Outback Meteor 4S User manual

MS4464H MS5664H
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and contact
your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
 For outdoor use only.
 Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
 Warning: accessible parts may be very hot. Keep young children away.
 Do not move the appliance during use.
 Turn off the gas supply at the gas bottle after use.
 Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
 Retain these instructions for future reference.
 Leak test annually, and whenever the gas bottle is removed or replaced. Check
the hose connections are tight and leak test each time you reconnect the gas
bottle.
 For Flare-up control please refer to the ‘OPERATION’ section of this manual.
Assembly and Operating Instructions for Outback®
Meteor 4S Gas Barbecue and Meteor 6S Gas Barbecue
2575 0359

2
 Pre-Assembled Component
 Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‗Hardware Reference Diagram‘.
CODE PART QTY Outback® Meteor 4S
Gas Barbecue Outback® Meteor 6S Gas Barbecue
HOOD
A1 Hood (Pre-Assembled to Body)1
A2 Hood Handle 1
A3 Warming Rack 1
A4 Heat Indicator 1
BODY
B1 Barbecue Body 1
B2 Burner 4 6
B3 Control Panel 1
B4 Knob 4 6
B5 Side Burner Valve, Hose and Regulator Assembly 1
B6 Flame Tamer 4 6
B7 Cooking Grill 2
B8 Drip Tray Left Bracket 1 
B9 Drip Tray Right Bracket 1 
B10 Drip Tray 1
B11 Drip Tray Handle 1 
TROLLEY
C1 Side Burner Shelf 1 
C2 Side Burner Shelf Panel 1 
C3 Side Burner Grid 1 
C4 Knob Bezel 1 
C5 Side Burner Knob 1 
C6 Side Burner 1 
C7 Side Shelf 1 
C8 Side Shelf Panel 1 
C9 Left Cabinet Panel Assembly 1 
C10 Right Cabinet Panel Assembly 1 
C11 Upper Support 1 
C12 Door Handle 2
C13 Left Door 1 
C14 Right Door 1 
C15 Bottom Panel 1 
C16 Balance Weight 1 
C17 Caster 2 
C18 Lockable Caster 2 
C19 Rear Panel 1 
HARDWARE
D1 M6x35 Bolt 8 
D2 M6x15 Bolt 20  
D3 ST4.0x10 Screw 21  
D4 M6 Nut 12  
D5 M4x10 Bolt 3 

3
Parts Diagram: Meteor 4S
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‗Hardware Reference Diagram‘.
A3
C18
C17
A2
C13 C14
B1
B3
A1
B5
B8 B9
B10
B11
A4
B7
B6
B2
B4
C11
C12
C9 C10
C7
C8
C1
C5
C2
C6
C3
C15
C19
C4

4
Parts Diagram: Meteor 6S
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‗Hardware Reference Diagram‘.
A2
B5
A4
B1
B3
A1
B2
B4
B7
B6
A3
C18
C17
C13 C14
C11
C12
C9 C10
C7
C8
C1
C5
C4
C2
C6
C3
C15
C19
C16
B8 B9
B10
B11

5
Hardware Reference Diagram
Specifications subject to change without prior notice.
D1
D2
D3 D4
D5
M6X35 BOLT 8PCS
M6X15 BOLT 20PCS
ST4.0X10 SCREW 21PCS
M6 NUT 12PCS
M4X10 BOLT 3PCS

6
Assembly
IMPORTANT!
 TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
 Remove any internal component or packaging from the barbecue body.
 Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
 Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Carefully turn the cabinet upside-down.
Attach the Casters (C17x2pcs) and Lockable Casters (C18x2pcs) onto the left/right
cabinet panels as shown. Ensure the lockable casters are installed on the rear side.
C17
C18
Attach the Left Cabinet Panel Assembly (C9) and Right Cabinet Panel Assembly (C10)
to the Bottom Panel (C15) using ST4.0x10 Screw (D3x6pcs), M6x35 Bolts (D1x8pcs)
and M6 Nuts (D4x8pcs) as shown.
C15
D3
C9 C10
D1 D4
Left cabinet panel
assembly
C18

7
Unscrew retaining bolts and retaining nuts from the Balance Weight (C16), then attach the
balance weight to the bottom panel using the bolts and nuts as shown.
3
4
C16
 Meteor 4S users skip this step and proceed directly to Step 4.
Attach the Rear Panel (C19) to the cabinet assembly using ST4.0x10 Screws (D3x7pcs)
as shown.
C19
D3

8
5
6
Attach the Upper Support (C11) to the front legs using M6x15 Bolts (D2x4pcs).
Carefully turn the assembled cabinet right side up.
Attach the Drip Tray Left Bracket (B8) to the Left legs using ST4.0x10 Screws (D3x2pcs) as
shown. Repeat above process for the Drip Tray Right Bracket (B9).
B8
B9 D3
C11 D2
D2

9
7
8
Fit the doors to the cabinet by depressing the spring pins and placing into the cabinet.
Unscrew the retaining bolts from one Door Handle (C12), then attach the door handle onto the
Left Door (C13) using the retaining bolts as shown. Repeat above process to install the other
door handle onto the Right Door (C14).
C12
C13

10
9
10
Carefully place the Barbecue Body (B1) onto the the cabinet structure and fix it using M6x15
Bolts (D2x4pcs) as shown.
Attach Side Shelf Panel (C8) onto Side Shelf (C7) using M6x15 Bolts (D2x2pcs) and M6 Nut
(D4x2pcs) as shown.
D2
C7
C8
D2
D4
