Warranty
LIMITED TWO YEAR CONSUMER WARRANTY:
Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove
to be defective in workmanship or material under normal use, for a period of two years from the
date of purchase from the dealer as indicated by the date code marking of the product PROVIDED
the product was installed by an authorized Directed dealer. During this two-year period, there will
be no charge for this replacement PROVIDED the unit is returned to Directed, shipping pre-paid.
If the unit is installed by anyone other than an authorized Directed dealer, the warranty period will
be one year from the date of purchase by the dealer as indicated by the date code marking of the
product. This warranty is non-transferable and does not apply to any unit that has been modified
or used in a manner contrary to its intended purpose, and does not cover damage to the unit
caused by installation or removal of the unit. During this one-year period, there will be no charge
for this replacement PROVIDED the unit is returned to Directed, shipping pre-paid. This warranty
is void if the product has been damaged by accident or unreasonable use, neglect, improper service
or other causes not arising out of defects in materials or construction. Units which are found to be
damaged by abuse resulting in thermally damaged voice coils are not covered by this warranty but
may be replaced at the absolute/sole discretion of Directed. ALL WARRANTIES INCLUDING BUT
NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, AND WARRANTY OF NON-
INFRINGEMENT OF INTELLECTUAL PROPERTY ARE EXPRESSLY EXCLUDED TO THE
MAXIMUM EXTENT ALLOWED BY LAW, AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE
SALE OF THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS
OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. Unit must be
returned to Directed, postage pre-paid, with bill of sale or other dated proof of purchase bearing
the following information: consumer's name, telephone number, and address, authorized dealer's
name and address, and product description. Note: This warranty does not cover labor costs for the
removal and reinstallation of the unit. IN ORDER FOR THIS WARRANTY TO BE VALID, YOUR
UNIT MUST BE SHIPPED WITH PROOF OF INSTALLATION BY AN AUTHORIZED DIRECTED
DEALER. ALL UNITS RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF
DIRECTED DEALER INSTALLATION WILL BE COVERED BY THE LIMITED 1 YEAR PARTS AND
LABOR WARRANTY. Note: This warranty does not cover labor costs for the removal and
reinstallation of the unit. BY PURCHASING THIS PRODUCT, THE CONSUMER AGREES AND
CONSENTS THAT ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE
RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA.
© 2003 Directed Electronics, Inc. All rights reserved. G27201/06/11/16/21/26 2-03
* ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
ENCLOSURE RECOMMENDATIONS
Nominal Impedance (parallel/series) 1.0 / 4.0ohm 2.0 / 8.0ohm 1.0 / 4.0ohm 2.0 / 8.0ohm 1.0 / 4.0ohm 2.0 / 8.0ohm
RE (DC resistance, parallel/series) 1.89 / 3.77 1.85 6.85ohm 1.76 / 3.53ohm 3.38 / 6.77ohm 1.78 /3.57ohm 3.39 / 6.76ohm
Sensitivity @ 2.84V/1m 86.46dB 84.21dB 84.22dB 85.32dB 87.64dB 88.1dB
Fs (free air resonance) 34.9Hz 38.5Hz 27.2Hz 26.1Hz 29.2Hz 30.46Hz
Qms (mechanical Q) 4.22 4.13 5.99 4.66 3.43 2.38
Qes (electrical Q) 0.54 0.62 0.59 0.48 0.60 0.62
Qts (totalQ) 0.48 0.54 0.54 0.44 0.51 0.49
BL (force factor, parallel/series) 8.86 / 17.72 TM 11.12 / 22.24 TM 7.78 / 15.51 TM 11.20 / 22.32 TM 8.83 /17.65 TM 11.26 / 23.37 TM
Sd (piston area) 347sq. cm 347sq. cm 496sq. cm 496sq. cm 780sq. cm 780sq. cm
53.8sq. in. 53.8sq. in. 76.9sq. in. 76.9sq. in. 121sq. in. 121sq. in.
Vas (volume acoustic suspension) 17.1 liters 15.7 liters 50 liters 59 liters 89.66 liters 107.23 liters
0.6 cu. ft. 0.56 cu. ft. 1.76 cu. ft. 2.09 cu. ft. 3.16 cu. ft. 3.21 cu. ft.
Xmax (linear excursion) 17.19mm 17.19mm 17.19mm 17.19mm 17.19mm 17.19mm
0.67in. 0.67in. 0.67in. 0.67in. 0.67in. 0.67in
Power (continuous thermal power handling) 500watts 500watts 500watts 500watts 500watts 500watts
Power (peak thermal power handling) 1000watts 1000watts 1000watts 1000watts 1000watts 1000watts
Outside Diameter 10.44in. 10.44in. 12.31in. 12.31in. 15.56in. 15.56in.
265mm 265mm 312mm 312mm 395mm 395mm
Mounting Diameter 9.187in. 9.187in 11.06in. 11.06in. 13.69in. 13.69in.
233mm 233mm 281mm 281mm 348mm 348mm
Mounting Depth 1.73in. 1.73in. 5.5in. 5.5in. 6.75in. 6.75in.
44mm 44mm 140mm 140mm 171mm 171mm
Basket Displacement 256.64 cu. in. 256.64 cu. in. 361.56 cu. in. 361.56 cu. in. 570.07 cu. in. 570.07 cu. in.
4.2 liters 4.2 liters 5.9 liters 5.9 liters 9.3liters 9.3liters
Voice Coil Diameter 2.58in. 2.58in. 2.0in. 2.0in. 2.0in. 2.0in.
65.55mm 65.55mm 51mm 51mm 51mm 51mm
Sealed Enclosure Volume 0.50 cu. ft. 0.50 cu. ft. 1 cu. ft. 1 cu. ft 1.85 cu. ft. 1.85 cu.ft.
14.60 liters 14.60 liters 35.40 liters 35.40 liters 56.64 liters 56.64 liters
Vented Enclosure Volume .95 cu. ft. .95 cu. ft . 1.3 cu. ft. 2 cu. ft. 2.75 cu. ft 2.63 cu. ft.
28.32 liters 28.32 liters 42.48 liters 42.48 liters 84.96 liters 84.96 liters
Port Diameter (inside diameter) 3.0in. 3.0in. 4.0in. 4.0in. 5in. 5in.
76mm 76mm 102mm 102mm 102mm 102mm
Port Length 5.67in. 5.67in. 13.61n. 7.44in. 8in. 6in.
203mm 203mm 254mm 254mm 304.8mm 304.8mm
Enclosures include basket and port displacment
P10D2 P10D4 P12D2 P12D4 P15D2 P15D4
SPECIFICATIONS
