ORANGEBOX Cubb Tables One Piece Table User manual

Page 1 of 8
148061 Rev A
P/N 1395698001
Cubb Tables One Piece Table
Assembly Instruction
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2018 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
#4
2x
2x
#3

Page 2 of 8
148061 Rev A
Sample BOM
(will change dependent on style number)
Parts List
Tabletop -Model Dependant
Oak Corner Leg -1363898001 or 1363892002
Metal Support End -Model Dependant
Metal Support Ctr -Model Dependant
Fixing Kit -1363884001, 002, 003 or 004
Cable Cover -11350092 (Meeting Height Only)
x1
x4
x2
x2
x1
x1
A-Tabletop x1
B-Corner Leg x4
E-M6 #4 csk Shoulder Screw
x8
G- M6x16 #3 Phillips Screws H-Cable Cover
x16 x4
F-M6 #4 csk Shoulder Nut
x8
C-Metal Support Center
D-Metal Support End
x2
x2

Page 3 of 8
148061 Rev A
D
D
C
C
1
2
A
G
#3
50%
G
16x
M6x16
#3

Page 4 of 8
148061 Rev A
34
B
F
E
4Nm
max
#4
2x
5
BA E F
4x, repeat step 3-4
4Nm
max
#4
2x

Page 5 of 8
148061 Rev A
6
#3
4Nm
max
L
Tighten
16x

Page 6 of 8
148061 Rev A
2x
7

Page 7 of 8
148061 Rev A
8
9
Install power (model dependant). Route cable down leg.
Reference assembly direction
143741 or 143742

Page 8 of 8
148061 Rev A
10
x4
Centered in leg
H
11
Model Dependant
