STAGE ENSEMBLE
P o r t a b l e D i g i t a l P i a n o
Owner’s Manual

SAFETY PRECAUTIONS AND INSTRUCTIONS
WARNING
Make sure that the voltage set is suitable for the instrument (the voltage is indicated next to the
power inlet). When using electric products, always follow basic precautions, including the
following:
1. Read all of these instructions before using the product.
2. To reduce the risk of injury, close supervision is necessary when the product is used near
children.
3. Do not use this product near water - for example, near a bathtub, washbowl, kitchen sink,
in a wet basement, near a swimming pool, or the like.
4. This product, either alone or in combination with an amplifier, headphones, or speakers
may be capable of producing sound levels that could cause permanent hearing loss. Do
not operate for a long period of time at a high volume level, or at a level that is
uncomfortable. If you experience any hearing loss, or ringing in your ears, you should
consult an audiologist.
5. The product should be located so that its location, or position, does not interfere with
proper ventilation.
6. This product should only be located away from heat sources such as radiators, heat
registers, and other products that cause heat.
7. The product should be connected only to the type of power supply described in the
operating instructions, or as marked on the product.
8. This product may be equipped with a polarized plug. This is a safety feature. If you are
unable to insert the plug into the outlet, contact an electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the plug.
9. The power-supply cord of the product should be unplugged from the outlet when left
unused for a long period of time. When re-plugging unit, turn on the instrument and leave
on for 3-5 hours to recharge the internal battery. The battery may need to be replaced
after two or three years of use.
10. Care should be taken so that objects do not fall, and liquids are not spilled, into the
cabinet through openings.
11. The product should be serviced by qualified personnel when:
a. The power-supply cord or the plug has been damaged, or
b. Objects have fallen, or liquid has been spilled, into the product, or
c. The product has been exposed to rain, or
d. The product does not appear to operate normally or exhibits a marked change in
performance, or
e. The product has been dropped or the cabinet damaged.
12. Do not attempt to service the product beyond that described in the maintenance
instructions. All other servicing should be referred to qualified service personnel.

GROUNDING INSTRUCTIONS
This product must be grounded (earthed). In the event of a malfunction or breakdown, grounding
provides a path of least resistance for electric current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded
in accordance with local codes and regulations.
DANGER
Do not modify the plug provided with the product - if it will not fit, have a proper outlet installed
by a qualified electrician.
TEMPO / VALUE DISPLAY
The messages contained in the Display may not always match the display pages. These are
merely examples of the many features of the product.
DISCLAIMER
The information contained in this manual has been very carefully revised. Due to the constant
effort to improve the product, the product specifications might differ to those in the manual. The
specifications are subject to modification without prior notice.
TAKING CARE OF YOUR INSTRUMENT
Your ORLA Stage Ensemble is a fine musical instrument and deserves careful treatment.
Follow the next few points carefully, to keep it at its best for many years.
- Never open the case and touch the internal circuits.
- Always switch the power OFF after use.
- Use a cloth or a damp sponge. If the dirt is particularly persistent, use a neutral detergent
to remove it. Never use solvents or alcohol.
- Do not place your instrument near electric motors, neon or fluorescent lamps as these
may generate disturbances.
- In most cases you just need to change the position of the instrument to avoid interference.
- Keep your instrument away from dusty environments, high humidity, and high
temperatures.
- Do not use on the same AC power outlet with electrical appliances, neon lights or
variable lighting systems.
- Before turning on the instrument, make sure that any external amplifier and speaker
system that you have connected to your instrument are turned off.
- Computer controlled instruments can be interrupted by spikes, surges and dropouts on the
AC power line. If your instrument stops working because of an AC power line
disturbance, switch it off for a few seconds and then switch it on again.
- Never disconnect the power cable without turning the power switch off.

GETTING STARTED
PREPARATION
This section contains information about setting up your instrument and preparing to play. Be sure
to go through this section carefully before using this instrument.
POWER SUPPLY
Plug the DC output cable from the power adapter into DC IN jack on the rear panel of your
instrument, and then plug the AC cable of your power adapter into a convenient wall AC power
socket.
1. Turn on the instrument by pressing the POWER ON/OFF switch located on the back panel.
2. Set the MASTER VOLUME to the desired level. The MASTER VOLUME controls the
overall volume for the entire instrument.
USING HEADPHONES OR AN EXTERNAL SOUND SYSTEM
A standard stereo headphone set can be plugged into the PHONES socket for private practice or
late-night playing. The internal speaker system is automatically switched off when the
headphone set is plugged into the PHONES socket. There are two sockets available on the rear
panel that allow the use of two headphone sets at the same time.
The LINE OUT (Left and Right) sockets can be used to deliver the output of the sound to an
external amplifier, stereo sound system, mixing console, or tape recorder.
SUSTAIN PEDAL (supplied)
The Stage Ensemble is supplied with a Sustain pedal.
Connect it to the Pedal Input number 2 to obtain the Sustain effect when used.
It has the same function as the ''sustain'' pedal on an acoustic piano.
It provides sustain and lets the sound slowly decay after the keys have been released.
SOFT/SOSTENUTO/SUSTAIN PEDAL (optional)
If necessary the Stage Ensemble can be used with an optional 3 Pedals pedalboard.
Insert the mono jack to the Pedal Input number 1 and the stereo jack in the Pedal Input number 2.
Soft Sustain
Sostenuto
The instrument now works with a set of three pedals giving the following functions:
SOFT: gives the piano voices a ''softer'' sound.
4

SOSTENUTO: this allows only the notes pressed on the keyboard before the Sostenuto
pedal is activated to sustain, and subsequent notes played afterwards will
not sustain.
SUSTAIN: has the same function as the ''sustain'' pedal on an acoustic piano. It
provides sustain and lets the sound slowly decay after the keys have been
released.
If the optional 3 Pedals pedalboard is used it is possible to program the Soft and Sostenuto pedals
to control the Start /Stop and Fill In features of the style section.
- Press the [FUNCTION] button a few times to select PEDAL on the display:
- Press [ENTER] button to confirm the function. The display indicates the current status.
- Use the [+/-] buttons to select Normal or Custom.
In Normal mode the pedals will be used for Soft and Sostenuto.
In Custom mode the pedals will be used for Start/Stop and Fill In.
The display will return to the normal display mode and the Pedal Mode is now set.
VOLUME SLIDERS
The Master Volume slider controls the overall volume of the instrument. It controls the volume
also when connected to a headphone set.
The Rhythm Volume slider controls the Drum Sounds volume when playing the automatic
accompaniment.
The Bass/Chord Volume slider controls the Auto Accompaniment volume when playing the
automatic accompaniment.
5

PANEL DISPLAY INDICATIONS
Your instrument features a large multi-function display (INFORMATION DISPLAY) that
shows all the important settings for the instrument. The section below briefly explains most of
the various icons and indications that may appear in the display.
(1) Message Display - This section displays the demo song, voice or style name and number that you
have selected. Other important functions and parameters are also displayed in this section.
(2) Active Input – Enables the user to make selection changes. The arrow indicates the active feature.
(3) Function – Indicates the status of the listed parameters: Touch Sensitivity, Sustain, OTS, Dual mode.
(4) Note Display - When you play a key on the keyboard, the note is displayed.
(5) Octave - The icon indicates the Octave of the played notes.
(6) Tempo – Indicates the tempo in BPM (Beats Per Minute).
(7) Track Volume - Displays the volume of each track dynamically, when a song or style is played.
(8) Chord – Indicates the chord played on the instrument.
DEMO SONGS
There are 26 demo songs in the internal memory. Listen to the pre-programmed demonstration
songs and they will give you a good idea of what the instrument can do.
- Power ON and set the Master Volume at half way.
- Press the [FULL KEYBOARD] button and the [METRONOME] button at the same time
to activate the DEMO function. The name of the selected DEMO will appear on the
INFORMATION DISPLAY. You can select the demo songs by using the [+/-] buttons.
- Press [FULL KEYBOARD] button and the [METRONOME] button again to stop the
DEMO song.
6

SELECTING AND PLAYING THE VOICES
Your instrument has 476 sounds in the internal sound library numbered from 01 to 476, and
8 Drum Kits numbered from 477 to 484. Sound 485 is the SOUND EFFECT bank preset.
The available sounds can be played in three different modes: Right 1, Right 2 and Left.
Right 1 - plays a single voice over the entire range of the keyboard.
Right 2 - mixes two different voices together for rich, complex sounds.
Left - allows the player to select one sound for the Left part and up to two sounds for the
Right part of the keyboard.
The complete list of the available Sounds is available in the SOUND LIST pages at the end of
this manual.
The first 128 sounds are listed according to the GM sound list from 1 to 128. From 129 to 476
the sounds are listed according to the ORLA XM Sound List that incorporates all the standard
General MIDI (GM) sounds plus all ORLA sound variations.
In GM mode the instrument allows the player to select the sounds according to standard GM
mapping. Most players remember the GM sound numbers, so this may be easier for them.
In the XM mode the complete sound list is available including not only all the GM sounds but
also the many sound variations especially developed by the expert team of ORLA musicians.
SOUND VOLUME
The volume of each section can be controlled with the related volume buttons.
The volume range is from 00 (no sound) to 127 (maximum volume).
SELECT A SOUND
Press the [VOICE] button - the voice mode is selected and the current voice number and name
will display on the Message Display section. By pressing the VOICE button several times you
can see that it automatically selects RIGHT1, RIGHT2, and LEFT (the related LED is blinking).
Press the numeric key-pad buttons or the [+/-] buttons to select the desired voice number
according to the Voice List.
To select a sound numbered between 1 and 99, for example 65 Soprano Sax:
OPTION 1: Press the [+/-] buttons until the number 65 is displayed.
OPTION 2: Use the numeric key-pad buttons as detailed below:
- Press the number 6 button and then the number 5 to select the sound.
- The sound number 65 Soprano Sax is now selected.
7

To select a sound numbered higher then 99, for example 123 Sea Shore, press the [+/-] buttons
until the number 123 is selected on the display.
To select the sound 123 using the numeric key-pad buttons:
- Press the number 1 button and hold it until the number 1 appears on the display.
- Press then the number 2 and the number 3 buttons in quick succession to select the sound.
- Sound number 123 Sea Shore is now selected.
SELECT RIGHT 1 SOUND
Press the [VOICE] button to select the sound of RIGHT 1. Select the desired sound as explained
above. The name of the RIGHT 1 sound will be indicated on the display.
To change the sound again, use the numeric key-pad buttons or the [+/-] buttons to select the
desired voice number according to the Voice List.
Press the [RIGHT 1] button to switch the section ON or OFF. When you select the RIGHT1
sound OFF the display will show:
SELECT RIGHT 2 SOUND
Press the [RIGHT 2] button and its LED is now blinking. In this mode you can play two different
sounds at the same time on the right part of the keyboard. The name of the RIGHT 2 sound will
be indicated on the display for a few seconds also indicating the RIGHT 2 sound selected at
present.
8

When the RIGHT 2 sound is indicated on the display and its LED is blinking, the sound can be
changed. Press the numeric key-pad buttons, or the [+/-] buttons to select the desired voice
number according to the Voice List.
Press the [RIGHT 2] button to switch this section ON or OFF.
SELECT LEFT SOUND
Press the [LEFT] buttons to select the LEFT voice. This will enter the instrument in SPLIT
MODE and automatically divide the keyboard into two parts. The current voice number and
name will display on the Message Display section.
The keyboard is now divided in two sections: Left and Right.
When the LEFT sound is indicated on the display the sound can be changed (remember, the
instrument gives approximately 4 seconds to input data). Press the numeric key-pad buttons or
the [+/-] buttons to select the desired voice number according to the Voice List.
Press the [LEFT] button to switch this section ON or OFF.
Note: It is possible to play the LEFT Sound together with the Auto Accompaniment.
SELECT THE SPLIT POINT
The default position of the Split point is G2 located below the [DEMO] buttons.
The Split Point can be set to any other key as follows:
- Press the [FUNCTION] button a few times to select on the display:
- Press [ENTER] button to confirm the function. The display indicates the current Split
Point position: 34 SplPoint.
- Use the [+/-] buttons to set the Split Point Value. The default value is 34 that corresponds
to note G2.
- To set the Split Point on the C2 position, change the value to 27.
The display will return to the normal display mode and the new Split Point is now set.
The new Left Sound Split Point will remain active until the instrument is switched OFF.
9

TWIN MODE
Press the [TWIN] button to select TWIN mode. In this mode, the keyboard will be separated into
two playing areas.
Right: from C#3 to C7
Left: from A-1 to C3
This will be very helpful when the instrument is used by two players at the same time (example:
Teacher and Student) and they will be able to play the same piano sound in the same octave.
Press [TWIN] button again to exit the Twin mode.
While the TWIN feature is selected using the optional 3 lever pedal, the pedals automatically
switch to a different configuration where there are 2 Sustain pedals, one for the left and one for
the right part of the keyboard.
Sustain Sustain
Left Right
The middle pedal remains set with the feature of the last selected setting, Sostenuto or Start/Stop
(see related paragraph).
GRAND PIANO
When pressed the [GRAND PIANO] button resets the instrument to the Grand Piano sound.
DRUM KITS AND EFFECTS
Your instrument has 8 different Drum kits that can be played on the keyboard when selecting
voice numbers - 477 through to 484.
Sound No. Drum Kit Sound No. Drum Kit
477 Standard 482 Jazz
478 Room 483 Brush
479 Power 484 Classic
480 Electric 485 Effects
481 Dance
The Sound number 485 is the Sound Effects preset.
10

OMC – ORLA MAGIC CHORD
Whenever you play a chord with the left hand, this function adds a complete chord to the melody
line played with the right hand based on the left hand notes that are being played. It is intended
to convert a single note melody into a full chord.
When using the OMC it is important to play the lower manual in a legato fashion with sustained
left hand chords.
This feature provides a very full overall professional sound, however it has greater effect if it is
not used all of the time.
DIGITAL REVERB
Press the [REVERB] button to turn the REVERB effect ON or OFF.
While the Reverb setting is indicated on the display, the parameter can be changed. Use the [+/-]
buttons to select the desired REVERB settings. The display will indicate the available Reverb
types: REVERB OFF, Room1, Room2, Room3, HALL1, HALL2, Plate, Delay, Pan
Delay.
It is possible to adjust the Reverb effect for each section.
- Press [FUNCTION] button to select R1 RevVo? on the display and use the [+/-] buttons
to select R2 RevVo? or Lf RevVo? page.
- Press the [ENTER] button to select the Right 1section.
- Use the [+/-] buttons or use the numeric key-pad buttons to change the Reverb value (the
range is from 00 to 63).
- Press the [+/-] buttons at the same time to set the default value.
After a few seconds the display will go back to the normal display mode and the new Reverb
Value for Right 1 section is now saved.
CHORUS EFFECT
Press the [CHORUS] button to turn the CHORUS effect ON or OFF.
While the Chorus setting is indicated on the display, the sound can be changed. Use the [+/-]
buttons to select the desired CHORUS types. The display will indicate the available Chorus
type: CHORUS OFF, Chorus1, Chorus2, Chorus3, Chorus4, Feedback, Flanger,
Short Delay, Feed Back Delay.
11

It is possible to Change the Chorus effect for each section.
- Press [FUNCTION] button to select R1 RevVo? on the display and use the [+/-] buttons
to select R1 Chr Vo? or Lf Chr Vo? or R2 ChrVo? R2 page.
- Press the [ENTER] button to select the Right 1 section.
- Use the [+/-] buttons or use the numeric key-pad buttons to change the Chorus value
(the range is from 00 to 63).
- Press the [+/-] buttons at the same time to set the default value.
After a few seconds the display will go back to the normal display mode and the new Reverb
Value for Right 1 section is now saved.
TOUCH SENSITIVITY
Just like an acoustic piano, your instrument has a keyboard with velocity control. This means the
level of the audio signal will be in proportion with the velocity of the key pressed. If you play
soft you will have a quiet sound, while if you play very hard you will have a much louder sound.
This function can be set to different levels to adjust the touch with your own playing style.
After the [TOUCH] button is pressed the display will show:
Using the + and – button selects the available Touch Sensitivity value:
00 No Touch Sensitivity - Sensitivity Off
01 Hard Touch Sensitivity - This setting requires the keys to be played quite
hard to produce maximum volume.
02 Normal Touch Sensitivity - This setting produces standard keyboard response.
This is the factory default mode.
03 Light Touch Sensitivity - This setting allows maximum volume with lighter
key pressure.
TRANSPOSE
It is possible to Transpose the natural key (C) of your instrument up or down.
The default C natural setting is indicated as C0 in the following table.
C C# D D# E F F# G G# A A# B CC# D D# E F F# G G# A A# B C
12

-12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0+1 +2 +3 +4 +5 +6 +7 +8 +9 +10 +11 +12
The examples below illustrate how to use the table above:
- To Transpose the instrument to the key of E above C, press the Transpose [+] button 4 times.
- To Transpose the instrument to the key of A# below C, press the Transpose [-] button 2 times.
Press the [TRANSP/PITCH] buttons at the same time to restore the instrument to the key of C0.
PITCH – FINE TUNING
The PITCH feature enables the player to tune the pitch of the instrument to match other
instruments.
Press the two buttons for a few seconds and the display will display: PITCH
Use the + and – buttons to set the desired Pitch value. The PITCH value on the display can be
changed between –64 and +63.
Press the [TRANSP/PITCH] buttons at the same time to set the default value (0).
AUTO ACCOMPANIMENT SECTION
Your instrument has 260 (01-260) accompaniment styles which can be used to provide fully-
orchestrated Auto Accompaniment.
When the Auto Accompaniment function is turned ON, the left part of the keyboard will be used
to play automatic accompaniments with orchestrated chords and bass lines, the right part of the
keyboard is available for playing the melody.
SELECT A STYLE
Press the [STYLE] button to enter the style select function. The current style number and name
will appear on the Display
Press the numeric key-pad buttons or the [+/-] buttons to select the desired style number with the
13

same system used to select the sounds.
You can see the complete Style List at the end of this manual.
The Styles are listed in groups according to the following table:
01 – 12 8 Beat 108 – 117 Blues & Gospel
13 – 20 16 Beat 118 – 136 Country
21 – 32 Ballad 137 – 158 Latin 1
33 – 43 Dance 159 – 182 Latin 2
44 – 56 Disco 183 – 212 Ballroom
57 – 86 Big Band & Swing 213 – 241 World
87 – 107 Rock & Boogie 242 – 260 Waltz
AUTO CHORD RECOGNITION
When playing the Auto accompaniment it is possible to change chords using one or more fingers
without selecting the One Finger Note system or the Multi-Finger Chord system. The internal
computer will automatically select it for you.
SINGLE FINGER MODE
SINGLE FINGER Mode makes it simple to produce beautifully orchestrated accompaniment
using major, minor, seventh, and minor-seventh chords by pressing a minimum number of keys
in the AutoAccompaniment section of the keyboard.
There are two different Single Finger mode available in the instrument:
-Chord System 1
-Chord System 2
These two types refer to the most common Single Finger systems used by portable keyboards
today. To select the desired Single Finger Type, see the [FUNCTION] button paragraph.
ChordSys 1 C Major Press the key C.
C minor Press the key C + the 3rd key to the right
C Seventh Press the key C + the 2nd key to the left
C minor 7th Press the key C + the 3rd key to the right + 2nd key to the
left
C chord - press C key C minor - press C + 3rd key to right
14

C 7th - press C + 2nd key to left C m 7th - press C + 2nd key to left and 3rd to right
ChordSys 2 C Major Press the key C.
C minor Press the key C + any black key to the left
C Seventh Press the key C + any white key to the left
C minor 7th Press the key C + any black + any white key to the left
C chord - press C key C minor - press C + any black key to left
C 7th - press C + any white key to left C minor 7th - press C + any black and any white to left
The default system is Type 1.
15

MULTI-FINGERED MODE
Your instrument recognizes the following chords:
16

FULL KEYBOARD
This feature allows you to play automatic chords over the full length of the keyboard.
Press the button and dedicated arrow will indicate it on the display.
When in full keyboard mode the chords played by the Auto Accompaniment System will not be
displayed on the screen.
AUTO ACCOMPANIMENT SELECT AND CONTROLS
A different accompaniment style can be selected at any time while the accompaniment is
playing. The style number and name on the Message Display will change as soon as the selection
is made, but the new style will start from the beginning of the next bar. If the Auto Set Up
function is not activated, the tempo will not change when the new style is running.
Your instrument provides a range of accompaniment features:
Start/Stop, Auto Accompaniment, Intro/Ending, Fill-In 1, Fill-In 2, Key Start, Synchro
Start, Start/Stop.
AUTO ACCOMPANIMENT
Press the [ACCOMP. ON/OFF] button to activate the Auto Accompaniment feature. The
indicator will appear on the display. Press it again to deactivate.
INTRO/ENDING
If you press this button before you start the rhythm, the normal rhythm pattern will be preceded
by a special introduction (INTRO). However, if you press the button when the rhythm is already
running, the instrument plays a final variation (ENDING) and the rhythm section will stop
automatically.
All of your instrument accompaniment patterns can be started with an appropriate introduction
by pressing the [INTRO/ENDING] button, once the style has been selected. When the INTRO
finishes playing, the accompaniment will change to the main style pattern.
If you press one of the [SYNCHRO START] buttons and then the [INTRO/ENDING] button,
the accompaniment will start from the introduction as soon as a chord is detected.
17

FILL IN 1 and FILL IN 2 - STYLE A/B VARIATIONS
There are 2 variations available for each style: Variation A and Variation B. Press the Fill 1 to
select Variation 1 and press Fill 2 to select Variation 2. The Auto Accompaniment pattern
changes depending on the chords you play with your left hand.
The fill-in buttons let you add dynamic variations and breaks in the rhythm of the
accompaniment, to make your performance sound even more professional. At the end of the
fill-in, the appropriate Style Variation is automatically selected. Note: the fill-in will play when
selected as long as one of the fill-in buttons is pressed.
AUTO START
There are two types of Auto Start features:
- SYNCHRO START When this feature is selected the Auto Start will automatically start
the style when the first key or chord is pressed.
- KEY START When this feature is selected the Auto Start will automatically start
the style when the first key or chord is pressed and automatically
stop the style when the key or chord is released.
Press the desired [AUTO-START] button if you want the accompaniment to start when you play
the first note or chord on the AUTO ACCOMPANIMENT section of the keyboard.
If you select the SYNCHRO START function, the START/STOP LED will light up indicating
that the Synchro Start feature is activated. When you then press the first chord on the left part of
the keyboard, the LED will work normally indicating the down-beat.
If you select the KEY START function the START/STOP LED will start blinking, indicating
that the Key Start feature is activated. When you then press the chord on the left part of the
keyboard, the LED will work normally indicating the down-beat.
START/STOP
The [START/STOP] button starts the selected accompaniment style immediately.
Press the [ACCOMP. ON/OFF] button to turn ACCOMPANIMENT on before starting the style.
The accompaniment will start with the rhythm drum sound when the [START/STOP] button is
pressed, and then the bass and chord parts will play as soon as the first note or chord is played on
the keyboard.
TEMPO CONTROL
The [-TEMPO+] buttons can be used to control the tempo of the Auto Accompaniment section,
the DEMO songs, and the record/play back of a song recording.
Press the [-TEMPO+] buttons to set the desired tempo value (20-280). The current tempo (beats
per minute) will appear on the Message Display.
The instrument also offers the ability to input TEMPO settings via the [+/-] buttons.
Press the [TEMPO+] and [TEMPO-] buttons simultaneously to restore the default tempo setting.
TAP TEMPO
This function allows you to set the rhythm tempo by tapping in tempo on the [TAP] button.
Tap on the button while the rhythm is playing, and the rhythm tempo will automatically set at the
desired speed.
18

To set the tempo before starting a rhythm, tap on the button 4 times.
METRONOME
The Metronome is a convenient feature for practice, and it can also provide a rhythmic guide
when recording.
The metronome sound is alternately turned on and turned off by pressing the [METRONOME]
button.
The Time Signature of the metronome can be set by using the [+/-] buttons when turning on the
metronome function and while the Time Signature value is indicated on the display.
To set the Time Signature (1/4, 2/4, 3/4, 4/4, 6/4, 3/8, 6/8, 9/8 ) press the [METRONOME]
button and the Time Signature set for the metronome will be indicated on the display, use the
[+/-] buttons to select the new value.
To change the Tempo use the [- TEMPO +] buttons to set the desired tempo speed.
To set the tempo of metronome, please see details in the TEMPO section.
OVERALL TOUCH SETUP – OTS
This function enables the instrument to set an appropriate registration for each rhythm.
When a style is selected and the OTS is activated (the icon is activated on the display), a nice
registration for both the left hand and right hand parts will be automatically selected. The OTS
will also select the optimum tempo for the style selected. An indicator illuminates in the
Message Display when the system is activated. When the registration is changed with the OTS
activated, the instrument will accept the changes but the registration will not be changed in the
internal memory.
A good way to start exploring the instrument is to listen to the OTS registrations. By selecting
the desired rhythm with the OVERALL TOUCH SET-UP system ON, you will hear 260 nice
registrations. The OTS system can be switched ON and OFF by pressing the [O.T.S] button.
REGISTRATION MEMORY
19

The instrument can store 5 groups x 4 banks of panel settings. By pressing the corresponding
memory button, you can recall these settings rapidly. You can customize the panel settings to
accommodate your performance and store them to the registration memory positions.
These settings will not be lost, even if the power is turned OFF.
STORING THE PANEL SETTINGS
It is possible to load up to 20 panel registrations using the 5 Memory (M1 – M5) positions and
4 memory banks.
By pressing the [STORE/BANK] button four times, you can select 4 different banks. The display
shows the available memory banks [1 to 4 MmryBank].
The following panel settings can be saved: Left/Right Sounds, Volume levels, Pan settings,
Tempo, Octave, Effects, Style and keyboard mode. Other global parameters are also memorized.
-Select the desired style, tempo, sounds, volume and effects.
- Select the Memory Bank where to store the new settings by pressing a few times the
[STORE/BANK] button, for example BANK 3.
-Press and hold [STORE/BANK] button, and then press one of the [M1-M5] buttons to
show where to store the panel setting, for example M1.
-The LCD displays
The current panel settings are now stored in the memory in position BANK 3 – M1.
It is possible to repeat this procedure for all available positions.
RECALLING THE SETTINGS
By pressing the [M1-M5] buttons, the information you have stored previously can be recalled.
Press [STORE/BANK] button to access the Memory banks (press a few times).
The LCD displays the panel settings and memory position number.
LOCK
Pressing the [LOCK] button turns the LOCK function ON/OFF. When the LOCK function is
ON, the registration sounds stored in each memory location can be recalled, while the style
accompaniment settings will be LOCKED. The display shows the related indicator arrow:
20
