Bio-logic®NavPRO ONE®
ASSR
Quick Start Guide
Doc. No.7-26-1389-EN/00
Part No.7-26-13809-EN
Bio-logic®

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
2
Bio-logic®
Turning On/Off, and charging the device
Start menu
On/off button on
right side
Current time
Note: this screen (test options)
can vary depending on your set up
Battery status
Select patient
Additional
information
about options for
current screen
Turn off device
Customize
settings
Power supply
connector

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
3
Bio-logic®
Auditory Steady State Response (ASSR)
Connect the transducer to the appropriate connector:
Headphones or insert earphones: blue connector
Probe: red connector
Second probe for binaural testing: blue connector
Clean the patient’s skin and place the electrode pads. Connect the clips to the corresponding sites.
Recommended montage is:
Testing
Connect the electrode cable
to the white and the probe
to the red connector.
White: high forehead
Black: cheek
Red: mastoid
For binaural testing, place
red electrode on the nape.

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
4
Bio-logic®
If you are using insert earphones, select the proper size ear tips and place it in the ear canal.
If you are using headphones, place them over the ears.
Select ASSR
Select the protocol you would like to use. To change the parameters, select one of the presets and then the
tools button at the bottom of the screen:
Select masking noise
(monaural testing only)
Select start, minimum and
maximum level for adaptive
mode
40 Hz: awake and adult patients
80 Hz: babies and higher frequencies
Auto: mixed rate, optimized for
performance
Half octave stimuli
provide better
frequency specificity
but longer testtime
select frequencies
to test
Fixed: will test all selected levels
Adaptive: used for threshold search
Configurable test parameters

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
5
Bio-logic®
Select the test ear by pressing either the Right or Left button, or Right + Left for binaural testing. Binaural
testing is available when headphones, insert phones or two ear probes are connected (if stimulating at low
intensity levels only).
Make sure the patient is sitting or lying down comfortably.
An impedance check will be performed prior to measurement. If impedance is below 6 k ohm, the start button
will become available. You can configure the settings for the test to autostart if the impedance is lower than
4 k ohm. If impedance is higher than 6 k ohm but below 12 k ohm, a skip button will become available. An
impedance below 6 k ohm is recommended for best test results.

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
6
Bio-logic®
ASSR test screen
Frequency being tested
Intensity level being tested
Impedance monitor
Simple calibration mode Expert calibration mode
Progress for each
tested frequency
Overall EEG, – value should
remain in the lower third. Press
to enable raw EEG view
Test progress
Stop test Pause ongoing test Skip this single test
If you are using an ear probe, a calibration will be performed together with the impedance check. You can
select the simple calibration or the expert calibration mode in the device set up.

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
7
Bio-logic®
ASSR test results
Note: These circles
indicate that other
screens are available
to view. Swipe your
finger right or left to
get other views.
Print results to a label
or to a pdf file
Press on a check mark
or circle to view details
Test conditions
Please note that the estimated audiogram is only available in the adaptive test mode.

Quick Guide:
Bio-logic®NavPRO ONE®ASSR
Otometrics - Next generation Bio-logic products
8
Bio-logic®
Quick Guide Information
Release date: 2017-01-11
Revision: 01
Valid from: Firmware Rev. 2.1, Mira PC Software Rev. 1.6.4
Applies to: Model: SOH100360, web description SOH09
All mentioned items, products, brands and trademarks are registered or owned by the mentioned companies.
All information, illustrations, and specifications provided within this manual are based on the latest product
information available at the time of publication. PATH medical reserves the right to make changes at any time
without notice.
Please note that not all products displayed on our webpage or advertising materials are available in all
territories.
Please contact your local distributor or PATH medical for further information.
The latest revision of the Quick Start Guide is available online at www.pathme.de/download.
Errors and omissions excepted.
