Outback Omega 100 User manual

Assembly and Operating Instructions for
Outback® Omega 100, Omega 200, and Omega 300 Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice. 0359
EN (Europe)
Omega 100 Omega 300Omega 200
WARNING
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children and pets away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
Retain these instructions for future reference.
Leak test annually, and whenever the gas bottle is removed or replaced. Check
that the hose connections are tight and leak test each time you reconnect the gas
bottle.
For Flare-up control please refer to the ‘OPERATION’ section of this manual.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.

2
CODE PART QTY OUTBACK®
OMEGA 100
OUTBACK®
OMEGA 200
OUTBACK®
OMEGA 300
Hood
A1 Hood (Pre-Assembled to Body) 1   
A2 Hood Handle 1   
A3 Upper Hinge Bracket 2   
A4 Warming Rack  1
Body
B1 Barbecue Body 1   
B2 Burner 1   
B3 Control Panel 1   
B4 Knob 2   
B5 Hose (if supplied) 
B6 Main Electrode 1   
B7 Gas Collector Box 1   
B8 Ignition Button 1   
B9 Lower Hinge Bracket 2   
B10 Cooking Grill 1 
B11 Lava Rock in Basket / Flame Tamer 1   
B12 Grease Cup Holder 1   
B13 Grease Cup 1   
B14 Arch Support 2   
B15 Body Handle 1
Trolley
C1 Side Burner Knob 1
C2 Side Burner Grid 1
C3 Side Burner Shelf 1
C4 Side Burner 1
C5 Side Burner Electrode 1
C6 Side Shelf 2 1
C7 Left Front Leg 1   
C8 Left Rear Leg 1   
C9 Right Front Leg 1   
C10 Right Rear Leg 1   
C11 Leg Endcap 2   
C12 Screen 1   
C13 Long Support Rod 2
C14 Short Support Rod 2
C15 Bottom Shelf  1 1
C16 Short Axle 2   
C17 Wheel 2   
C18 Hubcap 2   
Hardware
D1 ST4.0x10 Screw 2   
D2 M5x10 Bolt 2   
D3 M6x15 Bolt 4
D4 M6x25 Bolt 4 
D5 M6x30 Bolt 4   
D6 M6x40 Bolt 8 8
D7 M6x50 Bolt 4 
D8 Axle Clip 2   
D9 M6 Nut  4 20 20
D10 Shelf Spacer 8 8
D11 Shelf Washer 8 8
1. Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased

3
2.1. Parts Diagram: Omega 100
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
Pre-assembled body unit includes
the following individual parts:
B10
B11
A2
B12
B13
B15
C12
C13 C14
C18 C17
C8 C10
C11
B5
C16
D8
or
A1 A3 B1 B2
B7
B3 B4
B9
D1
D2B8
B6
B14
C7 C9

4
2.2. Hardware Reference Diagram: Omega 100
Specifications subject to change without prior notice.
C16
D8
D3
D7
D4, D9 D5

5
3.1. Parts Diagram: Omega 200
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
C15
Pre-assembled body unit includes
the following individual parts:
A2
B5
or
A1 A3 B1 B2
B7
B3 B4
B9
D1
D2B8
B6
B14
B12
B13
C12
C18 C17
C11
C16
D8
C6
B10
B11
C8 C10
C7 C9

6
3.2. Hardware Reference Diagram: Omega 200
Specifications subject to change without prior notice.
C16
D8
D4, D9 D5, D9
D6, D9, D10, D11
D7, D9

7
4.1. Parts Diagram: Omega 300
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
C15
B10
B11
A2
B12
B13
B5
C3
C4
C5
C12
C11
C6
C2
C18 C17 C16
D8
or
Pre-assembled body unit includes
the following individual parts:
A1 A3
A4
B1 B2 B3
B4
D1
D2
B8
B6 B7
B9 B14
C1
C8 C10
C7 C9

8
4.2. Hardware Reference Diagram: Omega 300
Specifications subject to change without prior notice.
C16
D8
D4, D9 D5, D9
D6, D9, D10, D11
D7, D9

9
5. Assembly
IMPORTANT!
TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
The assembly of this barbecue requires 2 people.
Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
Please read the Important Information section carefully before assembly and use of your
barbecue.
2
CAUTION! Care must be taken to ensure the hood or lid does not fall open unexpect-
edly or becomes damaged when it is set on the ground.
1  Omega 100  Omega 200  Omega 300
 Omega 100  Omega 200  Omega 300
C8
C10
C8
Omega 100 and Omega 200 Omega 300
or
NOTE: The warming rack is not supplied for Omega 100 and Omega 200
C10

10
Ensure that the legs with the Velcro attached to them are at the front of the
barbecue, facing inwards.
3
4
 Omega 100  Omega 200  Omega 300
 Omega 100  Omega 200  Omega 300
Omega 100 and Omega 200 Omega 300
C7
C9 C9
D4
D9
D4
D9
D4
D9
D4
D9
D4
D9
D4
D9
D4
D9
D4
D9
Omega 100 and Omega 200 Omega 300
C7
