Oregon Scientific RM323A User manual

2004.10.20, 3:08 PMFNT COVER
Radio-Controlled Travel Alarm
Clock With World Time
Model : RM323A
User Manual

1
CONTROL BUTTONS: FRONT PANEL
1. [SNOOZE/LIGHT] BUTTON
- Press to turn on the back-light for 5 seconds
- Press to activate the Snooze function when the alarm
goes off
-Press and hold for 3 seconds to turn off the alarm
when the alarm goes off
2. [WORLD TIME] BUTTON
- Press to enter the world time setting mode
3. [ MODE ] BUTTON
-
Press to change between the clock and calendar display modes
- Press and hold for 2 seconds to enter the clock and
calendar setting mode
RADIO-CONTROLLED TRAVEL ALARM
CLOCK WITH WORLD TIME
MODEL NO.: RM323A
USER MANUAL
INTRODUCTION
Congratulations on purchasing the RM323A Radio-controlled
Travel Clock with World Time.
This clock is a compact device for travellers. It is designed to
automatically synchronize its current time and date with the
U.S. Atomic clock.
In addition to the local time and calendar display, the users
can also select to display the corresponding time of 130 major
world cities.
This clock also comes with favorable features including key-
lock function, multilingual day-of-the-week display, EL back-
light, hourly chime and dual alarm with 8-minute snooze
function.
RM323A_M_Eng.p65 2004.10.21, 6:47 PM1

2
4. FOLDABLE TABLE STAND
BEFORE YOU BEGIN
Before operation, remember to slide the key-lock switch to
the left to release all key operations.
BATTERY INSTALLATION
1. Remove the battery compartment door.
2. Insert two (2) pieces of “AAA” 1.5V batteries as shown.
3. Press [RESET].
4. Replace the battery compartment door.
4. [ALARM] BUTTON
- Press to toggle among the calendar, weekday alarm
and single alarm modes
- Press and hold for 2 seconds to enter the setting modes
of the corresponding alarm in display
5. [ALARM ON/OFF] BUTTON
- Press to activate/deactivate the corresponding alarm
in display
CONTROL BUTTONS: REAR PANEL
1. [KEY-LOCK] SLIDE SWITCH
- Slide to lock the key-functions
2. [RESET] BUTTON (inside battery compartment)
- Press to return all settings to default values
3. ROTARY KNOB [UP] AND [DOWN] BUTTONS
- Scroll up or down to increase/ decrease the value of a setting
RM323A_M_Eng.p65 2004.10.21, 6:47 PM2

3
When the battery power level is low, the low battery indicator [ ]
will light up. Replace the batteries accordingly.
CTIVATING THE BACK-LIGHT
When the unit is placed on the table, press [SNOOZE/LIGHT]
button downward to turn on the back-light for 5 seconds.
DISPLAY MODES
Press [MODE] button to display the following in sequence:
1Current Time with Seconds
World City Name Abbreviation & Time
2) Current Time with Weekday
World City Name Abbreviation & Time
3) Calendar
World City Name Abbreviation & Time
To display the dual alarm times, press [ALARM] button.
ABOUT RADIO RECEPTION
This clock is designed to automatically synchronize its calen-
dar clock once it is brought within the range of the WWVB
radio signal broadcast from Ft. Collins, Colorado. When the
unit is within range, its radio-control mechanism will override
all manual settings unless auto-reception of radio signal has
been manually deactivated.
When the clock is receiving radio signal, the radio reception
icon will start to blink. A complete reception generally takes
about 2 to 10 minutes, depending on the strength of the radio
signal. When the reception is complete, the radio reception
icon will stop blinking. The strength of the reception for the
last full hour will be indicated.
For better reception, place the unit away from metal objects
and electrical appliances to minimize interference.
Should you wish to deactivate the RF controlled function, press
and hold [DOWN] button for 3 seconds. The radio reception
icon will disappear. To reactivate the RF controlled function,
press and hold [UP] button for 3 seconds again and the radio
reception icon will be re-displayed.
RM323A_M_Eng.p65 2004.10.21, 6:47 PM3

4
SETTING THE CLOCK AND CALENDAR
CLOCK MANUALLY
1. Press and hold [MODE] button for 2 seconds.
2. Using the [UP]/[DOWN] button to scroll through the 4
U.S. time-zones (Pacific, Mountain, Central or Eastern)
or non-U.S.cities. Press [MODE] to confirm.
3. If non-U.S. city is selected, the world time city will be
flashing. Use [UP]/[DOWN] to select the city (for city
names abbreviation, please refer to the section “Selecting
the World Time”). Press [MODE] to confirm.
4. Repeat the same procedures to set the hours, minutes,
year, month, day, language of day-of-week and hourly-
chime on/off by using [UP]/[DOWN] button.
5. Press [MODE] button to save the changes and exit.
6. For the language for day-of-week, you can select “E” for
English, “D” for German, “F” for French, “I” for Italian or
“S” for Spanish. The day-of-week can be expressed as
an abbreviation in five different languages. The languages
and their selected abbreviations for each day of the week
are shown in the language chart below.
NOTE When changes are made to the minute, the sec-
onds will start from zero. The unit will also save all changes
and return to normal display automatically after the unit
has been left idle for a minute.
ABOUT THE HOURLY-CHIME FUNCTION
When the Hourly-Chime is set to on, the indicator [ ] will
light up and a beep sound will be given out at the beginning of
each hour.
Monday Tuesday Wed. Thursday Friday Saturday Sunday
Day-of-the-week
Language
English
German
French
Italian
Spanish
-Strong
-Weak
-No Reception
-Receiving
RM323A_M_Eng.p65 2004.10.21, 6:47 PM4

5
SETTING THE ALARM
This clock is equipped with 2 alarms: Weekday Alarm and
Single Alarm. For the Weekday Alarm, alarm will only sound
out at the preset times during weekday (i.e., from Monday to
Friday) and will be automatically disabled during the week-
end (i.e., Saturday and Sunday). For the Single Alarm, alarm
will sound out once at the preset time.
To set the alarm:
1. Press [ALARM] to change to the respective alarm-time
display mode.
2. Press and hold [ALARM] for 2 seconds.
3. Use [UP]/[DOWN] button to enter the hours. Press
[ALARM] button to confirm.
4. Use [UP]/[DOWN] to enter the minutes. Press [ALARM]
to exit.
The alarm will be automatically activated after setting. The
corresponding Alarm-On indicator [ ] or [ ]will appear.
To deactivate the alarm, press the [ ON/OFF ] button when
the corresponding alarm time is displayed. [ -: -- ] will be dis-
played to indicate such deactivation.
ALARM AND SNOOZE FUNCTION
An alarm will go off for 2 minutes in two-step crescendo
patterns if undisturbed. The Alarm-On indicator will flash and
the back-light will be activated for 5 seconds. To mute the
alarm, press any key. Pressing [SNOOZE/LIGHT] button
will activate the snooze function.
When the snooze function is activated, the alarm will be
muted temporarily and set off again after 8 minutes. To disable the
snooze function when the alarm goes off, you can press
and hold the [SNOOZE/LIGHT] button for 3 seconds.Alternatively
press [ALARM] or [ ON/OFF] button.
SETTING THE WORLD TIME
This clock features a World-time display function so that you
can check the corresponding time of different places in the
world instantly with DST [Daylight Saving Time] automatically
adjusted. The names of the world cities are shown in an abbre-
viated 3-letter format (e.g., “WDC” for Washington DC, U.S.).
To set the world time:
1. Press [WORLD TIME] button once. The World-Time icon
will be flashing.
2. Use the [UP]/[DOWN] button to select the world city.
3. Press the [WORLD TIME] button to confirm.
RM323A_M_Eng.p65 2004.10.21, 6:47 PM5

6
World City Abbreviations Reference Table
Country Name City code Time Offset DST Period
(GMT = 0)
Addis Ababa, Ethiopia ADD 3 No DST
Adelaide, Australia ADL 9.5 From Last Sunday in October to Last Sunday in March
Auckland, New Zealand AKL 12 From 1st Sunday in October to 3rd Sunday in March
Ankara, Turkey AKR 2 From Last Sunday in March to Last Sunday in October
Algiers, Algeria ALG 1 No DST
Amsterdam, Netherlands AMS 1 From Last Sunday in March to Last Sunday in October
Anchorage AK, USA ANC -9 From 1st Sunday in April to Last Sunday in October
Antananarivo, Madagascar ANT 3 No DST
Asuncion, Paraguay ASU -4 From 1st Sunday in September to 1st Sunday in April
Athen, Greece ATH 2 From Last Sunday in March to Last Sunday in October
Atlanta GA, USA ATL -5 From 1st Sunday in April to Last Sunday in October
Abu Dhabi, U.A.E AUH 4 No DST
Bucharest, Romania BBU 2 From Last Sunday in March to Last Sunday in October
Barcelona, Spain BCN 1 From Last Sunday in March to Last Sunday in October
Baghdad, Iraq BDD 3 From 1st April to 1st October
Belgrade, Yugoslavia BEG 1 From Last Sunday in March to Last Sunday in October
Beijing, China BEJ 8 No DST
Berlin, Germany BER 1 From Last Sunday in March to Last Sunday in October
Beirut, Lebanon BEY 2 From Last Sunday in March to Last Sunday in October
Bangkok, Thailand BKK 7 No DST
Brisbane, Australia BNE 10 No DST
Bogota, Colombia BOG -5 No DST
Boston MA, USA BOS -5 From 1st Sunday in April to Last Sunday in October
Bern, Switzerland BRN 1 From Last Sunday in March to Last Sunday in October
RM323A_M_Eng.p65 2004.10.21, 6:47 PM6

7
Brussels, Belgium BRU 1 From Last Sunday in March to Last Sunday in October
Brasilia, Brazil BSB -3 From 2nd Sunday of October to 3rd Sunday of February
Buenos Aires, Argentina BUA -3 No DST
Budapest, Hungary BUD 1 From Last Sunday in March to Last Sunday in October
Cairo, Egypt CAI 2 From Last Friday in April to Last Friday in September
Casablanca, Marocco CAS 0 No DST
Canberra, Australia CBR 10 From Last Sunday in October to Last Sunday in March
Caracas, Venezuela CCS -4 No DST
Calcutta, India CCU 5.5 No DST
Chicago IL, USA CGX -6 From 1st Sunday in April to Last Sunday in October
Colombo, Sri Lanka CMB 6 No DST
Copenhagen, Denmark CPH 1 From Last Sunday in March to Last Sunday in October
Cape Town, South Africa CPT 2 No DST
Dhaka, Bangladesh DAC 6 No DST
Damascus, Syria DAM 2 From 1st April to 1st October
New Delhi, India DEL 5.5 No DST
Detroit MI, USA DTW -5 From 1st Sunday in April to Last Sunday in October
Dublin, Ireland DUB 0 From Last Sunday in March to Last Sunday in October
Frankfurt, Germany FRA 1 From Last Sunday in March to Last Sunday in October
Guatemala City, Guatemala GUA -6 No DST
Geneva, Switzerland GVA 1 From Last Sunday in March to Last Sunday in October
Hamburg, Germany HAM 1 From Last Sunday in March to Last Sunday in October
Hanoi, Vietnam HAN 7 No DST
Havana, Cuba HAV -5 From 1st Sunday in April to Last Sunday in October
Ho Chi Minh City, Vietnam HCM 7 No DST
Helsinki, Finland HEL 2 From Last Sunday in March to Last Sunday in October
Hong Kong, China HKG 8 No DST
Honolulu HI, USA HNL -10 No DST
RM323A_M_Eng.p65 2004.10.21, 6:47 PM7

8
Houston TX, USA HOU -6 From 1st Sunday in April to Last Sunday in October
Indianapolis, IN, USA IND -5 No DST
Istanbul, Turkey IST 2 From Last Sunday in March to Last Sunday in October
Jakarta, Indonesia JKT 7 No DST
Johannesburg, South Africa JNB 2 No DST
Kabul, Afghanistan KBL 4.5 No DST
Khartoum, Sudan KHA 3 No DST
Kiev, Ukraine KIE 2 From Last Sunday in March to Last Sunday in October
Kingston, Jamaica KIN -5 No DST
Kathmandu, Nepal KTM 5.75 No DST
Kuala Lumpur, Malaysia KUL 8 No DST
Kuwait City, Kuwait KWI 3 No DST
Las Vegas NV, USA LAS -8 From 1st Sunday in April to Last Sunday in October
Los Angeles CA, USA LAX -8 From 1st Sunday in April to Last Sunday in October
Lima, Peru LIM -5 No DST
Lisbon, Portugal LIS 0 From Last Sunday in March to Last Sunday in October
London, UK LON 0 From Last Sunday in March to Last Sunday in October
Lagos, Nigeria LOS 1 No DST
La Paz, Bolivia LPB -4 No DST
Luxembourg, Luxembourg LUX 1 From Last Sunday in March to Last Sunday in October
Madrid, Spain MAD 1 From Last Sunday in March to Last Sunday in October
Melbourne, Australia MEL 10 From Last Sunday in October to Last Sunday in March
Mexico City, Mexico MEX -6 From 1st Sunday in April to Last Sunday in October
Managua, Nicaragua MGA -6 No DST
Miami FL, USA MIA -5 From 1st Sunday in April to Last Sunday in October
Milan, Italy MIL 1 From Last Sunday in March to Last Sunday in October
Manama, Bahrain MNA 3 No DST
Manila, Philippines MNL 8 No DST
RM323A_M_Eng.p65 2004.10.21, 6:47 PM8

9
Montreal, Canada MON -5 From 1st Sunday in April to Last Sunday in October
Moscow, Russia MOW 3 From Last Sunday in March to Last Sunday in October
Montevideo, Uruguay MVD -3 No DST
Nassau, Bahamas NAS -5 From 1st Sunday in April to Last Sunday in October
Nairobi, Kenya NRB 3 No DST
New York NY, USA NYC -5 From 1st Sunday in April to Last Sunday in October
Oslo, Norway OSL 1 From Last Sunday in March to Last Sunday in October
Ottawa, Canada OTW -5 From 1st Sunday in April to Last Sunday in October
Port-au-Prince, Haiti PAP -5 No DST
Paris, France PAR 1 From Last Sunday in March to Last Sunday in October
Perth, Australia PER 8 No DST
Pheonix, AZ, USA PHE -7 No DST
Phnom Penh, Cambodia PNH 7 No DST
Port-Of-Spain, Trinidad & Tobago POS -4 No DST
Papeete, French Polynesia PPT -10 No DST
Prague, Czech Republic PRG 1 From Last Sunday in March to Last Sunday in October
Portland OR, USA PTL -8 From 1st Sunday in April to Last Sunday in October
Pretoria, South Africa PTR 2 No DST
Panama City, Panama PTY -5 No DST
Yangon, Myanmar RGN 6.5 No DST
Rio de Janeiro, Brazil RIO -3 From 2nd Sunday of October to 3rd Sunday of February
Reykjavik, Iceland RKV 0 No DST
Rome, Italy ROM 1 From Last Sunday in March to Last Sunday in October
Riyadh, Saudi Arabia RUH 3 No DST
San Salvador, El Salvador SAL -6 No DST
Santiago, Chile SCL -4
From 1st Sunday on or after 9th October to 1st Sunday on or after 9th March
Seattle WA, USA SEA -8 From 1st Sunday in April to Last Sunday in October
Seoul, South Korea SEL 9 No DST
RM323A_M_Eng.p65 2004.10.21, 6:47 PM9

10
San Francisco CA, USA SFO -8 From 1st Sunday in April to Last Sunday in October
Shanghai, China SHA 8 No DST
Singapore, Singapore SIN 8 No DST
San Jose, Costa Rica SJO -6 No DST
San Juan, Puerto Rico SJU -4 No DST
Salt Lake City UT, USA SLC -7 From 1st Sunday in April to Last Sunday in October
Sofia, Bulgaria SOF 2 From Last Sunday in March to Last Sunday in October
Sao Paulo, Brazil SPL -3 From 2nd Sunday of October to 3rd Sunday of February
Stockholm, Sweden STH 1 From Last Sunday in March to Last Sunday in October
Sydney, Australia SYD 10 From Last Sunday in October to Last Sunday in March
Tashkent, Uzbekistan TAS 5 No DST
Tokyo, Japan TKY 9 No DST
Taipei, Taiwan TPE 8 No DST
Tripoli, Libya TRP 2 No DST
Toronto, Canada TRT -5 From 1st Sunday in April to Last Sunday in October
Quito, Ecuador UIO -5 No DST
Vancouver, Canada VAC -8 From 1st Sunday in April to Last Sunday in October
Vienna, Austria VIE 1 From Last Sunday in March to Last Sunday in October
Warsaw, Poland WAW 1 From Last Sunday in March to Last Sunday in October
Washington DC, USA WDC -5 From 1st Sunday in April to Last Sunday in October
Wellington, New Zealand WLG 12 From 1st Sunday in October to 3rd Sunday in March
Zurich, Switzerland ZRH 1 From Last Sunday in March to Last Sunday in October
RM323A_M_Eng.p65 2004.10.21, 6:47 PM10

11
THE RESET BUTTON
The [RESET] button is used to enhance synchronization of
signals after battery replacement or when the unit is operating
in an unfavourable way or malfunctioning. Use a blunt stylus
to hold down the button. All settings will return to their default
values.
KEY-LOCK FUNCTION
To lock all key-operation when carrying this clock with you,
slide the [KEY-LOCK] switch to the right. To operate this clock
again, slide the switch to the opposite direction.
TABLE-STANDING
This unit is designed specially to facilitate table-standing.
MAINTENANCE
When handled properly, this unit is engineered to give you
years of satisfactory service. Here are a few product care
instructions:
1. Do not immerse the unit in water. If the unit comes in
contact with water, dry it immediately with a soft lint-free
cloth.
2. Do not clean the unit with alcohol containing detergent,
abrasive or corrosive materials. Abrasive cleaning agents
may scratch the plastic parts and corrode the electronic
circuit.
3. Do not subject the unit to excessive: force, shock, dust,
temperature, or humidity. Such treatment may result in
malfunction, a shorter electronic life span, damaged
batteries, or distorted parts.
4. Do not tamper with the unit’s internal components. Doing
so will terminate the unit’s warranty and may cause
damage. The unit contains no user-serviceable parts.
5. Only use new batteries as specified in this instruction
manual. Do not mix new and old batteries as the old
batteries may leak.
6. Read this instruction manual thoroughly before operating
the unit.
RM323A_M_Eng.p65 2004.10.21, 6:47 PM11

12
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn more
about Oregon Scientific products such as digital cameras; MP3
players; children's electronic learning products and games;
projection clocks; health and fitness gear; weather stations;
and digital and conference phones. The website also includes
contact information for our customer care department in case
you need to reach us, as well as frequently asked questions
and customer downloads.
We hope you will find all the information you need on our
website, however if you'd like to contact the Oregon Scientific
Customer Care department directly, please visit:
www2.oregonscientific.com/service/support
OR
Call 949-608-2848 in the US.
For international enquiries, please visit:
http://www2.oregonscientific.com/about/international/
default.asp
SPECIFICATIONS
Proposed operating range : (23.0°F to 122.0°F)
-5.0°C to +50.0°C
Radio Control : Auto synchronize current
time and date by Radio signal
form the U.S. Atomic Clock
Clock format : 12-hour format
(hh:mm:ss)
Calendar format : Month-Day-Year
Alarm : Single and Weekday 2-minute
crescendo Alarm with
8-minute snooze function
Power : Uses two (2) UM-4 or
“AAA” 1.5V batteries
Weight : 2.7 oz (76.5 g)
(without battery)
Dimensions : (L)3.5" x (W)2.7" x (T)0.7"
(89 x 68.6 x 18 mm)
With Carrying Pouch
CAUTION
-The contents of this manual and technical
specifications are subject to change without further
notice.
-Due to printing limitations, the displays shown in this
manual may differ from the actual display.
-The contents of this manual may not be reproduced
without the permission of the manufacturer.
RM323A_M_Eng.p65 2004.10.21, 6:47 PM12

13
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2)
This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residen-
tial installation.
This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the inter-
ference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and re-
ceiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio / TV techni-
cian for help.
DECLARATION OF CONFORMITY
The following information is not to be used as contact for sup-
port or sales. Please call our customer service number (listed
on our website at www.oregonscientific.com), or on the war-
ranty card for this product) for all inquiries instead.
We
Name: Oregon Scientific, Inc.
Address: 19861 SW 95th Place, Tualatin,
Oregon 97062 USA
Telephone No.: 1-800-853-8883
Fax No.: 1-503-684-3332
declare that the product
Product No.: RM323A
Product Name: Radio-Controlled Travel Alarm
Clock with World Time
Manufacturer: IDT Technology Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1,41 Man Yue St.,
Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, in
cluding in terference that may cause undesired operation.
RM323A_M_Eng.p65 2004.10.21, 6:47 PM13

14
Trouble
All function keys are disabled
Reception icon "Antenna" is not
shown
-Clock time is not correctly set; and/or
-Reception icon "Antenna" displays
as "No reception"
Possible Cause
Rear slide switch is locked
Auto-reception of clock radio signal has
been disabled
The clock radio signal is not received
because:
-Electromagnetic interference exists, or
the Main Unit is located within reinforced
concrete walls or shadowed area
location
-Orientation of placement is not at opti-
mum position for reception of clock
radio signal
Remedy
Unlock the rear switch
Enable this function by following the
instructions in the User’s Manual
-Locate the Main Unit far from PC,
mobile phone etc and re-locate it near
the window sill. Wait at least 24 hours
(note: during night-time signal is
stronger, particularly after rain)
-The clock radio signal is searched at
1:00, 2:00, 3:00, 9:00, 15:00, 21:00
every day automatically
-To force the signal reception please
refer to instructions in the User’s
manual
Warning:
- For other cases not listed in the above, feel free to contact our help line
- Do not disassemble the unit. This will void the warranty
TROUBLESHOOTING GUIDE --- RM323A
RM323A_M_Eng.p65 2004.10.21, 6:47 PM14

2004.10.20, 3:08 PMREAR COVER
© 2004 Oregon Scientific. All rights reserved.
P/N.: 086-002832-04
BACK COVER

1
ES
RELOJ ALARMA A CONTROL
REMOTO CON LA HORA
INTERNACIONAL
MODELO NO.: RM323A
MANUAL DEL USUARIO
INTRODUCCIÓN
Felicitaciones por su compra del Reloj Alarma RM323A a Control
Remoto y con la Hora Internacional.
Este Reloj es un dispositivo compacto, ideal para las personas ue
viajan. Su diseño le permite una sincronización automática del
horario y de la fecha actual con el Reloj Atómico de EE. UU.
Además del visor de la hora local y del calendario, los usuarios
también pueden elegir la visualización del horario correspondiente
a las 130 principales ciudades del mundo.
Este Reloj también cuenta con la función de blo ueo de reloj,
pantalla multilingüe para los días de la semana, luz de fondo de EL,
alarma horaria y alarma dual con función “snooze” (repetición de
alarma) de 8 minutos.
BOTONES DEL CONTROL: PANEL
FRONTAL
1. BOTÓN [SNOOZE/LIGHT]
- Pulsar para encender la luz de fondo 5 segundos
- Pulsar para activar la función “snooze” cuando suena la alarma
- Pulsar y mantener oprimido 3 segundos para silenciar la alarma
después de sonar
2. BOTÓN [WORLD TIME]
- Pulsar para entrar en el modo de ajuste de hora mundial
3. BOTÓN [MODE]
- Pulsar para alternar entre los modos de reloj o almana ue
- Pulsar y mantener oprimido 2 segundos para entrar en el modo
de ajuste de reloj y almana ue

ES
2
. BOTÓN [ALARM]
- Pulsar para alternar entre los modos de almana ue, alarma de
día de la semana y alarma simple
- Pulsar y mantener oprimido 2 segundos para entrar en los
modos de ajuste de la alarma correspondiente en pantalla
5. BOTÓN [ALARM ON/OFF]
- Pulsar para activar/desactivar la alarma correspondiente en pantalla
BOTONES DE CONTROL: PANEL
TRASERO
1. CONMUTADOR DESLIZANTE [KEY-LOCK]
- Deslizar para blo uear las funciones de las teclas
2. BOTÓN [RESET] (dentro del compartimiento de pilas)
- Pulsar para devolver todos los ajustes a sus valores
predeterminados
3. BOTONES ROTATIVOS [UP] Y [DOWN]
- Desplazar hacia arriba o hacia abajo para aumentar/reducir el
valor de un ajuste
. SOPORTE PLEGABLE DE MESA
ANTES DE EMPEZAR
Antes de encender la unidad, recuerde deslizar el blo ueador de
teclas hacia la iz uierda para activar todas las funciones de las teclas.
INSTALACIÓN DE LAS PILAS

3
ES
1. Retirar la tapa del compartimiento de pilas.
2. Introducir dos (2) pilas tamaño “AAA” de 1,5 V según se muestra.
3. Pulsar RESET.
4. Volver a colocar la tapa del compartimiento de pilas.
Cuando el nivel de energía de la pila es bajo, el indicador de bajo
nivel de pila [ ] se iluminará. Cambiar las pilas según corresponda.
ENCENDIDO DE LA LUZ DE FONDO
Pulsar [SNOOZE/LIGHT] para encender la luz de fondo
5 segundos.
MODOS DE VISUALIZACIÓN
Pulsar [MODE] para ver la información siguiente en secuencia:
1) Hora actual con segundo
Abreviatura del nombre de la ciudad del
mundo y Hora
2) Hora actual con día de la semana
Abreviatura del nombre de la ciudad del
mundo con Hora
3) Almana ue
Abreviatura del nombre de la ciudad del
mundo con Hora
Para ver las horas de la alarma doble, pulsar el botón [ALARM].
ACERCA DE LA RECEPCIÓN DE RADIO
Este reloj se ha diseñado para sincronizar automáticamente su reloj
almana ue una vez ue se encuentre dentro del radio de alcance de
la señal de radio. Cuando la unidad está dentro del alcance, su
mecanismo de radiocontrol anulará todos los ajustes manuales, a
menos ue la recepción automática de la señal de radio haya sido
desactivada manualmente.
Cuando el reloj está recibiendo la señal de radio, el icono de
recepción de radio empezará a parpadear. Una recepción completa
tarda generalmente entre 2 y 10 minutos, según la intensidad de la
señal de radio. Cuando la recepción ha terminado, el icono de
recepción de radio parará de parpadear. La intensidad de la recepción
para la última hora completa se indicará en la pantalla.
Para obtener mejor recepción, alejar la unidad de objetos metálicos
y aparatos eléctricos a fin de reducir la interferencia al mínimo.
Si desea desactivar la función de control por RF, pulsar y mantener
oprimido el botón [DOWN] 3 segundos. El icono de recepción de
radio desaparecerá. Para reactivar la función de control por RF, pulsar
y mantener oprimido [UP] 3 segundos otra vez y el icono de
recepción de radio volverá a aparecer en la pantalla.

ES
4
AJUSTE MANUAL DEL RELOJ Y DEL
RELOJ ALMANAQUE
1. Pulsar y mantener oprimido el botón [MODE] 2 segundos.
2. Utilice el botón [UP]/[DOWN] para avanzar o retroceder a través
de las 4 zonas horarias de EE. UU. (Pacífico, de las Montañas,
Central u Oriental) o de las ciudades ue no están dentro de los
EE. UU. Presione el [MODO] para confirmar.
3. Si selecciona una Ciudad ue no está dentro de los EE. UU., se
encenderá la ciudad del horario Internacional. Utilice [UP]/
[DOWN] para elegir la ciudad. (para la abreviatura de los
nombres de las ciudades, lea la sección “Selección de la Hora
Internacional”). Presione [MODO] para confirmar.
4. Repita los mismos procedimientos para poner la hora, minutos,
año, mes, día, el idioma del día de la semana y encienda/apague
on/off el campaneo cada hora-usando el botón [UP]/[DOWN].
5. Pulse el botón [MODE] para salvar los cambios y salir.
6. Para seleccionar el idioma del día de la semana, usted puede
escoger “E” para Inglés, “D” para Alemán, “F” para Francés, “I”
para italiano o “S” para Español. El día de la semana puede
expresarse en forma de una abreviación en cinco idiomas
diferentes. Los idiomas y sus abreviaciones seleccionadas para
cada día de la semana son mostrados en el cuadro de los idiomas
anotado debajo.
Nota: Cuando se realizan cambios en los minutos, los segundos
empezarán a partir de cero. La unidad guardará también todos los
cambios y regresará a la pantalla normal automáticamente después
de ue la unidad haya estado inactiva durante un minuto.
Francés
Idiomas Día de la semana
Lunes Martes Miércoles Jueves Viernes Sábado Domingo
Inglés
Alemán
Italiano
Español
- Fuerte
- Débil
- No hay recepción
- Recibiendo
