Origin DSUB6 User manual

Installation Manual
V 1.1
Model:
DSUB6
In-Ceiling Dual 6.5”
Subwoofer
Enclosure Manual Only for
Port Tube Installation

1
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6 INSTALLATION MANUAL
Table of Contents
Introduction 1
Installation Requirements and Recommendations 2
What’s Included 2
Required Tools/Items 3
Planning 4
Important 4
Location 5
Installation 6
1) Wiring 6
2) Installing the DSUB6 7
3) Connecting the Wires 8
4) Installing the New Construction Bracket 10
5) Drywall 10
Troubleshooting 11
Technical Assistance 12
Warranty 12
Limited Lifetime Warranty 12
Requirements and Warranty Coverage 13
Return Process 13
Specifications 14
Introduction
Thank you for purchasing the DSUB6 In-Ceiling Subwoofer. At Or-
igin Acoustics, we take pride in providing you with a high quality
product. All of Origin Acoustics’ speakers are designed to have ex-
cellent sound quality, longevity, and a simple installation process.
The Director Minimal Opening Collection is designed to be visual-
ly unobtrusive while maintaining Origin’s high quality sound. The
DSUB6 subwoofer itself is installed behind the ceiling by attach-
ing the enclosure to one of the joists in the ceiling with the sound
being directed into the room via a port tube (sold separately).
This instruction booklet covers the necessary information for a
smooth installation of your DSUB6, including: the tools you will
need, step-by-step instructions for installation, troubleshooting
tips for problems that may occur, and all warranty information. If
for any reason you experience problems or if you have installation
questions please call us at [phone]. Hours of operation are
8:00am to 5:00pm (Pacific Time), Monday through Friday.
You will find the instructions for installing the port tube and fin-
ishing the install with the port tube cartons.

2 3
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6 INSTALLATION MANUAL
Required Tools/Items
• Speaker wire
• Wire stripper
• Drill (5/16” or 8mm)
• Wrench (½”)
For this setup, use a
multi-stranded wiring designed
for amplifier to speaker connec-
tions. The gauge of wire used
can have an impact on the per-
formance of your speakers and
we would recommend that you
choose the largest wire size that
is practical for your installation.
Which gauge to select depends
on the length of wire to be used
on any particular speaker. In
general the shorter the run the
smaller the wire size you can
use, however you can never go
wrong by using a thicker gauge.
Wire Length Recommended
Gauge
Feet Meter
0-100 0-30 16
50-150 15-45 14
100+ 30+ 12
Speaker Wire Recommendations
What’s Included: DSUB6
• Subwoofer enclosure
• Terminal jumper (for use only when driving the DSUB6 with a
single channel
• Template for locating mounting screws
• Lag screws (x6)
• Washers (x6)
Installation Requirements and Recommendations
Subwoofer
Enclosure
Joist
Joist
Figure 3.1: DSUB6 Enclosure

4 5
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6 INSTALLATION MANUAL
Planning
IMPORTANT
The DSUB6 is designed to be flexible, capable of working with dif-
ferent amplifier configurations and port options. Before installing
the DSUB6, you will want to know the answer to two questions:
1. Will you be driving it with a 2-channel amplifier or a designat-
ed subwoofer amplifier? The 2-channel option works fine but
the separate subwoofer amplifier will allow you to adjust the
subwoofer output to achieve the sub-to-satellite balance you
want regardless of subwoofer location or number of satellite
speakers used. If you opt for the separate subwoofer amplifier,
you will need to run three paired speaker wires to the speaker
location.
Location
Find a location for the subwoofer. Positioning it near the satellite
speakers is visually and sonically advantageous; being close to
walls, especially corners, is very helpful when maximum loudness
is important. Start with where you want the port opening to be.
Then determine where the enclosure needs to be placed to allow
the port tube to easily reach the desired port opening location.
For the subwoofer to fit, the joists need to be at least 14” apart.
Figure 4.1: DSUB6F68
(6/8” Port)
Figure 4.2: DSUB6F3
(4” Port)
2. We oer two port options so that the grilles will match any
Director speaker you choose. You will want to know at this
point if this subwoofer will be used with the Director D38
mini-speakers or with some other Director speaker since the
ports are of dierent lengths and diameters.

6 7
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6 INSTALLATION MANUAL
You will need a wire that has at least two conductors; one that can be
identified as the positive and the other as the negative. All two conductor
wires have some means of identifying which conductor is which, but at
times this identification may be subtle. It’s crucial that you keep track of
which wire you use for positive (+) and negative (-). Typically if the wires
are colored red and black, the red wire is used for positive and the black
wire is used for negative, but sometimes other colors or patterns are
used. You can choose whichever color of wire you want to be positive and
negative as long as you remain consistent throughout the install.
On both your amplifier and your speaker the connectors will be identi-
fied as red for positive and black for negative. It is very important to look
carefully at the speaker wires and be certain that the same wire that is
attached to the positive connector in the amplifier is attached to the pos-
itive connector in the speaker.
About Speaker Wire
Installation
1) Wiring
Plan how you’ll route the wire to your desired speaker location.
Most likely the DSUB6 will be installed in a new home during con-
struction but you can install it into an existing home if you have
access to the space above the ceiling or below the floor. Be sure to
avoid all obstacles such as AC wiring, pipes, and ducts.
2) Installing the DSUB6
Hold the template to the joist that you plan on attaching the sub-
woofer enclosure to. Drill six holes through the marked locations
on the template using a 5/16” (8mm) drill bit. Face the enclosure’s
rubber damping pad towards the joist and secure it in place with
the supplied lag screws and washers. We recommend that one
person holds the subwoofer in place while another tightens the
screws to secure the DSUB6 to the joist.
Figure 7.1: Securing DSUB6 to Joist using Template
Template
Joist
Enclosure
Screws (x6)

8 9
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6 INSTALLATION MANUAL
You are now ready to attach the port tube to the enclosure. Refer
to the manual included in the port tube carton for instructions.
Figure 9.1: Separate Subwoofer
Amplifier Wiring
3) Connecting the Wires
Strip ¼ to ½ inch (6 to 12 mm) of the insulation o both ends of
the wire and twist the ends to avoid stray strands.
A. When using a 2-Channel Amplifier
Insert the le & right channel wires from the receiver into the
connectors labeled “input from amplifier”, making sure that
the positive wire is being attached to the red connection and
the negative wire is being attached to the black connection.
You will also probably want to run the wires from the
DSUB6’s terminals labeled “output to speakers” at this time.
A zip tie on the enclosure is provided to oer stress release
for the wires.
Figure 8.1: 2-Channel Wiring
B. When using a Separate Subwoofer Amplifier
Use the supplied terminal jumper to connect two of the
DSUB6 input terminals, then connect the positive wire from
the subwoofer amplifier to the positive input terminal and
the negative wire the remaining input terminal. The satellite
speakers will be wired directly to the 2-channel amplifier.
Amplifier
Subwoofer
Amplifier
Amplifier

10 11
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6 INSTALLATION MANUAL
This warranty may not be valid if the product was purchased
through an unauthorized dealer. This warranty only applies to
the individual that made the original purchase, and it cannot be
applied to other purchases. The purchaser must be prepared to
provide proof of purchase (receipt). This warranty will not be val-
id if the identifying number or serial number has been removed,
defaced, or altered.
This warranty does not cover the following:
• Accidental damage
• Damage caused by abuse or misuse
• Damage caused by attempted repairs/modifications by
anyone other than Origin Acoustics or an authorized dealer
• Damage caused by improper installation
• Normal wear, maintenance, and environmental issues
• Damage caused by voltage inputs in excess of the rated
maximum of the unit
• Damage inflicted during the return shipment
Before making any return attempts, it is required that you first
contact Origin Acoustics. Return product to Origin Acoustics
or your dealer, either in person or by mail. It’s preferable if the
product is returned in the original packaging. If this isn’t possible,
the customer is responsible for insuring the shipment for the full
value of the product.
This warranty is in lieu of all other expressed or implied warranties.
Some states do not allow limitations on implied warranties, so this
may not apply depending on the customer’s location. (For more
information, see Magnuson-Moss Warranty Act.)
Origin Acoustics warrants to the original retail purchaser only that
this Origin Acoustics product will be free from defects in materials
and workmanship, provided the speaker was purchased from an
Origin Acoustics authorized dealer.
If the product is determined to be defective, it will be repaired or
replaced at Origin Acoustics’ discretion. If the product must be
replaced yet it is no longer manufactured, it will be replaced with
a model of equal to or greater value that is the most similar to
the original. If this is the case, installing the replacement model
may require mounting modifications; Origin Acoustics will not be
responsible for any such related costs.
Return Process
Requirements and Warranty Coverage
Limited Lifetime Warranty
Warranty
If you have any questions or concerns about installing or using
this product, you can reach us through one of the following meth-
ods:
Phone: [phone]
Hours of operation: 8:00am - 5:00pm (Pacific Time), Mon - Fri
Email: [e-mail]
If you are having technical trouble, please include the model num-
ber and briefly explain what steps you took to resolve the problem
in your email, or be prepared to answer these questions over the
phone. If you are considering returning the product, it’s required
that you contact Origin Acoustics prior to any return attempts.
This way we can determine if the issue can be resolved without
returning the product, or if needed we can provide instructions
and support for the return process.
Technical Assistance

©2016 Origin Acoustics. All copyrighted, trademarked and
patented elements mentioned herein are the sole property of
Origin Acoustics.
Model Number DSUB6
Part Number DSUB6000
Woofer Cone Material Polypropelene with
rubber surround
Woofer Diameter 6.5” (165mm)
Frequency Response 37 to 140Hz ±3dB
Impedance 8 ohm nominal, 6 ohm min
Power Handling 150 Watts
Sensitivity 86dB
Enclosure Dimensions 7.9x11.8x17”
(200x300x430mm)
Mounting Depth 7.9” (200mm)
Specifications

Installation Manual
V 1.1
Model:
DSUB6F68
In-Ceiling Dual 6.5”
Subwoofer
Manual Only for Port Tube &
Finishing Kit Installation

1
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6F68 INSTALLATION MANUAL
Table of Contents
Introduction 1
Installation Requirements and Recommendations 2
What’s Included 2
Required Tools/Items 2
Installation 3
IMPORTANT 3
1) Installation before Drywall 3
2) Installation aer Drywall 4
3) Mounting the Grille 4
4) Painting the Grille 5
Specifications 6
Troubleshooting 7
Technical Assistance 8
Warranty 8
Limited Lifetime Warranty 8
Requirements and Warranty Coverage 9
Return Process 9
Introduction
This instruction manual is for the 6” port tube designed to work
with DSUB6 subwoofer and grilles that match the Director 6 and 8
series speakers. It covers the necessary information for a smooth
installation including: the tools you will need, step-by-step in-
structions for installation, troubleshooting tips for problems that
may occur, and all warranty information. If for any reason you
experience problems or if you have installation questions please
call us at [phone]. Hours of operation are 8:00am to 5:00pm
(Pacific Time), Monday through Friday.

2 3
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6F68 INSTALLATION MANUAL
Required Tools/Items
• Measuring tape
• Standard slotted screwdriver
• #2 phillips screwdriver
• Hammer or screw gun
What’s Included: DSUB6F68
• 6” port tube with plastic
connectors on one end
• BR68 new construction
bracket
• Flathead screws (x8)
• Hose clamp (on opening end of
port tube)
• Separate carton containing:
BZ68 ZipClip ring
Round grille
Port adapter
Installation Requirements
and Recommendations
Installation
IMPORTANT
These instructions are intended for new construction installs but
you can use them for retrofit installs provided that the DSUB6
enclosure is already installed with the open end of the port tube
reaching its desired location.
Installation before
Drywall
Use the 8 supplied screws to at-
tach the port tube to the enclo-
sure. Test the wired DSUB6 to
see that it’s working properly.
If you are using 2 channels of
input, make sure to test both.
Install the BR68 new construc-
tion bracket to position the
hole for the port opening. Make
sure this hole is located close
enough to the enclosure so that
you will be able pull about 6” of
the port tube through this hole.
4
3
2
1
Port
Tube
BR68New
Construction
Bracket
PlasticPort
Connector
Figure 2.1: DSUB6F68
Figure 2.2: Tools
Figure 3.2: Installed Port Tube

4 5
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6F68 INSTALLATION MANUAL
Installation aer Drywall
Install the BZ68 ZipClip ring. Pull the port tube through the ring,
slip the port adaptor into the end and tighten the screw on the
hose clamp to get a snug, secure attachment.
Fit the port adaptor into the InstaMount, and twist it clockwise
into place. When the arrows on the port adaptor line up with one
of the lock icons on the InstaMount the speaker is tightly in place.
You will probably want to twist the port adaptor counterclockwise
an inch or two before twisting it into the InstaMount so that the
torque of the port tube doesn’t accidentally “un-twist” the port
adaptor when it’s in use.
Mounting the Grille
The DSUB6 6” Port Tube kit comes with a round grille. If you need
a square grille you will need to order our SQ68. Simply fit the grille
over the speaker and it will be held in place with magnets.
Painting the Grille
In some situations you may
want to paint the grille to col-
or-match the walls, ceiling,
or trim in the room. The grille
must be painted with spray
paint. Most hardware stores
will mix a can of paint to match
whatever color you need.
Lightly spray the front of the
grille with the paint from a
distance, being careful not to
plug any of the holes. Diluting
the paint with paint thinner
will lessen the risk of filling any
holes. If a hole gets plugged,
use a can of compressed air to
open it. Once the paint is dry,
put the cloth back on the grille.
Figure 5.1: Remove Cloth
Figure 5.2: Spray Grille
Figure 4.1: Trim Ring Install

6 7
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6F68 INSTALLATION MANUAL
Problem Possible Cause
No Sound
The volume may be turned down or muted. Check
the volume settings on both the amplifier and the
television/computer/CD player/etc.
Make sure the proper source is selected on the am-
plifier or receiver.
Check the cord connecting the amplifier with the
source. The cord may be damaged or plugged into
the wrong input or output.
Check the wires connecting the amplifier with the
speakers. Make sure they’re connected properly and
not damaged in any way.
Poor Sound Quality
If you hear something like static, or the sound is cut-
ting in and out, check the audio cables. If the prob-
lem increases when a cable is being moved, then the
cable is most likely faulty or not connected properly.
Today’s audio systems may have several places to
adjust the volume, for example your MP3 player may
have a volume control, and your amplifier may also
have one. Check to be certain that the volume isn’t
turned up past 80% on any device.
Try changing sources to be certain that the selection
you’ve chosen is a good quality recording.
If possible, it’s oen good to try to isolate the problem first. For
example, if you’re playing a DVD on a television and there’s no
sound, try connecting an MP3 player to the system to see if that
works. If it does work, then the problem is with the television, DVD
player, or the cables connecting them. If it doesn’t work, the prob-
lem will be with the amplifier, speakers, or those cables.
Troubleshooting
Model Number DSUB6F68
Part Number DSUB6F680
Grille Diameter (Round) 10” (253mm)
Port Tube Dimensions
(Diameter x Length)
6x31” (152x800mm)
Cutout Diameter 8.75” (222mm)
Specifications

8 9
844·674·4461
[e-mail] WWW.ORIGINACOUSTICS.COM
DSUB6F68 INSTALLATION MANUAL
This warranty may not be valid if the product was purchased
through an unauthorized dealer. This warranty only applies to
the individual that made the original purchase, and it cannot be
applied to other purchases. The purchaser must be prepared to
provide proof of purchase (receipt). This warranty will not be val-
id if the identifying number or serial number has been removed,
defaced, or altered.
This warranty does not cover the following:
• Accidental damage
• Damage caused by abuse or misuse
• Damage caused by attempted repairs/modifications by
anyone other than Origin Acoustics or an authorized dealer
• Damage caused by improper installation
• Normal wear, maintenance, and environmental issues
• Damage caused by voltage inputs in excess of the rated
maximum of the unit
• Damage inflicted during the return shipment
Before making any return attempts, it is required that you first
contact Origin Acoustics. Return product to Origin Acoustics
or your dealer, either in person or by mail. It’s preferable if the
product is returned in the original packaging. If this isn’t possible,
the customer is responsible for insuring the shipment for the full
value of the product.
This warranty is in lieu of all other expressed or implied warranties.
Some states do not allow limitations on implied warranties, so this
may not apply depending on the customer’s location. (For more
information, see Magnuson-Moss Warranty Act.)
Origin Acoustics warrants to the original retail purchaser only that
this Origin Acoustics product will be free from defects in materials
and workmanship, provided the speaker was purchased from an
Origin Acoustics authorized dealer.
If the product is determined to be defective, it will be repaired or
replaced at Origin Acoustics’ discretion. If the product must be
replaced yet it is no longer manufactured, it will be replaced with
a model of equal to or greater value that is the most similar to
the original. If this is the case, installing the replacement model
may require mounting modifications; Origin Acoustics will not be
responsible for any such related costs.
Return Process
Requirements and Warranty Coverage
Limited Lifetime Warranty
Warranty
If you have any questions or concerns about installing or using
this product, you can reach us through one of the following meth-
ods:
Phone: [phone]
Hours of operation: 8:00am - 5:00pm (Pacific Time), Mon - Fri
Email: [e-mail]
If you are having technical trouble, please include the model num-
ber and briefly explain what steps you took to resolve the problem
in your email, or be prepared to answer these questions over the
phone. If you are considering returning the product, it’s required
that you contact Origin Acoustics prior to any return attempts.
This way we can determine if the issue can be resolved without
returning the product, or if needed we can provide instructions
and support for the return process.
Technical Assistance

©2016 Origin Acoustics. All copyrighted, trademarked and
patented elements mentioned herein are the sole property of
Origin Acoustics.
