Outback Meteor Select 3 Burner Gas BBQ MH3330 User manual

0359
Assembly and Operating Instructions for Outback®
Meteor Select 3 Burner Gas BBQ
Drawings are not to scale.
Specifications subject to change
without prior notice.
WARNING
• For outdoor use only. Not for commercial use.
• Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
• Warning: accessible parts may be very hot. Keep young children and pets away.
• Do not move the appliance during use.
• Turn off the gas supply at the gas bottle after use.
• Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
• Retain these instructions for future reference.
• Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
• For Flare-up control please refer to the ‘OPERATION’ section of this manual.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
MH3330

2
CODE PART QTY Outback® Meteor Select 3
Burner Gas BBQ
HOOD
A1 Hood (Pre-Assembled to Body) 1 
A2 Hood Handle 1 
A3 WarmingRack 1 
BODY
B1 Barbecue Body 1 
B2 Burner 3 
B3 Control Panel 1 
B4 Knob 3 
B5 Hose and Regulator Assembly 1 
B6 Lava Rock in Basket 1 
B7 Cooking Grill 1 
B8 Cooking Griddle 1 
B9 Drip Tray Left Bracket 1 
B10 Drip Tray Right Bracket 1 
B11 Drip Tray 1 
B12 Drip Pan 1 
B13 Ignition Button 1 
TROLLEY
C1 Side Shelf 2 
C2 Left Side Shelf Panel 1 
C3 Right Side Shelf Panel 1 
C4 Left Leg 2 
C5 Right Leg 2 
C6 Front Upper Panel 1 
C7 Front Lower Panel 1 
C8 WireBase 1 
C9 Wheel 2 
C10 Wheel Hubcap 2 
C11 Axle 1 
HARDWARE
D1 ST4.0x10 Screw 10 
D2 M5x15 Bolt 4 
D3 Ø5 Washer 4 
D4 M5 Nut 4 
D5 M6x15 Bolt 12 
D6 M6x65 Bolt 12 
D7 Ø6 Washer 4 
D8 M6 Nut 8 
D9 Locknut 2 
Pre-Assembled Component
Quantity varies according to model purchased
 Appearance, size, and construction may differ according to model purchased
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.

3
Parts Diagram
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
A3
B5
B9 B10
B11
C8
C11
C3
C2
C9
C6
C7
C5
B12
C4
B3
A2
A1
C1
D9
B7 B8
B6
C10
B2
B1
B4
B13

4
Hardware Reference Diagram
Specifications subject to change without prior notice.
D6
D7 D8
D5 D1
D5
D6
D8 D3 D4D2

5
Assembly
IMPORTANT!
• TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
• Remove any internal component or packaging from the barbecue body.
• Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
• Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Attach the Legs (C4,C5) to the Panels (C6,C7) using ST4.0x10 Screws (D1x8pcs) as shown.
Attach the front panel assembly and the Legs (C4,C5) to the Wire Base (C8) by inserting the
M6x65 Bolts (D6x4pcs) through the legs, wire base, Ø6 Washers (D7x4pcs) and secure with M6
Nuts (D8x4pcs). Ensure that the holes in the top of each leg which to fix barbecue body are in the
front of the side.
Rear view
Front view
C5C4
C6
C7
D1
C8
D8
D7
D6
C4C5

6
3
4
C9C11
D9
Unscrew the Locknuts (D9) from both ends of the Axle (C11).
Slide the axle through the corresponding holes in the left legs. Slide the Wheels (C9) over each
end of the axle. Secure the wheels into place with the locknuts. Place the Wheel Hubcaps
(C10) onto the outside of the wheels.
Lay the assembled trolley on its side. Lay the Barbecue Body (B1) on its back and slide into
position between the trolley legs.
CAUTION! Care must be taken to ensure the hood or lid does not fall open unexpectedly
or becomes damaged when it is set on the ground.
Insert the M6x65 Bolts (D6x8pcs) through the guide holes of each leg and screw into barbecue
body tightly.
D6
C10

7
5
6
Attach the Left Side Shelf Panel (C2) onto one Side Shelf (C1) using M6x15 Bolts (D5x2pcs) and
M6 Nuts (D8x2pcs).
C2
C1
D5
D5
D1
Attach the left side shelf assembly to the barbecue body using a ST4.0x10 Screw (D1) and
M6x15 Bolts (D5x4pcs) as shown.
D8

8
7
8
Attach the Right Side Shelf Panel (C3) onto the other Side Shelf (C1) using M6x15 Bolts
(D5x2pcs) and M6 Nuts (D8x2pcs).
C3
C1 D5
D5
D1
D8
Attach the right side shelf assembly to the barbecue body using a ST4.0x10 Screw (D1) and
M6x15 Bolts (D5x4pcs) as shown.

9
9
10
Attach the Drip Tray Right Bracket (B10) to the barbecue body using M5x15 Bolts (D2x2pcs),
Ø5 Washers (D3x2pcs) and M5 Nuts (D4x2pcs) as shown. Repeat the above process for the
Drip Tray Left Bracket (B9).
NOTE: Ensure that the big tabs of the brackets which stop the drip tray are located at
the front of the barbecue.
B10 D3
Insert the Drip Tray (B11) by sliding it underneath the barbecue body. Insert the Drip Pan
(B12) into position.
D2
B12
B11

10
11
12
Carefully lay the Lava Rock (B6) into the barbecue body ensuring it lies level within the body.
Lay the Grill (B7) and Griddle (B8) into place.
Configuration: Left — Cooking Grill, Right — Cooking Griddle
NOTE: Ensure that the lava rock lies directly underneath the grills.
Attach the Warming Rack (A3) to barbecue body as shown.
B7 B8
B6
A3
