1Introduction
1.1 Purpose
The purpose of this Technical Note is to provide detailed instructions on how to replace and
configure an ADMX.
1.2 Principles
The following principles must be followed when performing the procedures in this Technical
Note.
1.2.1 Torque Table
The following table provides the torque that should be used when tightening screws of the
listed types, as relevant.
Table 1-1: Torque Values
Screw Type
Torque
M8
25N/m
M6
10.2N/m
M5
6N/m
M4
2.5N/m
M3
1.35N/m

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 2 of 10
1.3 ADMx Description
The ADMX (mounted on the PEDESTAL) and the BDMX (inside the BDE CCU) multiplexer
modules form the communications link between the ADE and BDE, minimizing the physical
connection to a single coaxial cable (LMR-200, LMR-400 or LMR-600, depending on the
required cable length).
The ADMX also provides integral amplification and attenuation of the Tx and Rx paths.
Figure 1-1: ADMx
1.4 Spare Kit Contents
The following table provides a list of the parts in the ADMX spare kit.
Table 1-2: Spare Part Kit Contents
KIT32-1664-008-SP
P/N
Description
Quantity
25-1184-2
ADMX - FOR AL-7103/7107-SYS
1
H04014071002
SCKT FH90 SCR M4X10 STST
4
H04015071202
SCKT FH90 SCR M5X12 STST
4

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 3 of 10
1.5 Required Tools and Parts
The following table provides a list of tools and customer-supplied parts that are needed to
perform the procedures in this Technical Note.
Table 1-3: Required Tools and Parts
Tool/Part Name
Notes
Figure
Open/ring wrench 13, 8 mm
Allen keys: 2.5, 3mm

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 4 of 10
2Preliminary Procedures
The preliminary procedures described below must be performed before replacing the ADMX.
1. Perform System Shut-Down of the vessel’s main power AC Voltage terminal outside the
RADOME.
2. Open the RADOME hatch.
3. Switch off the ADE POWER BOX at the ANTENNA PEDESTAL base (located inside the
RADOME).
4. Manually rotate the PEDESTAL AXES to gain convenient access to the serviced unit.
In the following procedures, be very careful when tightening and loosening the
screws with which the parts are assembled and attached to the system. Some of
these screws are delicate and can be damaged by excess force. When using an
Allen key make sure to insert the key all the way into the screw head to avoid
thread stripping.
WARNING!
The Utility Outlet is connected directly to the vessel’s AC voltage input
terminals (125 VAC / 250 VAC). Therefore, there still exists live voltage at the
Utility Outlet after disconnecting the power supply to the ADE using the Mains
Power On/Off Switch.
Only qualified and authorized personnel are allowed to carry out system
service/maintenance procedures.

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 5 of 10
3Replacing the ADMx
3.1 Removing the ADMx
Step 1
Using an 8mm Open/ring
wrench, disconnect the
described RF cable from the
ADMX.
Step 2
Unlock and remove the
network cable.
Step 3
Using an 8mm Open/ring
wrench, disconnect the two
described RF cable from the
ADMX.

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 6 of 10
Step 4
Manually unscrew and
remove the plug.
Step 5
Use a 2.5mm Allen key to
remove the four screws
securing the ADMX mounting
plate.
Step 6
Use a 3mm Allen key to
remove the four screws
securing the ADMX mounting
plate.

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 7 of 10
3.2 Installing an ADMx
Step 1
Position the mounting plate
as described.
Note the plate’s angle.
Step 2
Secure the new ADMX to its
mounting plate using a 3mm
Allen key.
Step 3
Mount the ADMX mounting
plate in its place on the
PEDESTAL and secure it
using a 2.5mm Allen key.

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 8 of 10
Step 4
Manually screw the plug to
the ADMX.
Mind the plugs pins and lead!
Step 5
Connect and tighten the TX
red RF cable to J2.
Connect and tighten the RX
red RF cable to J1.
Step 6
Reconnect and tighten blue
RF cable to the ADMX.

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 9 of 10
Step 7
Reconnect the network cable
to the ADMX.

TEC32-1664-009 OceanTRx7™ ADMx Technical Note Page 10 of 10
4Post replacement check
After the ADMX has been replaced, perform the following test procedures to verify system
functioning.
1. Start up the system (see the OceanTRx7™ Installation and Operation Manual for
instructions).
2. Verify that there are no ERR/WRN system messages and that there is communication
between the CCU and the ACU.
3. Perform 1dbcp with the NOC and confirm the system is back online.
