oraimo OIM-211A User manual

ICE MAKER
OIM-211A
User Manual
[email protected]
us.oraimo.com
Scan to Visit Our Website

CONTENTS
1
IMPORTANT
SAFETY
INSTRUCTIONS
1-2
2
KNOWING
YOUR
ICE MAKER
3-5
3
USING
YOUR
ICE MAKER
6-8
4
CLEANING
AND
MAINTENANCE
9-11
5
TROUBLE-
SHOOTING
GUIDE
12-13
6
WARRANTY
AND
SERVICE
14
ICE MAKER

READ ALL INSTRUCTIONS BEFORE USE AND SAVE FOR FUTURE REFERENCE
Specifications
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by person responsible for their safety.
Close supervision is necessary when any appliance is used by or near children. Children should be
supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not
be done by children unless they are older than 8 and supervised. Keep the appliance and its cord out of
reach of children.
Use the appliance only for intended household purposes as described in this User Manual.
INTENDED USE
When using an electrical appliance, especially when children are present, basic safety
precautions should always be followed, including the following:
This appliance must be provided with correct voltage via a professionally installed power socket. Make sure
the voltage indicated on the label of the appliance is the same as your local supply.
DO NOT operate the appliance with a damaged cord or plug or if the product malfunctions, is dropped or
damaged in any manner.
Always plug the appliance directly into a wall outlet / receptacle. Never use with an extension cord or
relocatable power tap (outlet / power strip).
DO NOT let cord hang over edge of table or counter, or touch hot surfaces.
DO NOT immerse any part in water or any other liquid.
ELECTRICITY SAFETY
DO NOT attempt to disassemble, repair, modify or replace any part of the appliance. No user serviceable
parts inside. All servicing should be performed by qualified personnel only.
Always place and use the appliance on a dry, stable, level, and horizontal surface. Make sure it cannot be
easily knocked over by a person or object.
Always turn the appliance OFF and unplug it before cleaning, making any repairs or servicing, or whenever not
in use.
DO NOT sit on or place any object on top of the appliance.
DO NOT use with water that is micro-biologically unsafe or of unknown quality.
DO NOT use mechanical devices to defrost. Carry out self-cleaning cycle to remove any frozen parts.
If the appliance is stored in a cold environment, wait at least 3 hours for the appliance to warm to room
temperature before plugging it in.
RELATED TO USE
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
DO NOT touch or hold the mains plug with wet hands.
01
Ice Maker
02
Ice Maker
Fill the water tank with fresh potable water or connect
with water filtration system to prolong the service life.
IMPORTANT SAFETY
INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS
DO NOT tilt the ice maker. If tipped over, set it upright
on a flat, level surface for at least 2 hours before use.
Input
Rated Power
Ice Basket Capacity
Water Tank
Daily Production
120V~ 60Hz
170W
3.3lbs./1.5kg
0.74Gal./2.8L
26lbs./12kg

04
Ice Maker
Drainpipe
Power Cord
Water Inlet
MAX
Control Panel
& Display
FRONT
Ice Basket
Ice Full Sensor
MAX Water Line
Water Tank
Water Level
Detector
Transparent
Lid
Ice Outlet
Water Filter
Inlet Pipe
(9.8ft. / 3m)
Ice Scoop
02
KNOWING
YOUR
ICE MAKER
REAR
This ice maker may have been tilted or placed upside down during transportation.
Please set it upright for at least 2 hours before initial use to allow the refrigerant
fluid to settle.
2h
Ice Scoop
Holder

03
USING YOUR
ICE MAKER
05
Ice Maker
Control Panel & Display
Start/Stop
Press to start or
stop making ice.
Self-cleaning
Hold for 3s to start
or stop cleaning cycle.
Ice Making
Indicator stays
solid on during
ice making cycle.
Cleaning
Indicator stays
solid on during
cleaning cycle.
Add Water
Indicator flashes
when lack of water.
Add water in time.
Ice Basket Full
Indicator stays
solid on when
ice full. Remove
ice in time.

03
07
Ice Maker
08
Ice Maker
Connect with Water Supply
System
Connect the other end with water
supply system. A 1/4'' connector may
be required.
* It is recommended to connect with
water filtration system to prolong the
service life of the ice maker.
Scoop Ice Out
The ice maker will start to produce ice in 15 minutes. Scoop
the ice cubes out once made.
Put in use or store in freezer to avoid melting.
Start Making Ice
Plug into a properly installed grounded outlet, then press
button to start ice making cycle. It will keep making ice until
the ice basket is full.
Add Water Manually
Take the ice basket out, fill the water tank with clean
potable water below MAX line.
* Recommended water type: distilled or demineralized water at
40~ 82°F.
Getting Started
Make sure the drain plug is firmly inserted before use.
The ice maker will stop making ice when the ice bin is full and resume in 8 hours
automatically. Remove the ice cubes timely, the unit will restart making ice
immediately if there is plenty of water.
Locate and Clean
Locate upright on a flat, level surface with at least 3 inches
of clearance on the sides and back. Clean the tank, ice
basket and ice scoop, then settle for at least 2 hours before
first use.
Automatic Refilling
To add water automatically, connect the included hose to the water supply system as
instructed. An adapter (not included) may be required as per the type of water supply
system in your home.
To avoid overflow of water, do not add water manually when the ice maker is already
connected to the water supply system.
Insert the Hose
Fully insert the included hose into the
water inlet till the end is reached.
To remove, hold against the gray ring
and pull out.
3 inch
3 inch
1 2
Remove
1
2
Insert
MAX
Not Included

10
Ice Maker
Self-Cleaning
To keep your nugget ice tasting fresh, we recommend that you carry out
self-cleaning at least once every 1 to 2 weeks.
Fill the tank with water below MAX line or
connect with water supply system.
Hold for 3s to start an 8-minute
self-cleaning cycle ( stays solid on).
Once completed, will turn off.
Unhook the drainpipe and lay down to
a sink.
MAX
3s
04
CLEANING AND
MAINTENANCE

11
Ice Maker
12
Ice Maker
Regular Cleaning
To remove the fallen dirt or fibers,
we recommend cleaning the ice
basket and water tank once a
week. Unplug before cleaning.
Unplug and take out the ice
basket. Remove the water
filter on the right corner of
the tank.
Rinse clean the ice basket.
and water filter with diluted
detergent and water.
Clean the water tank using
a soft cloth moistened with
water.
To clean the exterior, use a
soft cloth dampened with
soapy water. Dry with a
soft cloth.
Removal of Scale
/Mineral Build-up
Fill the tank with water below
MAX line.
Add in distilled white vinegar or
citric acid descaling agent. Set
aside for 12 hours or overnight.
Hold CLEAN for 3s to start self-
cleaning cycle. Repeat up to 3
cleaning cycles.
Drain the mixture and continue
running 3 cleaning cycles with
fresh water for each rinse.
TROUBLESHOOTING GUIDE
The troubleshooting guide addresses the most common problems. If problems persist,
feel free to contact the Customer Support at [email protected]
flashing
• Lack of water. Fill water up to the MAX
level and press to restart.
• Disassemble the water filter. Check and
clean when necessary.
• Check if the water level detector is
blocked. Clear and restart.
PROBLEM SOLUTION
1
2
3
4
1
2
3
4
For scale or mineral build-up,
follow the directions to deep
clean periodically or when
needed. Do not clean with
solvents or chemicals.
When not in use for an extended period of time, drain the water tank and clean as
instructed. Cover and store in a cool, dry location away from direct sunlight.
solid on
• Ice bin full. Remove ice and press to
restart.
• Ice full sensor damaged. Contact
Customer Support for help.
solid on, flashing
• Ice-making assembly is defrosting.
Wait 30 to 45 minutes for the ice maker
to return to normal automatically.
• Or you can hold for 3s to carry
out a self-cleaning cycle, then press
to restart after cleaning is done.
flashing, flashing
Ice-making assembly is frozen. Wait 20
minutes for the ice maker to defrost
automatically. Unplug after 20 minutes
then restart.
MAX
12H

13
Ice Maker
14
Ice Maker
The ice maker does not
work or stops making
ice suddenly
Noise during ice making
• Make sure the ice maker is placed
upright on a flat, level surface with at
least 3 inches of clearance on the sides
and back.
• Check if the fan at the back is blocked
by any foreign objects.
• Carry out a self-cleaning cycle to
remove any frozen parts.
Water leaks
• Check if the hose is fully inserted into the
water inlet till the end is reached.
• Unplug the hose and check if the inserted
end is intact and flat. Cut for a new flat end
when necessary.
• Wrap the connection part with PTFE thread
seal tape for a tight connection.
Ice making cycle is
normal but no ice is
being formed
• Ice making capacity goes down as the
environmental temperatures go up, and will
be severely reduced at temperatures over 90°F.
• A restricted drain or standing water in the
water tank. Check the drainpipe for kinks.
• Check if lights up. stays solid on
during ice making cycle.
• Check if the tank is lack of water.
Fill with water and press to restart.
• The ice maker will stop making ice
when the ice basket is full and resume
in 8 hours automatically. Remove the
ice cubes timely, the unit will restart
immediately.
• Hold for 3s to carry out a
self-cleaning cycle.
• Disassemble the filter at the bottom of
tank. Check and clean when necessary.
Thanks for choosing Oraimo Ice Maker.
This product is covered with Oraimo product and labor warranty for 12 months
from the date of its original purchase.
The warranty will not apply in cases of:
- Misuse, dismantling, or repairs performed by unauthorized personnel.
- Any appliance that has been tampered with or used for commercial purpose.
- Use of force, natural hazards, damage caused by external influences.
- Damage caused by non-observance of the User Manual, e.g. connection to an
unsuitable mains supply or non-compliance with the instructions.
- Partially or completely dismantled appliances.
- Defects caused by or resulting from damages from shipping or alteration to the
product or any of its parts that have been performed by unauthorized personnel.
We can only provide after-sales service for products that are sold by
Oraimo or Oraimo authorized retailers and distributors.
If you have purchased your appliance from a different place, please
contact your seller for return and warranty issues.
※Please have your order ID
ready before contacting
Customer Support.
WARRANTY
AND
SERVICE
Ice cubes easily melted
The ice basket is not refrigerated and the
ice cubes will melt if not used. Please put
the ice cubes in use or store in freezer
once made to avoid melting.

15
Ice Maker
Warranty Certificate
[email protected]
us.oraimo.com
Scan to Visit Our Website
Made in China
This product is covered by a guarantee from the date of purchase. The warranty is valid only
when the warranty card is properly completed. Warranty is limited to the core product. Accesso-
ries included in the package are not covered. Please contact us if you have a question or experi-
ence a problem with the product, we promise we will give you a satisfied solution within 24 hours.
Order ID
Product Model
Problem Description
Customer's Name
Rev_1.0
Intertek
4008051
CM
