Orion Power Systems SCR2 User manual

S
POWER AVAILABILITY
On-Line UPS
127/220V; 120/208 V
USER MANUAL
SCR2 10kVA Online UPS

i
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.0 GLOSSARY OF SYMBOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.0 INTRODUCTION AND SYSTEM DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3.0 SYSTEM DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.1 Transient Voltage Surge Suppression (TVSS) and EMI/RFI Filters. . . . . . . . . . . . . . . . . . . . 5
3.2 Rectifier/Power Factor Correction (PFC) Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.3 Inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.4 Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.5 DC to DC Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.6 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.7 Static Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.0 MAJOR COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4.1 Main Frame and Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Internal Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3 Input/Output Terminal Blocks and Optional Output Distribution . . . . . . . . . . . . . . . . . . . . . 8
5.0 WHAT’SINCLUDED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6.0 INSTALLATION AND CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6.1 Install the Main Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.1.1 Tower UPS Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.1.2 Installing the Adjustable Rack-Mount Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.2 External Battery Cabinet Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.3 Connect Input/Output Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.3.1 Distribution Module Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.3.2 Input & Output Terminal Block Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6.3.3 Add an Output Power Distribution Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.4 Install the Internal Battery Packs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.0 INITIAL STARTUP AND ELECTRICAL CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
7.1 Hardwire Input Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7.2 Output Receptacle Distribution Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

ii
8.0 CONFIGURATION PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9.0 CONTROLS AND INDICATORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9.1 ON/Alarm Silence/Battery Test Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9.2 OFF/Bypass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9.3 L1 & L2 Load Level Indicators (Two Rows of Indicators: 4 Green, 1 Amber). . . . . . . . . . . . 22
9.4 Battery Level Indicators (5 Green) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.5 Fault Indicator (Red) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.6 Bypass Indicator (Amber) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.7 UPS ON Indicator (Green). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.8 Battery Indicator (Amber) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.9 AC Input Indicator (Green) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10.0 MODES OF OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10.1 Normal Mode Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10.2 Battery Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10.3 Battery Recharge Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

iii
11.0 COMMUNICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
11.1 Communications Interface Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11.1.1 DB-9 Interface Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11.1.2 Communications—SNMP WEB CARD SNMP Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11.2 Pin 4 - Remote Shutdown on Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11.3 UPS Intelligent Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11.4 RemoteEmergencyPowerOff................................................. 26
12.0 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
12.1 BatteryReplacement........................................................ 27
12.1.1 Internal Battery Replacement Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
12.2 UPS Power Module Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
13.0 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
14.0 SPECIFICATIONSS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

iv
FIGURES
Figure 1 10 kVA Dual Inverter (front and rear views ). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 2 Internal battery pack and connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 3 Hardwire terminal blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 4 Optional output distribution modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 5 Support base and spacers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 6 60A branch circuit breaker connection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 7 Hardwire terminal connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 8Control and indicator overlays, vertical and horizontal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 9 REPO switch connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 10UPS back panel-control location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 11Power module replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
TABLES
Table 1 Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 2 DB-9 pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 3 Fault indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Table 4 Alarm conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Table 5 Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table 6 Battery run times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Table 7 UPS specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Table 8 Battery specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 9 Optional output distribution specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Table 10 Replacement 10kVA power module specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Table 11 External battery cabinet specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

1
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important safety instructions. Read all safety, installation and operating
instructions before operating the Uninterruptible Power System (UPS). Adhere to all warnings on the
unit and in this manual. Follow all operating and user instructions. Individuals without previous
training can install and operate this equipment.
It is not intended for use with life support and other designated critical devices. Maximum load must
not exceed that shown on the UPS rating label. If uncertain, consult your local distributor or
Sales representative.
This UPS is designed for use on a properly grounded (earthed), 100/200, 110/220, 115/230, 120/208,
120/240 or 127/220 VAC, 50 Hz or 60 Hz supply. The factory default setting is 127/220 VAC, 60 Hz.
Installation instructions and warning notices are located in this manual.
This UPS is only for use with a four-wire input (L1, L2, N, G).
This UPS MAY NOT be used with a three-wire, single-phase utility source (L1, N, G).
ELECTROMAGNETIC COMPATIBILITY—The Series complies with the
limits for a CLASS A DIGITAL DEVICE, PURSUANT TO Part 15 of FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful interference and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Operating this device in a residential area is likely to cause harmful interference that users must
correct at their own expense.
Operate the UPS in an indoor environment only in an ambient temperature range of 32°F to +104°F
(0°C to +40°C). Install it in a clean environment, free from conductive contaminants, moisture,
flammable liquids, gases and corrosive substances.
This UPS contains no user serviceable parts except the internal battery pack. The Off/Bypass push
button does not electrically isolate internal parts. Under no circumstances attempt to gain access
internally other than to replace the batteries due to risk of electric shock or burn. Do not continue to
use the UPS if the front panel indications are not in accordance with these operating instructions or if
the UPS performance alters in use. Refer all faults to your local distributor, Sales
representative or the Sales Technical Support Group.
Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and
the required precautions. Keep unauthorized personnel away from the batteries. PROPER
DISPOSAL OF BATTERIES IS REQUIRED. REFER TO YOUR LOCAL LAWS AND REGULATIONS
FOR BATTERY DISPOSAL REQUIREMENTS.
Never block or insert any object into the ventilation holes or other openings of the UPS.
DO NOT CONNECT equipment that could overload the UPS or demand half-wave rectification from
the UPS, for example: electric drills, vacuum cleaners, laser printers, hair dryers or any other
appliance using half-wave rectification.
Storing magnetic media on top of the UPS may result in data loss or corruption.
Turn the UPS off and isolate the UPS before cleaning; use only a soft cloth, never liquid or aerosol
cleaners. Keep the front and rear vents free of dust accumulation that could restrict airflow.
!WARNING
Opening or removing the cover may expose you to lethal voltages within this unit even when
it is apparently not operating and the input wiring is disconnected from the electrical source.
Observe all cautions and warnings in this manual. Failure to do so may result in serious
injury or death. Refer all UPS and battery service to qualified service personnel. Do not
attempt to service this product yourself. Never work alone.

2
When replacing batteries, replace with the same authorized replacement battery kits.
When replacing power module, replace with the same authorized replacement
power module kit.
!CAUTION
Do not dispose of battery or batteries in a fire. The battery may explode.
Do not open or mutilate the battery or batteries. Released electrolyte is harmful to skin and
eyes. It is toxic.
!CAUTION
A battery can present a risk of electrical shock and high short circuit current. The following
precautions should be observed when working on batteries:
•Remove watches, rings and other metal objects.
•Use tools with insulated handles.
•Wear rubber gloves and boots.
•Do not lay tools or metal parts on top of batteries.
•Disconnect charging source prior to connecting or disconnecting battery terminals.
•Determine if the battery is inadvertently grounded. If inadvertently grounded, remove
source of ground. Contact with any part of a grounded battery can result in electrical shock.
The likelihood of such shock will be reduced if such grounds are removed during
installation and maintenance (applicable to a UPS and a remote battery supply not having a
grounded supply circuit).

Glossary of Symbols
3
1.0 GLOSSARY OF SYMBOLS
Risk of electrical shock
Indicates caution followed by important instructions
AC input
AC output
Requests the user to consult the manual
Indicates the unit contains a valve-regulated lead acid battery
Recycle
DC voltage
Equipment grounding conductor
Bonded to ground
AC voltage
ON/Alarm Silence/Battery Test
OFF/Bypass
!
i
PbH2SO4
-
+
R

Introduction and System Description
4
2.0 INTRODUCTION AND SYSTEM DESCRIPTION
Congratulations on your choice of the Online 10Kva RT 127V Uninterruptible
Power Supply (UPS). It provides conditioned power to microcomputers and other sensitive
electronic equipment.
Upon generation, AC power is clean and stable. However, during transmission and distribution it is
subject to voltage sags, spikes or complete power failure that may interrupt computer operations,
cause data loss or even damage equipment. The UPStation 10Kva RT protects equipment
from these disturbances.
The 10Kva RT is a compact, on-line UPS. An on-line UPS continuously conditions
and regulates its output voltage whether utility power is present or not. It supplies connected
equipment with clean sinewave power. Sensitive electronic equipment operates best from sinewave power.
For ease of use, the 10Kva RT features a light-emitting diode (LED) display to
indicate both load percentage and battery capacity. It also provides self-diagnostic tests, a
combination ON/Alarm Silence/Battery Test button, a Standby button, user configurable program and two
levels of alarms when the unit is operating on battery.
The 10Kva RT has an interface port for communication between the UPS and a
network server or other computer systems. This port provides detailed operating information
including voltages, currents and alarm status to the host system when used in conjunction with
Winpower software. Winpower software can also control UPS operation remotely.

System Description
5
3.0 SYSTEM DESCRIPTION
3.1 Transient Voltage Surge Suppression (TVSS) and EMI/RFI Filters
These UPS components provide surge protection and filter both electromagnetic interference (EMI)
and radio frequency interference (RFI). They minimize any surges or interference present in the
utility line and keep the sensitive equipment protected.
3.2 Rectifier/Power Factor Correction (PFC) Circuit
In normal operation, the rectifier/power factor correction (PFC) circuit converts utility AC power to
regulated DC power for use by the inverter while ensuring that the waveshape of the input current
used by the UPS is near ideal. Extracting this sinewave input current achieves two objectives:
• The utility power is used as efficiently as possible by the UPS.
• The amount of distortion reflected on the utility is reduced.
This results in cleaner power being available to other devices in the building not being protected by
the 10Kva RT.
3.3 Inverter
In normal operation, the inverter utilizes the DC output of the power factor correction circuit and
inverts it into precise, regulated sinewave AC power. Upon a utility power failure, the inverter
receives energy from the battery through the DC to DC converter. In both modes of operation, the
UPS inverter is on-line and continuously generating clean, precise, regulated AC output power.
3.4 Battery Charger
The battery charger utilizes energy from the utility power and precisely regulates it to continuously
float charge the batteries. The batteries are being charged whenever the 10Kva RT is plugged in,
even when the UPS is not turned on.
Input Output
Inverter
Battery
Battery
Charger
DC to DC
Converter
Rectifier
/PFC
TVSS &
EMI/RFI
Filters
L1
GG
Static
Bypass
L2
N
L1
L2
N

System Description
6
3.5 DC to DC Converter
The DC to DC converter utilizes energy from the battery system and raises the DC voltage to the
optimum operating voltage for the inverter. This allows the inverter to operate continuously at its
optimum efficiency and voltage, thus increasing reliability.
3.6 Battery
The 10Kva RT utilizes valve-regulated, nonspillable, flame retardant, lead acid
batteries. To maintain battery design life, operate the UPS in an ambient temperature of 68°F to 77°F
(20°C to 25°C). Optional external battery cabinets are available to extend battery run times.
3.7 Static Bypass
The 10Kva RT provides an alternate path for utility power to the connected load
in the unlikely event of a UPS malfunction. Should the UPS have an overload, overtemperature or
UPS failure condition, the UPS automatically transfers the connected load to bypass. Bypass
operation is indicated by an audible alarm and illuminated amber Bypass indicator (other indicators may
be illuminated to indicate the diagnosed problem).
The user may manually transfer the connected load from the inverter to bypass by pressing the
Standby button once.
NOTE
The bypass power path does NOT protect the connected equipment from disturbances
on the utility supply.

Major Components
7
4.0 MAJOR COMPONENTS
The 10Kva RT is composed of three major assemblies to provide easier handling, installation
and versatility.
4.1 Main Frame and Electronics
This 6U cabinet arrives without internal batteries to lighten the UPS for easier installation. Once the
cabinet has been placed in its final floor or rack position, the internal batteries may be installed. The
UPS is shipped with standard hardwire terminal blocks for input and output connections.
Figure 1 10Kva RT Dual Inverter (front and rear views)
4.2 Internal Battery Pack
The center front bezel can be removed by unscrewing the side mounted screws to reveal the battery
access plate. The cover plate can be removed by extracting the three screws at the top of the cover
plate and lifting the plate off. The two internal battery packs are compact assemblies ready to slide
into the battery compartment after the front battery access plate has been removed. Electrical
connection is made with the two slotted battery connectors.
Figure 2 Internal battery pack and connector
Battery connector
on front of battery pack
FRONT VIEW
!
Status Indicators
and Controls
Front Bezel
Battery Compartment (behind front bezel);
Internal Battery Pack is shipped loose
(See Section 4.2)
Support Base
Hardwire
Knockouts
Intelligent®
Cooling Fan,
1 of 3
REPO
Switch
External Battery
Connectors
DB-9
Communications
Ports, 2
Input Circuit
Breaker
Output
Circuit
Breaker
UPS/Bypass
Breaker
REAR VIEW

Major Components
8
4.3 Input/Output Terminal Blocks and Optional Output Distribution
The UPS is shipped with hardwire terminal blocks. For maximum flexibility, additional distribution
options are available that provide the benefit of output receptacle convenience.
Figure 3 Hardwire terminal blocks
Figure 4 Optional output distribution modules
INPUT
L1
N
L2N L1
L2
OUTPUT
Power Distribution Option
with Internal Connector
Power Distribution Option
Power Distribution Option
with Internal Connector
120A 125V
PUSH TO
RESTART
OUTPUT BREAKER 20A 250V~/T OUTPUTBREAKER 20A 250V~/T
OUTPUT L1
OUTPUT L2
PD~102
120A 125V
PUSH TO
RESTART
OUTPUT BREAKER 20A 250V~/T OUTPUT BREAKER 20A 250V~/T

What’s Included
9
5.0 WHAT’SINCLUDED
The RT 10Kva is shipped with the following items:
•RT 10Kva user manual
•Vertical display overlay
•Front bezels
•Top bezels
•Battery cover grille
•Power Modulecovergrille
•Battery packbrackets - 2
•Serialcable, 10 ft. (3m)
•Rackmounthandles
•Support bases - 2
•Mountinghardware
•Ferrite beads(2)
Support base
with spacers
Mounting hardware
Front bezels
Vertical
display
overlay
Rack-mount
handles
serial cable
10 ft (3m)
Battery cover
Ferrite
beads (2)
!
!
S4K6U
L1 L2
AC INPUT
- +
BATTERY
UPS ON
BYPASS
Battery brackets
Box containing accessories is shipped in the UPS’
battery compartment

Installation and Configuration
10
6.0 INSTALLATION AND CONFIGURATION
This section includes instructions on how to install, configure and perform initial electrical checks of
your UPS installation.
DO NOT attempt to start the UPS, turn on any circuit breaker or energize the input power until
instructed to do so in 7.0 - Initial Startup and Electrical Checks.
Visually inspect the UPS for freight damage. Report damage to the carrier and your local distributor
or Sales representative.
Install the UPS indoors in a controlled environment, where it cannot be accidentally turned off. Place
it in an area of unrestricted airflow around the unit, away from water, flammable liquids, gases,
corrosives and other conductive contaminants. Maintain a minimum clearance of 4" (100mm) in the front
and rear of the UPS. Maintain an ambient temperature range of 32°F to 104°F (0°C to 40°C).
6.1 Install the Main Cabinet
The RT 10Kva may be installed either as a tower unit or in a rack, depending on available
space and use considerations. Determine the type of installation and follow the appropriate
instructions in either 6.1.1 - Tower UPS Installation or 6.1.2 - Installing the Adjustable Rack-Mount
Kit. .
6.1.1 Tower UPS Installation
When using the RT 10Kva in a tower configuration, use the included support base (shown
below, left) to stabilize the UPS.
If any external battery cabinets are added, they will include spacers to accommodate the additional
cabinets (shown in Section 6.2).
Figure 5 Support base and spacers
Attach Bezels to Top
When used as a tower, the RT 10Kva requires bezels attached to the top. To connect
the bezels:
1. Position the UPS so that the battery compartments are on the right side.
2. Attach the top bezels by placing them on the mounting holes and sliding them toward the rear of
the UPS.
!CAUTION
The UPS is heavy (see 14.0 - Specifications). Take proper precautions when lifting or
moving it.
NOTE
UPS operation in sustained temperatures above 77°F (25°C) reduces battery life.
End Bases
Spacers

Installation and Configuration
11
6.1.2 Installing the Adjustable Rack-Mount Kit
This kit contains parts needed to mount several different models of UPS and external battery
cabinets into EIA310-D standard four-post racks that are 18-32" deep (457-813mm). The weight
limit per pair of adjustable rack-mounting brackets is 270 pounds (123 kg).
RT 10Kva rack-mount bracket kit, includes:
Tools needed for installation are:
•one Phillips screwdriver
•one 7mm wrench
The adjustable rack-mounting brackets feature retaining latches to prevent users from inadvertently
sliding the UPS or battery cabinet out of the rack.
To install the rack mount brackets:
1. Unpack two (2) rack-mounting bracket assemblies and
mounting hardware from this kit. Bracket assemblies are
interchangeable between left-hand or right-hand.
Remove inner member of each bracket assembly as shown
in at right by extending it to its outermost position,
depressing the retaining latch and then pulling the inner
member out of the bracket assembly.
2. Determine the height position inside the rack enclosure
where you want to mount the UPS or battery cabinet.
3. Install the rear member of each bracket assembly into rack
enclosure with two (2) M5 screws provided in this kit (see
figure at right). The return flanges on the bracket assembly
fit to the inside of rack mounting rails. Insert screws loosely
(finger-tight) into the top and bottom holes of the return
flange on the rear member. Extend the bracket assembly by
sliding the front member forward until it touches the front
rack mounting rail. Insert two (2) M5 screws loosely (finger-
tight) into top and bottom holes of the return flange on each
front member. Make sure bracket assemblies are at the
same mounting height on all four (4) rack mounting rails.
Item Quantity
Rear bracket members 2
Front bracket members 2
Inner bracket members 2
M4 x 8mm machine screws 16
M4 locking hex nuts 8
M5 x 16 mm machine screws 12
Grease packet. 1
!CAUTION
Reduce the risk of tipping the rack enclosure by
placing the UPS or battery cabinet in the lowest
possible rack position.
Return
flanges
Inner
members
Front
members
Retaining
Latches
M5 screws
M5 screws
Front rack
mounting rails
Rear rack
mounting
rails

Installation and Configuration
12
4. Get eight (8) M4 screws and eight (8) M4 nuts from the
hardware pack in this kit. Each nut has a locking, nylon
insert that begins gripping the screw when it is halfway
tight. Make sure to tighten the nut and screw completely to
ensure locking action.Fasten the rear member and the front
member together using (4) screws and (4) nuts per bracket
assembly as shown in at right. For maximum support, insert
fasteners for each bracket assembly as far apart as possible,
depending on rack depth, while still joining both members
(see figures at right). Check alignment of bracket assemblies
and TIGHTEN ALL SCREWS FROM Steps 2 and 3.
5. Prepare the UPS or battery cabinet (the “equipment”) for
rack mounting by following instructions in the equipment’s
user manual. The equipment may require additional parts to
be added or parts to be removed for rack mounting. After it is
prepared, lay the equipment in rack-mounting position.
Fasten the inner members from Step 1 to the equipment on
both sides as shown at right with eight (8) M4 screws
provided in the kit. Make sure retaining latch is near the rear
of the equipment as shown (see figure at right).
6. Open the grease packet provided in the kit. Apply a 1" long
bead of grease at four (4) places inside the bottom, curved
tracks of the front members as shown below right. The grease
will allow the equipment to slide into the bracket assemblies
more easily.
7. Insert the equipment, with inner members attached in
Step 5, into the bracket assemblies by inserting the top and
bottom edges of the inner members into the top and bottom
curved tracks of the front members and sliding the
equipment into the rack (see figure at right). Ends of inner
members are tapered to allow the rear of the equipment to be
angled upward before insertion, if space allows.
Then the rear, bottom edges of the inner members can be
placed into the front edge of the bottom tracks and the front
of the equipment can be tipped up so they are level to insert
the top edges of the inner members before sliding the equip-
ment into the rack (see figure below right). The equipment
should move smoothly into the bracket assemblies. If it does
not, recheck the alignment of the front and rear members
from Steps 2 and 3.
8. Secure the front of the equipment to the rack mounting rails
to prevent the equipment from sliding out of position. If
securing holes are provided on the front of the equipment
that align with the center holes on the return flange of the
front members, you can use the four (4) extra M5 screws
provided in the kit to secure the equipment. Otherwise, the
equipment should be secured to the front of the rack with
four (4) customer-supplied fasteners.
!CAUTION
Lifting equipment into the rack may be a two-person
job, depending on the weight of the equipment. (See
equipment’s user manual.)
32" rack
depth
M4 nuts
M4 nuts
M4
screws
18" rack
depth
M4 nuts
M4 nuts
M4
screws
UPS or battery
cabinet
Front
M4 screws
M4 screws
Retaining latch
UPS or
battery
cabinet
Apply
grease
(inside)
Apply
grease
Insert the UPS into the front
members, lift the front ...
... and push it
into the rack.

Installation and Configuration
13
6.2 External Battery Cabinet Installation
Optional RT 10Kva external battery cabinets may be connected to the UPS to provide additional
battery run time. External battery cabinets are designed to be placed on one side of the UPS or
stacked beneath the UPS.
The external battery cabinet frame and battery kits are shipped separately. This 4U cabinet arrives
without internal batteries to lighten the cabinet for easier installation. Once the cabinet has been
placed in its final floor or rack position, the internal batteries may be installed.
When the external battery cabinet is received, it should be inspected for freight damage. Report
damage to the carrier and your local distributor or sales representative.
To install an external battery cabinet:
1. For slide rail installations, first remove the top bezel. Optional rack-mount handles are shipped
with the external battery cabinet and may be installed now.
2. Fasten the slides into position with the screws according to the instructions included with the
slide rails.
3. Use the enclosed support bases for the tower option to
prevent the assembly from tipping over. One additional set
of support base extensions ships with each external
battery cabinet.
4. Install the two battery packs and secure with the two
brackets supplied.
5. Connect the two slotted battery cables.
6. Attach the battery cover plate and the two front bezels.
7. Connect the supplied external battery cabinet cables to
either set of connectors on the rear of the external battery
cabinet, then to the rear of the UPS.
8. The UPS is now equipped with additional backup battery
run time. For approximate battery run times, refer to Table
6 - Battery run times in this manual.
9. Do NOT turn on the battery cabinet circuit breaker at this
time. Please complete the remainder of the installation first.
!CAUTION
The external battery cabinet(s) are heavy (see 14.0 - Specifications). External battery
cabinets can be used in rack-mount or tower configuration. Take proper precautions when
lifting them.
!CAUTION
Verify that the battery cabinet circuit breaker is in the OFF position. Dot no energize the
battery cabinet at this time. When installation is complete, you will be instructed to turn on
the circuit breaker.
NOTE
UPS automatically detects the number of standard
batteries that are connected. The configuration
program may be used to set up the UPS for operation
with non-standard external batteries.
+
Support Base With
Spacers for External
Battery Cabinets
UPS and
External Battery Cabinet
+
BAT TE R Y CONNE C TOR
BAT TE R Y CONNE C TION
CIRCUIT BREAKER +++

Installation and Configuration
14
6.3 Connect Input/Output Power
The UPS has hardwire terminal blocks for input and output electrical connections. Optional output
distribution modules permit connecting additional loads to the UPS. These optional plug-and-play
distribution modules offer different types and numbers of connection plugs.
6.3.1 Distribution Module Electrical Connections
Electrical connections are made through a removable conduit box that attaches to the rear of
the UPS.
The installer must provide a 60A branch circuit breaker. The input circuit breaker and the output
circuit breaker on the rear fixed-panel of the UPS disconnect all power between the main cabinet and
the distribution box.
The manual bypass switch passes utility power directly to the bypass switch from the input terminal
block. The input circuit breaker does not disconnect power from the manual bypass switch.
Figure 6
!WARNING
The UPS must be completely powered down before beginning to make these electrical
connections.
!CAUTION
A disconnect switch shall be provided by others for AC input circuit. To reduce the risk of fire,
connect only to a circuit provided with branch circuit over-current protection for 60 amperes
rating in accordance with the National Electric Code, ANSI/NFPA 70.
!CAUTION
A disconnect switch shall be provided by others for AC output circuit. To reduce the risk of fire,
connect only to a circuit provided with branch circuit overcurrent protection for 60 amperes
rating in accordance with the National Electric Code, ANSI/NFPA 70."
Optional
Output
Distribution
Plate
Utility
Input
60A External
Branch
Circuit Breaker
60A
Input
Circuit
Breaker
Output
Terminal
Block
60A
Output
Circuit
Breaker
60A Maintenance
Bypass Breaker
UPS
Input
Indicator
Output
Indicator

Installation and Configuration
15
6.3.2 Input & Output Terminal BlockConnections
Conduit entry holes are provided on the rear and side of the box. Input and output wiring should not share the
same conduit.
For best performance, distribute all L-N loads evenly between L1 and L2.
Table 1 Electrical requirements
Input Current
Rating
Recommended (Max.) External
Overcurrent Protection
Recommended Wire
(including ground wire)
(75°C copper wire)
Maximum Wire
Accepted by
Terminal Block
Terminal
Tightening
Torque
GWA4GWA6A06A84 22 in-lb
(2.48N-m )
NOTE
1. The installer must provide circuit breaker protection according to local codes. The utility disconnect
should be within sight of the UPS or have an appropriate lock-out. Maintain service space around the
UPS or use flexible conduit.
2. The installer must provide output distribution panels, circuit breaker protection or emergency
disconnects according to local codes. Output circuits must not share a common conduit with any
other wiring.
OUTPUT INPUT 60Amp Max. Branch
Overcurrent Protection
6 AWG - USE COPPER WIRE ONLY - 22 in-lb- Strip 8mm
0
127
220
Output to Load - See Note 1
0
220
Input to UPS - See Note 2
N L1L2N L1L2
N L1L2N L1L2
127
127
127
