Techly IADAP USB31-HDMI User manual

USB 3.1 Type- C to HDMI
Adapter（DP Alt mode）
User Manual
Contents
1.0 Introduction ........................................................1
2.0 Features .............................................................1
3.0 Specifications ......................................................2
4.0 Package Contents ................................................2
5.0 Product Show ......................................................2
6.0 Operation ...........................................................3
7.0 Connection Diagram .............................................3

1
USB 3.1 Type- C to HDMI
Adapter
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or using this product. Please keep this manual for future
reference.
1.0 INTRODUCTION
This USB3.1 Type-C to HDMI Adapter provides high throughput using
the USB 3.1 bus and supports the high definition monitors with high
resolution and high refresh rate. The USB3.1 Type-C Adapter allows
you to connect your desktop PC or laptop's USB port to an extra
monitor or TV.
2.0 FEATURES
Standard USB3.1 Type-C
Supports USB 3.1 input and HDMI output
Flexible USB Type-C Switching Support for USB 5G and
DisplayPort 1.2 Alt mode
Supports per lane data rates of 5.4 Gbps (HBR2), 2.7 Gbps (HBR)
and 1.62 Gbps (RBR)
Supports multiple color formats: RGB 6/8/10/12-bit per
component (bpc) and YCbCr4:4:4, YCbCr4:2:2,8/10/12bpc
Supports HDMI 1.4 and former versions
Supports resolution up to 3840x2600 @60Hz (mirror mode) in
DP1.1 (or 1.2) in SST mode.
Supports resolutions as follows:
4Kx2K，@ 24Hz、25Hz、30Hz；
1080P，@24Hz、50Hz、60Hz；
720P、480P、576i、480i，@50Hz and 60Hz
Supports HDMI audio
Supports bus-powered and self-powered operation

2
3.0 SPECIFICATIONS
Signal Inputs/Output
Input port
USB3.1 Type-C Male x1
Output port
HDMI Female x1 (HDMI 1.4)
Warranty
Limited Warranty
1 Year
Environmental
Operating Temperature
0 ℃to +45℃
Operating Humidity
10% to 85 % RH (no
condensation)
Storage Temperature
-10℃to +80℃
Storage Humidity
5% to 90 % RH (no
condensation)
Certifications
FCC,CE
Power Requirement
USB bus power
External Power Supply
NO
Accessories Adapter
Size(L-W-H)
Main Unit :41.5×37×14.5mm
Cable: 150mm
Remote control
NO
User Manual
English Version
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
Main unit x1
User Manual x1
5.0 PRODUCT SHOW

3
6.0 OPERATION
①Connect USB3.1 Type-C port of this product to computer
②Connect HDMI output of this product to HDTV using one HDMI
M/M cable
Attention: Insert / Unplug cable gently.
7.0 CONNECTION DIAGRAM
P/N13009
