SitOnit Seating Switchback User manual

Switchback
HOME EDITION HEIGHT ADJUSTABLE DESK
Find your t.
Stand or sit, mix it up with the press of a button. Switchback®
height-adjustable desk elevates the way you work from home—while
maximizing ergonomics and minimizing fatigue.
C6586 Rev A |www.sitonit.net |1
INSTALLATION VIDEO

Read the entire instruction manual before you start installation and assembly. If you
have any questions regarding any of the instructions or warnings, please contact your
local distributor for assistance.
To report any issues with this product, contact our customer experience team at:
[phone] or [email protected].
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this product. Save these instructions.
When using an electrical product, basic precautions should always be followed,
including the following.
DANGER: TO REDUCE THE RISK OF ELECTRIC SHOCK
Use Care When Cleaning
Always unplug this furnishing from the electrical outlet before cleaning. Follow all
cleaning guidelines provided by the manufacturer.
2|C6586 Rev A |www.sitonit.net
Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK

Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK
IMPORTANT SAFETY INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS:
Approved Users Only
For household/residential use only. Close supervision is necessary when this
product is used by, or near children, invalids, or disabled persons.
Keep Dry and Use Care When Cleaning
Keep all electrical components away from water and humidity. Do not operate
where aerosol (spray) products are being used or where oxygen is being
administered.
Do not use outdoors. This equipment is approved for indoor use only.
Do Not Modify
Use this product only for its intended use as described in these instructions. Do
not use attachments not recommended by the manufacturer.
Avoid Damage
Keep the cord away from heated surfaces. Unplug from outlet before putting on
or taking o parts. To disconnect, turn all controls to the o position, then remove
plug from outlet.
Inspect Regularly
Never operate this product if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return the
product to a service center for examination and repair.
Inspect table system regularly and immediately stop using the product if it is
damaged or has loose parts.
C6586 Rev A |www.sitonit.net |3

WARNING / AVERTISSEMENT
WARNING / AVERTISSEMENT
RISK OF INJURY / RISQUE DE BLESSURE
Maximum load 220 lb including worksurface
Charge maximale 220 lb incluant la surface de travail
RISK OF FIRE AND SHOCK / RISQUE D'INCENDIE ET DE CHOC
Use only min SJ type or equivalent, 18 AWG cord minimum
Utilisez uniquement un type SJ minimum ou équivalent, cordon 18 AWG minimum
WARNING / AVERTISSEMENT
RISK OF ELECTRIC SHOCK, FIRE, AND INJURY /
RISQUE DE CHOC ÉLECTRIQUE, D'INCENDIE ET DE BLESSURE
Review the assembly instructions to conrm that the appropriate critical components
and accessories are being used with the furnishing
Consultez les instructions d'assemblage pour conrmer que les composants et
accessoires essentiels appropriés sont utilisés avec l'équipement
IMPORTANT SAFETY INSTRUCTIONS
4|C6586 Rev A |www.sitonit.net
Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK

Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK
Servicing of Double-Insulated Products
In a double-insulated product, two systems of insulation are provided instead of
grounding. No grounding means is provided on a double-insulated product, nor is a
means for grounding to be added to the product. Servicing a double-insulated product
requires extreme care and knowledge of the system and is to be done only by qualied
service personnel. Replacement parts for a double-insulated product must be identical
to the parts they replace. A double-insulated product is marked with the words
“DOUBLE INSULATION” or “DOUBLE INSULATED”.
IMPORTANT SAFETY INSTRUCTIONS
C6586 Rev A |www.sitonit.net |5

Do Not Overload Table
Make sure the table system is not overloaded by the weight of the tabletop and
objects on table. Evenly distribute load; excess loads near the edges can reduce
stability and lead to tip-over. Do not exceed maximum load of 220 lb.
Assemble With Care
Failure to follow instructions could result in product failure or potential injury. Keep
ngers clear of pinch points
Use Care to Keep the
Table From Tipping Over
Before moving the table system,
clear all objects and equipment
from the table to reduce the risk
of tipping over. Do not lift the table
system by the tabletop. Adjust
the table to its lowest height
before moving. In order to avoid
risk of tipping or collapse, make
sure corded objects will not be
pulled o the table or cause other
objects to fall.
Clearance Around
the Table
Conrm that the surroundings on
all sides of the table system are
clear and make sure the power
cord moves freely as desk moves
up and down.
If the tabletop encounters
resistance while moving, it
will rebound.
WARNING RISK OF DEATH AND SERIOUS INJURY
1"
1"
1"
1"
1"
1"
1"
1"
6|C6586 Rev A |www.sitonit.net
Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK

Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK
• 6 mm Hex Key
Recommended Tools
• Top/Frame Assembly (1)
• Leg/Column Assembly (2)
Parts
6 mm Hex Key
Top/Frame
Assembly
Leg/Column
Assemblies
C6586 Rev A |www.sitonit.net |7

A
B
A
B
B
A
A
Fastener
Frame Sticker
Match with
the leg sticker
Step 1: Insert the legs into the frame, sliding the fasteners into the
notches on the crossbeam.
Match with
the frame sticker
Leg Sticker
SLIDE!
8|C6586 Rev A |www.sitonit.net
Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK

Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK
Step 2: Tighten the leg's four fasteners with the 6 mm hex key.
TOOLS
This step is repeated on the other column.
A
A
Column
Fastener
6 mm Hex Key
C6586 Rev A |www.sitonit.net |9

Step 3: Plug in the legs to the control box. Use the extension cord to span
the longer distance from leg B.
A
A
B
B
B
A
A
B
A
A
A
B
B
A
B
B
Extension Cord
Control Box
A
A
A
B
B
A
B
B
10 |C6586 Rev A |www.sitonit.net
Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK

Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK
Step 4: With the help of another person, turn the table upright.
Caution:
Do not rock the table upright. This will
damage the and control bracket that is
pre-installed under the tabletop.
Hand Control Bracket
C6586 Rev A |www.sitonit.net |11

Step 5: Insert the hand control into the hand control bracket.
Hand Control Bracket
Hand Control
12 |C6586 Rev A |www.sitonit.net
Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK

Switchback HOME EDITION HEIGHT-ADJUSTABLE DESK
Initialization
Before the rst use, or when the display
screen shows "RST".
1. Press the down button until the table
reaches its lowest position.
2. The table is initialized after it makes a
di sound and the frame rebounds.
Reset to Factory Settings
To reset to factory settings, press both
up and down arrows at the same time
and hold for ten seconds until you
hear a beep.
Temporary (Safety) Lock
TO LOCK: press the up arrow and
the S key for ve seconds until you see
"LOC" on the display.
TO UNLOCK: Press the down arrow
and the S key for ve seconds until you
see "LOC" on the display.
Anti-Collision
Your height-adjustable desk is also
programmed with Anti-Collision
technology. When the desk comes
into contact with an object it will
automatically stop and retract.
Move Desk Up and Down
Raise the desk by pressing the up arrow
and lower the desk by pressing the
down arrow.
Set a Memory Position
The memory buttons can store up
to four preset height positions. To
program a button:
1. Press the Sbutton and “S-" will
begin ashing.
2. Then press any of the buttons
numbered one through four to store
a preset height.
3. After the height has been set, press
one of the buttons to move to the
preset height.
Set the Minimum Height
1. Move the desk to any height
below 37 inches
2. Press the up and down arrows at
the same time, and hold for ve
seconds until you hear a beep.
Set the Maximum Height
1. Move the desk to any height
above 38 inches
2. Press the up and down arrows at
the same time, and hold for ve
seconds until you hear a beep.
1234
S
Display Set
Up/Down Memory
C6586 Rev A |www.sitonit.net |13

Error Code Description Solution
E1 Faulty Power Replace power
E2 A-Synchronist Height Over 1 cm Initialize the table
E4 Handset Error Unplug and replug the handset in
E6 Faulty Power Replace power
E7 Faulty Power Replace power
E7 Slopiing Tabletop Check the tabletop
E11 Motor Defect Check the motor's wire
E12 Faulty Hand Control Replace the hand control
E14 Faulty Motor Replace the motor
E15 Faulty Motor Replace the motor
E16 Faulty Motor Replace the motor
E17 Faulty Motor Replace the motor
E18 Overloaded Replace the load on the table
E21 Motor Defect Check the motor's wire
E22 Faulty Hand Control Replace the hand control
E24 Faulty Motor Replace the motor
E25 Faulty Motor Replace the motor
E26 Faulty Motor Replace the motor
E27 Faulty Motor Replace the motor
E28 Overloaded Replace the load on the table
HOT Overtime Operation Automatic recovery after 20 minutes
14 |C6586 Rev A |www.sitonit.net
