Orava Stoma fresh User manual

Stoma fresh
Sonic electric toothbrush
Instruction manual EN
Stoma fresh

2EN
Intended use of the device
The device is intended solely for personal oral hygiene, to the
extent determined by technical and operational parameters and
functions, safety and user instructions, and external influences of
the operating environment.
ORAVA electrical appliances are manufactured according to
the state of the art and recognized safety rules. Nevertheless,
improper or improper use or improper use may result in injury or
endangerment to the life of the user or a third party or to a third
party. damage to equipment and other property.
1. GENERAL SAFETY INSTRUCTIONS AND WARNINGS
• This document contains important safety instructions and warnings
for safe, correct and economical operation of the electrical
equipment. Its compliance helps the user avoid risks, increase
reliability and product life.
• In this document, the general term product is used in text parts
such as:
electrical equipment - any device used for the production,
conversion, transmission, distribution or use of electricity.
• From the point of view of the purpose of using electricity, the
concept of electrical equipment in the strict sense of the word will
include the following categories:
- household electric appliances,
- information and communication equipment,
- consumer electronics,
- lighting equipment,
- electrical and electronic tools,
- toys and equipment for sporting and recreational purposes,
- medical devices (aids),
- monitoring and control devices,
- vending machines.
1.1 General safety instructions
• Before operating the unit, we recommend that you carefully read
the instruction manual and operate the equipment in accordance
with the instructions!
• The safety instructions and warnings in this manual do not cover all
the possible conditions and situations that may arise when using
the device. The user must understand that a factor that cannot be
incorporated into any of the products is personal responsibility and
caution. These factors must therefore be ensured by users serving
this device.

3EN
• Failure to follow the safety instructions and warnings is forbidden
by the manufacturer for any damage to health or property!
• Keep the instruction manual as close to the device as possible
throughout its service life. Always keep the instruction manual
together with the appliance for future use and use by new users.
• Use the appliance only for the intended purpose and in the manner
specified by the manufacturer.
• The appliance is intended for home and similar indoor use without
special focus.
• This appliance is intended, in addition to domestic use, for the
following uses:
- in shops, offices and other similar work environments;
- in economic buildings;
- in hotels, motels and other residential environments;
- in bed and breakfast establishments.
• It is not a professional device for commercial use.
• Do not change the technical parameters and features of the device
by unauthorized modification or modification of any part of the
device.
• The manufacturer is not responsible for damages caused during
transportation, misuse, damage or destruction of the equipment
due to adverse weather conditions.
1.2 Safety of the operating environment
• Do not use the device in an industrial environment or outside
environment!
• Do not expose the appliance to:
- sources of excessive heat or open flame,
- dripping or splashing water,
- vibration and excessive mechanical stress,
- insects, animals and plants,
- aggressive and chemical substances.
• The operating environment of the device must always be in
accordance with the basic characteristics set out.
• Features of the operating environment:
1. Ambient temperature: +5 ÷ +40 ° C
2. Humidity: 5 ÷ 85%
3. Altitude: ≤ 2 000 m
4. Occurrence of water: intermittent condensation of water or
occurrence of water vapor
5. Occurrence of foreign bodies: quantity and type of dust are
insignificant
6. Protection degree: min. IP20 (device protected from touching
dangerous parts by hand and non-waterproof)

4EN
• This degree of protection is not indicated on the product and on the
technical parameters in the operating instructions.
• If the protection class of the product is different from IPX0, this
information is then displayed on the label of the appliance or in the
technical data of the operating instructions.
• Other characteristics of the domestic operating environment
(mechanical stress - vibrations and vibrations, occurrence of plant,
animals, weather effects ...) are negligible in terms of effect on the
correct and safe use of electrical equipment.
1.3 Electrical safety
• Before connecting the appliance to the power supply for the
first time, make sure that the voltage on the appliance label
corresponds to that of the household electrical outlet.
• The electric appliance is designed to power from 1 / N / PE ~ 230 V
50 Hz.
• The electrical safety of the appliance is guaranteed only if it is
properly connected to the mains.
• Electrical protection class I equipment is equipped with a
protection against electric shock by means of protective earthing of
inanimate parts, which can become dangerous when the device is
malfunctioning. Always connect such devices to properly installed
mains sockets that are equipped with earthing conductors and
have a properly grounded earthing conductor.
All electrical equipment is equipped with a three-wire power supply.
• Class II electrical equipment is protected against electric shock
by double insulation or by enhanced insulation of hazardous
live electrical parts. Device of protection class II it must not be
equipped with means to connect protective earthing.
All electrical equipment is equipped with two-wire power supply.
• Class III electrical equipment is a device that is powered by a small
safe voltage source (battery or accumulator) and does not present
any danger to the user from electrical shock.
• In order to provide increased safety against the risk of electric
shock due to the use of electrical appliances by laypersons, it is
recommended to install the power supply circuit for sockets with
a rated current not exceeding 20 A RCD with a rated operating
current not exceeding 30 mA.
To ensure the safety and correctness of the electrical installation,
consult a qualified electrician.
• Only use a power cord with a plug (mains lead) supplied with the
device and compatible with a wall socket. Using another cable may
result in fire or electric shock.
• Always connect an electrical appliance to an easily accessible
mains socket. In the event of an operating fault, the appliance must
be switched off as soon as possible and disconnected from mains
supply.

5EN
• The power cord and mains plug must always be easily accessible
for safe disconnection of the electrical appliance from the power
supply.
• Do not pull off the power cord by pulling the cable. Disconnect the
power cord by pulling the plug behind the power cord plug.
• If you use an extension cord, make sure that the total rated power
of all devices connected to the extension cord does not exceed the
max. current load on the extension cable.
• If you need to use an extension cord or power supply block, make
sure that the extension cord or power pack is plugged into a power
socket, and not to another extension cord or power supply. The
extension power cord or power supply block must be designed for
grounded electrical plugs and connected to a properly grounded
electrical socket.
• The power plug of the appliance must be compatible with the mains
socket. Never use any adapters or modify the socket in any other
way. Do not use inappropriate or damaged drawers!
• To avoid electrical shock, plug the power cables into properly
grounded electrical sockets. If the device is equipped with a 3-pole
plug, do not use adapters that do not have a grounding element or
remove the grounding element from the plug or adapter.
• Do not bend, crush or otherwise expose the power cord of the
appliance to mechanical stress or external heat sources. Damage
to the power cord may result in electric shock.
• When the power cord is damaged, disconnect the appliance from
the mains and do not use it again.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service department or a similarly qualified person
to avoid the risk of electric shock.
• Regularly check and maintain the electrical appliance as well
as the power cord and power socket. Disconnect the power plug
regularly and clean it if necessary. Pollution by dust or other
substances may cause disruption of the insulating state and
consequently fire.
• Do not expose the appliance to water or moisture. The ingress of
water into the appliance increases the risk of electric shock.
If the power cord is wet or the water has penetrated the water,
disconnect it immediately from the mains. If the appliance is
plugged into a mains socket and if possible, turn off the power
circuit before attempting
unplug the power. If you are pulling wet wires from a live power
source, be very careful.
• If the electrical equipment is installed (connecting) the protective
covers are dismantled, the electrical parts must not be accessible
to the user when the installation is finished.

6EN
1.4 Safety of persons
• This appliance is intended for use and operation by persons
without electrotechnical qualification - lay people, according to the
instructions specified by the manufacturer.
• Device operation includes activities such as switching on and off,
user manipulation and setting of operating parameters, visual
or auditory inspection of the equipment, and user cleaning and
maintenance.
• This appliance can be used by children under the age of 8 and
persons with reduced physical, sensory or mental capabilities or
lack of experience or knowledge when supervised or instructed to
use the appliance safely and understand the dangers involved.
• Children may not play with the appliance.
• Cleaning and maintenance for users may not be performed by
children unattended.
• Always keep the appliance out of reach of children during use and
operation. Be sure to download the appliance even for a freely
accessible power cord.
• Always be careful when operating the electric appliance! Do not
use an electric appliance if you are overly tired, under the influence
of medication or narcotic drugs that reduce attention and focus.
• Inattention during operation may result in serious injury.

7EN
1.5 Cleaning, maintenance and repairs
• Observe the normal user cleaning and maintenance of the
appliance in the recommended way. Do not use solvents or harsh
cleaners for cleaning. Pollution and visible stains from finger
contact, respectively. The hands can be cleaned using detergent
detergents specially designed to clean household appliances.
• If you do not use the appliance, clean it or disconnect the appliance
from the power supply when the appliance is faulty.
• Electrical appliances that are cleaned after use and are not
intended to be completely or partly immersed in water or other
liquid, protect against the effects of dripping and / or splashing
water and before immersion.
• Electric household appliances, like all other technical devices, are
subject to the surrounding environment and natural wear. Since the
legal framework of regular maintenance is not laid down for lay-in
electrical household appliances, the manufacturer recommends
that the user have the appliance checked and cleaned at least
once a year by a specialist workshop.
• By doing so, it is possible to achieve safety, operational reliability
and increased service life.
• Do not disassemble the electric appliance! The appliance works
with a dangerous voltage. For this reason, always switch off
the appliance and disconnect it from the mains supply during
user maintenance. In the event of a fault, please have the repair
serviced by an authorized service center.
• Before calling a service:
1. Verify that you are unable to remedy the malfunction yourself
according to the procedure described in the chapter „Remedy
of operating faults“.
2. Turn the appliance off and on to make sure the fault reappears.
3. If the malfunction of the appliance still persists after these
operations, call the nearest specialist service center.
• Never repair the electric appliance yourself!
• Unauthorized, unqualified and improper use of an electric
appliance may result in electric shock or other serious injury.
• Only carry out the warranty or post-warranty repair of an electrical
appliance to an authorized qualified person (*).
(*) Competent qualified expert: the sales department of the manufacturer or importer or the
person qualified and authorized to carry out this type of activity with the ability to avoid
all risks.

8EN
2. Special safety instructions. Read carefully!
• Electrical device is designed and manufactured in such a way as
to allow safe operation and use by unauthorized personnel. Despite
all the measures that have been made by the manufacturer for
safe use, operation and use, and carry certain residual risks and
associated potential hazards.
• The following symbols and their meanings have been used on
the device and in the accompanying documentation to indicate
potential hazards:
This symbol alerts users that if the safety instructions for
using and operating the device are not followed, there is a
risk of:
Risk of serious injury or death! Risk of equipment damage
or other property damage!
This symbol indicates that the product is double insulated
between hazardous parts (parts with hazardous voltage
from the power supply) and parts that are accessible in
normal use.
When charging the built-in battery using the AC adapter,
use only accessories that are safe.
This marking of the electrical device means that the device
is designed with an outer cover to protect against water
ingress. This is the level of protection against immersion in
water (within 30 minutes at a depth of 1 meter).
Transportation/Transfer
• Take care when moving and carrying to avoid tipping, falling and
damaging the unit.
Risk of equipment damage!
Unpacking/Packaging
• Unpack the device and accessories before use and dispose of all
parts of the packaging materials, etiquettes and labels.
• Store the packaging materials in a safe place or keep them away
from children and incapacitated persons.
Risk of serious injury!
There is a risk of suffocation!
IP X7

9EN
Inspection/Commissioning
• We recommend performing initial and subsequent regular
inspections of the device. Use the device only with accessories
supplied and approved by the manufacturer.
• Never use the device if it is incomplete, damaged or parts or
accessories have been damaged during use (eg due to a fall).
Risk of serious injury!
• Inspect and assemble the unit before commissioning, following the
instructions in “Before Use”.
• Never clean the device (body with electrical parts) in such a way
as to allow it to be immersed in the liquid and the liquid to enter the
device.
• Clean electrical parts only with a damp cloth and wipe dry or allow
to dry.
• Keep the device clean and dry. Risk of serious injury!
Warning!
• If the product has been stored at lower temperatures, first
acclimatize it (about ˝ to 1 hour) before using it again to remove
any moisture inside the enclosure, stiffening moving parts, and
maintain the mechanical strength of the plastic parts.
Operation/Supervision
Warning!
• This product may only be used with original and
undamaged parts and accessories.
• Suitability and proper use are specified in section
„Use“.
Risk of serious damage to health!
Warning!
• Keep the device dry.
• Do not use or place the device near containers
containing water. Should the device fall into the water,
turn it off and allow the device to dry completely.
• If the device subsequently shows signs of malfunction
or damage, take it to a qualified service center for
inspection.
• Never overload the device beyond the limits specified
in the technical data!

10EN
Do not expose the device to:
- direct sunlight, sources producing excessive heat,
- vibration and mechanical stresses,
- polluting chemicals,
- water and excessive moisture,
- insects, plants,
- aggressive environmental impacts.
Risk of serious injury!
There is a risk of damage to the device or other
property damage!
• Observe the operating mode of the device (operation
/ operation time and pause) according to the
operating and use instructions. Clean the device
regularly. Contamination of the device can result
in reduced operating parameters and possible
consequential irreversible damage.
• If any safety part (mechanical, electrical) is part of the
device, never put it out of operation! if the safety part /
component is damaged or malfunctioning, do not use
the device!
Safety of persons
• This device may be used by children over 8 years of
age and persons with reduced physical, sensory or
mental abilities or lack of experience or knowledge if
they are supervised or instructed in the safe use of
the device and understand the dangers involved.
• Children must not play with the device.
Risk of serious injury!
There is a risk of damage to the device or other
property damage!
• If you have had gum or mouth surgery in the past two
months, consult your dentist before using the device
for the first time.
• If your gums bleed for more than a week or
abnormally bleed while using the device, consult your
dentist for further use.

11EN
• If you have medical complications, consult your
doctor before using the device for the first time.
• This product is for cleaning teeth, gums and tongue
only. Use it only for these purposes!
• Stop using the device if you have any problems or
pain and contact your doctor.
• The device is for personal oral hygiene only and is not
intended for use by multiple people in a dental office
or dental clinic.
• If you have a pacemaker or other implanted device,
consult your doctor about the possibility of using the
device.
Built-in battery warnings
• The device is powered by a rechargeable battery, only charge it
with the appropriate chargers approved by the dealer and intended
for use with this device.
• If you do not have a charger, the battery charges while connected
to a PC via the supplied USB cable.
• Unplug the charger when not in use.
• Do not leave a fully charged battery connected to a charger as
overcharging may shorten its life.
• If you do not use a fully charged battery, it will discharge itself over
time.
• Never use a damaged charger.
• Battery capacity and battery life will be reduced if you leave the
device in hot or cold places, such as in a closed car in summer or
winter.
• Always try to keep the battery between 15 °C and 25 °C.
• Battery performance is particularly limited at temperatures well
below freezing.
• The rechargeable battery is located inside the device and is not
accessible to the customer.
• Do not throw unnecessary batteries into a fire - they may explode.
• The battery may explode if damaged.

12EN
Power supply
Power from built-in rechargeable battery
The device is powered by a built-in rechargeable battery.
Charge the battery before first use, or whenever the battery is low (the
device turns off arbitrarily or cannot be turned on).
The brush has a waterproof handle. It is electrically safe and is intended for
use in the bathroom. However, it is not intended for underwater use.
• Plug the AC adapter into a power socket and insert the brush handle into
the charging stand.
The charging indicator lights up.
• The first full charge requires 16 hours and the next full charge requires
only 12 hours. A single charge allows up to 30 days of brush usage.
The charge indicator flashes red or does not light up when the battery is
low. While charging, it will blink red and the indicator will turn green when
fully charged.
• After charging, unplug the AC adapter from the wall socket to save power,
or leave it plugged in and leave the brush in the charging stand.
There is no risk of overcharging the battery.
• If you do not use the brush for a long period of time and then start
charging it, the charging indicator will not light immediately (flash). This is
normal and does not indicate a malfunction. After charging for 30 minutes,
the indicator lights up and flashes red.
HOW TO ACHIEVE THE LONGEST BATTERY LIFE
To ensure the longest battery life, we recommend:
• Store, use and charge the battery at room temperature. Too high
temperatures can negatively affect its service life.
• Do not leave the battery fully charged or completely discharged for a long
time.
• Do not keep the battery fully charged at all times.
• Do not discharge the battery completely.

13EN
Description of elements
1 Brush head
2 Ergonomically shaped handle with
non-slip surface finish
3 Button 1 (On/Off/Toggle Toothing
Mode)
4 LED cleaning mode indicator CLEAN
(normal cleaning)
5 SENSITIVE Cleaning Mode LED
(sensitive cleaning)
6 LED cleaning mode indicator
MASSAGE
7 LED cleaning mode indicator WHITE
8 LED cleaning mode indicator POLISH
(polishing)
9 Battery charge/charge LED
10 Power cord
11 Charging stand
12 Charging port

14EN
Using a toothbrush
Before use, make sure the brush is correctly assembled, the brush head
is attached to the handle, and the battery is charged. Moist the brush
bristles with water and apply a paste to them.
Turn on the brush by pressing and holding button 1 for a few seconds.
CORRECT CLEANING TECHNIQUES
• We recommend that you start by cleaning the right half of the upper dental
arch from the outside. To clean, proceed from the front to the front, placing
the brush bristles at the teeth at an angle of about 45 ° in the line around
the gums.
• Move the brush to other teeth with short, slow movements.
• Once you have cleaned the outside of the right half of the upper arc, move
the brush to the inside of the dental arch.
Proceed backwards to the front again.
• Adapt the brush angle to the tooth arrangement. To clean the inside of
the front teeth, hold the brush handle vertically so that the tip of the brush
head faces up.
• Finally, clean the upper tooth surfaces.
• In the same way, clean the right half of the lower arc, the left half of the
lower arc, and finally the left half of the upper arc.
• To clean the inside of the front teeth of the lower arch, hold the brush
handle vertically so that the tip of the brush head faces down.
SETTING THE CLEANING MODE
• When the brush is turned on, briefly press button 1 repeatedly to
toggle between the cleaning modes in the order of CLEAN, SENSITIVE,
MASSAGE, WHITE and POLISH. To change the set mode, you must
press button 1 within 5 seconds of turning the brush on or the last mode
setting changed while the corresponding LED of the currently selected
mode flashes. When this time has elapsed, the LED for the corresponding
mode stops flashing, and when you press and hold button 1, to turn off
the brush.
• The last setting used is stored. This means that the next time you turn on
the brush, it will start running in the mode that was last set.

15EN
• CLEAN mode is designed for daily routine tooth brushing. The brush head
vibrates at a high frequency, removing tartar and bacteria on the teeth.
• SENSITIVE mode is designed to clean sensitive teeth and gums by gently
brushing the teeth.
• MASSAGE mode is a combination of tooth brushing and massage. The
brush cleans the teeth at an extremely fine frequency.
• WHITE mode is designed for more intensive tooth cleaning (whitening).
• POLISH mode is designed for polishing teeth and gums. Higher intensity
and high frequency polishes and smoothes teeth.
PAUSE FUNCTION
• The toothbrush is equipped with a timer that pauses the toothbrush briefly
every 30 seconds until it turns off automatically, notifying you that you
should start cleaning the next part of your teeth. This will ensure that you
will clean all dentition quadrants for the same amount of time.
AUTOMATIC SHUTDOWN TIMER
• The auto-off timer automatically turns off the toothbrush after 2 minutes of
operation.
This is the time recommended by dentists to brush their teeth with a sonic
toothbrush (in POLISH mode, the brush only works for 1 minute).
• When the brush is turned off, the LEDs turn off.
• After use, make sure the toothbrush is turned off and clean it as described
in the Cleaning and Maintenance chapter.
Then place the brush back into the charging stand.

16EN
Troubleshooting
Warning!
If you have any problems with this device, try this troubleshooting guide.
If the measures do not help, do not attempt to remove the device cover or
repair it yourself. There is a risk of loss of warranty.
Why doesn’t the brush work?
• The brush may not be charged. Charge the brush for at least 16 hours for
the first time and then after approx.
• There may be no electricity in the socket. Power supply to the sockets
in mirror cabinets above washbasins or in shaving drawers in bathrooms it
is often disconnected by switching off the light.
• The brush attachment may need to be reinserted or replaced.
Why do I feel a tickle when using a brush?
• When using the brush for the first time, you may feel a little tickling
or tingling. When you get used to brushing your teeth, this feeling will
disappear.
The brush attachment squeezes my teeth. What can I do about it?
• To avoid this, hold the brush properly facing, ie with bristles leaning against
the edge of your gums at a slight angle.
It seems to me that the brush is less efficient. Why?
• The Sonicare brush may need to be replaced.
• The brush attachment may need to be replaced.
Why does Sonicare brush change performance during cleaning?
• The brush may be in Clean or White mode. Clean and White modes have
different brush sound and movement.

17EN
Cleaning and maintenance
• For hygiene reasons, clean the toothbrush regularly after each use.
• Make sure the brush is off before cleaning.
• Rinse the brush head thoroughly under lukewarm running water to remove
any paste and other debris. If you use on brushing teeth whitening paste,
we recommend to apply a brush of soap on the head of the brush and
then wash it thoroughly under lukewarm running water. At least once a
week remove the brush head from the handle and wash it under running
water where it attaches to the handle.
• Rinse the brush handle under lukewarm running water and then dry.
• If the charging stand is dirty, wipe it with a damp cloth and then dry it. Do
not allow the AC power plug to come into contact with water or moisture.
Do not wash the pedestal under running water or immerse it in water.
• Do not use abrasive cleaners, thinners, etc. to clean any parts. The surface
of the appliance may be damaged and damaged.
Technical specifications
Power (charging stand): DC 5 V/1A (not supplied)
Power (toothbrush): Built-in Li-ion battery, 800 mAh, 3.7 V
Brush dimensions (WxDxH): 3 x 3.1 x 24, 8 cm (with extension)
Base dimensions (WxDxH): 3 x 3.1 x 24.8 cm
Weight: 112 g (without stand)
Noise level: 65 dB
The declared noise emission value of this appliance is 65 dB (A), which
represents the sound power level A relative to the reference sound power
of 1 pW.
Supplied accessories: instructions manual (1), charging stand (1)
handle (1), brush head (2), carrying case (1)
Subject to change!

18EN
BATTERY DISPOSAL
Batteries contain substances harmful to the environment and therefore
do not belong in the normal household waste. Take them for disposal in
accordance with applicable regulations and standards at their take-back
points.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
The symbol on the product or on its packaging indicates that this product
does not belong to household waste. It is necessary to take it to a collection
point for electrical recycling
and electronic equipment.
By ensuring proper disposal of this product, you will help prevent negative
consequences
to the environment and human health that would otherwise be caused by
inappropriate disposal of this product. For more detailed information about
recycling of this product, please contact your local authority, your household
waste disposal service or the shop where you purchased the product.
This product meets all the essential requirements of the EU directives that apply to it.
Producer:
Importer:
ORAVA retail 1, a.s.
Seberíniho 2
821 03 Bratislava
Slovenská republika
ORAVA distribution CZ, s.r.o.
Ostravská 494
739 25 Sviadnov
Česká republika
ORAVA retail 1, a.s.
Seberíniho 2
821 03 Bratislava
Slovenská republika
