Outback Meteor 4 User manual

0359
Assembly and Operating Instructions for Outback®
Meteor 4 Burner Gas BBQ
Drawings are not to scale.
Specifications subject to change
without prior notice.
WARNING
 For outdoor use only. Not for commercial use.
 Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
 Warning: accessible parts may be very hot. Keep young children and pets away.
 Do not move the appliance during use.
 Turn off the gas supply at the gas bottle after use.
 Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
 Retain these instructions for future reference.
 Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
 For Flare-up control please refer to the ‘OPERATION’ section of this manual.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
MS4431CD

2
CODE PART QTY Outback® Meteor 4 Burner
Gas BBQ
HOOD
A1 Hood (Pre-Assembled to Body) 1 
A2 Hood Handle 1 
A3 Warming Rack 1 
BODY
B1 Barbecue Body 1 
B2 Burner 4 
B3 Control Panel 1 
B4 Knob 4 
B5 Hose and Regulator Assembly 1 
B6 Flame Tamer 4 
B7 Cooking Grill 2 
B8 Drip Tray Left Bracket 1 
B9 Drip Tray Right Bracket 1 
B11 Charcoal Basket 1 
TROLLEY
C1 Side Burner Shelf 1 
C2 Side Burner Shelf Panel 1 
C3 Side Burner Grid 1 
C4 Knob Bezel 1 
C5 Side Burner Knob 1 
C6 Ignition Button 1 
C7 Side Burner 1 
C8 Side Shelf 1 
C9 Side Shelf Panel 1 
C10 Left Front Leg 1 
C11 Left Rear Leg 1 
C12 Right Front Leg 1 
C13 Right Rear Leg 1 
C14 Upper Support 1 
C15 Storage Box Handle 1 
C16 Storage Box 1 
C17 Front Panel 1 
C18 Side Panel 4 
C19 Bottom Panel 1 
C20 Wheel 2 
C21 Wheel Hubcap 2 
C22 Axle 1 
C23 Body Support A 2 
C24 Body Support B 2 
HARDWARE
D1 ST4.0x10 Screw 28 
D2 M4x10 Bolt 3 
D3 M4x10 Step Bolt 4 
D4 M6x15 Bolt 16 
D5 M6x40 Bolt 16 
D6 M6 Nut 12 
D7 Locknut 2 
B10 Drip Tray 1 
 Pre-Assembled Component
 Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.

3
Parts Diagram
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
A2
A3
B1
B2
B4
B6
B7
B8 B9
C1
C18
C14
C3
C21 C19
C15
C22
C9
C7
C2
C5
C4
C20
C16
C17
C13C11
B3
A1
C8
D7
B5
C12
C10
C23 C24
C6
B10
B11

4
Hardware Reference Diagram
Specifications subject to change without prior notice.
D1
D2
D3
D4
D5
D6
D4
D6

5
Assembly
IMPORTANT!
 TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
 Remove any internal component or packaging from the barbecue body.
 Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
 Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Attach the Left Legs (C10,C11) to the Side Panels (C18x2pcs) using ST4.0x10 Screws
(D1x8pcs) as shown.
Attach the Right Legs (C12,C13) to the Side Panels (C18x2pcs) using ST4.0x10 Screws (D1x8pcs)
as shown.
Left Cabinet Panel Assembly
Right Cabinet Panel Assembly
C10
C11
D1
C18
C13
C12
D1
C18

6
3
4
Attach the left / right cabinet panel assembly to the Bottom Panel (C19) using M6x40 Bolts
(D5x8pcs) and M6 Nuts (D6x8pcs) as shown.
Unscrew the Locknuts (D7) from both ends of the Axle (C22).
Slide the axle through the corresponding holes in the left legs. Slide the Wheels (C20) over each
end of the axle. Secure the wheels into place with the locknuts. Place the wheel Hubcaps (C21)
onto the outsides of the wheels.
C19
C20
D7
C21

7
Attach Drip Tray Left Bracket (B8) to the left legs using ST4.0x10 Screws (D1x2pcs) as shown.
Repeat above process for Drip Tray Right Bracket (B9).
Install Front Panel (C17) between left / right front legs using ST4.0x10 Screws (D1x4pcs).
5
6
C17
NOTE: Please Ignore Holes at
Base of Front Panel(C17) No
Screws are Required.
B8 B9

8
Remove the retaining bolts from Storage Box Handle (C15), and then attach it onto Storage Box
(C16) using the retaining bolts.
7
8
Install the storage box assembly between left / right front legs using M4x10 Step Bolts (D3x4pcs).

9
9
10
Attach the Upper Support (C14) to the front legs using M6x15 Bolts (D4x4pcs).
C14
Remove the retaining bolts from legs, and then attach Body Support A (C23) onto the left rear
leg and right front leg and attach Body Support B (C24) onto the right rear leg and left front
leg using the retaining bolts.
e
e f
f
f
e C23
C24

10
11
12
Carefully place the Barbecue Body (B1) onto the cabinet structure and fix using M6x40 Bolts (D5x8pcs)
as shown.
Attach Side Burner Shelf Panel (C2) onto Side Burner Shelf (C1) using M6x15 Bolts (D4x2pcs)
and M6 Nuts (D6x2pcs).
C2
C1
D4
D6
