Oreck Little Helper CC1000 User manual

Little Helper
™ Vac
Model: CC1000
®
Important!
Read this manual carefully,
and keep for future reference.
User’s
Guide

2
Other Oreck accessories available at:
Other Oreck accessories available at:
Other Oreck accessories available at:
Thank You for purchasing an Oreck Little Helper™Vac! This
state of the art vacuum cleaner will help you have a cleaner,
healthier home.
At Oreck we understand that our customers are unique and
expect superior service. To meet your needs, we offer
different customer service options to work with your lifestyle
and preferences.
Welcome to our Call. Click. Visit. customer service
program. To speak with an Oreck representative call:
Enjoy
Click
Call
Visit
USA: 1•800•989•3535
Canada: 1•888•676•7325
On the web, point and click at: www.oreck.com
or visit www.oreck.com and click locate a store on
the top right.
Visit us in person at one of over 450 store
locations. To find the nearest store, please call
888•oreck (1•888•673•2578).

3
Contents
General Warnings .................................. 4
Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation ..................................... 4
Parts ............................................. 6
Product Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly...................................... 6
Operation......................................... 7
Operating the Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Emptying the Dust Container . . . . . . . . . . . . . . . . . . . . . 7
Cleaning the HEPA Filter. . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning the Motor Protection Filter. . . . . . . . . . . . . . . . 8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Accessories ....................................... 9
Warranty......................................... 10

4
Safety
IMPORTANT SAFETY
INSTRUCTIONS
!
General Warnings
When using an electrical appliance, basic precautions should
always be followed, including the following:
Read all instructions before using this vacuum cleaner
WARNING! To reduce the risk of fire, electric shock, or injury:
• The vacuum is intended for household use only.
• Use the vacuum only as described in this manual.
• Use only manufacturer’s recommended attachments.
Environment
Use of the vacuum outdoors or on wet surfaces may result in
damage to the appliance and void the warranty.
Use of the vacuum on stairs may cause imbalance, slippage or
tumbling. Always check your balance and ensure your footing
when cleaning on stairs.
Use of the vacuum in an enclosed space containing flammable,
explosive materials or toxic vapors may result in an unexpected
spark or fire. Do not use the vacuum in such an enclosed space.
Always check exposed wiring and wire connections before use.
Operation
This appliance has moving parts and powerful suction
capability. Do not allow it to be used as a toy and always
maintain close attention when used by or near children.
Loose clothing, jewelry and long hair may become entangled in
the moving parts of the vacuum and cause personal injury. Al-
ways keep loose clothing, jewelry, fingers and all parts of body
away from openings and moving parts.
Use of the vacuum with an opening blocked may reduce air-
flow. Keep all openings free of dust, lint, hair etc.
Improper handling of the power cord may result in wiring
connection damage and potential sparking or shock. Always fol-
low these instructions when handling the power cord:
• Do not pull or carry the vacuum by the cord

5
• Do not use the cord as a handle
• Do not unplug the vacuum by pulling on the cord
• Do not close a door on the cord
• Do not pull the cord around sharp edges or corners
• Keep the cord away from heated surfaces
• Do not run the vacuum or other appliance over
the cord
• Always grasp the plug, not the cord, when unplugging
the vacuum
A damaged cord or plug may cause a spark, shock and fire.
Always check the cord and plug before use. If appliance is
not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center
or call customer service at: U.S.: 1-800-989-3535 Canada:
1-888-676-7325.
Using the vacuum with wet hands and on wet surfaces may
result in unexpected shock, slippage and personal injury.
Do not handle the plug or appliance with wet hands or on
wet surfaces.
Vacuuming burning or smoking objects, flammable or com-
bustible liquids and toxic material may result in a fire and
personal injury. Do not vacuum burning or smoking objects,
flammable or combustible liquids.
Unplugging the vacuum while the controls are ON may cause
sparking and fire. Turn OFF all controls before unplugging.
Do not leave appliance unattended when plugged in. Unplug
from outlet when not in use and before servicing.
SAVE THESE
INSTRUCTIONS

6
1. Dust Container Release
2. Hose intake
3. ON/OFF Switch
4. HEPA Filter
5. Dust container with filter
6. Floor Nozzle
7. Flexible Suction Hose
8. Extension Wands
9. 2-in-1 Nozzle
10. Suction Control
11. Carry Handle
12. Suction Hose Release
Buttons
13. Shoulder Strap
(Not pictured)
Side and Front View
Product Components
Assembly
Shoulder Strap
Clamp one end of the shoulder strap in front slot located be-
tween the ON/OFF switch and the dust container release button.
Clamp opposite end of shoulder strap in slot at back of handle.
Suction Hose
Firmly insert the end of the suction hose into the canister
intake until it locks into place.
To disconnect hose, press and hold suction hose release button
on both sides of the suction hose, pull to remove.
2
5
2
78
9
10
1
3
4
11
12
Maintenance
Parts

7
Operating the Vacuum
1. Attach the desired accessory to the end of the suction
hose.
2. Unwind the necessary length of cable and insert the plug
in a 120V/60Hz socket.
3. Vacuum at a steady speed. There is no need to exert pressure.
Emptying the Dust Container
For maximum performance of your Oreck Little Helper™Vac,
the dust container needs to be emptied when it becomes approxi-
mately 1/3 full or if the suction power of the unit is reduced.
To empty the dust container:
1. Disconnect the suction
hose from the hose intake.
2. Press the dust container
release button to release
the dust container and
then slide it off the unit
base.
3. Lift the dust container
release to open to bottom
panel of the dust container.
4. Empty the contents of the
dust container into the
trash can.
5. Close the bottom panel
of the dust container and
slide it on the unit base
until it snaps into place.
Performing maintenance on the vacuum while
it is plugged into a wall outlet may result in
unexpected vacuum operation, shock and
personal injury. Always turn the vacuum OFF
and unplug before performing inspection and
maintenance.
WARNING!
!
Operation
Maintenance

8
Cleaning the Motor Protection Filter
The inlet filter is located on the rear wall of the unit base and
should be cleaned approximately every 10th time you empty
the dust container.
To clean the motor protection filter:
1. Remove thedust container.See
“EmptyingtheDust Con-
tainer.”
2. Remove the motor protec-
tion filter from the motor
inlet.
3. Gently wipe debris from
the filter or if necessary,
the filter can be washed in
warm water without any
additives.
4. Replace the dry filter over
the tabs in the motor inlet.
IMPORTANT: The motor protection filter should NEVER be
installed into the motor inlet damp or wet. Always allow the
filter to air dry completely.
Cleaning the HEPA Filter
Depending on usage, the main filter should be cleaned every
4 - 6 months.
To clean the dust container filter:
1. Remove the dust container.
See “Emptying the Dust
Container.”
2. Press the HEPA filter
locking tab in and slide the
HEPA filter assembly out of
the dust container.
3. Clean the filter by tapping
and gently brushing with a
cloth or gentle scrub brush.
4. After cleaning, slide HEPA
filter assembly back into
dust container until it locks
into place.
Motor
Protection
Filter

9
Trouble-
shooting
Accessories
Part Number
Replacement Filters, 2 pack combo
(dust container filter and motor protec-
tion filter)
CC1000FILTS
If the following troubleshooting tips do not resolve the prob-
lem please contact Oreck Customer Service.
U.S.: 1-800-989-3535 Canada: 1-888-676-7325
Important! Always unplug and allow the vacuum to cool down
before conducting any troubleshooting. See safety warnings.
Problems Possible Source Areas to Check
Cleaner will
not run
Not plugged in
properly.
No electricity in
wall outlet.
Needs service.
Be sure cleaner is
firmly plugged into
wall outlet.
Check electrical
source - fuse or circuit
breaker.
Take to service center
or call for nearest
service center.
Vacuum will
not pick up
or has low
suction
Hose/wand tool is
clogged.
Remove obstructions.
Tools/Wands
will not stay
together
Proper friction
fit not being
obtained.
Push and turn.

10
Warranty
ORECK MANUFACTURING COMPANY:
(Oreck Manufacturing Company gives you the following
limited warranty for this product only if it was originally
purchased for residential use, not resale, from Oreck, an Oreck
franchise or an Oreck Authorized Retail Dealer, it has not been
used for commercial use, and it has been used and maintained
in accordance with the product’s owner’s manual.)
Oreck will repair or replace, free of charge, to the original
purchaser, any part that is found to be defective in material
or workmanship within one (1) year of the date of purchase.
This limited warranty applies to normal domestic use. Any
commercial use of this product will void this limited warranty.
This limited warranty does not cover the replacement of
expendable or consumable parts such as carbon motor brushes,
edge brushes, drive belts, brushes, disposable bags, wheels,
lights, light bulbs and other parts subject to normal wear
unless they are defective in material or workmanship.
This limited warranty does not apply to any part subjected
to accident, abuse, commercial use, alteration, misuse,
damage caused by act of God, the use of voltages other than
indicated on the serial number displayed on this product
or service of this product by other than Oreck or an Oreck
Authorized Service Center. Oreck does not authorize any
person or representative to assume or grant any other warranty
obligation with the sale of this product.
Oreck’s limited warranty is valid only if you retain proof
of purchase from Oreck, an Oreck Franchise or an Oreck
Authorized Retail Dealer for this product. If you purchase
this product from any other source, your purchase is “AS IS,”
which means Oreck grants you no warranty, and that you, not
Oreck, assume the entire risk of the quality and performance
of this product, including the entire cost of any necessary
servicing or repairs of any defects.
Oreck’s liability for damages to you for any costs whatsoever
arising out of this statement of limited warranty shall be
limited to the amount paid for this product at the time of
original purchase, and Oreck shall not be liable for any direct,
indirect, consequential or incidental damages arising out of the
use or inability to use this product.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or
exclusion may not apply to you.

11
ALL EXPRESS AND IMPLIED WARRANTIES FOR
THIS PRODUCT, INCLUDING IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD, AND NO WARRANTIES,
WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER
THIS PERIOD.
Some states do not allow limitations on the duration of implied
warranties, so the above limitation may not apply to you.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.

12
©2010 Oreck Holdings, LLC.
All rights reserved. All marks, text, logo’s, product configura-
tions and registered trademarks are owned and used under the
authority of Oreck Holdings, LLC
27000-01 REV A 02/10 ECN R-9796
