OSP Home Furnishings RV9848 User manual

Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when
assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or
information on other products, please visit our website: www.officestar.net or call or write us.
RV9848
August, 2019
RAVEL DESK

LIMITED WARRANTY
OSP Home Furnishings™ warrants to the original purchaser that this product will be free from defects in material and workmanship as
described below. OSP Home Furnishings™ will repair or replace, at its option, without charge to the original purchaser only, defective
products or parts for one (1) year from the date of purchase. Replacement parts can only be supplied if parts are available. Items out of
production may be unavailable. This warranty shall be effective for the applicable time period beginning from the date of purchase as shown
on your original sales receipt. This warranty is your sole remedy for product defects and excludes defects due to or arising in connection
with product abuse or misuse, use modification of, or attachments to the product, and products or parts not used, maintained, or installed
in accordance with the company’s installation, maintenance and/or applicable guidelines. There are no other warranties, express or implied,
other than those specifically described, including without limitation any implied warranty of merchantability or of fitness for a particular purpose.
OSP Home Furnishings™ will not be responsible for incidental or consequential damages. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal
rights and you may also have other rights which may vary from state to state. Our quality standards are among the highest in the industry.
Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our Parts Department will do everything possible
to promptly remedy the problem. Contact us via e-mail parts@officestar.net, by Fax [phone], or toll free parts number 1-800-
950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time. To make a warranty claim, contact Parts Department. Provide
model number, proof of purchase, description of the problem and obtain return authorization. At its option OSP Home Furnishings™ will:
(a) Supply compatible components of current manufacture. (b) Repair the customer’s component. The customer must prepay freight on any
components returned to the factory. Return freight on components still in warranty will be paid by OSP Home Furnishings™.
1. Do not use this product unless all screws and bolts are securely tightened.
2. Check that all screws and bolts are tight every three months or as needed.
3. Dispose of packing material properly. Do not use plastic cover as head covering. It may cause suffocation.
4. Do not use this product as a stepladder.
5. Use this product for its intended purpose only.
6. FOR INDOOR RESIDENTIAL USE ONLY.

PARTS
(C) Upper Left Side Panel (1 PC) (D) Upper Right Side Panel (1 PC)
(E) Upper Left Divider Panel (1 PC) (F) Upper Right Divider Panel (1 PC)
(A) Top Panel (1 PC) (B) Shelf (1 PC)
(I) Lower Right Side Panel (1 PC) (J) Lower Divider Panel (1 PC)
(G) Upper Back Panel (1 PC) (H) Lower Left Frame (1 PC)

PARTS
(M) Lower Right Back Panel (1 PC) (N) Lower Cross Panel (2 PCS)
(O) Drawer Front Panel (1 PC) (P) Drawer Back Panel (1 PC)
(K) Lower Crossrail (1 PC) (L) Lower Left Back Panel (1 PC)
(S) Drawer Crossbar (1 PC) (T) Drawer Crossrail (1 PC)
(Q) Drawer Side Panel (1 PC) (R) Drawer Shelf (1 PC)

PARTS
(U) Drawer Support (1 PC) (V) Drawer Adjustment Panel (1 PC)
HARDWARE LIST
NO DRAWING DESCRIPTION SIZE QUANTITY
1Screw 2 PCS
12 PCS + 2 EXTRA
16 PCS + 2 EXTRA
20 PCS + 2 EXTRA
2 PCS
6 PCS + 1 EXTRA
64 PCS + 4 EXTRA
4 PCS
68 PCS + 4 EXTRA
Screw
Screw
Screw
Screw
Screw
Cam Screw
Cam Screw
Cam Nut
#6.5 x 1/2”
#6 x 1/2”
#8 x 1/2”
#10 x 1-1/2”
M4 x 22mm
N/A
N/A
N/A
2
3
4
5
6
7
9
8
59 PCS + 4 EXTRA
42 PCS + 4 EXTRA
1 PC
2 PCS
2 PCS
Wooden Dowel
Plastic Cap
Drawer Rail
Handle
L Bracket
N/A
N/A
N/A
N/A
N/A
10
11
12
14
13
6 x 25mm

HARDWARE LIST
NO DRAWING DESCRIPTION SIZE QUANTITY
15 Caster 2 PCS
1 PC
1 PC
4 PCS
Grommet
USB Power Unit
Shelf Pin
N/A
N/A
N/A
N/A
16
17
18
180°
CAM LOCK INSTRUCTIONS
Phillips Screwdriver also needed for assembly (not provided).

If you need to remove the drawer with ball bearing slides from the unit, follow the
steps below to prevent any damage to the slides or the drawer.
If you need to remove the drawer, please pull the drawer all the way out, then push the plastic release
lever of the ball bearing slide up on one side and down on the other side, and then pull the drawer
completely out. See detail #A.
DRAWER INSTALLATION
Detail #A
Detail #B
To place the drawer back, simply push the ball bearing cart all the way to the end of the slide (in both sides),
and align the slide runners on the drawer with the slide tracks on the unit and push it carefully inside until
it stops. See detail #B.
Note: If they do not align properly, remove and repeat step 2

STEP 2
STEP 1
(A)
(7)
(7)
(7)
(7)
(C)
(F)
(D)
(G)
(E)
(10)
(10)
FULLY TIGHTEN ALL CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 3
STEP 4
(D)
(D)
(G)
(G)
(C)
(C)
(9)
(9)
(A)
(11)
(11)
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 5
STEP 6
(7)
(7)
(B)
(F)
(A)
(E)
(9)
(11)
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 7
STEP 8
(8)
(8)
(H)
(D)
(F)
(E)
(C)
(4)
(4)
(B)
FULLY TIGHTEN ALL SCREWS (4) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM SCREWS (8) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 9
STEP 10
(H)
(L)
(9)
(11)
(K)
(K)
(L)
(10)
(10)
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 11
STEP 12
(M)
(I)
(7)
(7)
(10)
(10)
(13 Rail)
(13 Rail)(13 Slide)
(I)
(2)
FULLY TIGHTEN ALL CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL SCREWS (2) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 13
STEP 14
(J)
(10)
(10)
(7)
(7)
(J)
(N)
(N)
(9)
(I)
(3)
(U)
(M)
FULLY TIGHTEN ALL CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL SCREWS (3) AND CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 15
STEP 16
(H)
(J)
(K)
(L)
(11)
(9)
(J)
(N)
(9)
(M)
(N)
(U)
(3)
FULLY TIGHTEN ALL SCREWS (3) AND CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 17
STEP 18
(I)
(H)
(L)
(K)
(L)
(16)
(11)
(9)
(6)
(9)
(J)
(6)
(K)
FULLY TIGHTEN ALL SCREWS (6) AND CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 19
STEP 20
(S)
(10)
(10) (P)
(T)
(R)
(7) (7)
(O)
(A)
(17)
(1)
FULLY TIGHTEN ALL SCREWS (1) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 21
STEP 22
(2)
(13 Slide)
(Q)
(Q)
(7)
(7)
(3)
(14)
(10)
(10)
(T)
(3)
(S)
(T)
FULLY TIGHTEN ALL SCREWS (2) AND CAM SCREWS (7) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL SCREWS (3) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 23
STEP 24
(P)
(R)
(9)
(Q)
(11)
(S)
(R)
(S)
(P)
(9)
(11)
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).

STEP 25
STEP 26
(S)
(R)
(15)
(3)
(O)
(R)
(S)
(Q)
(O)
(11)
(9)
FULLY TIGHTEN ALL CAM NUTS (9) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
FULLY TIGHTEN ALL SCREWS (3) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
