracle Corporation and its affiliates are
not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and services unless otherwise set forth in an applicable agreement
between you and Oracle. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content,
products, or services, except as set forth in an applicable agreement between you and Oracle.
Access to Oracle Support
Oracle customers that have purchased support have access to electronic support through My Oracle Support. For information, visit http://www.oracle.com/pls/topic/lookup?
ctx=acc&id=info or visit http://www.oracle.com/pls/topic/lookup?ctx=acc&id=trs if you are hearing impaired.

Référence: E24460-09
Copyright © 2016, 2018, Oracle et/ou ses affiliés. Tous droits réservés.
Ce logiciel et la documentation qui l'accompagne sont protégés par les lois sur la propriété intellectuelle. Ils sont concédés sous licence et soumis à des restrictions d'utilisation et
de divulgation. Sauf stipulation expresse de votre contrat de licence ou de la loi, vous ne pouvez pas copier, reproduire, traduire, diffuser, modifier, accorder de licence, transmettre,
distribuer, exposer, exécuter, publier ou afficher le logiciel, même partiellement, sous quelque forme et par quelque procédé que ce soit. Par ailleurs, il est interdit de procéder à toute
ingénierie inverse du logiciel, de le désassembler ou de le décompiler, excepté à des fins d'interopérabilité avec des logiciels tiers ou tel que prescrit par la loi.
Les informations fournies dans ce document sont susceptibles de modification sans préavis. Par ailleurs, Oracle Corporation ne garantit pas qu'elles soient exemptes d'erreurs et vous
invite, le cas échéant, à lui en faire part par écrit.
Si ce logiciel, ou la documentation qui l'accompagne, est livré sous licence au Gouvernement des Etats-Unis, ou à quiconque qui aurait souscrit la licence de ce logiciel pour le
compte du Gouvernement des Etats-Unis, la notice suivante s'applique :
U.S. GOVERNMENT END USERS: Oracle programs, including any operating system, integrated software, any programs installed on the hardware, and/or documentation,
delivered to U.S. Government end users are "commercial computer software" pursuant to the applicable Federal Acquisition Regulation and agency-specific supplemental
regulations. As such, use, duplication, disclosure, modification, and adaptation of the programs, including any operating system, integrated software, any programs installed on the
hardware, and/or documentation, shall be subject to license terms and license restrictions applicable to the programs. No other rights are granted to the U.S. Government.
Ce logiciel ou matériel a été développé pour un usage général dans le cadre d'applications de gestion des informations. Ce logiciel ou matériel n'est pas conçu ni n'est destiné à être
utilisé dans des applications à risque, notamment dans des applications pouvant causer un risque de dommages corporels. Si vous utilisez ce logiciel ou ce matériel dans le cadre
d'applications dangereuses, il est de votre responsabilité de prendre toutes les mesures de secours, de sauvegarde, de redondance et autres mesures nécessaires à son utilisation dans
des conditions optimales de sécurité. Oracle Corporation et ses affiliés déclinent toute responsabilité quant aux dommages causés par l'utilisation de ce logiciel ou matériel pour des
applications dangereuses.
Oracle et Java sont des marques déposées d'Oracle Corporation et/ou de ses affiliés. Tout autre nom mentionné peut correspondre à des marques appartenant à d'autres propriétaires
qu'Oracle.
Intel et Intel Xeon sont des marques ou des marques déposées d'Intel Corporation. Toutes les marques SPARC sont utilisées sous licence et sont des marques ou des marques
déposées de SPARC International, Inc. AMD, Opteron, le logo AMD et le logo AMD Opteron sont des marques ou des marques déposées d'Advanced Micro Devices. UNIX est une
marque déposée de The Open Group.
Ce logiciel ou matériel et la documentation qui l'accompagne peuvent fournir des informations ou des liens donnant accès à des contenus, des produits et des services émanant de
tiers. Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers, sauf mention contraire stipulée
dans un contrat entre vous et Oracle. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des
dommages causés par l'accès à des contenus, produits ou services tiers, ou à leur utilisation, sauf mention contraire stipulée dans un contrat entre vous et Oracle.
Accès aux services de support Oracle
Les clients Oracle qui ont souscrit un contrat de support ont accès au support électronique via My Oracle Support. Pour plus d'informations, visitez le site http://www.oracle.com/
pls/topic/lookup?ctx=acc&id=info ou le site http://www.oracle.com/pls/topic/lookup?ctx=acc&id=trs si vous êtes malentendant.

Contents
Using This Documentation ................................................................................. 9
1 Universal HBA Overview ............................................................................... 11
Kit Contents ................................................................................................. 11
Universal HBA Features and Specifications ....................................................... 11
Operating System and Technology Requirements ................................................ 15
Boot Support ................................................................................................ 15
System Interoperability ................................................................................... 16
Host Platform Support ............................................................................ 16
Switch Compatibility ............................................................................. 17
Storage Support ............................................................................................ 18
Array Storage Support ............................................................................ 18
Tape Storage Support ............................................................................. 18
Environmental Requirements ........................................................................... 19
2 Universal HBA Installation and Removal ...................................................... 21
Observing ESD and Handling Precautions ......................................................... 21
First Time Setup ........................................................................................... 22
Preparing for Installation ................................................................................ 22
Installing and Removing SFP+ Optical Transceiver Modules ......................... 23
▼ To Replace the PCI Bracket ............................................................... 25
Best Practices For HBA Installation .......................................................... 27
Installing the Hardware .................................................................................. 29
▼ To Install the Universal HBA ............................................................. 29
Connecting the Cables ............................................................................ 30
▼ To Apply Power .............................................................................. 34
Understanding LED Status Indicators ................................................................ 36
Removing the Hardware ................................................................................. 37
5

Contents
▼ To Remove the Universal Host Bus Adapter .......................................... 37
3 Operating Protocol Mode Configuration ....................................................... 39
About the Operating Protocol Mode ................................................................. 39
Determining and Changing the Current Operating Protocol Mode ........................... 40
Using the Fast!UTIL Utility to Determine and Change the Operating Protocol
Mode ................................................................................................... 41
▼ To Determine and Change the Operating Protocol Mode Using the UEFI
Setup Menus ......................................................................................... 46
▼ To Determine and Change the Operating Protocol Mode Using the FCode
Utility .................................................................................................. 49
Determining and Changing the Operating Protocol Mode Using the
QConvergeConsole CLI .......................................................................... 50
▼ To Determine and Change the Operating Protocol Mode Using the
QConvergeConsole GUI ......................................................................... 54
SR-IOV/FC-IOR Support ................................................................................ 57
4 Software Installation ..................................................................................... 59
Driver Software for the Oracle Solaris OS ......................................................... 59
Oracle Solaris Diagnostic Support ............................................................ 60
Installing Software for the Red Hat and SUSE Linux OSes ................................... 60
▼ To Install Universal HBA Software for the Red Hat and SUSE Linux
OSes ................................................................................................... 61
Installing Software for the VMware Technology ................................................. 61
▼ To Install the Universal HBA Software for the VMware Technology .......... 61
Installing Software for the Windows OS ............................................................ 62
▼ To Install the Universal HBA Software for the Windows OS .................... 62
Diagnostic Support for the Oracle Solaris, Red Hat, SUSE Linux, and Windows
OSes ........................................................................................................... 63
▼ To Install Diagnostic Support for Oracle Solaris, Red Hat, and SUSE Linux
OSes ................................................................................................... 63
Installing the CLI for Updating the BIOS and FCode ........................................... 64
Updating the Universal HBA Firmware ............................................................. 64
▼ To Update the Universal HBA Firmware .............................................. 64
5 Known Issues ................................................................................................ 69
Link Aggregation Control Protocol (LACP) Cannot Be Used In Certain
Conditions .................................................................................................... 69
6 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

Contents
Perform a One-Time Firmware Update For FC SR-IOV Support ............................ 70
vpd r/w failed Error Messages Are Displayed ................................................. 70
Cannot Boot Net Over DHCP Through the Universal HBA ................................... 71
Glossary ............................................................................................................ 73
7

8 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

Using This Documentation
■Overview – Describes how to troubleshoot and maintain the universal host bus adapter
■Audience – Technicians, system administrators, and authorized service providers
■Required knowledge – Advanced experience troubleshooting and replacing hardware
Product Documentation Library
Documentation and resources for this product and related products are available at http://
docs.oracle.com/cd/E24648_01/index.html.
Feedback
Provide feedback about this documentation at http://www.oracle.com/goto/docfeedback.
Using This Documentation 9

10 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

1
♦ ♦ ♦ C H A P T E R 1
Universal HBA Overview
This chapter provides a basic overview of Oracle's Sun Storage 16 Gb Fibre Channel (FC)
PCIe Universal Host Bus Adapter (HBA), which is a low-profile, dual-port PCIe HBA that
uses Cavium, formerly QLogic, technology. This chapter also describes the various operating
systems, host platforms, storage, and infrastructure configurations that support the universal
HBA, and lists the universal HBA environmental requirements.
This chapter contains the following sections:
■“Kit Contents” on page 11
■“Universal HBA Features and Specifications” on page 11
■“Operating System and Technology Requirements” on page 15
■“Boot Support” on page 15
■“System Interoperability” on page 16
■“Storage Support” on page 18
■“Environmental Requirements” on page 19
Kit Contents
■Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic, with a low-
profile bracket installed
■Standard PCIe bracket
■Accessing Documentation document
■China RoHS Material Disclosure
Universal HBA Features and Specifications
Oracle's Sun Storage 16 Gb Fibre Channel (FC) PCIe Universal host bus adapter (HBA) (part
number 7101674) is a standalone, PCIe low-profile universal HBA that uses Cavium, formerly
Chapter 1 • Universal HBA Overview 11

Universal HBA Features and Specifications
QLogic, technology. The HBA is considered universal because it is a configurable board that
enables you to change its operating protocol mode from a two-port 16 Gb FC HBA to a two-
port 10 GbE Fibre Channel over Ethernet (FCoE) Converged Network Adapter. The universal
HBA has four possible configurations:
■10 GbE FCoE Copper — This configuration provides twin-ax copper cable connectivity
and 10 GbE FCoE HBA functionality. No optical transceiver modules are installed in, nor
provided with, this configuration of the universal HBA.
■16 Gb FC SW (shortwave) Optical — This configuration requires installing 16 Gb
FC shortwave optical transceiver modules in the SFP+ connector of the universal HBA,
enabling 16 Gb Fibre Channel HBA functionality.
■10 GbE FCoE SR (short-range) Optical — This configuration requires installing 10
GbE short-range optical transceiver modules in the SFP+ connectors of the universal HBA,
enabling 10 GbE FCoE Converged Network Adapter functionality.
■16 Gb FC LW (longwave) Optical—This configuration requires installing 16Gb FC long-
range optical transceiver modules in the SFP+ connectors of the universal HBA, enabling
16 Gb FC HBA functionality.
Note - If you are using the Universal HBA in an FCoE Converged Network Adapter
configuration, keep in mind that Link Aggregation Control Protocol (LACP) cannot be used on
the same port as FCoE or iSCSI.
Figure 1, “Sun Storage 16 Gb FC PCIe Universal Host Bus Adapter, QLogic, with SFP+
Transceiver Modules,” on page 13 shows the physical features of the universal HBA with
optical transceiver modules installed, but without any cables attached.
12 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

Universal HBA Features and Specifications
FIGURE 1 Sun Storage 16 Gb FC PCIe Universal Host Bus Adapter, QLogic, with SFP+ Transceiver Modules
Table 1, “Universal Host Bus Adapter Features and Specifications,” on page 13 lists the
features and specifications of the universal HBA. For a list of supported operating systems, see
Table 2, “Supported Operating System/Technology Versions (Minimum) ,” on page 15.
TABLE 1 Universal Host Bus Adapter Features and Specifications
Feature Description
Form factor Standard low-profile form factor
Connector types Small form-factor pluggable plus (SFP+) cages that can be connected with twin-ax cabling
from supported switch manufacturers (See “Switch Compatibility” on page 17), or can
have the following transceivers:
■ SFP+ 16 Gb FC shortwave (part number 7101676)
■ SFP+ 10 GbE FCoE short-range (part number 7101678)
■ SFP+ 16 Gb FC longwave (part number 7101680)
PCIe specification compliance ■ PCI Express Base Specification Revision 3.0
Lanes ■ PCI Express Gen 2 x8
■ PCI Express Gen 3 x4 (x8 Mechanical)
PCIe hot-plug and hot-swap functionality Supported
Maximum power consumption Approximately 24 Watts
Solaris Dynamic Reconfiguration Supported
FCoE full offload in hardware Supported
Boot support Fibre Channel, Fibre Channel over Ethernet, and Ethernet for all operating systems (See
“Boot Support” on page 15)
Chapter 1 • Universal HBA Overview 13

Universal HBA Features and Specifications
Feature Description
Test suite Provided by Oracle VTS software
Receive side scaling (RSS) Supported
MSI-X Supported
Fibre Channel support ■ Dual-port Fibre Channel with 16/8/4 auto negotiation
■ Topologies supported: FC-SW switched fabric (N_Port), FC-AL arbitrated loop (not
supported at 16 Gb) (NL_ Port), and Point-to-point (N_Port)
■ Dual-port Fibre Channel over Ethernet
FC and FCoE compatibility ■ Fibre Channel Physical and Signaling (FC-PH, FC-PH2, FC-PH3)
■ Fibre Channel Generic Services (FC-GS-3)
■ Fibre Channel Framing and Signaling (FC-FS)
■ Fibre Channel Physical Interface (FC-Pl)
■ Fibre Channel Tape and Medium Changers (FC-Tape)
■ Fibre Channel Protocol for SCSI (FCP-3-SCSI)
■ Fibre Channel Switch Fabric (FC-SW-4)
■ Fibre Channel Protocol for SCSI Support (FC-FCP, FC-FCP2)
■ FMA support
■ FC and FCoE boot code for all supported operating systems
Note - Link Aggregation Control Protocol (LACP) cannot be used on the same port as
FCoE or iSCSI.
Ethernet and NIC support Standard Ethernet and Enhanced Ethernet:
■ IEEE 802.1Q VLAN
■ IEEE 802.1p and 802.1D
■ IEEE 802.3x
■ IEEE 802.1Qbb
■ IEEE 802.1Qaz
■ DCBX CEE Rev 1.01
Controller hardware support:
■ Jumbo frames support for frame sizes of at least 9 KB
■ Hardware TCP/UDP checksum generation
■ Hardware IPv4/IPv6 checksum offload
■ Hardware large segmentation offload
■ Hardware Header and Data Split
■ Full-duplex operation is supported
■ Up to 128 MAC addresses
■ Unicast and multicast address filtering
■ VMware NetQueue
■ Packet filtering based on MAC address or VLAN tag
■ Microsoft receive side scaling (RSS)
■ NIC teaming
■ PCI hot-plug functionality
■ Pre-boot eXecution environment (PXE) boot
14 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

Operating System and Technology Requirements
Feature Description
■ iSCSI boot
Operating System and Technology Requirements
The universal HBA requires the operating system (OS) and technology versions listed in
Table 2, “Supported Operating System/Technology Versions (Minimum) ,” on page 15, at
minimum.
TABLE 2 Supported Operating System/Technology Versions (Minimum)
Operating System/ Technology Supported Versions (minimum)
Oracle Solaris OS ■ Oracle Solaris 10 1/13 for the x86 (64-bit) platform (+ patches 149168-07 and
149176-11)
■ Oracle Solaris 10 1/13 for the SPARC platform (+ patches 149167-07 and
149175-11)
■ Oracle Solaris 11.1 for the x86 (64-bit) platform (+ SRU 13.4)
■ Oracle Solaris 11.1 for the SPARC platform (+ SRU 13.4)
■ Oracle Solaris 11.2 for the x86 (64-bit) and SPARC platforms
■ Oracle Solaris 11.3 for the x86 (64-bit) and SPARC platforms
Oracle Linux OS ■ Oracle Enterprise Linux 5.9 (Unbreakable Enterprise Kernel (UEK) 2.6.39-
400, at minimum)
■ Oracle Enterprise Linux 6.4 (UEK 2.6.39-400, at minimum)
SUSE Linux OS ■ SUSE Linux Enterprise Server (SLES) 10 SP4
■ SLES 11 SP2
Red Hat Linux OS ■ Red Hat Enterprise Linux (RHEL) 5.89 (64-bit)
■ RHEL 6.4 (64-bit)
Microsoft Windows OS ■ Windows Server 2008 SP2+ (64-bit)
■ Windows Server 2008 R2 including SP1 (64-bit)
■ Windows Server 2012
VMware technology ■ VMware ESX/ESXi 5.1
■ VMware ESX/ESXi 5.0
Boot Support
FC SAN and FCoE SAN booting through the universal HBA is supported, as listed in Table 3,
“Universal HBA Boot Support,” on page 16.
Chapter 1 • Universal HBA Overview 15

System Interoperability
TABLE 3 Universal HBA Boot Support
Operating System/Technology FC SAN Boot Support FCoE SAN Boot Support
Oracle Solaris 10 1/13 Yes No
Oracle Solaris 11.1, 11.2, 11.3 Yes No
Oracle Linux 5.9 and later No No
Oracle Linux 6.4 and later No No
RHEL 5.9 and later Yes†Yes†
RHEL 6.4 and later Yes†Yes†
SLES 10 SP4 and later Yes†Yes†
SLES 11 SP2 and later Yes†Yes†
Windows Server 2008 SP2+ Yes†Yes†
Windows Server 2008 R2 Yes†Yes†
Windows Server 2012 Yes†Yes†
†While using the Driver Update disk during the installation process. Driver Update is available at the Oracle support area of the QLogic
web site: http://driverdownloads.qlogic.com/QLogicDriverDownloads_UI/Oracle_Search.aspx
System Interoperability
This section provides information about platforms and switches that are compatible with the
universal host bus adapter. This sections contains the following topics:
■“Host Platform Support” on page 16
■“Switch Compatibility” on page 17
Host Platform Support
The universal HBA is supported by the platforms listed in Table 4, “Platform Support,” on page
16. For the most up-to-date information about supported platforms, see your system product
notes and web pages.
For information about the supported OS/technology versions, see Table 2, “Supported
Operating System/Technology Versions (Minimum) ,” on page 15.
TABLE 4 Platform Support
Platform Supported OS/Technology
Oracle's SPARC Servers
Fujitsu M10-1, M10-4, and M10-4S Oracle Solaris
16 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

System Interoperability
Platform Supported OS/Technology
Fujitsu M10 PCI Expansion Unit Oracle Solaris
SPARC T4-1 and T4-2 Oracle Solaris
SPARC T5-2, T5-4, and T5-8 Oracle Solaris
SPARC T7-1, T7-2, and T7-4 Oracle Solaris
SPARC M5-32 and M6-32 Oracle Solaris
SPARC M7-8 and M7-16 Oracle Solaris
SPARC 7-2 and 7-2L Oracle Solaris
Oracle SuperCluster M6-32 Oracle Solaris
Oracle's x86 Servers
Sun Server X4-2, X4-2L, X4-4, and X4-8 Oracle Solaris, Windows, Linux, VMware
Oracle Server X5-2, X5-2L, X5-4, and X5-8 Oracle Solaris, Windows, Linux, VMware
Oracle Server X6-2 and X6-2L Oracle Solaris, Windows, Linux, VMware
Oracle Exalytics In-Memory Machine X4-4 and X5-4 Oracle Solaris, Windows, Linux, VMware
Zero Data Loss Recovery Appliance X4, X5, and X6 Oracle Solaris, Windows, Linux, VMware
Oracle's Telco Servers
Netra SPARC T4-1 Oracle Solaris
Netra SPARC S7-2 Oracle Solaris
Netra X4270 M3 Oracle Solaris, Windows, Linux, VMware
Netra Server X3-2 and X5-2 Oracle Solaris, Windows, Linux, VMware
Switch Compatibility
Note - For technical support issues with any switches, refer to the product documentation or
contact the switch manufacturer.
The universal HBA supports connecting to any 16 Gb/s Fibre Channel (FC) switch and all
Fibre Channel Over Internet (FCoE) switches from any vendor that follows standard FC
specifications, and follows 10GbE NIC/FCoE specifications, with the following considerations:
■Direct Access Storage for FC is supported with COMSTAR.
■FC-SW switched fabric is supported when the HBA is connected to a 16 Gb/s FC switch.
■FC point-to-point (FC-P2P) (N_Port) is supported.
■FC-AL is not supported at 16 Gb/s or faster.
■An FCoE-capable switch is always required for FCoE connections.
Note - This documentation lists switches that are specifically not supported by the universal
HBA, when applicable.
Chapter 1 • Universal HBA Overview 17

Storage Support
Note - If you are using a switch to connect to the Universal HBA in CNA Operating Protocol
Mode, keep in mind that Link Aggregation Control Protocol (LACP) cannot be used on the
same port as FCoE or iSCSI.
Storage Support
This section lists the supported arrays and tape storage devices that can connect to the universal
HBA through a supported switch (see “Switch Compatibility” on page 17). This section
provides the following topics:
■“Array Storage Support” on page 18
■“Tape Storage Support” on page 18
Array Storage Support
The universal HBA supports connecting to, via a supported switch, the following storage
devices:
■Oracle ZFS Storage ZS3-2, ZS3-4, ZS3-BA, ZS4-4
■Oracle ZFS Storage Appliance Racked System ZS4-4
■Oracle ZFS Backup Appliance
■Oracle FS1-2 Flash Storage System
■Oracle's Sun Storage 2540 M2 Array
■Oracle's Sun Storage 6180 Array
■Oracle's Sun Storage 6540 Array
■Oracle's StorageTek 6580, 6780 with 8 Gbps FC host interface cards
■Oracle's Pillar Axiom 600 storage system
■Oracle's Sun Storage 7110, 7210, 7310, 7410 unified storage systems
■Oracle's Sun ZFS Storage 7120, 7320, 7420, 7720 appliances
Tape Storage Support
The universal HBA supports connecting to, via a supported switch, the following tape storage
devices:
■Oracle's StorageTek SL24 Tape Autoloader
18 Sun Storage 16 Gb Fibre Channel PCIe Universal Host Bus Adapter, QLogic Installation Guide For HBA Model
7101674 • August 2018

Environmental Requirements
■Oracle's StorageTek SL48 Tape Library
■Oracle's StorageTek SL500 Modular Library
■Oracle's StorageTek SL3000 Modular Library
■Oracle's StorageTek SL8500 Modular Library
■Oracle's StorageTek Virtual Tape Library: VTL Value and VTL Value Plus
■Oracle's StorageTek T10000B, T10000C Tape Drives
■Oracle's StorageTek 9840C Tape Drive
■Oracle's StorageTek 9840D Tape Drive
■IBM LTO4
■IBM LTO5
■HP LTO4
■HP LTO5
■StorageTek Virtual Storage Manager 7
Environmental Requirements
The universal HBA environmental requirements are listed in Table 5, “Universal Host Bus
Adapter Environmental Requirements,” on page 19.
TABLE 5 Universal Host Bus Adapter Environmental Requirements
Specification Operating Non-Operating
Temperature 0ºC to 55ºC, non-condensing -40ºC to 70ºC, non-condensing
Relative Humidity
(RH)
10% to 90% RH, non-condensing, 27ºC max wet bulb 93% RH, non-condensing, 38ºC max wet bulb
Altitude 3000 m 12,000 m
Vibration 0.20 g in all axes, 5-500 Hz sine 1.0 g in all axes, 5-500 Hz sine
Shock 5 g, 11 ms half-sine 30 g, 11 ms half-sine
