StarTech.com USB32DPES User manual

Manual Revision: 05/28/2015
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
*actual product may vary from photos
Slim USB 3.0 to DisplayPort External
Video Card
Please ensure that the latest
drivers from the StarTech.com
website are installed before
plugging in the USB 3.0 Video
Adapter
USB32DPES

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and
Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements.............................................................................................................................. 1
Installation ..............................................................................................2
Driver Installation Windows .................................................................................................................. 2
Multiple USB Video Adapter Installation .......................................................................................... 3
Verifying Installation................................................................................................................................ 3
Supported Resolutions .........................................................................4
Technical Support ..................................................................................5
Warranty Information............................................................................5

Instruction Manual
1
Introduction
Packaging Contents
• 1 x USB 3.0 to DisplayPort video adapter
• 1 x Quick install guide
System Requirements
• DisplayPort enabled display device (e.g. monitor, projector, HTDV, etc)
• USB enabled computer system with:
Microsoft Windows® 8/8.1 (32/64-bit) 7 (32/64-bit) Vista (32/64 bit)
Operating systems are subject to change. For the latest requirements, please
visit: http://www.starTech.com/USB32DPES
Available USB port (USB 3.0 recommended)
Recommend Specications for 1~2 Video Adapters:
CPU: Intel® Core™ i3 2.8 GHz or equivalent (i5 recommended for HD video)
RAM: 2 GB or more (4 GB recommended for HD video)
Recommend Specications for 3~4 Video Adapters:
CPU: Intel® Core™ i5 Quad Core 2.8 GHz or equivalent
RAM: 4 GB or more
Recommend Specications for 5 Video Adapters:
CPU: Intel® Core™ i7 Quad Core 3.0 GHz or equivalent
RAM: 8 GB or more

Instruction Manual
2
Installation
Please ensure that the driver installation is complete prior to the physical
installation (plugging in) of the USB 3.0 Video Adapter
Driver Installation Windows
1. Download the latest drivers from the StarTech.com website.
2. Locate the Setup.exe application. This le will be located in the root directory of the
downloaded le.
3. Executing the Setup.exe
application will launch the
following screen. Please click
on Next:
*Ensure that the USB Video
Adapter is not connected to
the host computer.
4. Once the Windows has nished
the driver installation, it will prompt you to restart the computer. Select “Yes, I want
to restart my computer now”, and click the “Finish” button.
5. While the computer is restarting, connect the video cable from the secondary
monitor/display to the adapter, and turn the monitor/display on.
6. Once Windows has fully loaded, plug the USB Video Adapter into an available USB
3.0 port of your PC or Notebook.
7. Windows will automatically install the drivers. Once installation is completed your
USB display will activate.

Instruction Manual
3
Multiple USB Video Adapter Installation
Ensure you have the latest version of the drivers installed, otherwise, please download
them from the StarTech.com website (www.startech.com).
1. Complete the standard driver installation steps, up to when you plug in the rst USB
Video Adapter.
2. Connect another monitor/display to the second USB Video Adapter, then turn on
the display.
3. Connect the USB type A connector on the second USB Video Adapter to an available
USB 3.0 port on the host computer. The driver installation will begin automatically.
Repeat these steps for each additional USB Video Adapter you wish to install. Once all
USB Video Adapters are installed, reboot the computer. After rebooting, you may be
prompted to reboot one nal time; please do so.
Verifying Installation
From the main desktop, right click on “computer” or “My Computer”, then select
Manage. In the new Computer Management window, select Device Manager from the
left window panel.
Double-click the Universal Serial Bus Controllers category and the USB adapter should
be visible.

Instruction Manual
4
An audio device will also be listed under the“Sound, video and game controllers”
category in Device Manager. As Windows will only support one audio output at a time,
this will override the default sound card on the computer (if any), resulting in no audio
from the computer speakers. Audio will only output over HDMI.
If you wish audio to output from the computer speakers instead of HDMI, then you
must manually change the default audio device from the“Hardware and Sound”
settings in the Control Panel.
Supported Resolutions
Resolution Color Depth
1920 x 1200 @ 60Hz 16, 32 bit
1920 x 1080 @ 60Hz 16, 32 bit
1680 x 1050 @ 60Hz 16, 32 bit
1600 x 900 @ 60Hz 16, 32 bit
1440 x 900 @ 60Hz 16, 32 bit
1360 x 768 @ 60Hz 16, 32 bit
1280 x 800 @ 60Hz 16, 32 bit
1280 x 768 @ 60Hz 16, 32 bit
1280 x 720 @ 60Hz 16, 32 bit
Resolution Color Depth
1600 x 1200 @ 60Hz 16, 32 bit
1400 x 1050 @ 60Hz 16, 32 bit
1280 x 1024 @ 60Hz 16, 32 bit
1280 x 960 @ 60Hz 16, 32 bit
1152 x 864 @ 60Hz 16, 32 bit
1024 x 768 @ 60Hz 16, 32 bit
800 x 600 @ 60Hz 16, 32 bit

Instruction Manual
5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
