Ormazabal cpg.0 lite Instruction manual

LIB
cpg.0 lite
GIS medium-voltage switchgear, gas
insulated, up to 24 kV, in accordance with
IEC Standard
General instructions
IG-310-EN, version 01, 31/03/2021

In view of the constant evolution in standards and design, the characteristics of the elements contained in this manual are subject
to change without prior notice. These characteristics, as well as the availability of components, are subject to confirmation by
Ormazabal.
CAUTION!
When medium-voltage equipment is operating, certain components are live, other parts may be in movement and some may
reach high temperatures. Therefore, the use of this equipment poses electrical, mechanical and thermal risks.
In order to ensure an acceptable level of protection for people and property, and in compliance with applicable environmental
recommendations, Ormazabal designs and manufactures its products according to the principle of integrated safety, based on
the following criteria:
• Elimination of hazards wherever possible.
• Where elimination of hazards is neither technically nor economically feasible, appropriate protection functions are
incorporated in the equipment.
• Communication about remaining risks to facilitate the design of operating procedures which prevent such risks,
training for the personnel in charge of the equipment, and the use of suitable personal protective equipment.
• Use of recyclable materials and establishment of procedures for the disposal of equipment and components so
that once the end of their service lives is reached, they are duly processed in accordance, as far as possible, with the
environmental restrictions established by the competent authorities.
Consequently, the equipment to which the present manual refers complies with the requirements of section 11.2 of Standard
IEC 62271-1. It must therefore only be operated by appropriately qualified and supervised personnel, in accordance with the
requirements of standard EN 50110-1 on the safety of electrical installations and standard EN 50110-2 on activities in or near
electrical installations. Personnel must be fully familiar with the instructions and warnings contained in this manual and in other
recommendations of a more general nature which are applicable to the situation according to current legislation[1].
The above must be carefully observed, as the correct and safe operation of this equipment depends not only on its design but also
on general circumstances which are in general beyond the control and responsibility of the manufacturer. More specifically:
• The equipment must be handled and transported appropriately from the factory to the place of installation.
• All intermediate storage should occur in conditions which do not alter or damage the characteristics of the equipment
or its essential components.
• Service conditions must be compatible with the equipment rating.
• The equipment must be operated strictly in accordance with the instructions given in the manual, and the applicable
operating and safety principles must be clearly understood.
• Maintenance should be performed properly, taking into account the actual service and environmental conditions in
the place of installation.
The manufacturer declines all liability for any significant indirect damages resulting from violation of the guarantee, under any
jurisdiction, including loss of income, stoppages and costs resulting from repair or replacement of parts.
Warranty
The manufacturer guarantees this product against any defect in materials and operation during the contractual period. In the
event that defects are detected, the manufacturer may opt either to repair or replace the equipment. Improper handling of this
equipment and its repair by the user shall constitute a violation of the guarantee.
Registered Trademarks and Copyrights
All registered trademarks cited in this document are the property of their respective owners. The intellectual property of this manual
belongs to Ormazabal.
[1] For example, in Spain the “Regulation on technical conditions and guarantees for safety in high-voltage electrical installations” – Royal Decree
337/2014 is obligatory.

IG-310-EN version 01; 31/03/2021 3
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Contents
Contents
1. General description ...................................................4
1.1. Models ......................................4
1.2. Standards applied............................4
1.3. Main components ...........................5
2. Technical characteristics..........................................11
2.1. Electrical ratings ............................11
2.1.1. Name plate .................................12
2.2. Mechanical ratings ..........................13
2.2.1. Dimensions.................................13
2.3. IP rating ....................................13
3. Normal service conditions(a) ....................................14
4. Handling and transport...........................................15
4.1. Transport conditions ........................15
4.2. Lifting means ...............................15
5. Storage......................................................................17
6. Installation ...............................................................18
6.1. Unpacking the equipment ..................18
6.2. List of assembly materials supplied ..........18
6.3. Minimum installation distances..............19
6.4. Cable connection trench ....................19
6.4.1. Recommended dimensions .................20
6.5. Fixing to floor...............................21
6.6. Connecting cubicles ........................22
6.7. Cable connection ...........................23
6.8. Equipment earthing ........................24
7. Operations sequence...............................................25
7.1. Disconnector function operation sequence
(cpg.0 lite-s) ................................25
7.1.1. Manual feeder disconnector operation ......26
7.1.2. Manual earthing switch operation ...........30
7.1.3. Dielectric test for the cables .................34
7.2. Circuit-breaker function operation sequence
(cpg.0 lite-v) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
7.2.1. Circuit-breaker operation....................40
7.2.2. Manual earthing switch operation ...........45
7.2.3. Dielectric test for the cables .................45
7.3. Busbar coupling function operation
sequence (cpg.0 lite-c) ......................52
7.3.1. Busbar coupling operation ..................53
7.3.2. Busbar decoupling operation................59
7.3.3. Right busbar earthing operation.............63
7.3.4. Right busbar earthing opening operation....69
7.3.5. Left busbar earthing operation . . . . . . . . . . . . . .73
7.3.6. Left busbar earthing opening operation .....79
8. Safety elements........................................................83
8.1. ekor.ivds voltage detectors .................83
8.2. Locking with padlock .......................83
8.2.1. Locking with key lock .......................83
8.3. Interlocks ...................................84
9. Maintenance.............................................................85
9.1. Voltage indicator test .......................85
9.2. Preventive maintenance of circuit-breakers ..86
10. Spares and accessories ............................................87
11. Environmental information ....................................88
11.1. Sulphur hexafluoride SF6....................88
11.2. Recyclability ................................88

IG-310-EN version 01; 31/03/2021
4
General description General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
1. General description
The cpg.0 lite switchgear is made up of a series of GIS
cubicles, gas-lled, for primary distribution in medium-
voltage networks up to 24 kV.
1.1. Models
Model Function
cpg.0 lite-v Circuit-breaker
cpg.0 lite-c Longitudinal busbar coupling
cpg.0 lite-s Disconnector
Table 1.1. cpg.0 lite cubicle models
1.2. Standards applied
Standard Description
IEC 62271-1 Common specications for high-voltage switchgear standards
IEC 62271-200 Alternating current metal-enclosed switchgear and controlgear for rated voltages above 1 kV and up to and
including 52 kV
IEC 62271-100 Alternating current circuit-breakers
IEC 62271-102 Alternating current disconnectors and earthing switches
IEC 61243-5 Voltage presence indicating relays
IEC 60529 IP ratings for enclosures
Table 1.2. Standards applied

IG-310-EN version 01; 31/03/2021 5
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
General description
1.3. Main components
1Busbar compartment
2Gas tank
3Gas pressure relief duct
4Cable compartment
5Control compartment
6Driving mechanisms compartment
Figure 1.1. Main elements cpg.0 lite cubicles

IG-310-EN version 01; 31/03/2021
6
General description General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Gas tank
This is a sealed compartment, made of stainless steel and
sealed for life, which houses the switching and breaking
switchgear, with the gas as the insulating medium.
Depending on the function the cubicle was designed for, it
may contain some of the following components inside:
• Three-position disconnector.
• Internal busbar and connections.
• Vacuum circuit-breaker.
Connection to the busbar is possible via top bushings.
Connection to the medium-voltage cables is made with the
bottom bushings.
The gas pressure is tested in each cubicle by means of a
temperature-compensated pressure switch with a volt-
free contact, allowing it to be used as aremote alarm or
blocking/trip for the position. Figure 1.2. Example of bushing position in gas tank (1)
Busbar compartment
The busbar compartment, designed to withstand an internal
arc inside, meeting the criteria of Annex A of Standard
IEC 62271-200, class IAC: AFL/AFLR, is located at the top
of the cubicle, separate from the gas tank. It is made from
sheet metal, oering the degree of protection necessary for
the connecting device.
The main busbar is insulated with solid material, which is
screened and earthed.
Toroidal-core current transformers and/or plug-in voltage
transformers can also be installed, thus avoiding the need
for metering cubicles.
Figure 1.3. Busbar compartment detail

IG-310-EN version 01; 31/03/2021 7
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
General description
Cable compartment
Located in the bottom part of the cubicle, this has a cover,
interlocked with the earthing of the power cables, which
allows front access to the medium-voltage cables. This
compartment is prepared to withstand an internal arc up
to 25 kA - 1 s, meeting the criteria of Annex AA of Standard
IEC 62271-200, class IAC: AFL/AFLR.
In the most complete case, the base can house the following
components:
• Internal arc protection kit in cable compartment.
• Two symmetrical screened connectors with reinforced
connection (screwable) per phase, or three compact
screened connectors with reinforced connection
(screwable) per phase.
• Cable clamps for the medium-voltage cables. Range of
cable diameters admitted: from 36 to 52 mm. For other
values, please ask Ormazabal.
• Earthing bars for cable connectors (optional).
• Toroidal-core current transformers.
• Voltage transformers with connection via medium-
voltage cable.
All the elements making up the enclosure are earthed
by means of a conductor consisting of a copper bar,
sized to withstand the rated short-time current. This is
located in the base, meaning it does not need to be
dismantled in order to insert or remove a cable and its
corresponding termination.
Figure 1.4. Detail of internal arc protection kit in cable compartment

IG-310-EN version 01; 31/03/2021
8
General description General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Exterior cable connections (bushing)
The cpg.0 lite cubicles have bushing on the front for
medium-voltage cable connection. These are made of
epoxy resin and can, thanks to their design, withstand the
current transformers. They are duly screened and designed
in line with Standard EN 50181, type "C".
They allow conductors to be connected via screwable
T-type connectors of any manufacturer.
The cable clamps in the cable compartment hold the
cables at their input to the cubicle and prevent the
connector and bushing combination from supporting
the weight of the cable. If cable input/output is via
a trench more than 2 m deep, the cables must be
fastened with additional cable clamps, depending on
the depth of the trench and the cable cross-section
(weight), in order to prevent the connector and
bushing combination from supporting the weight of
the cable.
Figure 1.5. Cable compartment

IG-310-EN version 01; 31/03/2021 9
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
General description
Gas pressure relief duct
The entire cubicle is prepared to withstand an internal arc
in the tank up to 25 kA - 1 s, meeting the criteria of Annex
AA of Standard IEC 62271-200, accessibility class IAC: AFL/
AFLR.
1Gas pressure relief membrane
2Gas vent from cable compartment
Figure 1.6. Pressure relief membrane and gas vent detail
A metal duct can take the gases produced by an internal arc
toward the top of the cubicle from the gas tank and cable
compartment.
Figure 1.7. Gas pressure relief duct (1)
Control compartment
Placed at the top of the cubicle and separate from the
medium-voltage area, this is ready for installation of the
metering equipment and protection relays. It contains
the terminal block with the control signals duly identied
in accordance with the wiring diagram provided with
the equipment. All the connections between the driving
mechanisms compartment and the control box are made
via connectors, which makes the assembly more exible,
and allows the control box to be assembled and connected
on site in a straightforward, direct way.
Figure 1.8. Control compartment detail

IG-310-EN version 01; 31/03/2021
10
General description General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Driving mechanism
In addition to a mimic diagram customised for each type of
function, this has the driving elements in its middle section:
disconnector/earthing switch and circuit-breaker driving
mechanisms, circuit-breaker opening/closing pushbuttons,
status indicators, groove for access of the spring charging
lever, etc.
Figure 1.9. Example of driving mechanism area

IG-310-EN version 01; 31/03/2021 11
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Technical characteristics
2. Technical characteristics
2.1. Electrical ratings
Functions
cpg.0 lite-v
cpg.0 lite-c
cpg.0 lite-s
Rated voltage [Ur]kV 24
Frequency [fr]Hz 50/60
Power frequency withstand voltage [Ud]
Between phases kV 50
Isolating distance kV 60
Lightning impulse withstand voltage [Up]
Between phases kV 125
Isolating distance kV 145
Table 2.1. Rated insulation levels for the cpg.0 lite family
cpg.0
lite-v
cpg.0
lite-c
cpg.0
lite-s
Rated current [Ir]
General busbar A 1250 1250 1250
Outgoing A630
1250 NA 1250
Short-circuit [Ik]
tk= 1 or 3 s kA 25 25 25
Table 2.2. Common rated currents for the cpg.0 lite family
Other characteristics: cpg.0 lite-v cpg.0 lite-c cpg.0 lite-s
Automatic reclosing sequence O - 0.3 s - CO - 15 s - CO
O - 0.3 s - CO - 3 min - CO NA
Motorised spring charging time s < 15 NA
Rated short-circuit breaking current kArms 25 NA
Rated short-circuit making current kApeak 65 NA
Opening time ms < 50* NA
Closing time ms < 50* NA
Rated no-load feeder current A 10 NA
Rated no-load cable current A 31.5 NA
Capacitor bank rated current A 400** NA NA
Internal arc rated current kA 25rms - 65peak
Internal arc rated time s 1
Electrical endurance
Circuit-breaker E2
Feeder disconnector: E0
Earth: E2***
Feeder disconnector: E0
Earth: E0
Mechanical endurance
Circuit-breaker M2
Feeder disconnector: M0 (manual)/M1 (motorised)
Earth: M0 (manual)/M1 (motorised)
M0 (manual)/M1 (motorised)
Internal arc classication in accordance
with IEC 62271-200 AFL[R] 25 kA 1 s
NA: Not applicable.
* Times based on minimum auxiliary operating voltages.
** Only on request.
*** In combination with the circuit-breaker
Table 2.3. Additional electrical ratings

IG-310-EN version 01; 31/03/2021
12
Technical characteristics General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
2.1.1. Name plate
Each unit has a name plate, with some of the following data,
showing the particular electrical ratings of each cubicle:
Figure 2.1. Example of name plate
Name plate
N° Cubicle serial number(*)
Type Ormazabal cubicle system.
Designation Cubicle model
Standards Standards applied to the equipment
UrEquipment rated voltage (kV)
UpLightning impulse withstand voltage (kV)
UdPower frequency withstand voltage (kV)
frEquipment rated frequency (Hz)
IrEquipment rated current (A)
Ik/IpShort-time withstand current/short-time withstand peak value
tkShort-time withstand current time
Pre Gas pressure inside the gas tank (MPa)
Pme Minimum operating gas pressure (MPa)
SF6Insulating uid mass (kg)
Year Year of manufacture
TC Thermal class
CO2e Equivalent CO2uid mass (t)
(*) This number should be reported to Ormazabal whenever technical support is required.
Table 2.4. List of information shown on the name plate

IG-310-EN version 01; 31/03/2021 13
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Technical characteristics
2.2. Mechanical ratings
2.2.1. Dimensions
Figure 2.2. Dimensions cpg.0 lite
Model Ioutgoing
a
[mm]
h
[mm]
hp
[mm]
f
[mm]
Weight*
[kg]
v630 500
2300
600
1160
440
600 475
1250 600 600 500
s 1250 600 600 450
c 1250 650 - 580
(*) The weight shown does not include the solid, screened main busbar, medium-voltage cables, side trim panels, metering transformers or equipment
inside the control box.
Table 2.5. Dimensions and weights of cpg.0 lite
2.3. IP rating
All power circuit elements are installed inside a stainless
steel gas tank, providing IP65 rating. The standard degree
of protection for the cubicle assembly, in all designations, is
IP3X. For other values, please ask Ormazabal.

IG-310-EN version 01; 31/03/2021
14
Normal service conditions(a) General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
3. Normal service conditions(a)
Installation Indoor
Maximum ambient temperature + 40 °C
Minimum ambient temperature - 5/- 15/- 25 °C
Maximum mean ambient temperature, measured over a 24-hour period + 35 °C
Maximum mean relative humidity, measured over a 24-hour period < 95%
Maximum mean vapour pressure, measured over a 24-hour period 22 mbar
Maximum mean vapour pressure, measured over a 1-month period 18 mbar
Maximum height above sea level 1000 m
Solar radiation Negligible
Ambient air pollution (dust, smoke, corrosive and/or ammable gases, vapours or salt) Insignicant
Vibrations caused by causes external to the switchgear or by seismic movements Insignicant
(a) For special service conditions (ambient temperature above +40°C, installation, storage or transport altitude over 1000m above sea level, signicant
pollution level, or others dierent to those described), check with Ormazabal.
Table 3.1. Normal service conditions
The specications refer to the section "Normal
service conditions for indoor cubicles" in Standard
IEC 62271-1 "Common specications for high-voltage
cubicles".

IG-310-EN version 01; 31/03/2021 15
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Handling and transport
4. Handling and transport
4.1. Transport conditions
During transport, the switchgear must be perfectly seated
and xed so that it cannot move about and possibly
damage the equipment. Always in upright position, directly
on the ground or on a timber pallet, depending on the
type of handling to be carried out. Check that the cubicle is
perfectly balanced at all times.
4.2. Lifting means
cpg.0 lite cubicles can be handled, one by one, by lifting
(with slings) or with a forklift truck (with a pallet):
Figure 4.1. Lifting a cpg.0 lite cubicle with chains Figure 4.2. Lifting a cpg.0 lite cubicle using a forklift truck (with pallet)

IG-310-EN version 01; 31/03/2021
16
Handling and transport General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Elevating castor wheels can be used to put the cubicles in
their nal position.
Supply optional (accessory kit nº: 619219). Please
check with Ormazabal.
Figure 4.3. Wheel anchors in the cubicle Figure 4.4. Positioned wheel detail

IG-310-EN version 01; 31/03/2021 17
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Storage
5. Storage
If it needs to be stored, the material must be placed on dry
ground or damp-proof insulating material, still in its original
packing, in order to prevent any damage during storage.
After prolonged storage, clean all the insulating parts
carefully before commissioning the equipment. The
enclosure should be cleaned with a clean, dry lint-free cloth.
Figure 5.1. Storage conditions detail
Storage must always be INDOORS, with the following
conditions recommended:
1. Ambient air temperature should not exceed 40 ºC
and its mean value, measured in a period of 24 hours,
should not exceed 35 ºC.
2. The ambient air temperature should not drop below
- 5°C. There are also cubicles with storage temperature
up to -15°C and up to -25ºC.
3. The switchgear must be protected from direct solar
radiation.
4. Maximum altitude is 1000 m.
5. The environmental air must not have any signicant
contamination from dust, smoke, corrosive and/or
inammable gases, vapours or salt.
6. The switchgear must be protected from the rain, and
the humidity conditions must be as follows:
a. The average relative humidity value, measured over
a period of 24 hours, must not exceed 95 %.
b. The average water vapour pressure value, measured
over a period of 24 hours, must not exceed 22 mbar.
c. The average relative humidity value, measured over
a period of one month, must not exceed 90 %.
d. The average water vapour pressure value, measured
over a period of one month, must not exceed
18 mbar.
7. During transport, vibrations caused by external factors
or seismic movements must be insignicant.
Any other conditions must be notied beforehand, since
the equipment must be factory-adjusted to atmospheric
pressure at the destination. If this is not the case, the
manometer needle may indicate an incorrect value, even if
the equipment's internal pressure is correct.

IG-310-EN version 01; 31/03/2021
18
Installation General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
6. Installation
6.1. Unpacking the equipment
The cpg.0 lite switchgear is supplied protected with a
plastic cover.
On receiving the equipment, check that the goods
supplied correspond to the order and associated docu-
mentation. If this is not the case, contact Ormazabal
immediately.
The disassembly process for the equipment is as follows:
1. Using a blade, cutter or similar tool, cut the cellophane
the cubicle is wrapped in.
2. Remove the cellophane.
3. Detach the white polystyrene corner pieces.
4. Unscrew the xings between the base and the pallet.
5. Dispose of any waste in an environmentally friendly
manner.
It is advisable to make a visual inspection of the
equipment to check whether it has suered any damage
in transit. If damaged, contact Ormazabal immediately.
6.2. List of assembly materials supplied
The cpg.0 lite switchgear is supplied on pallets along with
all the material required for installation and operation.
Depending on the cubicles which form part of the supply,
the assembly materials delivered will be some of the
following:
1. Spring charging and actuating levers.
2. Interconnection busbars and busbar compartment
enclosure elements.
3. Earthing bars.
4. Side trim panels.
5. Nuts and bolts.
6. Alcohol and paper roll.
7. Miscellaneous material.
Ensure the pallet contains the elements indicated in
the materials list provided with the supply. If it does
not, contact Ormazabal.

IG-310-EN version 01; 31/03/2021 19
General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
Installation
6.3. Minimum installation distances
The minimum distances to the walls and ceiling, in
accordance with Standard IEC-62271-200 Annex AA, are as
follows:
Figure 6.1. Minimum installation distances detail
Minimum distances [mm]
Cubicle
Side wall (a) 100
Roof (b) 350*
Front clearance (c) Operation:
1000
Cubicle
removal:
1500
Rear wall (d) 100**
* Recommended distance for busbar assembly work: 1500 mm.
** If the cubicle is class IAC AFLR: 800 mm.
Table 6.1. Minimum installation distances
For other building work layouts, please check with
Ormazabal
6.4. Cable connection trench
The surface where the cubicles will be installed must be
level with a tolerance of ± 1 millimetre per metre. Check
the general layout of the cubicles in order to ensure the
medium- and low-voltage cable access is correct.
Figure 6.2. Cable trench with tracks detail
Figure 6.3. Cable trench detail

IG-310-EN version 01; 31/03/2021
20
Installation General instructions
cpg.0 lite: GIS medium-voltage switchgear,
gas insulated, up to 24 kV,
in accordance with IEC Standard
6.4.1. Recommended dimensions
Minimum recommended dimensions based on the trench
dimensions used in the tests in accordance with Standard
IEC 62271-200. The dimensions of the trench may vary in
accordance with the minimum radius of curvature of the
cables used.
Figure 6.4. Trench dimensions
Minimum distances [mm]
Trench
Depth (e) 500*
Depth (f) 610*
(*) The dimensions of the trench depend on the characteristics of the
cables used.
Table 6.2. Minimum recommended dimensions for the cable connection
trench
