Oshkosh Corporation JLG 2632R Use and care manual

Operation and Safety Manual
Original Instructions - Keep this manual with the machine at all times.
®
AS/NZS
ANSI GB
Models
2632R
3246R
3121787
October 4, 2019 - Rev D

WARNING
Operating, servicing and maintaining this vehicle or equipment
can expose you to chemicals including engine exhaust, carbon
monoxide, phthalates, and lead, which are known to the State of
California to cause cancer and birth defects or other
reproductive harm. To minimize exposure, avoid breathing
exhaust, do not idle the engine except as necessary, service your
vehicle or equipment in a well-ventilated area and wear gloves
or wash your hands frequently when servicing. For more
information go to www.P65Warnings.ca.gov.

FOREWORD
3121787 a
FOREWORD
The Mobile Elevating Work Platform (MEWP) models covered in this manual are designed and tested to meet or exceed various
compliance standards. Please refer to the manufacturer’s nameplate affixed to the subject MEWP for specific standard compliance
information.
This manual is a very important tool! Keep it with the machine at all times.
The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating proce-
dures essential for the safe and proper machine operation for its intended purpose.
Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior noti-
fication. Contact JLG Industries, Inc. for updated information.
Refer to www.JLG.com for Warranty, Product Registration, and other machine-related documentation.

SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
b3121787
SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
INDICATES AN IMMINENTLY HAZARDOUS SITUATION. IF NOT AVOIDED, WILL
RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE A RED BACK-
GROUND.
INDICATES A POTENTIALITY HAZARDOUS SITUATION. IF NOT AVOIDED,
COULD RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE AN
ORANGE BACKGROUND.
INDICATES A POTENTIALITY HAZARDOUS SITUATION. IF NOT AVOIDED, MAY
RESULT IN MINOR OR MODERATE INJURY. IT MAY ALSO ALERT AGAINST
UNSAFE PRACTICES. THIS DECAL WILL HAVE A YELLOW BACKGROUND.
NOTICE
INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY
OR INDIRECTLY TO THE SAFETY OF PERSONNEL OR PROTECTION OF PROP-
ERTY.
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO THE POTENTIAL PERSONAL INJURY HAZ-
ARDS. OBEY ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO AVOID POSSIBLE INJURY OR DEATH.

SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS
3121787 c
THIS PRODUCT MUST COMPLY WITH ALL SAFETY RELATED BULLETINS. CON-
TACT JLG INDUSTRIES, INC. OR THE LOCAL AUTHORIZED JLG REPRESENTA-
TIVE FOR INFORMATION REGARDING SAFETY RELATED BULLETINS WHICH
MAY HAVE BEEN ISSUED FOR THIS PRODUCT.
NOTICE
JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER OF
RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT
THE CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE.
NOTICE
JLG INDUSTRIES, INC. MUST BE NOTIFIED IMMEDIATELY IN ALL INSTANCES
WHERE JLG PRODUCTS HAVE BEEN INVOLVED IN AN ACCIDENT INVOLVING
BODILY INJURY OR DEATH OF PERSONNEL OR WHEN SUBSTANTIAL DAMAGE
HAS OCCURRED TO PERSONAL PROPERTY OR THE JLG PRODUCT.
Contact:
Product Safety and Reliability Department
JLG Industries, Inc.
13224 Fountainhead Plaza
Hagerstown, MD 21742
USA
or Your Local JLG Office
(See addresses on manual rear cover)
In USA:
Toll Free: 877-JLG-SAFE (877-554-7233)
Outside USA:
Phone: [phone]
E-mail: [e-mail]
For:
•Accident Reporting
•Product Safety Publica-
tions
•Current Owner Updates
•Questions Regarding
Product Safety
•Standards and Regulations
Compliance Information
•Questions Regarding Special
Product Applications
•Questions Regarding Prod-
uct Modifications

REVISION LOG
d3121787
REVISION LOG
Original Issue - A . . . . . . . . . . . . . . . . . . . . . . . . . . . . January 25, 2019
Revised - B. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . March 26, 2019
Revised - C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . May 2, 2019
Revised - D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . October 4, 2019

TABLE OF CONTENTS
3121787 i
SECTION - 1 - SAFETY PRECAUTIONS
1.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
1.2 PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Operator Training and Knowledge. . . . . . . . . . . . . . . . . . . . . .1-2
Workplace Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Machine Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
1.3 OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Trip and Fall Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Electrocution Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Tipping Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
Crushing and Collision Hazards. . . . . . . . . . . . . . . . . . . . . . . . .1-9
1.4 TOWING, LIFTING, AND HAULING. . . . . . . . . . . . . . . . . . . . . . . 1-11
1.5 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Maintenance Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Battery Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
SECTION - 2 - USER RESPONSIBILITIES, MACHINE PREPARATION,
AND INSPECTION
2.1 PERSONNEL TRAINING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Operator Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Training Supervision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Machine Familiarization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.2 PREPARATION, INSPECTION, AND MAINTENANCE . . . . . . . . .2-2
Inspection and Maintenance Table . . . . . . . . . . . . . . . . . . . . .2-3
2.3 PRE-START INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
2.4 WALK-AROUND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Inspection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
2.5 FUNCTION CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
SECTION - 3 - MACHINE CONTROLS, INDICATORS, AND
OPERATION
3.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
3.2 DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
3.3 OPERATING CHARACTERISTICS AND LIMITATIONS . . . . . . . .3-2
Placards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
3.4 PLATFORM LOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
3.5 BATTERY CHARGING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
3.6 LANYARD ATTACH POINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
3.7 MACHINE CONTROL LOCATIONS . . . . . . . . . . . . . . . . . . . . . . . . .3-4
3.8 GROUND CONTROL CONSOLE. . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
Ground/Platform/OFF Key Selector Switch . . . . . . . . . . . . . .3-6
Hourmeter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Platform Lift/Lower Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Inverter ON/OFF Switch (If Equipped). . . . . . . . . . . . . . . . . . .3-6
Ground Emergency Stop Switch . . . . . . . . . . . . . . . . . . . . . . . .3-6
Overload Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
MDI Indicator (If Equipped). . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

TABLE OF CONTENTS
ii 3121787
3.9 POTHOLE PROTECTION SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . .3-8
3.10 PLATFORM MANUAL DESCENT. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.11 PLATFORM CONTROL STATION. . . . . . . . . . . . . . . . . . . . . . . . . .3-10
Emergency Stop Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
Lift/Drive Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
Black/White Directional Arrow . . . . . . . . . . . . . . . . . . . . . . . .3-11
Drive/Lift/Steer Joystick Control . . . . . . . . . . . . . . . . . . . . . . .3-11
Steering and Traveling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Traveling Forward and Reverse. . . . . . . . . . . . . . . . . . . . . . . .3-12
Raising And Lowering Platform . . . . . . . . . . . . . . . . . . . . . . .3-13
Arm Guards (If Equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Overload Indicator (LSS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Tilt Indicator Warning Light and Alarm . . . . . . . . . . . . . . . .3-13
Variable Tilt - Platform Restricted Height Indicator . . . . .3-14
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Battery Charge Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
System Fault Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Indoor/Outdoor Operation Indicator . . . . . . . . . . . . . . . . . .3-15
Indoor/Outdoor Operation Mode Switch . . . . . . . . . . . . . .3-15
Low/High Drive Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
3.12 GRADE AND SIDESLOPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16
3.13 PLATFORM EXTENSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17
3.14 PLATFORM RAILS FOLD-DOWN PROCEDURE
(IF EQUIPPED) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18
Platform with Rail-in-Rail Extension Deck . . . . . . . . . . . . . .3-18
Platform with Dual Rails Extension Deck . . . . . . . . . . . . . . .3-20
3.15 PARKING AND STOWING MACHINE. . . . . . . . . . . . . . . . . . . . . .3-22
3.16 MACHINE LIFTING AND TIE DOWN . . . . . . . . . . . . . . . . . . . . . .3-23
3.17 TOWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-25
Hydraulic Brake Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-25
Push Button Brake Release (AUS Market Only) . . . . . . . . .3-26
SECTION - 4 - EMERGENCY PROCEDURES
4.1 GENERAL INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 INCIDENT NOTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.3 EMERGENCY OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Operator Unable to Control Machine . . . . . . . . . . . . . . . . . . . 4-2
Righting of Tipped Machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Platform Caught Overhead. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.4 PLATFORM MANUAL DESCENT. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
SECTION - 5 - ACCESSORIES
5.1 AVAILABLE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 OPTIONS/ACCESSORIES RELATIONSHIP TABLE . . . . . . . . . . . . 5-2
5.3 DC/AC POWER INVERTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Preparation and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

TABLE OF CONTENTS
3121787 iii
5.4 PIPE RACKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Preparation and Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
5.5 ANTI-VANDALISM PACKAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
5.6 RAIL-MOUNTED PLATFORM EXTENSION HANDLES . . . . . . . .5-7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
5.7 FOOTSWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
5.8 MAGNETIC GATE LATCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
5.9 JLG™ MOBILE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9
Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Document Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
SECTION - 6 - SPECIFICATIONS AND OPERATOR MAINTENANCE
6.1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Other Publications Available Specific to this Machine . . .6-1
Serial Number Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
6.2 SUPPLEMENTAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
6.3 MACHINE SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Operating Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Machine Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Maximum Allowable Operating Slope . . . . . . . . . . . . . . . . . .6-3
Platform Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
6.4 CRITICAL STABILITY WEIGHTS . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
6.5 BATTERY CHARGER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-5
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-5
Delta-Q . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
Eagle Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
Green Power (China (GB) Only) . . . . . . . . . . . . . . . . . . . . . . . . .6-7
6.6 LUBRICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Hydraulic Oil Operating Temperature Chart. . . . . . . . . . . . .6-8
6.7 OPERATOR MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Engaging the Safety Prop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Hydraulic Oil Check Procedure . . . . . . . . . . . . . . . . . . . . . . . 6-10
Battery Maintenance and Safety Practices. . . . . . . . . . . . . 6-11
Battery Quick-Disconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
6.8 TIRE WEAR AND DAMAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Wheel and Tire Replacement . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Wheel Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
6.9 DECAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
6.10 DIAGNOSTIC TROUBLE CODES (DTC) . . . . . . . . . . . . . . . . . . . 6-18
SECTION - 7 - INSPECTION AND REPAIR LOG

TABLE OF CONTENTS
iv 3121787

SECTION 1 - SAFETY PRECAUTIONS
3121787 1-1
SECTION 1. SAFETY PRECAUTIONS
1.1 GENERAL
This section outlines the necessary precautions for proper and
safe machine usage and maintenance. In order to promote
proper machine usage, it is mandatory that a daily routine is
established based on the content of this manual. A maintenance
program, using the information provided in this manual and the
Service and Maintenance Manual, must also be established by a
qualified person and must be followed to ensure that the
machine is safe to operate.
The owner/user/operator/lessor/lessee of the machine must not
accept operating responsibility until this manual has been read,
training is accomplished, and operation of the machine has been
completed under the supervision of an experienced and quali-
fied operator.
These sections contain the responsibilities of the owner, user,
operator, lessor, and lessee concerning safety, training, inspec-
tion, maintenance, application, and operation.If there are any
questions with regard to safety, training, inspection, mainte-
nance, application, and operation, please contact JLG Industries,
Inc. (“JLG”).
FAILURE TO COMPLY WITH THE SAFETY PRECAUTIONS LISTED IN THIS MANUAL
COULD RESULT IN MACHINE DAMAGE, PROPERTY DAMAGE, PERSONAL INJURY OR
DEATH.

SECTION 1 - SAFETY PRECAUTIONS
1-2 3121787
1.2 PRE-OPERATION
Operator Training and Knowledge
•Read, understand, and study the Operation and Safety Manual in
its entirety before operating the machine. For clarification, ques-
tions, or additional information regarding any portions of this
manual, contact JLG Industries, Inc.
•An operator must not accept operating responsibilities until ade-
quate training has been given by competent and authorized per-
sons.
•Allow only those authorized and qualified personnel to operate
the machine who have demonstrated that they understand the
safe and proper operation and maintenance of the unit.
•Read, understand, and obey all DANGERS, WARNINGS, CAUTIONS,
and operating instructions on the machine and in this manual.
•Ensure that the machine is to be used in a manner which is within
the scope of its intended application as determined by JLG.
•All operating personnel must be familiar with the emergency con-
trols and emergency operation of the machine as specified in this
manual.
•Read, understand, and obey all applicable employer, local, and
governmental regulations as they pertain to your utilization and
application of the machine.
Workplace Inspection
•Precautions to avoid all hazards in the work area must be taken by
the user before and during operation of the machine.
•Do not operate or raise the platform from a position on trucks,
trailers, railway cars, floating vessels, scaffolds or other equipment
unless the application is approved in writing by JLG.
•Before operation, check work area for overhead hazards such as
electric lines, bridge cranes, and other potential overhead obstruc-
tions.
•Check operating surfaces for holes, bumps, drop-offs, obstruc-
tions, debris, concealed holes, and other potential hazards.
•Check the work area for hazardous locations. Do not operate the
machine in hazardous environments unless approved for that pur-
pose by JLG.
•Ensure that the ground conditions are adequate to support the
maximum tire load indicated on the tire load decals located on the
chassis adjacent to each wheel.
•This machine can be operated in nominal ambient temperatures
of 0oF to 104oF (-20oC to 40oC). Consult JLG to optimize opera-
tion outside of this temperature range.

SECTION 1 - SAFETY PRECAUTIONS
3121787 1-3
Machine Inspection
•Do not operate this machine until the inspections and functional
checks have been performed as specified in Section 2 of this man-
ual.
•Do not operate this machine until it has been serviced and main-
tained according to the maintenance and inspection require-
ments as specified in the machine’s Service and Maintenance
Manual.
•Ensure all safety devices are operating properly. Modification of
these devices is a safety violation.
MODIFICATION OR ALTERATION OF A MEWP SHALL BE MADE ONLY WITH PRIOR WRIT-
TEN PERMISSION FROM THE MANUFACTURER.
•Do not operate any machine on which the safety or instruction
placards or decals are missing or illegible.
•Check the machine for modifications to original components.
Ensure that any modifications have been approved by JLG.
•Avoid accumulation of debris on platform floor. Keep mud, oil,
grease, and other slippery substances from footwear and platform
floor.
1.3 OPERATION
General
•Machine operation requires your full attention. Bring the machine
to a full stop before using any device, i.e. cell phones, two-way
radios, etc. that will distract your attention from safely operating
the machine.
•Do not use the machine for any purpose other than positioning
personnel, their tools, and equipment.
•Before operation, the user must be familiar with the machine
capabilities and operating characteristics of all functions.
•Never operate a malfunctioning machine. If a malfunction occurs,
shut down the machine. Remove the unit from service and notify
the proper authorities.
•Do not remove, modify, or disable any safety devices.
•Never slam a control switch or lever through neutral to an oppo-
site direction. Always return switch to neutral and stop before
moving the switch to the next function. Operate controls with
slow and even pressure.
•Do not allow personnel to tamper with or operate the machine
from the ground with personnel in the platform, except in an
emergency.
•Do not carry materials directly on platform railing unless approved
by JLG.
•When two or more persons are in the platform, the operator shall
be responsible for all machine operations.
•Always ensure that power tools are properly stowed and never left
hanging by their cord from the platform work area.

SECTION 1 - SAFETY PRECAUTIONS
1-4 3121787
•Do not assist a stuck or disabled machine by pushing or pulling
except by pulling at the chassis tie-down lugs.
•Fully lower platform and shut off all power before leaving
machine.
•Remove all rings, watches, and jewelry when operating machine.
Do not wear loose fitting clothing or long hair unrestrained which
may become caught or entangled in equipment.
•Persons under the influence of drugs or alcohol or who are subject
to seizures, dizziness or loss of physical control must not operate
this machine.
•Hydraulic cylinders are subject to thermal expansion and contrac-
tion. This may result in changes to the platform position while the
machine is stationary. Factors affecting thermal movement can
include the length of time the machine will remain stationary,
hydraulic oil temperature, ambient air temperature and platform
position.
Trip and Fall Hazards
•Prior to operation, ensure all gates and rails are fastened and
secured in their proper position.
•JLG Industries, Inc. recommends that all persons in the platform
wear a full body harness with a lanyard attached to an authorized
lanyard anchorage point while operating this machine. For further
information regarding fall protection requirements on JLG prod-
ucts, contact JLG Industries, Inc.
•Identify the designated lanyard anchorage point(s) at the platform
and securely attach the lanyard. Attach only one (1) lanyard per
lanyard anchorage point.
•Enter and exit only through gate area. Use extreme caution when
entering or leaving platform. Ensure that the platform assembly is
fully lowered. Face the machine when entering or leaving the plat-
form. Always maintain “three point contact” with the machine,
using two hands and one foot or two feet and one hand at all
times during entry and exit.

SECTION 1 - SAFETY PRECAUTIONS
3121787 1-5
.
•Keep both feet firmly positioned on the platform floor at all times.
Never position ladders, boxes, steps, planks, or similar items on
unit to provide additional reach for any purpose.
•Never use the scissor arm assembly to gain access to or leave the
platform.
•Keep oil, mud, and slippery substances cleaned from footwear and
the platform floor.
Electrocution Hazards
•This machine is not insulated and does not provide protection
from contact or proximity to electrical current.
•Maintain distance from electrical lines, apparatus, or any ener-
gized (exposed or insulated) parts according to the Minimum
Approach Distance (MAD) as shown in Table 1-1.
•Allow for machine movement and electrical line swaying.
•Maintain a clearance of at least 10 ft (3 m) between any part of the
machine and its occupants, their tools, and their equipment from
any electrical line or apparatus carrying up to 50,000 volts. One
foot additional clearance is required for every additional 30,000
volts or less.

SECTION 1 - SAFETY PRECAUTIONS
1-6 3121787
•The minimum approach distance may be reduced if insulating
barriers are installed to prevent contact, and the barriers are rated
for the voltage of the line being guarded. These barriers shall not
be part of (or attached to) the machine. The minimum approach
distance shall be reduced to a distance within the designed work-
ing dimensions of the insulating barrier. This determination shall
be made by a qualified person in accordance with the employer,
local, or governmental requirements for work practices near ener-
gized equipment.
DO NOT MANEUVER MACHINE OR PERSONNEL INSIDE PROHIBITED ZONE (MAD). ASSUME
ALL ELECTRICAL PARTS AND WIRING ARE ENERGIZED UNLESS KNOWN OTHERWISE.
Table 1-1. Minimum Approach Distances (M.A.D.)
VOLTAGE RANGE
(Phase to Phase)
MINIMUM APPROACH DISTANCE
in Feet (Meters)
0to50KV 10(3)
Over50KVto200KV 15(5)
Over200KVto350KV 20(6)
Over350KVto500KV 25(8)
Over500KVto750KV 35(11)
Over750KVto1000KV 45(14)
NOTE: This requirement shall apply except where employer, local or govern-
mental regulations are more stringent.

SECTION 1 - SAFETY PRECAUTIONS
3121787 1-7
Tipping Hazards
•Ensure that the ground conditions are adequate to support the
maximum tire load indicated on the tire load decals located on the
chassis adjacent to each wheel. Do not travel on unsupported sur-
faces.
•The user must be familiar with the operating surface before driv-
ing. Do not exceed the allowable sideslope and grade while driv-
ing.
•Do not elevate platform or drive with platform elevated while on
or near a sloping, uneven, or soft surface. Ensure machine is posi-
tioned on a smooth, firm surface within the limits of the maximum
operating slope before elevating platform or driving with the plat-
form in the elevated position.
•Before driving on floors, bridges, trucks, and other surfaces, check
allowable capacity of the surfaces.
•Never exceed the maximum platform capacity as specified on the
platform. Keep all loads within the confines of the platform, unless
authorized by JLG.
•Keep the chassis of the machine a minimum of 2 ft (0.6 m) from
holes, bumps, drop-offs, obstructions, debris, concealed holes,
and other potential hazards at the ground level.
•Do not operate the machine when wind conditions exceed specifi-
cations shown in Section 6.3 or as shown on the capacity placard
on the platform billboard. Factors affecting wind speed are; plat-
form elevation, surrounding structures, local weather events, and
approaching storms.
•Wind speed can be significantly greater at height than at ground
level.
•Wind speed can change rapidly. Always consider approaching
weather events, the time required to lower the platform, and
methods to monitor current and potential wind conditions.
•Do not increase surface area of the platform or the load. Increased
areas exposed to wind will decrease stability.
•Do not increase the platform size with unauthorized modifications
or attachments.
DO NOT OPERATE THE MACHINE WHEN WIND CONDITIONS EXCEED SPECIFICATIONS
SHOWN IN SECTION 6.3 OR AS SHOWN ON THE CAPACITY PLACARD ON THE PLAT-
FORM BILLBOARD.

SECTION 1 - SAFETY PRECAUTIONS
1-8 3121787
Table 1-2. Beaufort Scale (For Reference Only)
BEAUFORT
NUMBER
WIND SPEED DESCRIPTION LAND CONDITIONS
mph m/s
0 0 0-0.2 Calm Calm.Smokerisesvertically.
1 1-3 0.3-1.5 Lightair Windmotionvisibleinsmoke.
2 4-7 1.6-3.3 Lightbreeze Windfeltonexposedskin.Leavesrustle.
3 8-12 3.4-5.4 Gentlebreeze Leavesandsmallertwigsinconstantmotion.
4 13-18 5.5-7.9 Moderatebreeze Dustandloosepaperraised.Smallbranchesbegintomove.
5 19-24 8.0-10.7 Freshbreeze Smallertreessway.
6 25-31 10.8-13.8 Strongbreeze Largebranchesinmotion.Flagswavingnearhorizontal.Umbrellause
becomesdifficult.
7 32-38 13.9-17.1 NearGale/ModerateGale Wholetreesinmotion.Effortneededtowalkagainstthewind.
8 39-46 17.2-20.7 FreshGale Twigsbrokenfromtrees.Carsveeronroad.
9 47-54 20.8-24.4 StrongGale Lightstructuredamage.

SECTION 1 - SAFETY PRECAUTIONS
3121787 1-9
•Never attempt to use the machine as a crane. Do not tie-off
machine to any adjacent structure. Never attach wire, cable, or any
similar items to platform.
•Do not cover the platform sides or carry large surface-area items in
the platform when operating outdoors. The addition of such items
increases the exposed wind area of the machine.
•Do not increase the platform size with unauthorized deck exten-
sions or attachments.
•If the scissor arm assembly or platform is caught so that one or
more wheels are off the ground, all persons must be removed
before attempting to free the machine. Use cranes, forklift trucks,
or other appropriate equipment to stabilize machine.
Crushing and Collision Hazards
•Approved head gear must be worn by all operating and ground
personnel.
•Keep hands and limbs out of the scissor arm assembly during
operation and when elevated without safety prop engaged.
•Watch for obstructions around machine and overhead when driv-
ing. Check clearances above, on sides, and bottom of platform
when lifting or lowering platform.

SECTION 1 - SAFETY PRECAUTIONS
1-10 3121787
•During operation, keep all body parts inside platform railing.
•Always post a lookout when driving in areas where vision is
obstructed.
•Keep non-operating personnel at least 6 ft. (1.8m) away from
machine during all operations.
•Under all travel conditions, the operator must limit travel speed
according to conditions of ground surface, congestion, visibility,
slope, location of personnel, and other factors.
•Be aware of stopping distances in all drive speeds. When driving in
high speed, switch to low speed before stopping. Travel grades in
low speed only.
•Do not use high speed drive in restricted or close quarters or when
driving in reverse.
•Exercise extreme caution at all times to prevent obstacles from
striking or interfering with operating controls and persons in the
platform.
•Ensure that operators of other overhead and floor level machines
are aware of the MEWP’s presence. Disconnect power to overhead
cranes. Barricade floor area if necessary.
•Do not operate over ground personnel. Warn personnel not to
work, stand, or walk under a raised platform. Position barricades
on floor as necessary.
