Orla GT3000 User manual

M U S I C A L I N S T R U M E N T S
GT3000
O w n e r s M a n u a l

1
CONTENTS
FEATURE
PAGE
FEATURE
PAGE
Safety
2
Automatic Set Up Programming
27
Instrument Care
3
Metronome
28
General Features
4
Transpose
28
Getting Started
4
Lower Volume
29
Overall Presets
5
Pitch
29
Footswitches
30
Factory Registrations
5
Styles Loading
31
Automatic Set Up
5
Styles Programing
32
Style List
6
Styles Programing New
32
Lock Button
7
Styles Reprograming Internal
37
Basic Features
8
Disk Recorder
39
Conductor
8
Standard Midi File Disk
40
Sound Sections
8
Disk Drive Crae & Use
41
Lower Flutes
11
Disk Drive Features
42
Upper Flutes
11
Disk Drive Functions
43
Overdrive
12
Disk Drive Play mode
43
Percussion
12
Disk Tracks Volume
43
Tremelo ( Motion Effect)
12
Disk Volume
43
Vibrato
12
Disk Octave /Sound Change
44
Basic Programing
13
Disk Chain
45
Registrations
13
Disk Play Loop
46
Saving Registrations
13
Disk Play Medley
46
Saving Registrations to Disk
14
Disk Services
46
Restoring Factory Registrations
15
Disk Save
47
Song Record
15
Disk Save OverallPresets
47
Advanced Features
16
Disk Save Automatic Set Up
48
Poly /Mono
16
Disk Save Custom Style
49
Lower Split
17
Disk Save Style Block
50
Percussion Type
17
Disk Save Midi Settings
51
Portamento
17
Disk Save All
52
Accordion Sounds
18
Disk Load
54
User Sound Bank
18
Disk LoadOverall Presets
54
Octave
19
Disk Load Automatic Set Up
54
Sustain
19
Disk Load Custom Style
54
FX Buttons
20
Disk Load Style Block
55
Lock
20
Disk LoadMidi Settings
55
OMC
20
Disk Rename
56
Reverb
21
Disk Copy
57
Chorus
22
Disk Delete
57
Enhancer
22
Disk Format
59
Auto Start
23
Midi Features
59
Rhythm features
23
Midi Fisa / Organ Mode
60
Start Stop
23
Midi Settings
60
Touch Sensitivity
23
Midi Master Mode
61
Drum Kit
24
Midi Piano Mode
61
Fill In ½
24
Midi Control
62
Intro Ending
24
Connections
63
Tempo
24
Reset
64
Auto Bass
25
Troubleshooting
65
Auto Chord
25
Midi Implementation Chart
66
MFC
25
Index
67
OFC
25

2
SAFETY PRECAUTIONS AND INSTRUCTIONS
WARNING
Make sure that the voltage set is suitable for the instrument (the voltage is indicated next to the AC
power inlet). Check the instrument main inlet and (if available) its dedicated amplification built in the
instrument optional stand. Set the right voltage, if necessary, by turning the voltage switch in the
appropriate position. Correct Voltage for Europe 230V.
110 V 230 V
When using electric products, always follow basic precautions, including the following:
1 Read all of these instructions before using the product.
2 To reduce the risk of injury, close supervision is necessary when the product is used near children.
3 Do not use this product near water - for example, near a bathtub, washbowl, kitchen sink, in a wet basement, near a
swimming pool, or the like.
4 This product, either alone or in combination with an amplifier and headphones, or speakers may be capable of
producing sound levels that could cause permanent hearing loss Do not operate for a long period of time at a high
volume level, or at a level that is uncomfortable. If you experience any hearing loss, or ringing in your ears, you
should consult an audiologist.
5 The product should be located so that its location, or position, does not interfere with proper ventilation.
6 This product should only be located away from heat sources such as radiators, heat registers, and other products
that cause heat.
7 The product should be connected only to the type of power supply described in the operating instructions, or as
marked on the product.
8 This product may be equipped with a polarized plug. This is a safety feature. If you are unable to insert the plug
into the outlet, contact an electrician to replace your obsolete outlet. Do not defeat the safety purpose of the plug
9 The power-supply cord of the product should be unplugged from the outlet when left unused for a long period of
time When reconnecting the unit, turn on the keyboard and leave on for 3-5 hours to recharge internal battery. The
battery may need to be replaced after two or three years of use.
10 Care should be taken so that objects do not fall, and liquids are not spilled, into the cabinet through openings
11 The product should be serviced by qualified personnel when
12 A The power-supply cord or the plug has been damaged; or
B Objects have fallen, or liquid has been spilled, into the product or
C The product has been exposed to rain or
D The product does not appear to operate normally, or exhibits a marked change in performance, or
E The product has been dropped, or the cabinet damaged
Do not attempt to service the product beyond that described in the maintenance instructions. All other servicing
should be referred to qualified service personnel.

3
GROUNDING INSTRUCTIONS
This product must be grounded (earthed). If should malfunction or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock This product is equipped
with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and grounded in accordance with the local codes and
regulations
DANGER
Do not modify the plug provided with the product - if it will not fit - have a proper outlet installed by a
qualified electrician
DATA HANDLING
The information contained in the internal memory may sometimes be lost due to incorrect user action.
Make sure to save important data into a floppy disk. ORLA will not be responsible for damages caused
by data loss.
MULTI INFORMATION DISPLAY
The messages contained in the Multi Information Display may not always match the display pages They
are merely examples of the many features of the product
DISCLAIMER
The information contained in this manual has been very carefully revised. Due to the constant effort to
improve the product, the product specifications might differ to those in the manual. The specifications
are subject to modification without prior notice.
TAKING CARE OF YOUR INSTRUMENT
Your keyboard is a fine instrument and deserves careful treatment. Follow carefully the next few points to keep
it at it’s best for many years.
- Never open the case and touch the internal circuits.
- Always switch the power 0ff after use.
- Clean with a cloth or a damp sponge. If the dirt is particularly persistent, use a neutral detergent to
remove it. Never use solvents or alcohol.
- Do not place your instrument near electric motors, neon or fluorescent lamps as these may generate
disturbances
- In most cases you just need to change the position of the instrument to avoid interference
- Keep your instrument away from dusty environments, high humidity, and high temperatures.
- Make sure that your local AC mains voltage matches the voltage indicated on the name plate in the back
of the instrument. Connect the power cord to the power supply.
- Do not use electrical appliances, neon lights or variable lighting system on the same AC Mains outlet.
- Before turning on the instrument, make sure that your amplifiers and speaker system are off.
- Computer controlled instruments can be interrupted by spikes, surges and dropouts on the power line. If
your instrument stops working because of a power line disturbance, switch it off for a few seconds and
then switch it back on.
- Never disconnect the power cable without turning off the power switch.

4
GENERAL FEATURES
- UPPER ORCHESTRA 1 22 Sounds + 22 USER SOUNDS selectable from 292 internal sounds, Chorus,
Sustain, Octave, Volume
- UPPER ORCHESTRA 2 18 Sounds + 18 USER SOUNDS selectable from 292 internal sounds,
Poly/Mono, Portamento, Chorus, Sustain, Octave, Volume
- UPPER FLUTES 9 Flute Pitches, 4 Organ Presets + 4 USER Organ Presets, Vibrato, Motion
Effect Slow/Fast, Slow Attack, Overdrive, Percussion’ 5 113’, 4’ -2 213’ -
Click 1/2/3, Sustain, Volume
- LOWER FLUTES 5 Flute Pitches, 4 Organ Presets + 4 USER Organ Presets, Vibrato, Sustain,
Volume
- SPECIAL Upper/Lower 14 Sounds + 14 USER SOUNDS selectable from 292 internal sounds, Chorus,
Sustain, Octave, Volume
- LOWER ORCHESTRA 22 Sounds +22 USER SOUNDS selectable from 292 internal sounds, Chorus,
Sustain, Octave, Volume
- BASS 8 Sounds +8 USER SOUNDS selectable from 292 internal sounds, Sustain,
Octave, Volume
- STYLE 90 Styles, 3 Variations, Auto Bass, Auto Chord, Intro/Ending, Fill In 1/2, Auto
Start, Auto Set Up, Acc.Volumes, Drum Volume
- AUTOMATIC SET-UP 90 Style Registrations
- OVERALL PRESETS 16 Programmable Presets
- DISK DRIVE (HD/DD) REAL TIME Standard Midi File, Record, Pause, Play.
- DIGITAL EFFECTS 12 internal reverb presets, 5 Enhancer effects
- MIDI 32 Midi Channels
- TUNING Pitch, Transpose
- CONNECTIONS 2 Left and Right (Stereo/Mono) outputs, 2 Left and Right (Stereo/Mono)
inputs, Headphone socket, 2 Pedal Volume socket, Double Pedal socket,
Sustain Pedal socket, Bass Pedalboard socket.
GETTING READY
- Connect the power cord to the power socket. Make sure that the voltage is suitable for the
instrument.
- Turn the power on by pushing the On/Off switch on the lower right cheek block. To turn the
power off push the On/Off button again.
- Move the Master Volume slider to adjust the overall volume. Moving the slider upwards it will
increase volume, or downwards to decrease volume.
- The Master Volume slider controls the volume of the speakers, of the headphones (located
below the lower keyboard on the left side) and of the Line Out jacks (located in the rear panel).
INTRODUCTION
Welcome to the world of electronic musical instruments. Your instrument has been designed and
manufactured using the latest technology and computerized systems, to offer you years of trouble free
pleasure.
GETTING STARTED
When your instrument is first switch on it will default to an organ sound. To play as an organ no
controls at all have to be selected. You simply are able to sit and play.
To enable ease of use from the beginning there are many automatic registrations and sounds built into
the instrument to enable either the beginner or professional player to obtain many sounds immediately.

5
OVERALL PRESETS.
There are 16 Overall Presets which can be selected using the Overall Preset button at the bottom of the
right hand side of the control panel just above the upper manual. The Overall Presets can be changed.
The factory settings are as follows:
A 1
Electronic Organ 1
B 1
Orchestral Strings
A 2
Electronic Organ 2
B 2
Classical Strings
A 3
Tibia Harmony
B 3
Solo Piano
A 4
Theatre Celeste
B 4
Latin Octave Piano
A 5
Full Theatre
B 5
Pub Piano
A 6
Jazz Organ
B 6
Scat Singers
A 7
Chapel Organ
B 7
Jazz Combo
A 8
Church Organ
B 8
Big Band Ballad
The Automatic Organ and Overall Presets are primarily set up to be played in the traditional manner
using bass pedals. However they can be used in conjunction with the Automatic Set Up in which case
bass pedals need not be played.
AUTOMATIC SET UP
This function sets up a registration for each style that is selected. There are 90 different styles built into
the instrument and they are selected using the 16 buttons located in the centre of the control panel to the
lower left hand side of the screen.
They are used in conjunction with the three Style Bank buttons that are situated to the lower left hand
side of the style buttons.
To select the 90 different styles using only 16 buttons the following system of operation is necessary.
If the first left hand button labeled WALTZ is selected and Style Bank A is selected the screen will
show that the STDWALTZ is selected.
If Style Bank A is changed to Style Bank B by depressing the button the rhythm will change to a Slow
Waltz and the screen will change to SL_WALTZ.
If Style Bank B is changed to Style Bank C by depressing the button the rhythm will change to a
Viennese Waltz and the screen will change to VIENNESE.
There are therefore 3 styles on each button.

6
Should 2 buttons be depressed at the same time, for example the SWING and STANDARD button then
the style written across the top of the two buttons will be selected and both of the LED’s will be
illuminated.
In this case in Style Bank A, a FOX TROT will be selected. In Style Bank B a SING SONG FOX
TROT . In Style Bank C a BARNDANCE.
The following chart shows the location of the styles that are available.
Rhythm
A
B
C
Upper Row
WALTZ
Waltz Standard ¾
Waltz Slow ¾
Waltz Viennese ¾
MAZURKA
Mazurka ¾
Mazurka 2 ¾
Mazurka ¾
WALTZ 2
Italian Waltz ¾
Oompah Waltz ¾
Musette ¾
POLKA
Polka
Party Polka
Polka 2
TANGO
Tango
Orchestral Tango
Passadoble
MARCH
March 2/4
March 6/8
Tarantella
SWING
Swing
Quickstep
Quickstep 2
FOX TROT
Fox Trot
Sing Song
Barn Dance
STANDARD
Standard
Hawaiian
Swing-rock
SHOW TIME
Broadway
Show Ballad
Nice & Easy
BIG BAND
Big Band
Big Band Ballad
Big Band 2
DIXIE
Dixie
Dixie 2
Honky Tonk
SHUFFLE
Shuffle
Shuffle 2
R & Blues
ROCK & ROLL
Rock & Roll
Boogie
Twist
BLUES
Blues
Gospel
Blues 2
Lower Row
BOSSA
Bossa
Bossa 2
Meneito
MAMBO
Mambo
Disco Mambo
Bolero
SAMBA
Samba
Samba 2
Disco Samba
SALSA
Salsa
Merengue
Gypsy
CHA CHA
Cha Cha
Guaracha
Cumbia
PARTY DANCE
Hullygully
Quadriglia
Talisman
RHUMBA
Rhumba
Beguine
Italian Rhumba
ROCK
Rock
Rock 2
Rock 3
COUNTRY 1
Country
Country Rock
Bluegrass
COUNTRY 2
Country Waltz ¾
Country 2beat
Country Ballad
8 BEAT
8 Beat
8 Beat 2
8 Beat 3
DANCE
House
Rap
Acid Jazz
16 BEAT
16 Beat
16 Beat 2
Funk
DISCO
Disco
Soul
Soul 2
SLOW ROCK
Slow Rock
Slow Rock 2
Slow Rock 3
For example to select the Hawaiian style using the chart, the STANDARD button has to be selected on
Style Bank B.

7
To set up a factory registration for each style on the instrument the Automatic Set Up button has to be
switched on.
This is on the control panel to the bottom left hand side of the Style Bank buttons.
The Automatic Set Up will select a complete registration for the entire instrument based on the style
that was selected. Auto Bass and Auto Chord are selected and also an Introduction plus sounds for the
Upper and Lower keyboards.
As soon as a chord is played on the lower keyboard an introduction will be played in the key based on
the chord played:
E.g. C chord key of C.
F chord key of F
Etc.
When the Automatic Set Up is selected the sounds that are being used are indicated by being
illuminated in the Upper Conductor section. Any sections that are not illuminated are also set up with
suitable sounds which can be used instead of, or as well as the sound originally selected simply by
switching on the relevant Conductor button.
The Automatic Set Up will remain On until switched Off. Therefore if a style is changed whilst playing
and the Automatic Set Up is on both the sound and tempo are likely to be changed. It is possible to
change the style while playing in the following way:
- Select the first style required.
- Switch On the Automatic Set Up
- Switch Off the Automatic Set Up
- Commence playing
- Change the style. The tempo and sounds will now remain the same.
It is also possible to use the Automatic Set Up in conjunction with the Overall Presets.
To do so follow the following procedure:
- Select the style required
- Switch On Automatic Set Up
- Switch Off Automatic Set Up
- Switch On the Lock button located to the right hand side of the Overall Presets.
- Commence playing. The registration selected by the Automatic Set Up still remains.
- Select an Overall Preset from any of the 16 available. The Upper keyboard registration will
change. However the accompaniments and Lower keyboard sounds will remain the same.
It is therefore possible in this way to combine the Automatic Set Up registrations with the 96 Automatic
Organ registrations plus any registrations that may be in the Overall Presets.
The automatic set up is normally registered for people who play with their own chords and with
Autobass.
To play with single finger chords change the MFC button at the top left side of the screen to the OFC
button.
To play with Bass pedals switch off the Autobass button.

8
BASIC FEATURES
CONDUCTOR
The Conductor enables different sections of sounds to be selected on the two keyboards. It is located at
the bottom of the control panel underneath the screen. The black buttons switch on the sounds for the
Upper keyboard. The gray buttons for the Lower keyboard.
If no Upper Conductor buttons are selected no LED’s above the black buttons will be illuminated and
there will be no sound on the upper keyboard.
There are 3 sections of sound solely allocated to the Upper keyboard:
- Upper Orchestra 1
- Upper Orchestra 2
- Upper Flutes
If Upper Orchestra 1 is selected on its own in the Upper Conductor section the sound that will be
selected will be the sound that is illuminated in the Upper Orchestra 1 section which is situated directly
above the Overall Presets section.
Like the Style section, there are more sounds than there are buttons.
To select a voice, STRINGS for example, press the button of the desired sound. The LED will confirm
your choice
To select the voice indicated between two LED’s, JAZZ ORGAN for example, press the two buttons
related to the LED’s.

9
The name of the selected sound will be also shown briefly on the display. There are 2 sounds on each
button. The second sound is selected by switching On the User button, which is set at the factory to
provide an alternative sound to that indicated on the button. The User sound can be altered. See later in
the manual.
Upper Orchestra 2 can be selected by switching On the Upper Orchestra 2 button in the Conductor
section. If Upper Orchestra 1 and Upper Orchestra 2 are both illuminated then the sounds in both
sections will sound simultaneously when played.
If Upper Orchestra 1 is switched Off in the Conductor then the sound of Upper Orchestra 2 will remain
on its own. The sound of Upper Orchestra 1 will not be heard even though the selected sound remains
illuminated in the section. This indicates the sound that is selected in Orchestra 1, which will activate
only when the Orchestra 1 Conductor button is switched On.
The sounds in Upper Orchestra 2 are selected in the same way as in Upper Orchestra 1. Unlike upper
Orchestra 1 which is permanently in a Poly mode (more than one note can be played simultaneously)
Orchestra 2 can also be used in a Mono mode (only one note can be played at the time).
Both sections have an Octave switch, which in the factory settings usually takes the sound on the Upper
keyboard down 1 octave. This can be altered. See relevant section later in the manual.
There is also a Sustain switch which when selected will make the sound carry on and gradually
decrease after the note is released, in the factory settings the amount of sustain is set to be suitable for
each instrument. The sustain time can be altered. See relevant section later in the manual.
Each section also has a Chorus button. This when selected provides a third dimension to the sound.
This can be changed. See relevant section later in the manual.
Upper Orchestra 2 also has a Portamento button. This only works when Orchestra 2 is set in Mono
mode. When selected if the notes are played in a legato fashion they will slide from one note to another.
If played in a staccato fashion there is no Portamento effect. This technique requires considerable
practice to perfect.
The Special section is different to all of the other sections in as much as it is not dedicated to a
particular keyboard. If it is selected in the Upper Conductor it becomes a third section for the Upper
keyboard. If selected in the Lower Conductor it becomes a second section for the Lower keyboard.
