Outdoor Router EZR33 Series User manual

PACKAGE CONTENTS
PACKUNGSINHALT
Outdoor Router
Außen-Router
4G & Wi-Fi Antennas
Rundum-Antennen
10-Meter LAN Cable
LAN-Kabel 32,8-Fuß
PLUG
for UK / EU
/ US / AU
L-Bracket & T-Wrench
Halterung & Schlüssel
PoE Injector
PoE-Injektor 48Volt
Mounting Kit
Montagesatz für außen
Check and count the package contents.
INTERFACE OVERVIEW
PORTS & SCHNITTSTELLEN AM ROUTER
4G ANTENNA
MAIN
4G ANTENNA
2.4G ANTENNA
BREATHER VALVE
OPEN THE ENCLOSURE
Use hexagon head on the
T-wrench to lose bolts in
anti-clockwise direction
CLOSE THE ENCLOSURE
Use T-wrench to tighten
bolts in clockwise direction
HEXAGON
BOLT
LOCKHOLE
ARE EMBOSSED NUMBERS
ON THE ENCLOSURE
~
2.4G
ANTENNA
CROSS
5MM HEX
5MM HEX
T-WRENCH
GLAND
1
1
3
4
5
6
6
STEP 1.1
STEP 1.2
STEP 2.4
EZR33.OutdoorRouter.com/v/33l
Scannen Sie den QR-Code oder besuchen Sie den URL-Link,
um die vollständige Ausgabe des Online-Handbuchs zu sehen.
Scan QR code or visit URL link to see the
complete edition of the online manual.
EZR33 SERIES QUICK GUIDANCE
EZR33 SERIE SCHNELLLEITUNG

RESET WAN
INPUT
BARREL
PoE
SIM CARD
ANTENNAS
STOPPER
RJ45 CONNECTOR
PoE INJECTOR
CAP
Smaller
SIM-CARD TRAY
PIN
PINHOLE
PoE
48V
INPUT
LAN
OUTPUT
DC POWER
9~48VOLT
(UP)
SYSTEM
WI-FI
FOR NANO-SIM
0.5” x 0.3”
LAN CABLE
LAN CABLE
AC PLUG
PUSH
BUTTON
MOTHERBOARD | SIM CARD & PoE
HAUPTPLATINE | SIM-KARTE UND PoE
SIM1 (UP )
SIM2
SIM2
SIM1
TURN OFF POWER BEFORE
INSERTING THE SIM CARD
* WARNINGS *
Use activated SIM card in the router *
Make sure the SIM card is working well *
Insert SIM card in the SIM1 slot *
Use the pin to push the pinhole
until the SIM card tray pops out
Insert a SIM card in the SIM1 slot
Reposition the SIM card tray
in the slot and push it back
1.
2.
3.
4.
5.
6.
7.
Take cap off from the gland.
Push out the stopper from
the inside of the gland.
Take one end of the LAN
cable through the cap.
Put LAN cable through
the barrel screw and plug
in the PoE & LAN port on
the motherboard.
Clamp the stopper on the LAN
cable and settle it in the barrel.
Turn the cap in the clockwise
direction to tighten it on the
barrel screw.
Connect another end of the
LAN cable to PoE port on the
PoE injector.
Connect AC plug on the PoE
injector to electrical outlet until
set up all the below steps (to 3.3).
NOTE
To exchange the AC plug, press and
hold the Push button then push the
AC plug upword to take it off.
i.
ii.
.1
.2
.3
PoE & LAN
PORT
LAN CABLE
Connect a computer to the
LAN port on the PoE injector
to get the Ethernet connection.
To use another router, connect its WAN
port to the LAN port on the PoE injector.
Close the lid & press it with your hand.
Use T-wrench to tighten four pieces
hexagon bolts on the lid.
Ensure no gap after tightening the screws!
8. ETHERNET
* The smaller end faces the outside.
STEP 2.1
STEP 2.2
STEP 2.5
STEP 2.4
STEP 2.3
4
2
5
6
3
Make sure the mobile carrier has
a strong enough signal in your area
The modem sensitivity is -101dBm
equals to approx. 2-bar on a phone
Refer to https://ezen.link/signal-test
Locate embossed numbers
1~6 on the top & bottom sides
1 & 3 for 4G antennas
4 & 6 for Wi-Fi antennas
Turn the hex part on the
antennas in the clockwide
direction to tighten them
BRACKET & MOUNTING
HALTERUNG UND BEFESTIGUNG
FIRMWARE CONFIGURATION
FIRMWARE KONFIGURATION
Walk around with a mobile phone and check the network type and signal bars.
Then choose a location with a 4G LTE network reception and strong signal reception.
After turning on power (step 2.3.7), use a phone or computer to join the Wi-Fi hotspot
Outdoor-WiFi-xxx or connect the computer to the LAN port on the PoE injector (step 2.3.8).
Open a web browser, enter the router IP
http://192.168.30.1 on the address bar.
Click the Login button to access the admin panel.
Use the cross end on T-wrench and M6 cross-head screws to
install the L-shape bracket on the backside of the enclosure.
Find a pole with diameter of Ø35~50mm.
1.
2.
Clasp the pole with U-bolts and holders, attach them on
either side of the L-shape bracket.
On another side of the bracket, put washers, spring washers,
and hex nuts on U-bolts. Tighten the nuts with an M10 spanner.
** Turn the bracket to be parallel with the pole if it's horizontal.
WASHER
SPRING WASHER
WASHER
SPRING WASHER
HEX NUT
U-BOLT HOLDER
HEX NUT
HOLDER
U-BOLT
INSTALL ON A POLE
http://192.168.30.1
AUTHORIZATION REQUIRED
Please enter your router password!
Password Login
Default has no password!
If unable to access, recheck the Wi-Fi and LAN
connections and clean the web browser cache.
*
POLE IS EXCLUDED
STEP 3.1
STEP 3.2
STEP 3.3
STEP 4.1

After accessing the router admin panel, navigate to System > System from the top menu.
Under the tab of General Settings, click the Sync with browser button to sync the time.
Go to System > Administration, input new custom router password twice, and save settings.
*Keep the new password in a safe place.
Go to Network > Wireless, click the Edit button on SSID: Outdoor-WiFi-xxx (Mode: Master).
Scroll down to Interface Configuration, change Wi-Fi SSID on ESSID field.
Click the tab of Wireless Security, choose WPA-PSK/WPA2-PSK on Encryption.
Input the Wi-Fi password on the Key field, then save settings.
It will use 1-2 minutes to reboot the Wi-Fi hotspot.
On the front page, check the modem status and the signal strength on the
right-side DEVICE section.
Go to Network > Interfaces, check the IP and traffic flow of the MOBILE interface.
It is non-necessary to change APN unless the mobile carrier requires to do so.
Click the Edit button on the MOBILE. Tap the Primary SIM1 (or SIM2) tab to change APN.
* Check the APN tutorial on https://ezen.link/APN.
It is also not necessary to change the protocol unless default one is no supported.
* Check the protocol tutorial on https://ezen.link/protocol.
Turn on DHCP mode on the phone or computer to obtain a local IP address from the
4G router. To use a static IP address, please comply with the below format.
Computer IP
Subnet mask
Gateway (Router IP)
192.168.30.100~249 ( pick one IP from 100~249 )
255.255.255.0 ( 24 on Windows )
192.168.30.1
Status
Disabled
Connection attempt failed
Network device is not present
Connected but no internet
Solution
Check if the SIM card is locked.
Re-insert the SIM card and check the signal strength.
The Guardian module is resetting. Wait for 2-3 minutes.
Check if the data plan supports use on a 4G router.
1. Status
2. Interface
3. APN
4. Protocol
MOBILE MODEM
LOCAL NETWORKS
The router might have glitches after running for days or weeks.
Reboot the router could solve most of the issues.
You may go to System > Reboot or unplug the PoE injector to reboot the router.
If the router works unstable after made changes to the firmware, please go to
System > Backup / Flash Firmware. Click the Perform reset button to run a soft reset.
If unable to access the router admin panel, please run a hard reset.
When the device is powered on, tap and hold the round Reset button for 5 seconds.
Then release it and wait for 4 minutes to boot up.
! IMPORTANT ! DO NOT TURN OFF POWER WHILE RESETTING THE ROUTER!
Thanks for reading! If you have questions while using the router,
please check the online manual at ezr33.outdoorrouter.com/v/33l
Please feel free to contact us if you need any further assistance.
RECOVERY
5. Debug
STEP 4.5
STEP 4.6
STEP 4.2
STEP 4.3
Router
password
Wi-Fi SSID
& password
Reboot
Soft
Reset
Hard
Reset
STEP 4.4
OutdoorRouter
www.outdoorrouter.com
Feel free to contact us if you need any further assistance.
Call Us
United Kingdom
United States
Australia
Send An E-Mail
[e-mail]
[phone]
[phone]
[phone]
Wenn Sie weitere Unterstützung benötigen, können Sie uns gerne kontaktieren.
WORKING PRINCIPLE
WIE FUNKTIONIERT EIN 4G-ROUTER?
Mobile
Internet
Cell
Tower
Wi-Fi & Ethernet
Secondary
Router
EZR33
Outdoor
4G Router

FCC Statement
FCC Statement
This device comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
●
This device does not cause harmful interference.
●
This device must accept any interference received, including interference that may cause undesired
operation.
If this device is modified without authorization from Ezen, the device may no longer comply with FCC
requirements for Class B digital devices. In that a case, your right to use the device may be limited by
FCC regulations. Moreover, you may be required to correct any interference to radio or television
communications at your own expense.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This device generates, uses and radiates radio frequency energy. If it is not installed and used in
accordance with the instructions, it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device
does cause harmful interference to radio or television reception, which can be determined by turning
the device off and on, the user may take one or more of the following measures:
●
Reorient or relocate the receiving antenna.
●
Reinforce the separation between the device and receiver.
●
Connect the device into an outlet on a circuit different from that to which the receiver is connected.
●
Consult the dealer or an experienced radio or TV technician for assistance.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. This equipment should be installed and operated with a minimum distance of
20 centimeters between the radiator and your body.
The device contains LTE Module: EC25-AF (Contains FCC ID: XMR201808EC25AF).
