Orion HBHS1 User manual

1
Made in USA
Installation Instructions
©2017Orion Energy Systems, Inc. All rights reserved. Orion and LightYears Ahead are trademarks/
service marks of Orion Energy Systems, Inc. Design modification rights reserved. 20170713
Orion Energy Systems, Inc.
orionlighting.com 1.800.660.9340
Use this instruction to install the fixture end cap kit in the
field.
LED-HBHS-EC01-KIT Components
1 (2) End Caps
2 Hardware for End Caps (4)
Tools Required for Installation
-Cordless drill
Step-by-Step Instructions
HBHS1 Field Installation Instructions
Instruction Number: P-INT-X-399
1
Unpack kit components. See Fig. 1 for HBHS1 without
end cap installed.
2
Place end cap onto fixture arm bar as shown in Fig.
2.
3
Screw end cap securely into place with hardware
provided. (See Fig. 3)
4
Repeat Step 2 and Step 3 on opposite end of fixture.
5
Proceed to mount fixture per customer selected
mounting method and complete electrical connections
to NEC/local code.
12
3
WARNING!
Risk of fire or electric shock. To reduce risk
of electrical shock, turn off power supply
before installation or servicing.
1. Field installers are responsible for recognizing specific site
requirements and making adjustments to assure a complete,
functional installation.
2. Make all power connections using UL listed components.
3. Electrical connections must be made by a qualified electrician
and in accordance with NEC and local codes.
Use this instruction to install the lens kit in the field.
LED-HBHS-LF01-KIT Components
1 Lens, Frosted Acrylic
2 (2) End Caps
3 Hardware for End Caps (4)
Tools Required for Installation
-Cordless drill
Step-by-Step Instructions
1
Unpack kit components. Follow Step 2 and Step 3
from end cap kit installation above.
2
Remove film from both sides of the lens. Insert lens
into fixture body with shiny side of lens facing away
from the fixture. (See Fig. 1a)
3
Complete installation of end cap as seen in Fig. 2a.
4
Proceed to mount fixture per customer selected
mounting method and complete electrical connections
to NEC/local code.
1a 2a

2
Made in USA
Installation Instructions
Orion Energy Systems, Inc.
orionlighting.com 1.800.660.9340
©2017 Orion Energy Systems, Inc. All rights reserved. Orion and LightYears Ahead are trademarks/
service marks of Orion Energy Systems, Inc. Design modification rights reserved. 20170713
Use this instruction to install the OESC sensor bracket kit in
the field.
LED-HBHS-SB01-KIT Components
1 OESC style sensor bracket, to be used with an OESC
sensor
2Hardware for bracket (8)
3OESC sensor (sold separately and shown for
demonstration of bracket install)
Tools Required for Installation
-Cordless drill
Step-by-Step Instructions
1
Unpack kit components.
2
Place sensor bracket over fixture arm bar on end of
fixture nearest to power connection (See Fig. 1b)
3
Install bracket with provided hardware on the back and
front sides of the bracket. (See circled areas on Fig. 2b
for hardware front installation and circled areas on Fig.
3b for hardware installation on back of bracket, both
sides of bracket need to be secured)
4
Once bracket is secured to arm bar, mount OESC
sensor box to bracket as shown in Fig. 4b to both
sides of the bracket.
5
Proceed to mount fixture per customer selected
mounting method and complete electrical connections
to NEC/local code.
1b 2b
HBHS1 Field Installation Instructions
Instruction Number: P-INT-X-399
3b 4b
Use this instruction to install the aisle application kit in the
field.
LED-HBHS-AA01-KIT Components
1 Reflector
2Hardware for reflector (2)
Tools Required for Installation
-Cordless drill
Step-by-Step Instructions
1
Unpack kit components.
2
See Fig. 1c for example of predrilled designated
holes (circled). Place aisle reflector between LED
arrays over predrilled designated mounting holes.
(See Fig. 2c)
3
Screw aisle reflector into place with provided
hardware. (See Fig. 3c)
4
Proceed to mount fixture per customer selected
mounting method and complete electrical connections
to NEC/local code.
1c 2c
3c

1
Made in USA
Installation Instructions
©2017 Orion Energy Systems, Inc. All rights reserved. Orion and LightYears Ahead are trademarks/
service marks of Orion Energy Systems, Inc. Design modification rights reserved.
Orion Energy Systems, Inc.
orionlighting.com 1.800.660.9340
Use this instruction to install a fixture wireguard in
the field for the HBHS1 product series.
Components
1 HBHS1 Series Fixture (ordered separately)
2 LED-HBHS-WG01-KIT-SP or LED-HBHS-WG01-KIT
NOTE: Kit includes: Fixture wireguard, hardware (4
flanged nuts, 4 flanged hex screws) (See Fig. A
for provided hardware)
Tools Required for Installation
-Cordless Drill with deep well socket
attachment
Step-by-Step Instructions
HBHS1 A1/B1/C1 Fixture Wireguard Field Installation
Instruction Number: P-INT-X-406
1
Unpack components.
2
Place wireguard onto fixture body so it is
positioned over locations for screws and nuts
to be installed. (See Fig. 1, Fig. 2, and Fig. 3 for
wireguard placement)
3
Fasten wireguard to fixture arm bar with
supplied flange hex screw (See Fig. 4). Tighten
nut on back side to prevent fastener from
coming loose (See Fig. 5 and Fig. 6). Repeat
this step for all (4) locations.
4
OPTIONAL: To prevent driver channel from
being dislodged in an impact, install self
supplied fasteners at both ends of the fixture
arm bars to the driver channel. (See Fig. 5 and
Fig. 6) (See Fig. 7 and Fig. 8)
5
Proceed to mount fixture per customer selected
mounting method and complete electrical
connections to NEC/local code.
A
2
4
5
1
3
WARNING!
Risk of fire or electric shock. To reduce risk
of electrical shock, turn off power supply
before installation or servicing.
1. Field installers are responsible for recognizing specific site
requirements and making adjustments to assure a complete,
functional installation.
2. Make all power connections using UL listed components.
3. Electrical connections must be made by a qualified electrician
and in accordance with NEC and local codes.
6
78

2
Made in USA
Installation Instructions
©2017 Orion Energy Systems, Inc. All rights reserved. Orion and LightYears Ahead are trademarks/
service marks of Orion Energy Systems, Inc. Design modification rights reserved.
Orion Energy Systems, Inc.
orionlighting.com 1.800.660.9340
Use this instruction to install a fixture wireguard in
the field for the HBHS1 product series.
Components
1 HBHS1 Series Fixture (ordered separately)
2 LED-HBHS-WG02-KIT-SP or LED-HBHS-WG02-
KIT
NOTE: Kit includes: Fixture wireguard, hardware
(4 self-drilling bolts) (See Fig. A for provided
hardware)
Tools Required for Installation
-Cordless Drill with deep well socket
attachment
Step-by-Step Instructions
HBHS1 D1/E1/F1 Fixture Wireguard Field Installation
Instruction Number: P-INT-X-406
1
Unpack components.
2
Place wireguard onto fixture body so it is
positioned over locations for screws and nuts to
be installed. (See Fig. 1 and Fig. 2 for wireguard
placement)
3
Install self-drilling bolts through wire guard into
the fixture arm bar. (See Fig. 3 and Fig. 4 for
locations)
4
OPTIONAL: To prevent driver channel from
being dislodged in an impact, install self
supplied fasteners at both ends of the fixture
arm bars to the driver channel. (See Fig. 5 and
Fig. 6)
5
Proceed to mount fixture per customer selected
mounting method and complete electrical
connections to NEC/local code.
A
2
4
5
1
3
WARNING!
Risk of fire or electric shock. To reduce risk
of electrical shock, turn off power supply
before installation or servicing.
1. Field installers are responsible for recognizing specific site
requirements and making adjustments to assure a complete,
functional installation.
2. Make all power connections using UL listed components.
3. Electrical connections must be made by a qualified electrician
and in accordance with NEC and local codes.
6

3
Made in USA
Installation Instructions
©2017 Orion Energy Systems, Inc. All rights reserved. Orion and LightYears Ahead are trademarks/
service marks of Orion Energy Systems, Inc. Design modification rights reserved. 20180108
Orion Energy Systems, Inc.
orionlighting.com 1.800.660.9340
Use this instruction to install a fixture wireguard in the
field for the HBHS1 product series.
Components
1 HBHS1 Series Fixture (ordered separately)
2 LED-HBHS-WG04-KIT-SP or LED-HBHS-WG04-KIT
NOTE: Kit includes: 2 Fixture wireguards, hardware
(4 bolts, 4 nuts, 4 wireguard mounting plates, 4
screws) (See Fig. A for provided hardware)
Tools Required for Installation
-Cordless Drill with deep well socket
attachment
Step-by-Step Instructions
HBHS1 G1/GA/H1/HA/I1 Fixture Wireguard Field Installation
Instruction Number: P-INT-X-406
1
Unpack components.
2
If fixture does not have a lens installed, move
to Step 2. If fixture has a lens installed, remove
end cap screws. (See Fig. 1)
3
Place wireguard mounting plate on end of
the fixture. If fixture has a lens installed,
use screws from Step 1 to attach wireguard
mounting plate in place. If fixture does not have
a lens installed, use the screws provided in the
hardware kit (See Fig. 2)
4
Repeat Step 3 for the other three mounting
locations.
5
Place wireguards onto the fixture so they line
up with the wireguard mounting plate holes.
(See Fig. 3)
6
Insert the bolt and attach the nut to the bottom
of the bolt to secure the wireguard in place.
(See Fig. 4 and Fig. 5)
7
Repeat Step 6 for other 7 hardware locations.
(See Fig. 6 for completed assembly)
8
Proceed to mount fixture per customer selected
mounting method and complete electrical
connections to NEC/local code.
A
2
4
5
1
3
WARNING!
Risk of fire or electric shock. To reduce risk
of electrical shock, turn off power supply
before installation or servicing.
1. Field installers are responsible for recognizing specific site
requirements and making adjustments to assure a complete,
functional installation.
2. Make all power connections using UL listed components.
3. Electrical connections must be made by a qualified electrician
and in accordance with NEC and local codes.
6
