Outsider FHTA80081A User manual

COOLER C A B INE T
Questions, problems, or missing parts?
Before returning to the store, call Customer Service.
8am - 5pm, PST Monday - Friday
Model No. FHTA80081A/FHTA80081C
B A R B E C U E S
FHTA80081A/FHTA80081C OUTSIDERBARB E CUES . C OM866-292-8800
RETAIN THIS MANUAL FOR FUTURE USE.
ASSE M BLY INSTR U C T I O N S
INSTRU C TIO N S D E M O NTAG E
G U ÍA DE L P R O D U C T O

IMPORTANT
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
P L E A S E D O N O T R E T U R N T O T H E R E T A I L E R / S T O R E
from where you purchased the product.
Please call our Toll-Free Customer Service Hotline at:
1-866-292-8800
To expedite any future warranty claims, please retain the instruction sheet and
receipt for future use.
SAFETY INSTRUCTION S
SAFETY SYMBOLS
IMP O RTANT: RETAIN FO R F U T U R E REF E RENCE, AND R E A D C A R E F ULL Y .
THIS PR O DUCT IS FOR OUTDO O R U S E O N L Y .
C A U T I O N DANGE R
Indicates a potentially
hazardous situation or
unsafe practice which, if not
avoided, may result in minor
or moderate injury.
Indicates a imminently
hazardous situation which, if
not avoided, will result in
death or serious injury.
WARNIN G
Indicates a potentially
hazardous situation which,
if not avoided, could result
in death or serious injury.
FHTA80081A / F HTA80081C OU TSID ERBAR B E CUES . COM866-292-880 0

LEVELING THE CABINETS
I M P O RTANT:
Leveling the cabinets is the most important part of installation, to ensure doors align properly and
countertop sets evenly. Cabinets need to be level and square. Each cabinet features levelers at
the corners that can be adjusted to acheive a perfectly level countertop. Turn levelers clockwise
to raise the height of the cabinet, and counter-clockwise to reduce the height.
L E V E L I N G Y O U R CABINETS
Be sure to level your cabinets in all three directions:
1. Front to Back
2. Vertically
3. Horizontally
FHTA80081A/FHTA8008 1 C O UTSIDERBARBECUES.COM866-292-880 0
1
2
3

PARTS LIST
Key Qty Description
AA 4 M4*30
BB 4 Washer-1
1 1 Cooler Cart Body
2 1 Cooler Lid
3 1 Condiment Caddy
4 4 Condiment Cups
5 1 Bottle Caddy
6 1 Garbage Bin
FHTA8 0 081A/ F HTA8008 1 C O UTSI D E RBAR B E CUES. C OM866-292-8800
Washer-1
M4*30
x 4AA
BB x 4
M6*20
CC x 4
DD x 2
EE x 1
Wrench
Washer-2
7 2 Handle
3
2
4
1
5
7
6

ASSEMBL Y
STE P 1
Requires: AA, BB, 1, 7
ATTA C H THE HANDL E S
Attach the handles (7) to the door using bolts (AA) and washers (BB).
FHTA80081A / F HTA80081C OUTSID E R BARBECU E S.COM866-292-88 00
7
1
AA
BB

ASSEMBL Y
STE P 2
Requires: 1, 3, 4
ATTA C H THE C ONDIMENT C A D D Y
Attach the condiment caddy (3) to the cooler using the keyhole-style slots.
Place the condiment cups (4) in the condiment caddy (3).
FHTA80081A/FHTA80081 C O U TSIDERB A R BECU E S .COM866-292-88 0 0
3
4
1

ASS E MBL Y
STE P 3
Requires: 1, 2
Place the cooler lid (2) over the cooler.
FHTA80081A / F HTA80081C OUTSIDE R BARBE C UES.C O M866-292-8800
STEP 4
Requires: 1, 5
Attach the bottle caddy (5) to the front
of the cart.
1
2
5
1

ASSEMBL Y
STEP 5
FHTA80081A/FHTA80081 C O U TSIDERB A R BECU E S .COM866-292-88 0 0
STEP 6
Requires: 1, 6
SECURING THE GARBAGEB I N
Place the garbage bin (6) in the
pull-out frame.
Requires: 1, DD, CC
Connect two cabinets together
using connector plate (DD) and
bolts (CC).
6
1
CCDD

ASSEMBLY
FHTA80081A/FHTA8008 1 C O UTSIDERBARBECUES.COM866-292-88 0 0
STE P 7
Your cabinets include ports for running electrical or plumbing. Installation of either is required to
be completed by licensed professionals. Each port has a cover that can be removed for access.

DOOR ALIGNMEN T
DOOR ALIGNMEN T
Outsider Barbecues cabinets feature a 6-way adjustable hinge that will allow you to adjust and align
all the doors after installation
1. The center screw face will adjust the door from side to side
2. The top and bottom screws allow adjustment up and down
3. The back screw face will adjust the door in and out
REMOVING DO O R S
INSTALLATION INSTRU C TION S
Hinges can be removed from the hinge plate by simply pressing in the release button on the
end of the hinge, and pulling away from the cabinet. They are re-attached by hooking the hinge
to the plate and snapping the pressure release into place.
1
2
FHTA80081A/FHTA80081 C O U TSIDERB A R BECU E S .COM866-292-88 0 0

CARE AND MAINTENANCE
CLEANING & MAINTENANCE
FHTA8 0 081 A/FHTA80 0 81 C OUTSIDERBARBECUES.COM 866-292-8800
