ORGTECHNICA ELKA MICRO 04 User manual

1
ORGTECHNICA” JSC - SILISTRA
ЕLECTRONIC CASH REGISTER
WITH FISCAL MEMORY
ELKA MICRO 04
INSTRUCTION MANUAL
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

2
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

3
СONTENTS:
PAGE
1.INTRODUCTION.. .. .. . . . . . . . .. .. .. . . . . . . 5
2.CONSTRUCTION OF THE CASH REGISTER . 5
2.1.Indication.... .. .. . . . . . . . .. .. .. . . . . . 5
2.2.Кeyboard.. . . . . . . .. . .. .. . . . . . . . .. 5
2.3.Printer……………….. .. .. . . . . . . . . . .. . . 9
2.4.Block memory .. .. .. . . . . . . . .. .. . . . 10
2.5.Fiscal memory…. . . .. .. . . . . . . . .. . . . 10
3.PREPARATION FOR WORK OF THECASH
REGISTER . . . .. .. . . . . . . . .. .. .. . . . . . . . 10
3.1.Installation of paper tape. .. .. . . . . . . . . 11
4.REGIMES FOR WORK . . . . . .. .. . . . . . . . . . . 12
4.1.Control tests…….. .. .. . . . . . . . . . . . .. .. 12
4.2.Regime PROGRAMMING .. . . . . . . . . . . . . 15
4.3.Regime SETTING THE CASH
REGISTER INTO EXPLOITATION
FOR WORK WITH FISCAL MEMORY . . 30
4.4.Regime REGISTRATION.. .. . . . . . . . .. .. . 30
4.5.Regime REPORTS of the cash register . . . 38
4.6.Regime REPORTS of fiscal memory. . . . .. 43
5.INDICATIONS OF OVERFILLING,BLOCKING
AND OFFICIALMESSAGES. . . . . . . .. .. . . . . 52
6.TECHNICAL SERVICE. . .. .. . . . . . . . . . .. . 54
APPENDIX. 1. . . . . . . . .. .. .. . . . . . . . .. .. 56
APPENDIX 2 . . . . . . . . . . .. .. .. . . . . . . . .. 57
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

4
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

5
1. INTRODUCTION
Thefollowinginstructioncontainsthenecessary informationfor
construction ,organizationand fiscalopportunities oftheelectroniccashregister
with fiscal memory ELKA MICRO 04. Instructionsfor correct exploitationand
storage ofthecash register havebeen given.
ELKA MICRO 04 isconstructedwithamemory capacity of 128kB andit
has thefollowingopportunities:
- 2000 assortments;
-9department/2 couldbechosendirectly fromthekeyboard, 1 by
default, 6 notchosenfrom thekeyboard, programmablefor repartitionof
assortments/.
- 2 operators with passwords.
Thecashregisteris extremely suitablefor work in the sphereof delivery
trade and deliveriestohomes, openmarkets, medical services.
ELKA MICRO04 is aprogrammablecashregister ,through whichan
opportunity is giventothecustomerto choosethe optimal regime ofwork
regarding theorganization of the trade subject.
2. CONSTRUCTION OF THE CASH REGISTER
Thedesign oftheapparatus isconformableto theergonomic
requirementsof this type.
Measures:290 x 135 x 75mm;
Weight: 0,5 kg
2.1. INDICATION
Theelectroniccashregisterwith fiscal memory has10 digit LCD
indication.
2.2 KEYBOARD
Thekeyboard includes11 digital and 13 functional keys withthe shown
designationsand location.
Whenworkingwiththecashregisterafter every properly perceivedkeya
short soundsignal isheard and whenthereisimpropermanipulationwith the
keyboard - there isacontinuoussoundsignal.
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

6
Thedigit blockservesfor enteringnumbers information.Key“00” enters
two zerossimultaneously,whichquickensthework with wholenumbers. Itis not
allowed the firstentereddigit to be 0or 00. The cashregisters gives opportunity
for work with variable decimalpoint position. Its placeissetby programming
Parameter 14. Regardingits valueisset theshiningof thedecimal point in
regime REGISTRATION. I n regimes PROGRAMMING, REPORTS WITH
CLEARING AND REPORTS WITHOUT CLEARING thedecimal point is
always at thefirstplaceasit intheseregimesit is only workedwith whole
numbers. Anexclusion is madewhenindicatingof some constants,whichare
fractionnumbers.
With key “.“ it isallowedtowork in regime REGISTRATION when
entering afractionquantity with key X” andwhenentering of percentage
deductions/additionswith keys -%”,”+%” .
Thefunctionsof thekeysdependonthe regimeof work and correspond
to Table 1.
7
CL
8
0
9
PF
F
4 X 5 6 VD
PLU
1 #2 2 3 +%
STL
#1
00 . -%
TL
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

7
ТABLE 1
REGIMES OF WORK
KEY Х Z P R
Entering
digital
information
Entering digital
information
Entering
digital
information
Entering
digital
information
Entering
decimal point
with fraction
numbers
Reportsof
fiscal memory
Reportsof fiscal
memory
Choice ofa
group for a
parameter.
Operations
VOID &
STORNO
Indicationof
date& hour;
Reportsof
fiscal memory
Indicationof date
& hour;
Reportsof fiscal
memory
Choiseof
parameter
Indicationof
date& hour;
Work with
quantity
Choice of
regime Choice ofregime
Choice of
regime
Closing abill;
Choice of
regime
Reportsof
fiscal memory
Reportsof fiscal
memory
Confirmationof
constant for
parameter
Subtotal
.
VD
X
F
00
1
0
9
STL
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

8
Continuation of Table 1
REGIMES OF WORK
KEY Х Z P R
Clearing of
indication and
clearingof
mistakeswhen
operating.
Clearing of
indication and
clearingof
mistakeswhen
operating.
Clearing of
indication and
clearingof
mistakeswhen
operating.
Clearing of
indication and
clearingof
mistakeswhen
operating.
Printing, with
clearing of the
electronic tape
Settingthe
hour
Percentage
deductions;
Officially taken
out sums
Report of
operators
Report of
operators
Setting the
hour
Percentage
additions ;
Officially
entered sums
Accumulation
in a
depatment
Programming of
codenumber of
cashier place
Daily financial
report
Daily financial
report
End of progra-
mming and
printinga
parameter
Payment in
cash;
Calculationof
therest
Transportation of the thermopaper tape
CL
-%
+%
PF
#1
#2
#1
TL
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

9
Continuation of Table 1
REGIMES OF WORK
KEY
Х Z P R
Report of
assortments;
Report of the
turn over of N
assortment
Report of
assortments;
Report of the
turn over of N
assortment
Choice of
haracteristicsfor
a parameter;
Printing
programmmed
assortments
Accumulation
of
assortment
2.3 PRINTER
Theelectroniccashregister ELKA MICRO04 workswithathermoprinter
LTP-1245 SEIKO.
TECHNICAL DATA OF PRINTER:
Way of printing: Thermal, signsintezing;
Speedofprinting: >5 lines/s
Number ofsymbolsin a line: 24
Measures: 76 x 56,5 x 21mm
Weight: 85 g
Toassure properwork it is compulsory thethermopaper roll tobewith a
plasticspool and to correspond to the following requirements:
width - (57,5_+ 0,5)mm;
outer diameter - maximum 55mm
durability - 5 years
specificweight - 53 to 60g/m2
TTENTION!
Theproducerdoesnot carry outresponsibility for damagesof printeror
the cashregistercaused by using consummative, no correspondingtothe
pointedrequirements.
PLU
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

10
2.4. BLOCK MEMORY
In theblock MEMORY are stored thevaluesof theprogrammed
parameters,thecurrent informationwhenworkingwith thecashregister.
After switchingoffthecashregister memory issuppliedby abuild-in
accumulator, located on logic plate. Astorageoftheinformationfor morethan
1500 hoursafter switching off the cashregister is guarantied.
2.5. FISCAL MEMORY
Thefiscal memory is energyindependent, constructively separate and
sealedblockinthecaseof thecashregister. In every daily financial report with
clearinginthe fiscal memory aBLOCK DATAis written,containingthenecessary
informationfor realizationtheturn-oversby every taxationgroup with
accumulation. Thisinformation could beprintedinregime REPORTS OF
FISCAL MEMORY” .Thecapacity of fiscalmemory provideswork of thecash
register for aperiod of 6years/1850 records/. Theinformationrecorded in the
fiscal memory could not bechanged.Arecord of datais accomplished after
setting theelectronic cash register with fiscal memory into exploitation. The cash
register shouldbe setintoexploitation afterstartingactivity of thetrade
project.Afterfiscalization of the cash register with fiscal memory every attempt to
workwithout fiscal memory isblocked and a message P2 ” is shownon the
indication.
3. PREPARATION FOR WORK OF THE CASH REGISTER
Beforesettingthecashregisterwith fiscal memory intoexploitationa
control check-out ismadefor eventual mechanicdamages.
In case that thecashregister hasbeentransportedin conditionsof lowor
hightemperature whenswitchingon, it should becompulsory left toget
acclimatized for 4 hours in thepackage and 1 hour ou t of it.
Theplaceforinstallationof thecashregistershould notbe exposedto
direct impact of heat sources.
Themounting of thecashregister should be accomplishedat aheight,
conformable to therequirements for convenient work at apropercorner on
observation of the indicationsby the operator and thecustomers.
Therooms inwhichthecashregisterwill beused should be with normal
firehazard regarding Order 2/ПCТН/ andwith normal dashing off.
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

11
Thecashregister functions atthefollowingconditionsoftheenvironment:
* temperaturefrom 0°C to45°C ;
* relative moisture of air to 80%;
* atmospherepressurefrom 84 to 107 kPa;
*vibrationsof floor with anamplitudenotbiggerthan0,15mm at therange
of from 5 to 35 Hz.
Thecashregister hasabuilt-in accumulator6V/1,3Ah,throughwhichnot
less than 20000 lines with onechargingcould beprinted. Recoverofthecapacity
of theaccumulatorbattery could be accomplishedthrough 16 hourcharging by
connectto powersupply adaptor. Theadaptor should provide6-9V AC or9-12V
DC voltage and current 200mA.
THE ACCUMULATOR BATTERY IS CONSUMATIVE AND IT IS
NOT A SUBJECT OF GUARNATY.
Beforstartingwork with thecashregistertheoperatorisresponsible to
check theavailability of thermopaper and ifthereisnot suchtoput atape.
The switch on and switch off of the cash register is done by a
button, located on the right side of the apparatus.
When switching the cash register it isindicated“-----” whichmeansthat a
password for choosing a regimeor an operator isrequired.
If more than6min thecash registerhasn’t beenworkingit switchesoff
itself. In regime REGISTRATION at not closed payment and at regime
PROGRAMMING the cash register does not swicht off itself. After
switching offduring followingjob it isnecessary again to press thebutton and to
enter apassword forenteringat thedesired regimeofwork.Ifthe cashregister
hasbeenswitchedoffat regime REGISTRATION aftersecondswitchingon it is
allowed thattheoperator could work without requiringto enter apassword for this
regime.
3.1. INSTALLATION OF THE THERMOPAPER TAPE
Remove theprint cover. Instalthethermopaper tape onthe axle,provided
for it.Putthepaperat thelowerslot of print cover /underthe shaft/.Unfastenthe
pinandby this fix paper.Thenpresskey ”PF” till showing 50mm of thepaper from
printingarea.
Takingoutthepapertapefromtheprintercouldbe accomplished by
pulling out therest of thepaper pressingkey “PF” at the same time.
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

12
Theproduceris notresponsiblefordamagesof printeror thecash
register if it hasbeen operated with raised pinofthermo head.
4. REGIMES OF WORK
Theregimesofworkcould bechosenby entering apassword relevant
regime/to six digits/. Passwordsby default areas follows:
1,2 - regime REGISTRATION
3 - regime READING WITHOUT CLEARING
4 - regime READING WITH CLEARING
5 - regime PROGRAMMING
6 - regime SERVICE
The consequenceof entering is as follows:
Consecutively presskeys “F”, thenimber of password from thedigit block
and “F”.
4.1. CONTROL TESTS
Regime CONTROL TESTS ischosenbyentering thepassword for
service regime. Thepassword by default is6, andtheconsequence of entering is
asfollows:
Press consecutively keys F”,”6”,”F”.
Thecashregisterwith fiscal memory is checked by testing programs
,controlling thegoodworkingorder oftheseparate knots.
Startingtests 1, 4, 5, 6 could bedone by digit keys from 1”, ”4”, ”5”,
”6” for therelevant test andby pressing key VD”.
The purposeof test programsis thefollowing:
Test 1 – for thecheckingout the printer .A signtableisprinted.
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

13
№ receipt
№ cash register-
ADVERTISING LINES
TPN 1111111111111111
0000*
! " # $ % & ‘ ( ) * +
, - . / 0 1 2 3 4 5 6 7
8 9 : ; < = > ? ? A В C
D E F G H I J K L M N O
P Q R S T U V W X Y Z
a b c d e f g
h i j k l m n o p q r s
t u v w x y z ~ I
є
000n
DD-ММ-YY
hh:mm
- NON FISCAL -
ОТ123456 03123456
- № fiscal memory
Test 4 - for checking Fiscal memory.
Readingand checkingthecontrol sum of all data blocks,recorded in
fiscal memory is accomplished. Areceipt is printedwith theresult of and the
recorded by theproducer individual number of thecashregister with fiscal
memory and theindividual number of fiscal memory module.
ADVERTISING LINES
TPN 1111111111111111
0000*
TEST FISCAL MEMORY
ОТ123456
03123456
000n
DD-ММ-YY
hh:mm
- NON FISCAL -
Trouble freefiscalmemory with
programmed individualnumber ofthecash
register andindividual numberoffiscal
memory
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

14
ADVERTISING LINES
TPN 1111111111111111
0000*
TEST FISCAL MEMORY
ОТ123456 03123456
DIFR FIS NUMBER
DIFR CASH NUMBER
000n
DD-ММ-YY
hh:mm
- NON FISCAL -
ОТ123456 03123456
Starting Test 4at cleared RAM. It is
necessary to confirm the numbersof the
cash register and thefiscal memory
ADVERTISING LINES
TPN 1111111111111111
0000*
TEST FISCAL MEMORY
ОТ123456
03123456
ERROR FISKAL MEMORY
000n
DD-ММ-YY
hh:mm
- NON FISCAL -
ОТ123456 03123456
In Fiscal memory it hasbeenfoundablock
with wrong control sum by daily report with
clearing.Fiscal memory isnot
damaged.Thisis amessagethatthe
secondrecordof thesamedatablock of
thedaily report withclearinghasbeen
finishedsucce-ssfully.Theblock with a
wrong control sumisalwaysignoredat
report of the Fiscal memory.
Test 5 - to checkout the RAM memory.
After completingthe test with memory in goodworking order theindicationlights
out "End" and a receipt of the type isprinted:
ADVERTISING LINES
TPN 1111111111111111
0000*
TEST RAM
128К O.K.
000n
DD-ММ-YY
hh:mm
- NON FISCAL -
ОТ123456 0312
Тst 6 - checkout ofROM.Aftercompletingthetest on theindication
panela check sum "ooо XXXX" islit out of the program versionofROM and
thestatusof the cashregister is printed .
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

15
ADVERTISING LINES
TPN 1111111111111111
0000*
VERSION 3.0
DEPARTMENTS 2
PRICE LOOK UPs 2000
AVAILABLE QTY
val add tax 3
CLERKS 2
FIS RECORDS 1850
000n
DD-ММ-YY
hh:mm
- NON FISCAL -
ОТ123456 031234
6
4.2.Regime PROGRAMMING
Regime PROGRAMMING” ischosen by entering apasswordfor this
regime.Thepassword by default is5, andtheconsequenceof entering is the
ollowing:
Consecutively presskeys F”, ”5”, ”F”.
4.2.1.GENERAL PRINCIPLES
Programming the cashregisterincludes settingfunctions, constantsand
letter text, classifiedin parameters. Every parameter ischosenby acertain
number.
The cash register isdeliveredwithasample program.
Choosingaparameteris accomplishedby enteringitsnumberfrom the
digit keyboard and pressingkey X”.
Ontheleft part of the indicationis shown amessage Pxx”, andon the
right - the value of theparameter, where xx” isthenumber of the parameter .
Tosavethe new programmed valuespresskey STL”.
Toexit thechosen parameter use thefollowing ways:
-by choosinganew parameter ;
-bypressingkey TL”. Informationfor thecorrespondingparameteris
printed.
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

16
Forparameters 30 and 31 it isnecessary topresskey TL” for the
secondtime.
It isnot compulsory tochoose parameters consecutively.
Programming all theparameters is not compulsory.
As certain parametercould be chosenonly for areference or check-out.,
withoutchanging itsvalue or itsmeaning (Key STL” isnot usedin operation
consequences).
Regardingtheconsequenceof operating,parametersaredivided
conditionally in threerigimes of work.
First REGIME – it coversparameterswith numbers from 2, 3, 7, 11,
12, 13, 14, 15, 16, 17, 20 and 21.
Second REGIME – it coversparameterswithnumbers from 19, 22, 23,
24, 27, 28, 29 and 37.
Third REGIME - it covers parameters with numbers 30 and 31.These
parametersinclude number L /number of department or assortment/ and every
L includesseveral characteristics M.
Forth REGIME – covers parameter 33.
Whenprogramming(setting anewvalue)of parameters 2, 14, 22, 28
and 30 thefollowing registers should becleared:
- cash and department (key TL”);
- assortments (key PLU”);
- operators(key +%”):
Forparameters 30 and 31 it is not necessary to report thecash register
with thefiscalmemory, if beforeprogrammingof the concrete department or
assortment noaccumulationhasbeedone in it.
4.2.2 REACTION AT WRONG PROGRAMMING OF PARAMETER
During theprocessofprogramming,theusageofakey different from the
participatingonesintheprogramming of thechosenparameter,is WRONG
OPERATION, accompanied by a long sound signal.
Correctionof wrongentered value ofparameter isaccomplishedby oneof
thefollowing ways:
*if theoperation is not closed yetwith key TL” is enteredthe new value
and then press key STL”;
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

17
* If theoperationhasbeenclosed withkey TL” ischosen again the
numberof parameter andrepeattheconsequenceof operatingwithcorrect
value.
4.2.3. FIRST REGIME OF PROGRAMMING
First regimeofprogrammingcoversparameterswithnumbers from 2, 3,
7, 11, 12, 13, 14, 15, 16, 17, 20 and 21.Themeaningof these
parametersisshown in Таble 2.
Consequence of operating:
N Х
where:
N– digit chosenfromthedigit keyboard with meaningthenumberof
parameter;
key. "Х" –chooses therelevant parameter Nandtakesout itsvalueon
theindication.Compulsory;
Х– number for value(meaning)of parameter . It is chosenfrom the digit
keyboard;
кey. "STL" – saves the new value Хfortheparameter. Operating with it is
notcompulsory if thevalue Хisnot tobechanged. Itis blocked if anumberof
parameter is not set ( N, "Х");
кey. "TL" - Printing thevalueoftheparameter. Areceipt with thenumber
of the parameter and its value isprinted. It isnot compulsory tooperatewith it to
finish workwith thechosen parameter.Compulsory for parameterswithnumbers
2, 20 and 21.
TTENTION!
When programming ZERO value for aparameter or apart of a
parameterusingkeys "0" или "00" is PROHIBITED.For thiscaseit is
necessary tousekey "CL .
X STL TL
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

18
ТABLE 2
№
para
me
ter
NAME
OF
PARAMETER
VALUE OF
Х
Value of
Х by
default
Proh.
2 Official 1*
3 Аutonomousor terminal 0-аutonomous
1- terminal 0
7 Work with whole or frac-tion
quantity in PROGRAMMING
0 - whole
1 - fraction 0
11 Printingtaxa-tion strikesoff in
theclientsreceipt
0 – prohibited
1 – allowed 0
12 Speedofexchange at work
with electronicscale 0, 1, 2, 3, 4 0
13 Number of advertising lines
4-4-adv.line
5-5-adv.line
6-6-adv.line
4
14 Positionofde-cimal point in
REGISTRATION
1 – 0.
3 – 0.00 3
15 Varietiesofprinting receiptsin
REGISTRATION 0, 1, 2 0 2*
16 Record of CET in EEPROM 0–allowed
1- prohibited 1 3*
17 Time for switchingoff theback
lightsof indication/s/ 0 to99 5 4*
20 Official 1*
21 Official 1*
REM RKS:
1. Aparameter isprogrammedbyaservicetechnicianwhensettingthe
cash register in work with fiscal memory.
2. By this parameter is definedoneofthevarietiesforprinting the
receiptsinregime “REGISTRATION”.
- VARIETY 0 – only a receipt for theclient isprinted;
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

19
- VARIETY 1 – the printed receiptfortheclientis finishedasasingle
sale - this meansthat thereceipt is finishedautomatically without pressingkey
"TL.
- BAРИAНТ 2 – a receipt fortheclientisprintedand adoublingreceipt
(doublingaccumulating receipt);
3. At Р16=1 CЕT it is writtenin theЕЕPROM andonly theclient receipts
are includedand thesefrom thedaily financial report.
4. With thisparameter is fixed the time for whichafterthelastpressedkey
back lights are switchedoff/if theindicationpanelhas backlights/.At 0value
back lightsarecontinuously on .
4.2.4. SECOND REGIME OF PROGRAMMING
Second regimefor programmingcoversparameterswithnumbers 19,
22, 23, 24, 27, 28, 29 и 37.Theseparametersinclude several meanings
,different by number М.
Sequence of operating:
N 1
M X
where:
N –number of parameter;
кey."Х" – choice of parameter. Compulsory;
М – characteristic digit for every parameter, definingthe numberof parts
for programming;
key ."PLU” – chooses respectively Mand shows ontheindicationits
value. It isnot compulsory if information forthis part of parameterisnot
necessary. Blocked ifnonumberfor a parameter hasbeenfixedandconcretely
М;
Х- value of M;
кey."STL” – saves thevalueof Х. It isnotcompulsory ifthevalueof Х
musn’t be changed. Blocked by a not fixed parameter and notcorrect valueof Х;
X
PLU
STL
PLU
STL
TL
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

20
кey."TL" –takes outto printingtheparameterandfinisheswork with it.
Compulsory only for P22.
ТАBLE 3
№
parameter
Name of
parameter М
Value of
Х
Value of X
by default Proh.
19 Work with key
“VD”
1–VOID
2-STORNO
0-allowed
1-prohibit.
0-allowed
1-prohibit
0
0
22
Valueof %
for taxation
group
1–tax group А
2–tax groupB
3–tax groupC
to 99.99%
to 99.99%
to 99.99%
0,00%
0,00%
0,00%
1*
2*
23
Entering
passwords
for regimes
and
operators
1-1st operator
2-2nd operator
3-regimeХ
4-regimeZ
5-regimeP
6-regimeS
To6 digits
1
2
3
4
5
6
3*
24
Work with %
additionsand
deductions
1-% additions
2-% deductions
0-allowed
1-prohibit.
0-allowed
1-prohibit
0
0
27
Тxt for
advertising
lines and an
advertisemen
t text at the
end of
receipt
1-1 adv.line
2-2 adv. line
3-3 adv. line
4-4 adv. line
5-5 adv. line
6-6 adv. line
7-1 line adver-
tisement text
8–2 line adver-
tisement text
24 symbols
for line
4*
5*
28 Names of
operators
1-1 оperator
2-2 оperator
8 symbols
for name
4*
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com
