INSTRUCTION MANUAL
TABLE WATER DISPENSER
MODEL: 7323498 (BYT92)
EAN: 6001224018271
INDOOR HOUSEHOLD USE ONLY
Please save and read this instruction manual carefully before use.

1
ENGLISH
INTRODUCTION
Thank you for purchasing our “Ottimo” Water Dispenser. Each unit has been manufactured to ensure safety, reliability,
and easy of use. Before use, please read these instructions carefully and save them for future reference.
IMPORTANT SAFEGUARDS
When using your “Ottimo” Water Dispenser, basic safety precautions should always be followed, including the following :
!This product is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge concerning the use of this product, unless they are supervised or
have been given instruction concerning use of the appliance by a person responsible for their safety.
!Children should be supervised to ensure that they do not play with the appliance.
!Always ensure that the voltage on the rating label corresponds to the voltage in your home.
!Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it must be replaced by
the manufacturer or a qualified person in order to avoid an electrical hazard.
!This product is intended for household use only. Industrial or commercial use will void the warranty, and the supplier
can not be held responsible for injury or damage caused when using the appliance for any other purpose than that
intended.
!Incorrect operation and improper use can damage the appliance and cause injury to the user.
!Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take the unit in for
examination and/or repair by an authorized service agent.
!To reduce the risk of electric shock, do not immerse or expose the motor assembly, plug or the power cord to water or
any other liquid.
!Never immerse the unit in water or any other liquid for cleaning purposes.
!Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the appliance. Always
unplug the unit when not in use, before cleaning or when adding or removing parts.
!The use of accessory attachments that are not recommended or supplied by the manufacturer may result in injuries,
fire or electric shock.
!Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a position where it can be
pulled on inadvertently.
!Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner or in a heated
oven.
!Use of an extension cord with this appliance is not recommended. However, if it is necessary to use an extension
lead, ensure that the lead is suited to the power consumption of the appliance to avoid overheating of the extension
cord, appliance or plug point. Do not place the extension cord in a position where it can be pulled on by children or
animals or tripped over.
!This appliance is not suitable for outdoor use. Do not use this appliance for anything other than its intended use.
!Do not carry the appliance by the power cord.

2
ENGLISH
!Do not leave this appliance unattended during use. Always unplug the unit when not in use. Allow it to cool before
putting on or taking off parts, and before cleaning the appliance.
!Always operate the appliance on a smooth, even and stable surface. Do not place the unit on a hot surface.
!The manufacturer does not accept responsibility for any damage or injury caused by the improper or incorrect use of
the appliance, or by repairs carried out by unauthorized personnel.
!In case of technical problems, switch off the machine and do not attempt to repair it yourself. Return the appliance to
an authorized service facility for examination, adjustment or repair. Always insist on the use of original spare parts.
Failure to comply with the above mentioned precautions and instructions, could affect the safe operation of this
machine.
!This appliance is intended to be used in household and similar applications such as:
-Staff kitchen areas in shops, offices and other working environments;
-Farm houses;
-By clients in hotels, motels and other residential type environments;
-Bed and breakfast type environments.
Warning: To avoid a hazard due to instability of the appliance, it must be fixed according to the instructions.
-Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction
-Do not damage the refrigerant circuit.
ENGLISH

3
KNOW YOUR WATER DISPENSER
1. Water guard
2. Power switch
(hot water switch: brown button)
(cool water switch: green button)
3. Indicator lamps (hot / normal / cold)
4. Data plate
5. Cold water tap
6. Hot water tap
7. Drip tray
8. Drain plug
9. Electric power cord
Circuit illustration :
SPECIFICATIONS
Voltage
:
AC 220 – 240V / 50Hz
Wattage
:
470 – 560W
Cord
:
3-pin grounded plug (to reduce the risk of electric shock).
Water heating
capacity
:
≥905L / h
Water cooling capacity
:
≤10 2L / h
Cooling power
:
85W / 0.7A
Coolant
:
R134a, 23g

4
ENGLISH
CHARACTER
!Adopting international advanced technique, fancy & beautiful sculpt, luxury& decorous appearance.
!These products have the character of energy saving, low noise, firm & durable structure, good stability etc.
Especially suit to use in hotels, households, and schools etc.
!These products' plastic part are made by high grade's material, and have the character of legerity, innocuity,
durability etc.
!These products adopt double protection of "temperature control"& "heating protection", the water temperature is
always controlled between 80and 95, can meet the demands of people for drinking coffee or tea and having
instant food,etc.
!The water dispenser series adopt compressor cooling, the refrigeration's capability is extremely strong, they are
your best choice in summer.
!These series of products can be used together with water purifier and general pure water pot.
USING YOUR WATER DISPENSER
You must read all instructions before using.
!Remove all packing material and please check carefully, making sure that your Water Dispenser is in good condition.
It must have no damage to the cord/plug.
!When use this product, the water must pour from the hot tap, then you can insert plug and turn on the switch to heat.
The heat vessel will be damaged if no water inside when heat.
!When the water dispenser product is moved and used. Do not incline it over 45° otherwise the compressor will be
damaged.
!It’s necessary to place the dispenser on indoor flat floor, and maintain its distance more than 15cm from the wall.
!Keep this machine away from high temperature, and give it a dry, breezy, and shade place, forbid to place
dispenser in outdoor ,direct sunlight, rain.
!Children are forbidden to push or pull the hot(red) water tap.
!Pull out the power plug and drain out the water from drain stopper when the machine is disengaged for a long time.
!The water pot & pipeline should be cleaned when your first use or use it again after a long-term rest. If the condition
is permitted, they should be disinfected and sterilized, and draining out the first time's heating water(switch off the
heating switch in the process of draining.)
!Sterilizing the water dispenser with disinfector every 3-6months, when choosing disinfector. Please tell the
drugstore the disinfector purpose, and use it according to disinfector instruction.
!Don't pull the power wire constrainedly. Don't pull or put the plug to start or stop the machine.
!Don't clean the machine with water to avoid unexpected electric shock, you should clean it by soft cloth.
!If you go out for a long time or no need using at night, you can switch off power supply. The aim is to save energy
and avoid accident happen.
!Don't change the power cord set at random. If it is destroyed, please contact manufacturer directly.
!If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
!The appliance must be positioned so that the plug is accessible.
