Osmond ERGOFIT User manual

ERGOFIT - INSTRUCTIONS
1.
SEAT HEIGHT
2. BACK ANGLE
3. SEAT TILT ADJUSTMENT
Lift the lever on the right-hand side
and take your weight off the seat to
raise the height. Remain seated to
lower the height. Release the lever
to lock the seat height.
To adjust the angle of the backrest,
lift the rear lever on the right-hand
side and lean the backrest to the
desired position. Return the lever to
the downward position to lock the
backrest in place.
Lift the middle lever on the right-
hand
side to release the seat tilt lock.
Tilt the seat while seated. Push the
lever back down to lock the seat
tilt.
4. SEAT ROCK TENSION
5. BACK HEIGHT
6. LUMBAR SUPPORT
Twist the knob on the underside of
the chair while in seat tilt
adjustment mode to adjust the
tension of the movement.
To adjust the height of the backrest,
grasp the bottom of the backrest
and raise to the desired height. To
allow the backrest to be lowered
again, raise the backrest all the way
to the top and lower it to its lowest
position.
As you are sitting on the chair
squeeze bulb, located underneath
the left-hand side of the seat,
repeatedly to inflate the lumbar
support. Press the button on the
bulb to deflate the lumbar support.

7. SEAT DEPTH
8. ARMREST HEIGHT
(TYPE A & B)
9. ARMREST FOLD (TYPE A)
Lift the lever on the left-hand side
and slide the seat forward or
backward. Release the lever to lock
the seat pan.
To adjust the height of the armrest
press the button on the side of the
armrest and lift or lower to the
desired position. The armrest will
lock in to a total of six different
heights.
To fold away the armrest, press the
button at the bottom of the armrest
and fold away to the rear until it
locks into position. To return the
armrest to its original position,
press the same button and rotate
the arm until the button locks back
into its upright position.
10. ARMREST RETRACT (TYPE B)
To adjust the retractable armrest,
press the button on the inside of the
armrest and pull either inwards or
outwards or, forwards or back until
you achieve the desired position.
11. ARMREST WIDTH (TYPE B)
12. HEADREST ADJUSTMENT
For additional width support, loosen
the three bolts on the underside of the
chair with an Allen key and adjust the
arms to the desired width.
Pull the headrest post up to the
raise the height or push it down to
lower the height. Rotate the cushion
up or down for varying support
