OSP Designs RCS28736 User manual

1
2
WARNING
1. Do not use this product unless all screws and bolts are
securely tightened.
2. Check that all screws and bolts are tight every three months
or as needed.
3. Dispose of packing material properly. Do not use plastic cover as
head covering. It may cause suffocation.
4. Do not use this product as a stepladder.
5. Use this product for its intended purpose only.
6. Intended for residential use only.
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and pull lever (1) up.
To lower seat height sit on chair and pull lever (1) up.
NOTE: It is normal for chair to slightly lower under body weight.
• LOCKING TILT ADJUSTMENT
For individual comfort, this chair has been equipped with an
adjustment that will allow the user to change the tension of the
tilting feature. Turn knob (2) clockwise to increase tension and
counter-clockwise to decrease or ease the tension. To lock,
return chair to the upright position and push lever (1) in. To
unlock, pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment knob completely.
RCS28736 / RCS28737
RACE CHAIR
ASSEMBLY INSTRUCTIONS
OSP DESIGNS SEATING LIMITED WARRANTY
OSP Designs chairs are warranted from the date of purchase against failure due to material and workmanship as follows:
• 5 Years on all non-moving metal parts.
• 2 Years on component parts including Control mechanisms, pneumatic cylinders, wood, plastic parts, base and casters.
• 1 Year on upholstery fabric and foam against wear and deterioration.
To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and obtain return authorization.
At it’s option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer’s component. The customer must prepay freight on any components returned to the factory. Return freight on components
still in warranty will be paid by Office Star Products.
*All warranties are limited to the original purchaser for normal Residential usage by persons weighing 200 lbs. or less. This warranty will not cover labor, freight
or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of Office Star
Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential damages is excluded. The
user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts@officestar.net, by Fax [phone], or toll free
parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time.
November, 2017

PARTS LIST
(C) Pneumatic Cylinder (1PC) (D) Bellows (1PC)
(E) Seat Plate (1PC) (FL & FR) Arm (2PCS)
(G) Back Cushion (1PC) (H) Seat Cushion (1PC)
(A) Base (1PC) (B) Caster (5PCS)
HARDWARE LIST
DRAWINGNO DESCRIPTION SIZE QUANTITY
1
2
3
4
5
6
Short Bolt M6 x 20
M6 x 25
2 PCS
10 PCS
4 PCS
6 PCS
2 PCS
1 PC
Long Bolt
Flat Washer
Plastic Cap
Plastic Cover
Allen Wrench
Ø6 x Ø18
M6

STEP 1
STEP 2
(A)
(C)
(D)
(B)
(3)
(1)
(6)
(H)
(E)
(3)
(2)
(6)
FULLY TIGHTEN ALL BOLTS.
PUSH HARD UNTIL YOU FEEL OR HEAR CASTER (B) SNAP INTO PLACE.

STEP 3
STEP 4
(H)
(C)
(FR)
(FL)
(H)
(E)
(2)
(6)
DO NOT FULLY TIGHTEN BOLTS.
PLACE THE ASSEMBLED SEAT ON TOP OF PNEUMATIC CYLINDER (C) AND APPLY DOWNWARD PRESSURE.

STEP 5
STEP 6
(G)
(5)
(4)
(2)
(6)
APPLY FIRM PRESSURE TO ALIGN & FULLY TIGHTEN ALL BOLTS.
ATTENTION: MAKE SURE ALL BOLTS ARE FULLY TIGHTENED BEFORE USING CHAIR.
