ORANGEBOX Cubb Series User manual

Page 1 of 9
P/N 1395702001
148062 Rev B
Cubb Tables Project Table
Assembly Instruction
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2018 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
#4
2x
#3
2x
#5
10mm
8mm

Page 2 of 9
148062 Rev B
Sample BOM
(will change dependent on style number)
Parts List
Tabletop -Model Dependant
Oak Leg Side A -1362864001
Metal Support End -1363757001
Metal Support Side -1363198001
Cross Beam -Model Dependant
Wire Fixing Kit -59382741
x1
x2
Oak Leg Side B -1362864002
x2
x2
x2
Mid Leg Support -Model Dependant
x2
x1
x1
Fixing Kit -1363884001 or 1363884001
x2
Cable Cover -11350093
x4
A-Tabletop x1 B-Mid Leg Support x2
K-M6 #4 csk Shoulder Screw
M-M8 #5 Hex csk Screw N-M6 Nut
L- M6x16 #3 Phillips Screws
G-Cable Cover
x16
x4 H-Side A Leg x2
J-M6 #4 csk Shoulder Nut
x16
C-Metal Support End x2
E-Cross Beam x1
D-Metal Support Side x2
I-Side B Leg x2
x4
x4
F-Wire Fixing Kit
x2
x16

Page 3 of 9
148062 Rev B
C
C
B
B
1
2
A
L
#3
50%
L
12x
M6x16
#3

Page 4 of 9
148062 Rev B
34
H
H
I
Cut out should
face inward
K
J
K
J
5
6
Cut out should
face inward
Apply to both A side legs
Apply to both B side legs
4Nm
max
#4
2x
4Nm
max
#4
2x
I

Page 5 of 9
148062 Rev B
D
D
8
x8
9
D
2x
#4
K
J
x12 7
Tighten
#3
4Nm
max
L
4Nm
max

Page 6 of 9
148062 Rev B
F
F
N
10
x4
#5 4Nm
max
11
M
12 13 14
Parallel
4Nm
max
x2
10mm

Page 7 of 9
148062 Rev B
15 16
15a
15b
x2
17 18
Hand tighten
Tug to ensure
tightened
correctly
x2
x2
Tighten
8mm

Page 8 of 9
148062 Rev B
20
Install power (model dependant). Route cable down leg.
Reference assembly direction
143741 or 143742
19

Page 9 of 9
148062 Rev B
G21
Centered in leg
22
x4
Model Dependant
