OTS ET4200CPp-RS8 User manual

ET4200CPp-RS8 / ET4200CPp-RS16
Receiver of 8/16-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000TX Ethernet Switch
1 V1.0(Draft)
This quick start guide describes how to install and use the receiver of 8/16-port Ethernet Extender over Coax with Power over Coax (PoC) + 4-port
10/100/1000Base-T Ethernet switch.
Overview
The ET4200CPp-RS8/16 receiver works with the transmitter of 1 port Ethernet Extender over Coax with PoC
(ET1100CPp-T) to provide Ethernet Extension of 8/16 channel 10/100Base-TX over Coaxial cable to 4-port
10/100/1000Mbps Ethernet. The maximum transmission distance is 800m. The product support PoC, hence, no
power point is required at the camera side for the transmitter (ET1100CPp-T) and its connected IP camera if the
camera obtain power from the transmitter via Power over Ethernet (PoE). The Ethernet data received by anyone
of the coax data port (1-8/16) at the receiver is transferred to all four Ethernet ports (P1-P4). The product is good
for retrofit of analogue system by using the existing coaxial cable infrastructure.
General
To ensure trouble free transportation and storage, all OT Systems products must be thoroughly inspected, tested
and properly packed before delivery. Check the product upon receipt for any visible damage which may have been
caused during shipment.
Package Content
Receiver of 8-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000Base-T Ethernet Switch x
1(ET4200CPp-RS8) or,
Receiver of 16-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000Base-T Ethernet Switch x
1(ET4200CPp-RS16)
AC Power Cord x 1
Quick Start Guide x 1
Physical Description
Front Panel
ET4200CPp-RS8
ET4200CPp-RS16

ET4200CPp-RS8 / ET4200CPp-RS16
Receiver of 8/16-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000TX Ethernet Switch
2 V1.0(Draft)
Rear Panel
ET4200CPp-RS8
ET4200CPp-RS16

ET4200CPp-RS8 / ET4200CPp-RS16
Receiver of 8/16-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000TX Ethernet Switch
3 V1.0(Draft)
Installation
ET4200CPp-RS8/16 can be installed on a 19”rack cabinet. The product has 4 mounting holes. Use 4 rack
mount screws to securely install the product in the rack cabinet.
Setup
1. The ET4200CPp-RS8/16 is a plug-and-play device. Connect the socket of AC power cord to the AC inlet of the
receiver and plug the other end into a standard AC outtlet. Turn on the switch, the PWR LED will then be lit.
2. The READY LED will be lit (ON) when the receiver is ready for data transfer.
3. Connect one end of the coaxial cable to the female BNC connector (COAX DATA) of ET4200CPp-RS8/16 and
the other end to the transmitter (ET1100CPp-T). If the transmitter and receiver are properly connected and
communicated with each other, the ACT will be lit (ON). The PoC LED will be lit too when the PoC is in use.
4. Connect the Ethernet cable from the NVR or PC or similar equipment to the Ethernet port (10/100/1000M). If
the cable is properly connected, the corresponding LED (100M or 1000M depend on the Ethernet connection)
at the RJ45 port with be lit. If there is data being transferred, the LED will be blinking.
Interface
RJ-45 Pin Assignment
Pin
Signal Name
1
TP0+
2
TP0-
3
TP1+
4
TP2+
5
TP2-
6
TP1-
7
TP3+
8
TP3-
Power Connection
The power interface of ET4200CPp-RS8/16 complies with the IEC60320-C14 standard and the AC power socket
complies with the IEC60320-C13 standard
IEC60320-C14 AC Power Socket
Mounting
Holes

ET4200CPp-RS8 / ET4200CPp-RS16
Receiver of 8/16-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000TX Ethernet Switch
4 V1.0(Draft)
Cable Connection
Interface Type
Support Description
Cable Type
RJ45
10Base-TX
100Base-TX
1000Base-T
Category 3 or above cable
Category 5 or above cable
Category 5 or above cable
BNC (Female)
Ethernet over Coax Data
RG-59/U or similar
Power
AC power interface with 100~240 VAC input
AC Power Socket
LED Status
Label
Colour
State
Indication
PWR
Green
Steady
Power on
Off
Power off
ACT
Green
Flashing
Data transfer within the coaxial cable
Off
No data transfer within the coaxial cable
READY
Green
Steady
The converter is ready for data transfer
Off
The converter is not ready
PoC 1-8
(ET4200CPp-RS8)
PoC 1-16
(ET4200CPp-RS16)
Green
Flashing
Detection stage
ON: 1 sec,
OFF: 5 sec
(Repeat)
Un-connected or broken coaxial cable
ON: 2 sec
OFF: 4 sec
(Repeat)
TX is connected with power adaptor (PoC not required)
ON: 3 sec
OFF: 3 sec
(Repeat)
Overload
ON
Power over Coax in use
Ethernet
100M
Green
Steady
Ethernet connection of 10/100Base-TX is established
Flashing
Transmitting or receiving Ethernet data
Off
Neither valid Ethernet connection established nor transmitting or
receiving Ethernet data
1000M
Yellow
Steady
Ethernet connection of 10/100/1000Base-T is established
Flashing
Transmitting or receiving Ethernet data
Off
Neither valid Ethernet connection established nor transmitting or
receiving Ethernet data

ET4200CPp-RS8 / ET4200CPp-RS16
Receiver of 8/16-port Ethernet Extender over Coax with PoC + 4-port 10/100/1000TX Ethernet Switch
5 V1.0(Draft)
Dimensions (Unit: mm)
Functional Descriptions
1U 19”Rack-mount.
Compatible with 1 port EoC Transmitter with PoC/PoE (ET1100CPp-T)
Support 16 coaxial cable connections, BNC connectors at rear panels
Support 4 10/100/1000Base-T Ethernet port, 2 ports in front panel and 2 ports in rear panel.
Fully compliant to IEEE 802.3 IEEE 802.3u, 802.3ab standard.
Support auto MDI/MDI-X
Support Power over Coax
Maximum transmission distance 800m
Support multicast
100VAC~240VAC, 50/60HZ power input
Plug and play installation, no PC required
Built in Surge protection
Operating temperature range 0℃to +50℃
Manual Earth Green manual is available in our website. www.ot-systems.com
