GWF Galicia 150cm Wall TV Unit with LED User manual

Size:
Colour:
Finish:
150 x 38 x 30 cm (WDH)
White or Grey or Black
Melamine Cabinet with Gloss Fronts
GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Version 1- 181206
PO No：
Page 1of 15
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking.
Tools Required
Number of people
x2
Thank you for purchasing the Galicia 150cm Wall TV Unit with LED.
Please read the instructions carefully to ensure safe operation of this product,
especially the installation warnings shown in Page 2 of this guide.
11/4 Hour
Set Up

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Version 1- 181206
Page 2of 15
IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
INFORMATION
CARE INFORMATION
Never use scourers, abrasives or chemical cleaners.
To clean, wipe with a damp sponge.
Do not use solvent based cleaners or detergents as they can bleach or damage the product.
WARNINGS
This product is designed to hold 15Kg in total, spread evenly over the whole unit.
Do not exceed this weight.
We recommend that this unit is assembled in the room intended for use.
When you are ready to start, make sure that you have the right tools, plenty of space and a
clean, dry area for assembly.
Unwrap all packaging materials and place the components on top of the carton box or on a
clean floor to prevent them from scratching.
Check the pack and make sure you have all the parts listed.
Ensure that this product is fully assembled as illustrated before use.
Check all screws or bolts are tightened and inspect regularly
Tools not included unless specified in parts list.
DO NOT
DO NOT
DO NOT
DO NOT
use power tools to construct this product.
tighten screws until parts are assembled or as advised in this guide.
over tighten screws or bolts.
use this product if parts are missing, damaged or worn.
N.B. This is a TV Unit designed to hang from the wall, only use the brackets provided.
WARNINGS:
1. In order to prevent the product falling down this product must be installed with the
wall hanging device provided - do not use any other means to support the product.
2. Carefully assess the suitability of the wall to ensure that the fastening device will
withstand the load and forces generated. Walls can be quite different in construction so
fixings are not supplied - choose the most suitable fixing for your wall type - if in doubt
consult an expert.
3. When drilling the wall always be sure the area to be drilled is free from hidden
electrical wiring, gas or water pipes.
4. The assembly of this product must be done carefully following the detailed stages
in the Assembly Instruction.
5. Installation of this product needs to be carried out in accordance with the
following instructions, see Stage 13 onwards...

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Version 1 - 181206
Page 3of 15
Parts and Fittings Checklist
Please check the pack contents before assembling the product. If any components are missing,
please contact your retailer.
The fittings pack contains small items that should be kept away from children.
6
7
4
1
3
2
8
9
5
All parts are packed in one carton
Size: 1468 x 364 x 15 mm Size: 1476 x 223 x 3 mm
Carton No: 1/1 Carton No: 1/1
Description: Base Panel Description: Back Panel
Qty: 1
Description: Centre Upright
Qty: 1
Size: 349 x 215 x 15 mm
Carton No: 1/1
Qty: 1
Carton No: 1/1
Carton No: 1/1
Carton No: 1/1
4
5
6
Qty: 1 Qty: 1 Qty: 1
Size: 1500 x 365 x 15 mm Size: 365 x 285 x 15 mm Size: 365 x 285 x 15 mm
1
2
3
Description: Top Panel
Description: LH Side Panel
Description: RH Side Panel
Size: 1500 x 70 x 15 mm
Carton No: 1/1
Description: Cross Fascia
Qty: 1
Description: LH Flap
1:ytQ
Size: 747 x 140 x 15 mm
Carton No: 1/1
Description: RH Flap
1:ytQ
Size: 747 x 140 x 15 mm
Carton No: 1/1
7
8
9

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
6
D
Screw for Fitting
Wall Support
(4x32mm)
Screw for Fitting Hinge
and back panel
(3.5x12mm)
15A
15B
14C
E 34
2F
Item QuantityCode
Fittings (to scale)
Cam Lock
Dowel (8x30mm)
Cam Bolt
10 20 30 40 50 60 70 80
(35mm overall)
Carcass Screw for
Fitting Centre Upright
to Base Panel
(M7x50mm)
Version 1 - 181206
Page 4of 15
General Hints & Tips
A
26mm
A
A
B
Tighten
FLUSH
CARCASS SCREW
Stop when
level

Version 1 - 181206
Page 5of 15
Fittings (not to scale)
QuantityCode Item
Hinge
1
4
1
NFlap Stay - RH
1Flap Stay - LH
Allen Key (4mm)
3L
3M
Q
R
P
GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Fittings (packed in each LED pack). Note; there are two packs per unit.
QuantityCode Item
4
4
2
H
12G
J
KCable Clip
LED Clip
Battery Box and
LED Strip
Screw for LED
& Cable Clips
Wall Support -
Fixed to Carcass
Wall Bracket
2
Plastic CoverS

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Fittings required
For this step:
Tools required
F x2
R
C x2
C
F
R
F
F
C
C
Version 1 - 181206
Page 6of 15
STEP 1
STEP 2
Fittings required
For this step:
Tools required
A x9
A
A
A
A
A
A
A
A
5
4
7
3
2
A

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Fittings required
B x4
4
2
3
C
C
C x4
Tighten
B
C
C
B
B
B
B
C
Version 1 - 181206
Page 7of 15
STEP 3
STEP 4
For this step:
Tools required
Fittings required
For this step:
Tools required
B x5
C x2
7
C
C
B
B
B
B
B

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Version 1- 181206
Page 8of 15
STEP 5
STEP 6
For this step:
Tools required
6
Fittings required
For this step:
Tools required
D x6
L x3
Fittings required
LD
DL
D
D
S
S
S x2

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
For this step:
Tools required
Version 1- 181206
Page 9of 15
STEP 7
STEP 8
For this step:
Tools required
Fittings required
EE
Q
EE
Q
A
A
A
A
A
A
1
1
8 9
&
C
C
C
C
C
C
B
B
B
B
B
B
B x6
C x6
Fittings required
Q x4
E x8
A x6

GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
Version 1- 181206
Page 10 of 15
STEP 9
Fittings required
For this step:
Tools required
G x12
J x4
K x4
i.
ii.
GG
GJK
H
x2 x2
50mm
25mm
Position wires and fit LED Clip (Q) and
Cable Clip (R) using screws (E).
Peel off cover from battery box
and adhere to mark on each
side of centre upright.
H x2

3
Adjusting flap in or out
Adjusting flap up or down
Adjusting flap left or right
5
4
Version 1- 181206
Page 11 of 15
STEP 10
For this step:
Tools required
1
2
E
E
9
8
Fittings required
E x8
GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS

STEP 11
Fittings required
For this step:
Tools required
E
E
Once flaps have been adjusted
vertically. Fit screws (E) to fix
plates (Q) in their final position.
E x8
Version 1- 181206
Page 12 of 15
STEP 12
For this step:
Tools required
N
E
E
P
E
E
Fittings required
E x8
N x1
P x1
GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
9
8

Version 1- 181206
Page 13 of 15
STEP 13
Fittings required
For this step:
Tools required
For this step:
Tools required
I. II.
III. IV.
M
same
horizontal
level
726mm
M x3
GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
742mm
STEP 14
E
E
Fittings required
E x2
Warning: Always ensure the area to be drilled is free from hidden
electrical wires, water or gas pipes.
NOTE THE DIFFERENCE
USE x3 WALL
FIXINGS PER
BRACKET
CAREFULLY FOLLOW THESE INSTALLATION INSTRUCTIONS

Version 1- 181206
Page 14 of 15
STEP 15
For this step:
Tools required
GALICIA 150CM WALL TV UNIT WITH LED ASSEMBLY INSTRUCTIONS
i. On the hanging supports, make sure
hooks (x) are fully extended.
ii. With help, hang the cabinet onto the
metal wall brackets by carefully aligning
the end panels so they just miss the ends
of the brackets. Turn upper screw(s) on
all three supports until unit is horizontal.
iii. When unit is hanging on the
brackets, tighten lower screws
clockwise, so clamping unit to wall
- do not over-tighten.
L
M
(x)
Make sure all three hooks are
the same level, before hanging.
i ii iii iv
v
vi
vii
CHANGING THE BATTERIES
USE GOOD QUALITY AA BATTERIES. FOR BEST RESULTS USE RE-CHARGEABLES.
SLIDE OFFLOOSE SRCEWTAKE DOWN
TIGHTEN SRCEW
STICK AGAIN
THE LID CHANGE BATTERIES
SLIDE LID BACK ON

Version 1- 181206
Page 15 of 15
Assembly Completed
Your Galicia 150cm Wall TV Unit with LED is now completely assembled.
Periodically check to ensure that the components are in their proper position, free from damage.
Also, make sure the connectors are tight and secure.
Keep instructions for future reference
