OT Systems FTD100-XXR3 Series User manual

All Digital Fiber Optic Manufacturing Specialists
Installation and Operation Manual
FTD100-XXR3 Series
8-bit Digital Series
Triple Independent Video
Fiber Optic Receiver
OT Systems Ltd., 2009
Rev 1.1

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 1
Models covered in this manual
Standalone Units
Single-Mode Receivers
FTD100-SSR3SA
FTD100-SSR3LSA
Multi-Mode Receiver
FTD100 –SMR3SA
Card Modules
Single-Mode Receivers
FTD100-SSR3
FTD100-SSR3L
Multi-Mode Receiver
FTD100-SMR3
Compatible with the following TRANSMITTERS:
FTD100Micro Series
FTD100M Series
FTD100 Series
Single-Mode
FTD100Micro-SST
FTD100Micro-SSTL
Multi-Mode
FTD100Micro-SMT
Single-Mode
FTD100M-SST
FTD100M-SSTL
Multi-Mode
FTD100M-SMT
Single-Mode
FTD100-SST(SA)
FTD100-SSTL(SA)
Multi-Mode
FTD100-SMT(SA)
Remark:
If the optical connector is FC type, the suffix in the model number will be “-FXX”. Eg.
FTD100-FSR3

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 2
Table of Contents
(1) SAFETY INSTRUCTIONS..........................ERROR! BOOKMARK NOT DEFINED.
(2) PRODUCT OVERVIEW ..........................................................................................4
2.1 Introduction.......................................................................................................4
2.2 Models selection table ......................................................................................5
(3) INSTALLATION .......................................................................................................6
3.1 General.............................................................................................................6
3.2 Standalone unit installation...............................................................................6
3.3 Card module installation ...................................................................................7
(4) CABLE CONNECTIONS & SETUP PROCEDURES...............................................7
4.1 System cable connections................................................................................7
4.2 Ground connection ...........................................................................................9
(5) OPERATIONAL GUIDES ........................................................................................9
(6) SPECIFICATIONS.................................................................................................10
(7) DRAWINGS...........................................................................................................11
(8) WARRANTY INFORMATION................................................................................11
(9)CONTACT INFORMATION ...................................................................................11

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 3
(1) Safety Instructions
Please be familiar with all information in this manual prior to installation and
operation.
Note 1: The products described contain a Class 1 laser or LED fiber optic emitter. The following
safety precautions apply.
Warning: Do not disconnect the fiber optic connector while the unit is powered up.
Exposure to Class I invisible optical radiation is possible when the internal fiber optic
connector is disconnected while the unit is powered up.
Caution: Any access to the controls, adjustments, or performing operations, which are
other than those specified may result in hazardous radiation exposure. Permanent eye
damage or other bodily injuries may be resulted from such exposure even for only
seconds.
Note 2: This assembly contains parts sensitive to damage by electrostatic discharge (ESD). ESD
precautionary procedures should be applied in the course of touching, removing or inserting parts
or assemblies.

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 4
(2) Product Overview
2.1 Introduction
The FTD100-XXR3 Series products comprise of either single-mode or multi-mode fiber optic
transmitters and receivers for the optical transmission of ONE forward (Tx → Rx) video in THREE
individual fiber links. The products work at wavelengths of 1310nm or 1550nm with either a
9/125um or 62.5/125um fiber for single-mode or multi-mode transmission respectively.
The FTD100-XXR3 Series products are compatible with the transmitters of the
FTD100Micro Series,FTD100M Series and FTD100 Series.
A non-compressed 8-bit digital video transmission scheme is implemented which supports
video in NTSC, PAL and SECAM formats.
For single-mode transmission, we also offer specifically designed products for long-haul
transmissions up to 60km. These models include the letter “L” in the suffix, e.g. FTD100-SSR3L,
etc. The FTD100-XXR3 Series units are available as standalone units, which can be mounted
horizontally or vertically wall-mounted on any fixture. The standalone unit comes with an external
power supply FT-PA/12V, which can be powered by local 110/220V power.
The FTD100-XXR3 Series are also available as plug-in card modules installed in a 19”
rack-mount chassis. Each plug-in card occupies one slot in the rack-mount chassis. The rack
mount chassis has to be ordered separately, and comes with its own power supply for powering
the installed card modules.

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 5
2.2 Models selection table
Type
Mode
Models1
Descriptions
Installation
requirements
Remarks
Standalone Units
Single-Mode
FTD100-SSR3SA
Triple Independendent Single-mode Video
Receiver Standalone Unit
Horizontally or
vertically
wall-mounted
Standalone
unit
FT-PA/12V
external power
supply is
included for
the Standalone
unit2
FTD100-SSR3LSA
Triple Independendent Single-mode
Long-haul Video Receiver Standalone Unit
Multi-Mode
FTD100-SMR3SA
Triple Independendent Multi-mode Video
Receiver Standalone Unit
Card Modules
Single-Mode
FTD100-SSR3
Triple Independendent Single-mode Video
Receiver Card Module
Housed in
FT-C18
chassis3
FT-C18
chassis has to
be ordered
separately
FTD100-SSR3L
Triple Independendent Single-mode
Long-haul Video Receiver Card Module
Multi-Mode
FTD100-SMR3
Triple Independendent Multi-mode Video
Receiver Card Module
1If the optical connector is FC type, the suffix in the model number will be “-FXX”. Eg. FTD100-FSR3
2FT-PA/12V works under 100 -240VAC, 50/60Hz power supply
3Refer to FT-C18 product manual for specifications

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 6
(3) Installation
3.1 General
All OT Systems products are thoroughly inspected, tested and securely packaged before
delivery to ensure a stable, intact and trouble-free service. Please check the equipment upon
receipt for any visible damage which may have been caused during shipping.
The FTD100-XXR3SA Series standalone units (Fig. 3.1) can be either horizontally or
vertically wall-mounted, or mounted on any fixture. The Standalone unit works with an external
power supply FT-PA/12V powered by local 110/220V power.
The FTD100-XXR3 Series card modules are housed inside the FT-C18 rack-mount chassis
(Fig. 3.2) with an included power supply unit. The whole chassis is powered by local 110/220V
power. FT-C18 is a standard 19” (483mm) rack-mount chassis which occupies 4 rack units
(177.8mm) in height. Each FT110DF card module occupies one slot and a total of 18 cards can
be housed inside the chassis.
3.2 Standalone unit installation
a) Mount the standalone unit onto a fixture, (either on the wall or on a flat surface) with four
screws through the holes on the mounting frame to secure it in position.
b) The provided power supply should also be mounted on the same fixture or in the proximity
for connection of the supply cables to the unit, provided that an AC power supply socket is
nearby for powering the adaptor.
c) Connect all the signal inputs and outputs at the back of the unit with appropriate cables:
fiber optic cable for optical link, BNC cables for video outputs.
d) Once the unit is powered up, check that the red POWER LED on the unit is lit. If not, check
the power supply cable connections between the unit and the power supply socket.
e) With all the signals available at the input and output ports, check the status of LEDs located
on the unit. With correct status of each LED, installation is now completed [for LEDs status, see
Operational Guides on this manual’s section (5)].
Fig. 3.1 Standalone unit
Fig. 3.2 FT-C18 chassis

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 7
3.3 Card module installation
a) Insert the card module into the FT-C18 chassis along the top and bottom card guides of an
empty slot and push the card into the multi-pin socket at the rear firmly. Secure with the provided
thumb screws.
b) Repeat the above procedure for all the rest card modules. Unused slots must be covered
with blank panels provided.
c) Connect all the signal inputs and outputs at the back of the unit with appropriate cables:
fiber optic cable for optical link, BNC cables for video outputs.
d) Once the chassis is powered up, check that the red POWER LED on the front and back
panels of the card modules are lit. If not, check the power supply cable connections between the
chassis and the power supply socket. For failures of individual card’s POWER LEDs, check the
corresponding card modules, whether they have been inserted properly.
e) With all the signals available at the input and output ports, check the status of LEDs located
on the unit.With correct status of each LED, installation is now completed [for LEDs status, see
Operational Guides on this manual’s section (5)].
(4) Cable Connections & Setup Procedures
4.1 System cable connections
Signal Type
Cable Type
Connector
Optical
Single-mode or Multi-mode fiber
ST (or FC) Connector
Video
Coaxial Video Cable
BNC Connector

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 8
Typical System Cable Connections Diagrams:
FTD100-XXR3 Series Receiver
Fig 4.1 Micro units to Card Module connection diagram
FTD100-XXR3SA Series Receiver
Fig 4.2 Micro units to Standalone unit connection diagram
TRANSMITTERS CAN BE:
FTD100Micro Series
FTD100M Series
FTD100 Series
TRANSMITTERS CAN BE:
FTD100Micro Series
FTD100M Series
FTD100 Series

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 9
4.2 Ground connection
For enhanced safety to reduce the risks of electrical shock and physical damage, caused by
lightning and other power surges, as well as a connection to the surge suppresion devices in the
product, a screw terminal is provided on the Standalone cabinets (Fig. 4.3). It is highly
recommended that the Standalone unit have good ground connections to the buildings ground in
accordance with the local codes.
Fig. 4.3 Standalone unit earth ground terminal location
(5) Operational Guides
LED Indicators
Indicator
Color
Description
CH1
CH2
CH3
PWR
Red
Lit when power is supplied to the Receiver.
OL
Yellow
Lit when optical signal from transmitter to receiver is active.
V1, V2 or V3
Green
Lit when video signals are available at the VIDEO OUT connectors.
Signal Ports
CH1
OPT 1-
ST (or FC) Optical Connector for fiber cable connection.
VIDEO OUT 1-
BNC Video Connector for video signal ouput.
CH2
OPT 2-
ST (or FC) Optical Connector for fiber cable connection.
VIDEO OUT 2-
BNC Video Connector for video signal ouput.
CH3
OPT 3-
ST (or FC) Optical Connector for fiber cable connection.
VIDEO OUT 3-
BNC Video Connector for video signal ouput.

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 10
(6) Specifications
MODELS*
PARAMETERS
FTD100-SSR3SA
FTD100-SSR3
(Single-Mode)
FTD100-SSR3LSA
FTD100-SSR3L
(Single-Mode)
FTD100-SMR3SA
FTD100-SMR3
(Multi-Mode)
OPTICAL
No. of Fiber / Connector
3 / ST(or FC)
3 / ST(or FC)
3 / ST(or FC)
Wavelength
1310 nm
1310 nm
1310 nm
Optical Power Budget
17 dB
24 dB
23 dB
Max Distance
40 km
60 km
4 km
ELECTRICAL VIDEO
Channel / Connector
3 / BNC
System
PAL, NTSC, SECAM
Bandwidth
≥6.0 MHz
Input/Output Impedance
75 Ohm
Input/Output Level
1.0 Vp-p typical
Differential Gain
< 1% typical
Differential Phase
< 1otypical
SNR
>60dB
POWER
Power consumption
12VDC @ 6W
Power Supply
Standalone unit: FT/PA12V DC Adaptor
Card module: Powered by FT-C18 chassis
Connector (Micro unit)
2-pin Screw Terminal
PHYSICAL
Weight
Standalone unit: 0.68 kg Card module: 0.22 kg
Dimensions (W x H x D)
Standalone unit: 156 x 30.5 x 223 mm (MAX)
Card module: 148 x 20.4 x 213 mm (MAX)
ENVIRONMENTAL
Operating Temperature
-40oC ~ +75oC
Storage Temperature
-40oC ~ +85oC
Relative Humidity
0 ~ 95% non-condensing
MTBF
>100’000 Hours
*If the optical connector is FC type, the suffix in the model number will be “-FXX”. Eg. FTD100Micro-FST

FTD100-XXR3 Series Installation & Operation Manual
www.ot-systems.com 11
(7) Drawings
Fig. 7.1 Dimensional drawings of Standalone unit (mm)
(8) Warranty Information
All OT Systems products are subject to a limited life-time warranty offered by the company
in normal circumstances. Please refer to the OT Systems Products Warranty Statement for
details. Access to the statement is available in our company website at www.ot-systems.com.
(9) Contact Information
OT Systems Ltd. (Hong Kong)
Unit 1023, 10/F Landmark North
39 Lung Sum Avenue
Sheung Shui, N.T., Hong Kong
Tel. [phone]
Fax. [phone]
[email protected]m
OT Systems Ltd. (USA)
River Heights Business Park
5375 US Highway 34
Oswego, IL 60543, USA
Tel. [phone]
Fax. [phone]
[e-mail]
