LevelOne NetCon WBR-3408 User manual

LevelOne
WBR-3408
User Manual
11g Wireless Broadband Router
(Roteador banda-larga sem fio- Wireless G)
Ver. 3.000

Safety
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifica-
tions to this equipment may cause harmful interference unless the modifications are
expressly approved in the instruction manual. The user could lose the authority to
operate this equipment if an unauthorized change or modification is made.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfe-
rence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
CE Declaration of conformity
This equipment complies with the requirements relating to electromagnetic compa-
tibility, EN 55022 class B for ITE, the essential protection requirement of Council
Directive 89/336/EEC on the approximation of the laws of the Member States
relating to electromagnetic compatibility.
CE Marking Warning
Hereby, Digital Data Communications, declares that this (Model-no. WBR-3408) is
in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
The CE-Declaration of Conformity can be downloaded at:
http://www.levelone.eu/support.php

General Public License
This product incorporates open source code into the software and therefore falls
under the guidelines governed by the General Public License (GPL) agreement.
Adhering to the GPL requirements, the open source code and open source license
for the source code are available for free download at http://global.level1.com.
If you would like a copy of the GPL or other open source code in this software on a
physical CD medium, LevelOne (Digital Data Communications) offers to mail this
CD to you upon request, for a price of US$9.99 plus the cost of shipping.

Table of Contents
CHAPTER 1 INTRODUCTION........................................................................................ 6
Wireless Router Features............................................................................................ 6
Package Contents ...................................................................................................... 10
Physical Details.......................................................................................................... 11
CHAPTER 2 INSTALLATION....................................................................................... 13
Requirements............................................................................................................. 13
Procedure................................................................................................................... 13
CHAPTER 3 SETUP......................................................................................................... 15
Overview .................................................................................................................... 15
Configuration Program............................................................................................. 17
Setup Wizard ............................................................................................................. 18
Home Screen .............................................................................................................. 20
LAN Screen................................................................................................................ 21
Mode Screen............................................................................................................... 23
Wireless - Options Screen......................................................................................... 24
Wireless - Schedule.................................................................................................... 26
Wireless - MAC Filter............................................................................................... 27
Wireless - MAC Filter - Trusted Wireless Stations................................................ 28
Wireless - WiFi Protected Setup (WPS) .................................................................. 30
Wireless - Wireless Distribution System (WDS)..................................................... 32
Wireless Security....................................................................................................... 34
Password Screen........................................................................................................ 39
CHAPTER 4 PC CONFIGURATION............................................................................. 40
Overview .................................................................................................................... 40
Windows Clients........................................................................................................ 40
Macintosh Clients...................................................................................................... 51
Linux Clients.............................................................................................................. 52
Other Unix Systems................................................................................................... 52
Wireless Station Configuration................................................................................ 53
Wireless Configuration on Windows XP................................................................. 53
CHAPTER 5 OPERATION AND STATUS ................................................................... 63
Operation - Router Mode ......................................................................................... 63
Status Screen.............................................................................................................. 63
Connection Status - PPPoE....................................................................................... 66
Connection Status - PPTP......................................................................................... 67
Connection Status - L2TP......................................................................................... 68
Connection Details - Dynamic IP Address............................................................... 69
Connection Details - Fixed IP Address.................................................................... 70
CHAPTER 6 ADVANCED FEATURES......................................................................... 71
Overview .................................................................................................................... 71
Internet....................................................................................................................... 71
Dynamic DNS (Domain Name Server)..................................................................... 74
Options ....................................................................................................................... 76
Schedule...................................................................................................................... 77
Port Trigger ............................................................................................................... 79
Single Port Forwarding............................................................................................. 81
Port Range Forwarding............................................................................................ 83
QoS.............................................................................................................................. 84
CHAPTER 7 ADVANCED ADMINISTRATION.......................................................... 86
Overview .................................................................................................................... 86

PC Database............................................................................................................... 87
Config File.................................................................................................................. 90
Logs............................................................................................................................. 91
E-Mail......................................................................................................................... 93
Diagnostics ................................................................................................................. 95
Remote Administration............................................................................................. 96
Routing....................................................................................................................... 98
Upgrade Firmware.................................................................................................. 102
CHAPTER 8 ACCESS POINT MODE......................................................................... 103
Overview .................................................................................................................. 103
Management Connections....................................................................................... 103
Mode Screen............................................................................................................. 104
Operation ................................................................................................................. 104
APPENDIX A TROUBLESHOOTING ........................................................................ 105
Overview .................................................................................................................. 105
General Problems.................................................................................................... 105
Internet Access......................................................................................................... 105
Wireless Access........................................................................................................ 106
APPENDIX B ABOUT WIRELESS LANS .................................................................. 108
Modes ....................................................................................................................... 108
BSS/ESS.................................................................................................................... 108
Channels................................................................................................................... 109
WEP.......................................................................................................................... 109
WPA-PSK ................................................................................................................ 109
WPA2-PSK .............................................................................................................. 110
WPA-802.1x............................................................................................................. 110
Wireless LAN Configuration.................................................................................. 111
APPENDIX C SPECIFICATIONS................................................................................ 112
Multi-Function Wireless Router ............................................................................ 112
Wireless Interface.................................................................................................... 112

6
Chapter 1
Introduction
This Chapter provides an overview of the Wireless Router's features
and capabilities.
Congratulations on the purchase of your new Wireless Router. The Wireless Rou-
ter is a multi-function device providing the following services:
Shared Broadband Internet Access for all LAN users.
Wireless Access Point for 802.11b and 802.11g Wireless Stations.
4-Port Switching Hub for 10BaseT or 100BaseT connections.
Installation
Wireless Router Features
The Wireless Router incorporates many advanced features, carefully designed to
provide sophisticated functions while being easy to use.
Internet Access Features
Shared Internet Access. All users on the LAN or WLAN can access the
Internet through the Wireless Router, using only a single external IP Address.
The local (invalid) IP Addresses are hidden from external sources. This
process is called NAT (Network Address Translation).
DSL & Cable Modem Support. The Wireless Router has a 10/100BaseT
Ethernet port for connecting a DSL or Cable Modem. All popular DSL and Ca-
ble Modems are supported.
PPPoE, PPTP and L2TP Support. The Internet (WAN port) connection
supports PPPoE (PPP over Ethernet), PPTP (Peer-to-Peer Tunneling Protocol)
and L2TP, as well as "Direct Connection" type services.
Fixed or Dynamic IP Address. On the Internet (WAN port) connection,
the Wireless Router supports both Dynamic IP Address (IP Address is allo-
cated on connection) and Fixed IP Address.
1

Introduction
7
Advanced Internet Functions
Application Level Gateways (ALGs). Applications which use non-
standard connections or port numbers are normally blocked by the Firewall.
The ability to define and allow such applications is provided, to enable such ap-
plications to be used normally.
Port Triggering. This feature, also called Special Applications, allows you to
use Internet applications which normally do not function when used behind a
firewall.
Port Forwarding. This feature allows Internet users to access Internet
servers on your LAN. The required setup is quick and easy.
Virtual Servers. This feature allows Internet users to access Internet servers
on your LAN. The required setup is quick and easy.
Dynamic DNS Support. DDNS, when used with the Virtual Servers feature,
allows users to connect to Servers on your LAN using a Domain Name, even if
you have a dynamic IP address which changes every time you connect.
URL Filter. Use the URL Filter to block access to undesirable Web sites by
LAN users.
Access Control. Using the Access Control feature, you can assign LAN
users to different groups, and determine which Internet services are available
to each group.
Scheduling. Both the URL Filter and Firewall rules can be scheduled to
operate only at certain times. This provides great flexibility in controlling Internet
-bound traffic.
Logs. Define what data is recorded in the Logs, and optionally send log data
to a Syslog Server. Log data can also be E-mailed to you.
QoS Support Quality of Service can be used to handle packets so that more
important connections receive priority over less important one.
Wireless Features
Standards Compliant. The Wireless Router complies with the
IEEE802.11g (DSSS) specifications for Wireless LANs.
Multi SSIDs Support. This feature can let you have 2 SSIDs on one AP,
which provides more easy way for Guest access and also secure your resource
at the same time.
WEP support. Support for WEP (Wired Equivalent Privacy) is included. Key
sizes of 64 Bit and 128 Bit are supported. WEP encrypts any data before
transmission, providing protection against snoopers.
WPA-PSK support. Like WEP, WPA-PSK encrypts any data before trans-
mission, providing protection against snoopers. The WPA-PSK is a later
standard than WEP, and provides both easier configuration and greater securi-
ty than WEP.
WPA2-PSK support. Support for WPA2 is also included. WPA2 uses the
extremely secure AES encryption method.
802.1x Support. Support for 802.1x mode is included, providing for the
industrial-strength wireless security of 802.1x authentication and authorization.
Wireless MAC Access Control. The Wireless Access Control feature can
check the MAC address (hardware address) of Wireless stations to ensure that
only trusted Wireless Stations can access your LAN.

Introduction
8
Simple Configuration. If the default settings are unsuitable, they can be
changed quickly and easily.
WPS Support. WPS (Wi-Fi Protected Setup) can simplify the process of
connecting any device to the wireless network by using the push button confi-
guration (PBC) on the Wireless Access Point, or entering a PIN code if there's
no button.
WDS Support. Support for WDS (Wireless Distribution System) allows the
Wireless Access Point to act as a Wireless Bridge. Both Point-to-Point and
Multi-Point Bridge modes are supported.
LAN Features
4-Port Switching Hub. The Wireless Router incorporates a 4-port
10/100BaseT switching hub, making it easy to create or extend your LAN.
DHCP Server Support. Dynamic Host Configuration Protocol provides a
dynamic IP address to PCs and other devices upon request. The Wireless
Router can act as a DHCP Server for devices on your local LAN and WLAN.
Configuration & Management
Easy Setup. Use your WEB browser from anywhere on the LAN or WLAN
for configuration.
Configuration File Upload/Download. Save (download) the configuration
data from the Wireless Router to your PC, and restore (upload) a previously-
saved configuration file to the Wireless Router.
Remote Management. The Wireless Router can be managed from any PC
on your LAN or Wireless LAN. And, if the Internet connection exists, it can also
(optionally) be configured via the Internet.
Network Diagnostics. You can use the Wireless Router to perform a Ping
or DNS lookup.
UPnP Support. UPnP (Universal Plug and Play) allows automatic discovery
and configuration of the Wireless Router. UPnP is supported by Windows ME,
XP, or later.

Introduction
9
Security Features
Password - protected Configuration. Password protection is provided to
prevent unauthorized users from modifying the configuration data and settings.
Wireless LAN Security. WPA-PSK, WEP and Wireless access control by
MAC address are all supported. The MAC-level access control feature can be
used to prevent unknown wireless stations from accessing your LAN.
NAT Protection. An intrinsic side effect of NAT (Network Address Transla-
tion) technology is that by allowing all LAN users to share a single IP address,
the location and even the existence of each PC is hidden. From the external
viewpoint, there is no network, only a single device - the Wireless Router.
Firewall. All incoming data packets are monitored and all incoming server
requests are filtered, thus protecting your network from malicious attacks from
external sources.
Protection against DoS attacks. DoS (Denial of Service) attacks can
flood your Internet connection with invalid packets and connection requests, us-
ing so much bandwidth and so many resources that Internet access becomes
unavailable. The Wireless Router incorporates protection against DoS attacks.

Introduction
10
Package Contents
The following items should be included. If any of these items are damaged or
missing, please contact your dealer immediately.
WBR-3408 11g Wireless Broadband Router
1 Cat-5 Ethernet (LAN) cable
Power Adapter
Quick Installation Guide
CD-ROM containing the on-line manual.

Introduction
11
Physical Details
Front Panel
EN
PT
Front Panel
WPS
Button
Push the WPS button on the WBR-3408, and also on your
other wireless device to perform WPS syncing to create a
secured wireless connection automatically.
Wireless
Security
On - Wireless security is On.
Off - Wireless security is Off.
Flashing (Blue) - When WPS sync in progress.
Wireless
On - Wireless Devices or Computers are connected to the
WBR-3408.
Off - No Wireless connections currently exist.
LAN
On - Wired Devices or Computers are connected to the
WBR-3408.
Off - No active wired connections on the LAN port(s).
Power
On - Router is ON and ready.
Flashing (Blue) - Router is booting up
Off - Router is OFF
WAN
On - Connection to the ADSL/Broadband Modem attached to
the WAN (Internet) port is established.
Off - No connection to the ADSL/Broadband Modem.
Flashing (Amber) –Router is attempting to connect to the
Internet.
Internet
On - Internet connection is available.
Off - No Internet connection available.

Introduction
12
Wireless
On / Off
Button
Push button for 3 seconds to Enable or Disable the wireless
signal.
Reboot
or Reset
Reboot - Press WPS and Wireless On/Off buttons together
for 5 seconds. The router will restart and boot again.
Reset –Press WPS and Wireless On/Off buttons together for
10 seconds.
All settings will be CLEARED and restored to factory defaults.
Rear Panel
Rear Panel
Power port
Connect the supplied power adapter here.
WAN port
(10/100BaseT)
Connect the DSL or Cable Modem here. If your modem came
with a cable, use the supplied cable. Otherwise, use a standard
LAN cable.
10/100BaseT
LAN connec-
tions
Use standard LAN cables (RJ45 connectors) to connect your
PCs to these ports.

13
Chapter 2
Installation
This Chapter covers the physical installation of the Wireless Router.
Requirements
Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45
connectors.
TCP/IP protocol must be installed on all PCs.
For Internet Access, an Internet Access account with an ISP, and a DSL con-
nection.
To use the Wireless Access Point, all Wireless devices must be compliant with
the IEEE 802.11g or IEEE 802.11b specifications.
Procedure
Installation Diagram
2

Installation
14
1. Choose an Installation Site
Select a suitable place on the network to install the Wireless Router.
For best Wireless reception and performance, the Wireless
Router should be positioned in a central location with mini-
mum obstructions between the Wireless Router and the PCs.
Also, if using multiple Access Points, adjacent Access Points
should use different Channels.
2. Connect LAN Cables
Use standard LAN cables to connect PCs to the Switching Hub ports on the
Wireless Router. Both 10BaseT and 100BaseT connections can be used simul-
taneously.
3. Connect ADSL Cable
Connect the DSL or Cable modem to the WAN port on the Wireless Router.
Use the cable supplied with your DSL/Cable modem. If no cable was supplied,
use a standard cable.
4. Power Up
Connect the supplied power adapter to the Wireless Router. Use only the pow-
er adapter provided. Using a different one may cause hardware damage.
5. Check the LEDs
The Power LED should be ON.
The LAN LED should be ON (provided the PC is also ON.)
The Wireless LED should be ON if Wireless PC is connected.
The WAN LED should be ON an ADSL or Cable modem is connected.
The Internet LED may be OFF. If Internet connection is working, it will be ON.
For more information, refer to Front in Chapter 1.

15
Chapter 3
Setup
This Chapter provides Setup details of the Wireless Router.
Overview
This chapter describes the setup procedure for:
Internet Access
LAN configuration
Wireless setup
Assigning a Password to protect the configuration data.
PCs on your local LAN may also require configuration. For details, see Chapter 4 -
PC Configuration.
Other configuration may also be required, depending on which features and func-
tions of the Wireless Router you wish to use. Use the table below to locate detailed
instructions for the required functions.
To Do this:
Refer to:
Configure PCs on your LAN.
Chapter 4:
PC Configuration
Check Wireless Router operation and Status.
Chapter 5:
Operation and Status
Use any of the following Advanced features:
Internet (DMZ, URL Filter)
Access Control
Dynamic DNS
Options
Schedule
Port Trigger
Single Port Forwarding
Port Range Forwarding
QoS
Chapter 6:
Advanced Features
3

Setup
16
Use any of the following Administration Configuration
settings or features:
PC Database
Config File
Logs
E-Mail
Diagnostics
Remote Administration
Routing
Upgrade Firmware
Chapter 7:
Advanced Administration

Setup
17
Configuration Program
The Wireless Router contains an HTTP server. This enables you to connect to it,
and configure it, using your Web Browser. Your Browser must support Java-
Script.
Internet Explorer 6 and above is recommended.
Preparation
Before attempting to configure the Wireless Router, please ensure that:
Your PC can establish a physical connection to the Wireless Router. The PC
and the Wireless Router must be directly connected (using the LAN ports on
the Wireless Router) or on the same LAN segment.
The Wireless Router must be installed and powered ON.
If the Wireless Router's default IP Address (192.168.0.1) is already used by
another device, the other device must be turned OFF until the Wireless Router
is allocated a new IP Address during configuration.
Using your Web Browser
To establish a connection from your PC to the Wireless Router:
1. After installing the Wireless Router in your LAN, start your PC. If your PC is
already running, restart it.
2. Start your WEB browser.
3. In the Address box, enter "HTTP://" and the IP Address of the Wireless Router,
as in this example, which uses the Wireless Router's default IP Address:
http://192.168.0.1
4. When prompted for the User name and Password, enter values as follows:
User name admin
Password password

Setup
18
If you can't connect
If the Wireless Router does not respond, check the following:
The Wireless Router is properly installed, LAN connection is OK, and it
is powered ON. You can test the connection by using the "Ping" com-
mand:
Open the MS-DOS window or command prompt window.
Enter the command:
ping 192.168.0.1
If no response is received, either the connection is not working, or
your PC's IP address is not compatible with the Wireless Router's IP
Address. (See next item.)
If your PC is using a fixed IP Address, its IP Address must be within the
range 192.168.0.2 to 192.168.0.254 to be compatible with the Wireless
Router's default IP Address of 192.168.0.1. Also, the Network Mask
must be set to 255.255.255.0. See Chapter 4 - PC Configuration for de-
tails on checking your PC's TCP/IP settings.
Ensure that your PC and the Wireless Router are on the same network
segment. (If you don't have a router, this must be the case.)
Ensure you are using the wired LAN interface. The Wireless interface
can only be used if its configuration matches your PC's wireless set-
tings.
Setup Wizard
The first time you connect to the Wireless Router, the Setup Wizard will run auto-
matically. (The Setup Wizard will also run if the Wireless Router's default settings
are restored.)
1. Step through the Wizard until finished.
You need to know the type of Internet connection service used by your ISP.
Check the data supplied by your ISP.
The common connection types are explained in the tables below.
2. On the final screen of the Wizard, run the test and check that an Internet con-
nection can be established.
3. If the connection test fails:
Check your data, the Cable/DSL modem, and all connections.
Check that you have entered all data correctly.
If using a Cable modem, your ISP may have recorded the MAC (physical)
address of your PC. Run the Wizard, and use the "Copy from PC" button to
copy the MAC address from your PC to the Wireless Router.

Setup
19
Common Connection Types
DSL Modems
Type
Details
ISP Data required
Dynamic
IP Address
Your IP Address is allo-
cated automatically, when
you connect to you ISP.
None.
Static (Fixed)
IP Address
Your ISP allocates a per-
manent IP Address to you.
IP Address allocated to you.
PPPoE
You connect to the ISP only
when required. The IP
address is usually allocated
automatically.
User name and password.
PPTP, L2TP
PPTP is mainly used in
Europe.
You connect to the ISP only
when required. The IP
address is usually allocated
automatically, but may be
Static (Fixed).
Server IP Address.
User name and pass-
word.
IP Address allocated to
you, if Static (Fixed).

Setup
20
Home Screen
After finishing the Setup Wizard, you will see the Home screen. When you connect
in future, you will see this screen when you connect. An example screen is shown
below.
Home Screen
Main Menu
The main menu, on the left, contains links to the most-commonly used screen. To
see the links to the other available screens, click "Advanced" or "Administration".
The main menu also contains two (2) buttons:
Log Out - When finished, you should click this button to logout.
Restart - Use this if you wish to restart the Wireless Router. Note that restart-
ing the Router will break any existing connections to or through the Router.
Navigation & Data Input
Use the menu bar on the left of the screen, and the "Back" button on your
Browser, for navigation.
Changing to another screen without clicking "Save" does NOT save any
changes you may have made. You must "Save" before changing screens or
your data will be ignored.
On each screen, clicking the "Help" button will
display help for that screen.
